Krups 466 User Manual

154415

Crystal Arome Plus / Crystal Arome Plus Time

c d

e f

Crystal Arome Plus Time

PROG

min

AUTO

OFF

g fl

2 31

Crystal Arome Plus Art. 466 Crystal Arome Plus Time Art. 467

USA

Instructions for Use Warranty

Guarantee of performance

Français 13

13 djhmode

Mode d’emploi Garantie

Garantie de rendement

Español 212

Instrucciones de uso Garantía

Garantía de rendimiento

USA

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons including the following :

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock and injury to persons, do not immerse cord, plugs or appliance in water or other liquid.

4. Close supervision is necessary when any appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the nearest KRUPS Service Center for examination, repair or adjustment.

7. The use of accessory attachments not recommended by KRUPS may result in fire, electric shock or injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. To disconnect, turn any control to «off» then remove plug from wall outlet.

12. Do not use the appliance for other than intended use.

13. Scalding may occur if the lid is removed during the brewing cycles.

14. Do not pour liquids other than water and descaling solutions specified in this manual into the water tank.

15. The glass carafe is designed for use with this appliance. It must never be used on a range top.

16. Do not set a hot glass carafe on a wet or cold surface.

17. Do not use a cracked glass carafe or a glass carafe having a loose or weakened handle.

18. Do not clean glass carafe with cleansers, steel wool pads, or other abrasive material.

SAVE THESE INSTRUCTIONS

SHORT CORD INSTRUCTIONS

A. A short power supply cord is to be provided to reduce risks

resulting from becoming entangled in or tripping over a longer cord.

B. Extension cords are available and may be used if care is

exercised in their use.

C. If an extension cord is used,

1) the marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance,

2) the longer cord should be arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over.

D. This appliance has a polarized plug (one blade is wider than

other). To reduce risks of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

USA

Description

a Duo Filter holder b Anti-chlorine / Anti-scale Duo Filter c Water tank d Removable filter holder e Water level indicator f Duo Filter replacement indicator

(according to model)

g On/Off switch (according to model) h Warming plate i Glass carafe j Control panel k Time setting l On/Off indicator m Duo Filter replacement reset button

Advantages of the Crystal Arome Plus/Crystal Arome Plus Time

• The “ Duo Filter ”: a double action anti-

chlorine and anti-scale filter

The elements which go into the “ Duo Filter ” (active vegetable based carbon and anti-scale resin) comply with current food safety legislation. Its silver salt processing acts as an anti-bacteria agent, for consumer safety. This filter has been tested successfully by recognized laboratories.

The vegetable-based and non-pollutive filter can be disposed of as domestic waste

The anti-chlorine action of the filter will give the coffee more delicate flavor. Tap-water often contains amounts of chlorine which will hinder the flavor. The “ Duo Filter ” eliminates the chlorine so that the smell and taste of the coffee are more perceptible.

The anti-scale filter will prolong the working life of your coffee-machine and will result in less frequent need to decalcify.

• Hermetic Coffee-carafe

The Hermatic coffee-carafe has a lid without a central hole, and an insulating grid on the pouring-lip. This design considerably reduces heat loss and preserves all the flavor of the coffee. It also prevents the entrance of air from the outside, which oxidizes the coffee and evaporates the aroma.

This coffee-carafe can be used in a microwave oven.

• “Stop ‘n Serve” Feature

Lets you pour a cup or two while brewing. The automatic filter seal will allow you to remove the carafe for 20 seconds without dripping coffee onto the warming plate.

• 24 Hour Programmable Timer (model

#467)

Lets you program the coffee maker for convenient “wake-up” coffee.

• Programmable Auto Shut-Off (model

#467)

Lets coffee stay hot from 1-5 hours before turning itself off.

Before first use

Setting the time (model #467)

• Plug in the KRUPS “Crystal Arome Plus

Time”. Make sure the control panel (j) is in the “off” position.

• The LCD display will be flashing

intermittently. This is your signal to set the digital clock.

• Turn the selector switch to position

Set the hours and minutes by pressing the “H” and “min” buttons respectively. The time is now set.

Running with water only

• Before making your first pot of delicious

coffee, we recommend operating the coffee maker once or twice with water only, without ground coffee or the Duo Filter to remove any possible dust.

• Be sure that the water container is empty.

• To remove the lid of the glass carafe, pick it

up from the back and lift.

(k).

• To replace the lid, put the front in place first

and then snap the back down into place.

• Always place the glass carafe securely in

place with the handle facing out and centered.

Inserting the “Duo Filter”

• Remove the DuoFilter (b) from its plastic

bag. Rinse in tap water.

• Open the hinged lid of the coffee maker and

remove the DuoFilter holder (a) (see fi- gure 1).

• Pivot the lower part of the holder and insert

the DuoFilter into its housing (see figure 2).

• Replace the holder in the coffee maker and

your machine is now ready for use (see

figure 3).

Preparing coffee

Filling the water chamber

• Open the hinged lid. Using the glass carafe,

pour in the desired quantity of cold water. (See figure 4). The water level indicator shows how much water you are filling into the container.

• The amount of freshly brewed coffee

delivered after the brewing process will always be slightly less than the amount put into the water container. This is due to the minimum absorption of the water by the ground coffee. Therefore, it is recommended that you add a little extra water at the beginning so that you will have the number of cups you desire.

• Replace the glass carafe on the warming

plate with the lid in position. (See fi-

gure 5).

Putting in the ground coffee

• With the hinged lid opened, insert a size 4

paper filter (KRUPS #983) or Gold Tone Filter (KRUPS #026) into the the filter holder. You can purchase KRUPS size 4 paper filters (#983) or KRUPS Crystal Arome Gold Tone Filter (#026) at your local KRUPS retailer or by calling the KRUPS Consumer Service Department at 1-800-526-5377, 24 hours a day, 7 days a week.

• We suggest using one level KRUPS

measuring scoop of ground cofee for each cup of robust coffee. After using your KRUPS coffee maker several times, you can adjust the measure to suit your own taste.

• Close the hinged lid, making sure that the

filter holder is securely in place.

• Turn the machine on (g). An indicator light

will illuminate.

“Stop ‘n Serve” feature

The “Stop’ n Serve” feature is KRUPS answer to the impatient coffee drinker’s clamor for “a quick cup of coffee!” This device automatically stops the flow of brewed coffee through the filter cone if the glass carafe is removed from the warming plate during the brewing cycle. You have about 20 seconds between the removal of the carafe and its being reinserted to pour one or two cups of coffee. The “Stop’n Serve” device closes off the filter cone so effectively that there is virtually no coffee-drip onto the waming plate. Once the carafe is replaced, the brewing cycle and the flow of coffee into the carafe are resumed.

If coffee does drip onto the warming plate after removal of the carafe, it is usually an indication that too much ground coffee has been placed into the paper filter. This causes the water that jets into the filter cone to overflow between the paper filter and the sides of the filter cone. The overflow carries coffee grounds that interfere with the snapshut action of the filter holder, thus allowing brewed coffee to continue to drip through.

If this blockage and subsequent dripping do occur, replace the glass carafe immediately and allow the full brewing cycle to brewing cycle to run its course, Do not remove the filter until the brewing cycle is completed.

Preparing “wake-Up” coffee (model #467)

This feature enables you to enjoy freshly brewed coffee at any pre-selected time within a 24-hour period.

• First set the digital clock (see “Setting the time”)
