KS KitSound ACCOMPLICE User Manual

kitsound.co.uk

ACCOMPLICE

POWERED HI-FI

Your product and batteries must be recycled or disposed of properly.

Please contact your local recycling centre for more information on proper disposal.

All trademarks are acknowledged as the property of their respective owners.

Unless otherwise stated their use does not imply that the trade mark owner is aliated with KitSound or endorses the products herein.

SPEAKERS

USER MANUALJB. 5373-a / Made in China. © KitSound is a trademark of Kondor Limited, 2017. Christchurch, Dorset, BH23 4FL, UK

Please read this manual carefully before use.

Instructions for use

Box contents

• KS Accomplice Powered Hi-Fi Speakers

• UK power cable

• Speaker cable

• 3.5 mm aux cable

• EU adaptor

• User manual

Functions

1. Mode

2. Volume–/Previous track

3. Volume+/Next track

4. Play/Pause

5. LED indicator

6. Spring speaker terminals

7. Aux input

8. Mains port

9. Power switch

To connect the speakers together

Important: Don’t pull up on the spring terminals. They are only designed to be pushed gently down.

1. Push down gently on the spring terminals of the master speaker as shown in Figure 1

2. Insert the red part of the speaker cable into the red terminal

3. Then insert the black cable in to the black terminal on the same speaker

4. Do the same with the other end of the speaker cable into the slave

6

9

1 2 3 5 4

M

8

7

Slave

speaker

Master

speaker

Master

speaker

Slave

speaker Figure 1

2 3

Pair the speaker to your device

Playing music on your speaker

1. Turn speaker on by pressing the Power switch (9)

2. Once the speaker is on it will enter pairing mode, with the LED indicator (5) ashing blue quickly

3. Turn your iOS, Android, or Windows device’s Bluetooth® ON and search for new devices

4. Select ‘KS Accomplice’. If asked for a passcode, enter ‘0000’, and the device will pair

5. A double beep will sound to conrm pairing and the LED indicator (5) will ash every 2 seconds

Note: ‘Bluetooth’ is a trademark of Bluetooth SIG, Inc. This product is in no way aliated with or endorsed by Bluetooth SIG Inc.

Re-pairing or pairing new devices

1. Turn o Bluetooth® connectivity on any previously paired devices

2. Follow the ‘Pairing the speaker to your device’ instructions

3. If a previously paired device is not present within the wireless connectivity range then the speaker will re-enter pairing mode

Wireless

When connected wirelessly, play the music on your device and the sound will play through both speakers. Some devices may require

you to select the audio output.

Auxiliary

1. Plug the 3.5 mm aux cable into the speaker’s Aux input (7) and your device

2. The LED indicator (5) will become a solid red colour

Changing the volume and track

If you want to... Wireless mode Auxiliary mode

Increase volume Press Volume+ (3) on Accomplice

or use your device

Decrease volume Press Volume– (2) on Accomplice

or use your device

Skip to the next track Hold Volume+ (3) for 3 seconds N/A

Skip to the previous track Hold Volume– (2) for 3 seconds N/A

Please note: Your device will have an internal amplier and if it is playing digital les like MP3s it will also have an integrated DAC
(Digital Audio Converter). If you turn the volume up to 100%, your device will be sending a distorted signal. To avoid this, and to

get the best quality from the speaker, we recommend that you do not run your device any higher than 95% volume. Some devices

output higher than others, so you may need to reduce the volume if you experience distortion.

Press Volume+ (3) on Accomplice
or use your device

Press Volume– (2) on Accomplice
or use your device

4 5

Care for your Accomplice

Troubleshooting

Please DON’T:

• Submerge the Accomplice speakers in water

• Drop the Accomplice as this will invalidate your warranty

• Open up the Accomplice speakers. There are no user serviceable parts inside

• Expose the Accomplice speakers to extreme temperatures or rapid changes of hot to cold or vice versa

Please DO:

• Clean the Accomplice speakers with a soft dry cloth and no detergents

Specications

Works with Bluetooth® V3

Wireless connectivity distance up to 10 m

Frequency response 80 Hz – 20 kHz

Drivers 2 x 3 inches

Output RMS 20 Watts

DC input voltage 12 V / 2 A

We hope you’ve now got all the information you need to get started, but if you’re having problems with anything, please feel free to
contact us at: [e-mail]

‘Hereby, Kondor Ltd declares that the radio equipment type,

KSACCO Accomplice Wireless Speakers, is in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address:

http://kondor.co.uk/product-documents.’

The use and operation of this speaker is beyond our control. Warrant y of the KS Accomplice is limited to defects caused by faulty manufacture or defects in materials only.
No warranty whatsoever is given or implied for damage caused by the user under any circumstances.

This does not aect your statutory rights.

Please do not attempt to open this product. There are no user serviceable parts inside, in particular if your product has an embedd ed, non-replaceable battery, do not
attempt to access or remove the batter y as this may cause personal injur y and will damage the product.

Making any attempt to open the product or carr y out repair voids any and all warranties.

We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a result of product improvement and development.

6 7
