KT&C KPC-HNV100M Specsheet

KT&C, Inc.

Part No.: KPC-HNV100M

Key Features

• 1/3” Sony Exmor Progressive Color CMOS

• 1280x720 30fps: 720p 60fps (frame conversion)

1080p 30fps (Scal e ,Center)

• HD-SDI (BNC)

• TV Out (BNC), NTSC/PAL Selectable

• SN Ratio: Max 50dB

• 30 Units IR LED With Max. 100ft

• True Mechanical Day & Night

• Mega Pixel Vari-Focal Lens (3.6~16.0mm)

• DNR, AWB, AGC, BLC

• Multilingual OSD

• Second Video Output

• AC 24V / DC 12V Dual Voltage

HD Camera Supports High Quality
Resolutions of 16:9 HD 1280 X 720, without
irritation of IP Camera installation

IR Vandal Dome Type HDcctv Camera

• 1.3 MP 720P 60fps (frame conversion)

• 1.3 MP 1080P 30fps (Scale, Center)

• Easy Installation (HD Ov er Coax (BNC))

• Mega Pixel Vari-Focal Lens (3.6~16.0mm)

• HD-SDI (Serial Data Interface Type Video Output)

• True Mechanical Day & Night

• 30 Units IR LED With Max. 100ft

• Outstanding Durability with IP66

Vandal-Proof Dome Housing

The die-casting aluminum
dome housing and
polycarbonate dome cover
ensures the perfect camera
durability and protects the
camera from external shock.

IP66 Rating (Weather-Proof)

Meeting the standards of IP66,
this dome will withstand dust and
heavy seas. Rugged enough for
any outdoor environment, yet
cosmetically designed to fit in
indoor environments.

O Lux Min. illumination with IR LEDs

KPC-HDV100M is equipped with built-in 30 units of IR LEDs. It can
capture clear image as far as 30M(100ft) away in total darkness.

30

16:9 HD 1280 X 720

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-HDV100M

HDcctv Provide Better Surveillance conditions than Conventional VGA Camera

3-Axis Rotating
Mechanism

3-Axis gimbal bracket rotates and
swifts horizontally and vertically,
so that user can install the camer
a in any place with exact pictures
needed.

General Feature Diagram

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

(Unit: mm)

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-HNV100M

Technical Specification

Model KPC-HNV100M

Signal System TV Out : NTSC / PAL selectable
Image Sensor 1/3” 1.3Mpx SONY Exmor Progressive CMOS
Effective Pixels 1296 (H) x 728 (V) 30fps
Unit Cell Size 3.75um (H) x 3.75um (V)
S/N Ratio Max 50dB
Min. Illumination 0 Lux (IR LED On)
Day & Night True Mechanical Day & Night

IR LED

IR LED Operation On (1Lux) / Off (3 Lux)
Min. Exposure Time 110.86us (1/9020 sec)

Video Output Mode

Lens Mount Mega Pixel Varifocal Lens 3.6mm ~16.0mm
IP Rating IP66 (Weatherproof)

OSD Menu Built in

SDI : 720P 60fps (frame conversion),

1080P 30fps (scale, center mode selectable)

30 IR LEDs, 850nm

Up to 100ft

Flickerless Off / 50Hz / 60Hz

Function

Operating Temperature -10 °C ~ 50 °C (14 °F ~ 122 °F)
Storage Temperature -20 °C ~ 70 °C (-4 °F ~ 158 °F)

Humidity

Power Supply

Conformity CE,FCC
Weight 950g (2.09 lbs.)

Shutter Speed Auto / Manual
Back Light Compensation (BLC) On / Off
White Balance Manual / Auto / Push

Operation: 20~80%

Storage: 20~95%

DC12V (±10%), Max. 800 mA

AC24V (±10%), Max. 10 W
