KT&C KPC-HDX131M Specsheet

KT&C, Inc.

Part No.: KPC-HDX131M

Key Features

• 1/3” Sony Exmor Progressive CMOS

• 1280x720 30fps: 720p 60fps (frame conversion)

1080p 30fps (Scal e ,Center)

• HD-SDI (BNC)

• TV Out (BNC, NTSC/PAL Selectable)

• True Mechanical Day & Night

• CS/C-Mount

• DNR, AWB, AGC, BLC

• Multilingual OSD

• DC 12V

Box Type HDcctv Camera

• 1.3 MP 720p@60fps (frame conversion)

• 1.3 MP 1080p@30fps (Scale, Center)

• Easy Installation (HD Over Coax (BNC))

• HD-SDI (Serial Data Interface Type Video Output)

• Selectable TV Out (NTSC / PAL)

• True Mechanical Day & Night

• Min. Illumination of 1.0 Lux (F1.2)

• Multilingual OSD

HD Camera Supports High Quality
Resolutions of 16:9 HD 1280 X 720,
without irritation of installation of
IP Camera.

16:9 HD 1280 X 720

HDcctv Provide Superb Surveillance conditions than Conventional VGA Camera

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-HDX131M

General Feature Diagram

BACK
1 MENU/SET BUTTON

2 UP BUTTON
3 DOWN BUTTON
4 LEFT BUTTON
5 RIGHT BUTTON
6 POWER LED
7 SDI OUT JACK
8 TV OUT JACK
9 MIC IN JACK (TBD)
10 AUDIO OUT JACK
11 TERMINAL (POWER,
RS-485, Digital
Input/Output)

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

Convenient OSD Menu

Settings can be easily controlled or adjusted by using the built-in
Buttons to access the integrated On-Screen Display (OSD) menu.
Multiple language options are available

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-HDX131M

Technical Specification

Model KPC-HDX131M

Signal System TV Out : NTSC / PAL selectable
Image Sensor 1/3” 1.3MP SONY Exmor Progressive CMOS
Horizontal Resolution More than 800 TVL
Effective Pixels 129 6 (H) x 728 (V) 30fps
Unit Cell Size 3.75um (H) x 3.75um (V)
S/N Ratio More than 50dB
Min. Illumination 1.0 Lux (F1.2)

Video Output Mode

Lens Mount CS/C-Mount
Lens Control Fixed, DC Iris, Video Iris (factory setting only)
Day & Night True Mechanical Day & Night

SDI : 720p60 (frame conversion),

1080p30 (scale, center mode selectable)

OSD Menu Built in
Flickerless Off / 50Hz / 60Hz
Back Light Compensation (BLC) On / Off

Function

Communication RS485
Operating Temperature -10 °C ~ 50 °C (-4 °F ~ 122 °F)
Storage Temperature -20 °C ~ 70 °C (-4 °F ~ 158 °F)

Humidity

Power Consumption
Weight 420g(0.93 Lbs.)

Auto Gain Control (AGC) Selectable
White Balance Manual / Auto / Push
User Set Up to 2 user
Language English, French, Spanish, Japanese, Chinese

Operation: 20~80%

Storage: 20~95%

DC 12V ±10%, Max. 500mA
