10.2.1.4 Edition 01.12 GB
Operating and installation instructions
Lago FB OT digital remote control
Translation from the German
© 2012 Elster GmbH
Safety
Safety
Please read and keep in a safe place
Liability
We will not be held liable for damages resulting from non-observance
of the instructions and non-compliant use.
Safety instructions
Information that is relevant for safety is indicated in the instructions
as follows:
DANGER
Indicates potentially fatal situations.
WARNING
Indicates possible danger to life and limb.
CAUTION
Indicates possible material damage.
All work and settings in the “Expert” chapters may only be carried
out by a qualified technician. Electrical interventions may only be
carried out by a qualified electrician. The heating system must be
disconnected from the power supply before any electrical work is
carried out on the unit.
Conversion
All technical changes are prohibited.
Please read through these instructions carefully before
installing or operating. Following the installation, pass the instructions on to the operator.
These instructions can also be found at www.docuthek.com.
Explanation of symbols
• , 1 , 2 , ... = Action
▷ = Instruction
Transport
On receipt of the product, check that the delivery is complete. Report
any transport damage immediately.
Storage
Store the product in a dry place. Ambient temperature: see Technical data.
Table of contents
Table of contents
Lago FB OT digital remote control.....................1
Safety.............................................1
Table of contents ...................................2
Verify type of application............................. 4
Part designations ....................................4
Selector switch ...........................................4
Display .................................................5
User – Settings .....................................6
Set time and day of the week...........................6
Set the desired temperature............................ 6
Display actual temperatures ............................7
Set operating mode ..................................7
Standby/OFF ..........................................7
1 Automatic mode 1 .....................................7
2 Automatic mode 2 .....................................7
Day mode ............................................7
Night mode (reduced night mode) ...........................8
Summer mode .........................................8
Select mode .............................................8
Set heating program 1 ................................8
Set heating program 2 ................................9
Holiday setting/holiday duration ........................10
Heating time setting/Change duration ...................11
Load factory settings (Reset) ..........................12
User – Set parameters ..............................1
List of parameters P01 to P04 .........................13
Explanation of the parameters .........................14
P01 Heat slope ..........................................14
P02 Room sensor influence.................................14
P03 Room sensor correction................................15
P04 Hot water according to program .........................15
User – Questions ..................................15
How do I switch to summer/winter time? .................15
How do I set the heating controller so that it gets warm
sooner in the morning? ..............................15
My heating does not get warm enough. What can I do? .....16
How do I set the heating system for holidays? .............16
How can I switch the heating system off during the summer? . 16
Is it possible to let the heating system run longer in the
evening for special occasions such as a party? ............16
How do I set the heating controller to save energy? .........16
My heating system is not running .......................16
Expert - Installation ................................17
Expert - Electrical connections ......................18
Electrical socket connection...........................18
Expert – Set parameters ............................18
List of parameters P05 to P13 .........................19
Explanation of the parameters .........................19
P05 Code no. input .......................................19
P06 Code no. change .....................................19
P07 Maximum boiler temperature ............................19
P08 Minimum boiler temperature.............................19
P09 Outside temperature frost protection ......................20
2
P10 Integral control section .................................20
P11 Transparent Slave Parameter 01 .........................20
P12 Transparent Slave Parameter 02 .........................20
P13 Software version and index (62.00) .......................20
Expert – Checklist for commissioning .................20
Accessories ......................................21
Outside sensor AF
Sensor values ...........................................21
................................21
Troubleshooting ...................................21
Technical data ....................................22
Glossary .........................................2
Flow temperature ...................................23
Desired and actual temperature ........................23
Setback temperature ................................23
Heat source .......................................23
Heating time.......................................23
Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Heating circuit allocation ...........................24
For the installation expert .............................24
Contact ..........................................24
Table of contents
3
Verify type of application
Verify type of application
Digital remote control with integral room temperature sensor and an OpenTherm interface for connecting a boiler control.
The remote control allows various operating functions, including
heating based on heating program, setting of individual room and
hot water temperature and monitoring of boiler data in the living area.
The LAGO FB OT uses the weather or room-based control function
to transmit the desired boiler value to the boiler controller via the
weather and/or room guided control function to make sure that the
gas boiler delivers the required heat volume at optimum efficiency.
When used with boiler controllers that support the OpenTherm Smart Power function, the display of the Lago
FB OT remote control is illuminated during operation.
The function is only guaranteed within the specified limits, see page
22 (Technical data).
Any other use will be deemed improper use.
Part designations
Th Fr Sa So
Mo Tu We
Reset
1
24
5
Prog2
/Eco
18
12
6
0
Prog1
/1...7
Mode
1
1 Selector switch
2 Rotary knob
for changing the set values and displaying temperatures
OK button
for displaying desired temperatures and confirming settings
4 Display
5 Base
Selector switch
Standard
Mode Operating mode selection
Desired daytime room temperature,
Desired night-time room temperature (setback
temperature),
Desired hot water temperature
Holiday setting/holiday duration
/Eco
Heating time setting/Change duration
Parameter setting for User and Expert
Prg1 Heating program 1
Prg2 Heating program 2
1...7 Setting the time and the day of the week
4
3
2
4
Verify type of application
Display
Mo Tu We Th Fr Sa Su
1
2
3
4
5
6
7
1 2
0
6121824
1 Days Monday–Sunday underlined
2 Communication with OpenTherm boiler
Status indications:
Burner,
Heatcircuit pump,
Storage charging pump,
Water pressure too low,
no flame
Reset Resets the boiler
4 Room temperature
5 Time
Reset
6 Operating modes:
Operational readiness/OFF (Heating and hot water
preparation OFF, frost protection operation only)
1 Automatic mode 1 (Heating according to heating program
1, hot water according to parameter 04)
2 Automatic mode 2 (Heating according to heating program
2, hot water according to parameter 04)
Day mode (24 hour heating with desired daytime room
temperature, hot water according to parameter 04)
Night mode (24 hour heating with setback temperature, hot
water according to parameter 04)
Summer mode (Heating OFF, hot water according to
parameter 04)
7 Display of the heating times
5
User – Settings
User – Settings
Set time and day of the week
1 Turn selector switch to 1...7.
▷ Minute display flashes.
Mo Tu We Th Fr Sa Su
2 Use the rotary knob to set the minutes.
Press the OK button to confirm.
▷ Hour display flashes.
4 Use the rotary knob to set the hours.
5 Press the OK button to confirm.
6 Use the rotary knob to set the week day.
7 Press the OK button to confirm.
▷ The new time and the day of the week is displayed.
▷ The clock continues to run for at least 10 min. without a power
supply.
8 Turn selector switch back to .
Set the desired temperature
The desired temperatures set the room temperatures for the heating phase
(desired daytime temperature) and the setback phase (desired night-time
temperature). The desired temperature for the hot water can be adjusted.
▷ The desired hot water temperature can only be set if the system
has a storage tank.
▷ Factory setting:
Desired daytime room temperature: 20 °C,
Desired night-time room temperature: 10 °C
Desired hot water temperature: 60 °C
▷
The desired daytime room temperature cannot be lower than
the desired night-time room temperature.
▷
The desired night-time room temperature cannot be greater than
the desired daytime room temperature.
1 Turn selector switch to .
▷ Desired temperature selection is displayed, flashes.
Mo Tu We Th Fr Sa Su
2 Press the OK button.
▷ The desired day-time room temperature flashes.
Use the rotary knob to select the desired daytime room tem-
perature.
▷ The temperature can be set in 0.5 °C increments.
4 Press the OK button to confirm.
▷ The new desired temperature is displayed.
6
User – Settings
5 Turn the rotary knob clockwise.
▷ The desired temperature selection is displayed, flashes.
6 Press the OK button.
▷ The desired night-time room temperature flashes.
7 Use the rotary knob to select the desired night-time temperature.
▷ The temperature can be set in 0.5 °C increments.
8 Press the OK button to confirm.
▷ The new desired temperature is displayed.
9 Turn the rotary knob clockwise.
▷ The desired hot water temperature is displayed
10 Press the OK button.
▷ The warm water value flashes.
11 Use the rotary knob to set hot water value.
▷ The temperature can be set in 1 °C increments.
12 Press the OK button to confirm.
▷ The new hot water temperature is displayed.
1 Finally, turn the selector switch back to
flashes.
.
Display actual temperatures
1 Turn selector switch to .
2 Use the rotary knob to set one of the following temperature
displays.
AF
*) Heat source temperature
*) Flow temperature
*) Hot water temperature
* The relevant desired temperature is displayed when the OK button is
pressed.
▷ If a sensor is not connected, the display will show -- --.
▷
The display reverts to the standard indication after a few seconds
without action.
Outside temperature
Set operating mode
The operating mode determines how the heating controller works.
Whether the heating system is to be controlled automatically or manually, during a party for example. Or how should the heating system
be controlled during longer periods of absence such as holidays?
▷
The heating controller leaves the factory with the setting
Standby/OFF. The operating mode must be changed for normal operation.
You can set the following operating modes
Standby/OFF
Heating and hot water preparation are deactivated. Only the frost
protection function remains active.
1 Automatic mode 1
Heating occurs according to heating program 1: Heating occurs
at identical times for Monday–Friday, as well as Saturday–Sunday.
Hot water according to parameter 04, see page 8 (Set heating
program 1).
2 Automatic mode 2
Heating occurs according to heating program 2: You can set Individual
heating times for each day. Hot water according to parameter 04,
see page 9 (Set heating program 2).
▷
Toggling between Automatic mode 1 and 2 can be useful for
shift workers. The times do not need to be entered for each
shift - they only need to be switched over.
Day mode
24 hour heating with desired daytime room temperature, see page 6
(Set the desired temperature). Hot water according to parameter 04
7
User – Settings
Night mode (reduced night mode)
Heating is reduced to the setback temperature on a permanent
basis. Hot water according to parameter 04, see page 15 (P04
Hot water according to program).
Summer mode
The heating system is switched off to save energy. Parameter 04 for
hot water must be set to 1, 2 or 4, see page 15 (P04 Hot water
according to program).
Select mode
1 Turn selector switch to “Mode”
▷ The new operating mode is displayed and flashes.
Mo Tu We Th Fr Sa Su
2 Select an operating mode using the rotary knob.
Press the OK button to confirm.
▷ The new operating mode is displayed.
▷ After you press the OK button, the current symbol is shown for
3 seconds before it starts flashing again.
4 Turn selector switch back to .
Set heating program 1
Heating program 1 is assigned to automatic mode 1. It is used
to define the heating times for the working week (Mon–Fri) and the
weekend (Sat–Sun). You can set three heating times per day.
▷ During heating times the controller heats to desired room tem-
perature, between heating times to setback temperature.
▷ Factory setting:
Mon–Fri: 6:00 to 22:00
Sat–Sun: 7:00 to 23:00
1 Turn selector switch to “Prg1”
This displays the heating program for the working week (Mon-Fri).
▷
Mo Tu We Th Fr Sa Su
016121824
2 Press the OK button.
▷ The start time of the first heating time flashes.
Use the rotary knob to select the start time.
▷ The heating time can be set in 15 minute increments.
4 Press the OK button to confirm.
▷ The new start time is displayed.
5 Turn the rotary knob clockwise.
6 Press the OK button.
▷ The end of the first heating time flashes.
7 Use the rotary knob to select the end time.
8 Press the OK button to confirm.
8
User – Settings
▷ The new end time is displayed.
9 Turn the rotary knob clockwise.
10 Press the OK button.
▷ The start time of the second heating time flashes.
11 Continue with step 3 to set the second and third heating time.
12 Turn the rotary knob clockwise.
▷ This displays the heating program for the weekend (Sat-Sun).
Mo Tu We Th Fr Sa Su
016121824
1 Continue with step 2 to set the three heating times for the week-
end in the same order.
▷
If you want to delete an existing heating time, use the rotary knob
to set the start or end time to “----”.
14 Finally, turn the selector switch back to .
▷
The heating program 1 has been set. In order to apply it, set
the operating mode to “ 1 Automatic mode 1”, see page 7
(Set operating mode).
Example: Display of the heating times for heating program 1
Heating takes place from Monday to Friday between 6:00 and 8:00
in the morning, from 11:30 to 13:00 at lunchtime and from 18:00 to
22:00 in the evening.
Mo Tu We Th Fr Sa Su
016121824
Set heating program 2
Heating program 2 is assigned to automatic mode 2. It can be
used to set the heating times for each individual day. You can set
three heating times per day.
▷ During heating times the controller heats to desired room tem-
perature, between heating times to setback temperature.
▷ Factory setting:
Mon–Fri: 6:00 to 8:00, 16:00 to 22:00
Sa–Su: 7:00 to 23:00
1 Turn selector switch to “Prg2”
▷ The heating program for Monday is displayed.
Mo Tu We Th Fr Sa Su
026121824
9
User – Settings
2 Press the OK button. The start time of the first heating time
flashes.
Use the rotary knob to select the start time.
▷ The heating time can be set in 15 minute increments.
4 Press the OK button to confirm.
▷ The new start time is displayed.
5 Turn the rotary knob clockwise.
6 Press the OK button.
▷ The end of the first heating time flashes.
7 Use the rotary knob to select the end time.
8 Press the OK button to confirm.
▷ The new end time is displayed.
9 Turn the rotary knob clockwise.
10 Press the OK button.
▷ The start time of the second heating time flashes.
11 Continue with step 3 to set the second and third heating time
for Monday.
12 Turn the rotary knob clockwise.
▷ The heating program for Tuesday is displayed.
1 Continue with step 2 to set the three heating times for each
working day.
▷
If you want to delete an existing heating time, use the rotary knob
to set the start or end time to “----”.
Example: see page 8 (Set heating program 1).
14 Finally, turn the selector switch back to
The heating program 2 has been set. In order to apply it, set
▷
.
the operating mode to “ 2 Automatic mode 2”, see page 7
(Set operating mode).
Holiday setting/holiday duration
In holiday mode, you can make a distinction between a “Present”
holiday where you remain at home and an “Absent” holiday where you
leave the home for between 1 and 99 days. The system automatically switches back to the previous mode at the end of the holiday.
▷ Factory setting:
Desired room temperature for present holiday: 20 °C,
Desired room temperature for absent holiday: 15 °C,
Duration of holiday: 0 days
1 Turn selector switch to
▷
Use the rotary switch to select between a “Present” and an
“Absent” holiday.
Present holiday
▷ This displays heating program 1 for the weekend (Su), the tem-
perature display flashes.
Mo Tu We Th Fr Sa Su
016121824
2 Press the OK button.
▷ Holiday duration is displayed, number of days flashes.
Use the rotary knob to set the duration of the holiday in days.
4 Press the OK button to confirm.
5 Finally, turn the selector switch back to .
▷ The holiday function starts immediately. The display shows HO
and the number of days of the holiday, 1 to 99.
10
User – Settings
▷ The days are automatically counted down every 24 hours.
Absent holiday
▷ During the holiday, the room is heated to 15 °C.
Mo Tu We Th Fr Sa Su
2 Press the OK button.
▷ Holiday duration is displayed, number of days flashes.
Use the rotary knob to set the duration of the holiday in days.
4 Press the OK button to confirm.
5 Finally, turn the selector switch back to
The holiday function starts immediately. The display shows HO
▷
.
and the number of days of the holiday, 1 to 99.
▷ The days are automatically counted down every 24 hours.
Early end of holiday
If the holiday ends earlier than planned, holiday mode can be reset
by setting the duration of the holiday to zero.
1 Turn selector switch to
.
▷ This relevant holiday mode (present or absent) is displayed, the
temperature display flashes.
2 Press the OK button.
▷ The duration of the holiday remaining is displayed and flashes.
Use the rotary knob to set number of days holiday to 0 .
4 Press the OK button to confirm.
5 Finally, turn the selector switch back to .
▷ The last operating mode selected is displayed.
Heating time setting/Change duration
The setting for this function depends on the current operating mode
selected. It is used to heat or reduce (up to 24 h) outside the valid
heating program without changing the operating mode.
Example extension of heating time.
The valid heating program ends at 22:00. The heating time can be
extended, e.g. for a party. After the set time, the heating automatically
reverts to the desired night-time room temperature.
1 Turn selector switch to /Eco.
2 Switch the rotary knob to “Heating”.
▷ The current desired day-time temperature and the valid heating
program are displayed, flashes.
Mo Tu We Th Fr Sa Su
0 6121824
2 Press the OK button.
▷ Hour display flashes.
Use the rotary knob to select the heating time in hours.
4 Press the OK button to confirm.
▷ The heating time is extended immediately.
5 Finally, turn the selector switch back to .
11
User – Settings
Example interruption of heating time.
If you leave the house for a few hours, you can reduce the heating
during an active heating program to save energy. Once the set time
has ended, the system automatically reverts to the current heating
program.
1 Turn selector switch to /Eco.
2 Switch the rotary knob to “Reduce”.
▷
The current desired night-time temperature and the valid heating
program are displayed, flashes.
Mo Tu We Th Fr Sa Su
0 6121824
2 Press the OK button.
▷ Hour display flashes.
Use the rotary knob to select the reduction time in hours.
4 Press the OK button to confirm.
▷ Reduction starts straight-away.
5 Finally, turn the selector switch back to .
Early ending of heating time.
1 Turn selector switch to
/Eco.
2 Press the OK button.
▷ The run-time remaining is displayed and flashes.
Use the rotary knob to set number of hours to 0 .
4 Press the OK button to confirm.
5 Finally, turn the selector switch back to .
Load factory settings (Reset)
▷
All personal settings, switching times and the CODE-NO are
reset to the factory defaults.
1 Take a note of all the settings you have made in these instruc-
tions, see page 13 (List of parameters P01 to P04).
2 Disconnect the device at the plug.
When switching the mains back on, keep the OK button pressed
until EE P appears in the display.
▷ The factory settings have been loaded.
12
User – Set parameters
User – Set parameters
You can change further parameters to adapt the heating system to
your requirements.
1 Turn selector switch to (parameter setting).
▷ The display shows .
2 Turn the rotary knob clockwise until the parameter you want to
change appears in the left-hand side of the display: 01 to 04 (heat
slope to hot water, based on program).
Press the OK button.
▷ Display flashes.
4 Use the rotary knob to set the desired value.
5 Press the OK button to confirm.
6 After you have made the setting, continue with step 2 if you want
to change further parameters, or turn the selector switch back
to .
▷ The table - List of parameters P01 to P04 - shows the possible
settings.
▷ Your remote control will only display those parameters for which
there are sensors connected.
List of parameters P01 to P04
P. no. Parameter Setting range Factory setting Own values
01 Heat slope 0.20–3.00 1.20
02 Room sensor influence OFF, 0–20 10
03 Room sensor correction -5 to +5 °K 0
04 Hot water according to program
0 = Off
1 = "Heating program 1“
2 = "Heating program 2“
3 = 1 hour before heating
4 = 24 hours hot water
4
13
User – Set parameters
Explanation of the parameters
P01 Heat slope
Selecting the correct heat slope saves energy because the heat
sources only heat to the point required by the respective outside
temperature.
The heat slope specifies the number of °C by which the flow temperature changes when the outside temperature rises or drops.
▷ Before you select the heat slope, set the room temperature to
the desired value, see page 6 (Set the desired temperature).
▷
Ideally, the heat slope is set when the outside temperature is
below 5 °C. Changes to the heat slope setting must be applied
in small steps and long intervals (at least 5 – 6 hours between
steps). The system must be allowed to adjust to the new value
after each change to the heat slope.
▷
Select the heat slope so that the desired room temperature is
achieved with the thermostat valves fully opened, and doors
and windows closed.
▷ Increase the heat slope if the desired room temperature is not
reached in combination with low outside temperatures.
▷ If the desired room temperature is not reached in combination
with high outside temperatures, increase the desired room temperature.
• Now change the heat slope.
▷ Typical values:
Floor heating: 0.4 to 0.8
Radiators: 1.0 to 1.5
3
100
80
Flow temperature [°C]
60
40
20
20 16 12 8 4 0 -4 -8 -16 -20
Outside temperature [°C]
2,5
2
1,5
1,2
1
0,8
0,6
0,4
0,2
P02 Room sensor influence
It is possible to adjust the influence of the room sensor on the control
process.
▷
The higher the set value the greater the influence of the room
sensor on the calculated flow temperature.
P02 = OFF purely weather-guided control
P02 = 0: purely weather-guided control
P02 = 20 purely room temperature control
Within the range 0–20 the heatcircuit pump operates up to the next
heating time if there is a heating requirement during the period of
reduced temperature Night (e.g. frost protection of when the temperature drops below the setback temperature). This prevents the
rooms from becoming too cool.
14
User – Questions
Example: P02 = 5
With this setting the desired temperature of the heat source is increased by 5°C when the room temperature drops below the desired
room temperature by 1°C.
P0 Room sensor correction
This setting can be used to correct measurement errors of the connected room sensor, e.g. when the room sensor is influenced by
incorrect positioning.
Setting range: P03 = -5 to +5 °C:
Example: Room sensor correction
Your room sensor measures 20 °C. A reference thermometer, however, determines 22 °C. Now set parameter 11 = 2 so that the value
2 °C is added to the measured value.
P04 Hot water according to program
This parameter can be used to define the heating times for hot water.
P04 = 0: Off (no hot water preparation)
P04 = 1: hot water in line with heating program 1
P04 = 2: hot water in line with heating program 2
P04 = 3: 1 hour before the heating times of automatic mode 1 or
2. (The desired automatic mode is set via the operating mode.)
With activated HO Holiday mode the hot water preparation is not
switched on.)
In “Summer” mode parameter 04 must be set to 1, 2 or 4.
P04 = 4: 24 hours hot water
User – Questions
How do I switch to summer/winter time?
To switch from summer to winter time and vice verse you need to
reset the time, see “page 6 (Set time and day of the week).
How do I set the heating controller so that it gets warm sooner in the morning?
There are two heating programs to set the heating times.
Heating program 1 for setting the heating times Mon–Fri (working
week) and Sat–Sun (weekend) for the week as a whole,
Heating program 2 for setting the heating times for each day of the
week Mon, Tue, Wed, Thu, Fri, Sat and Sun.
Heating program 1 is assigned to operating mode 1 automatic
mode 1.
Heating program 2 is assigned to operating mode 2 automatic
mode 2.
First select automatic mode 1 or 2, see page 7 (Set operating mode).
Then adjust the associated heating program to suit your needs,
see page 8 (Set heating program 1) or page 9 (Set heating
program 2).
Example: P04 = :
If “Automatic mode 1” was selected as the operating mode, the
heating controller will always switch on the hot water one hour before
switching on the heating. If HO Holiday mode is activated, the hot
water is not switched on.
15
User – Questions
My heating does not get warm enough. What can I do?
You have two options.
First increase the desired room temperature Day, see page 6
(Set the desired temperature).
Wait for a few hours to give the heating system time to respond to
the new setting.
Should the room(s) still not get warm enough, you can increase the
heat slope for the direct heatcircuit or the mixing valve circuit, see
page 14 (P01 Heat slope).
Should this measure not be sufficient, see page 21 (Troubleshooting) and contact your heating engineer.
How do I set the heating system for holidays?
If you want to go away for a number of days, you can set the heating
controller to the operating mode “ Holiday setting”. The heating
system will revert to automatic mode at the end of the holiday so
that it will be warm when you come home, see page 7 (Set
operating mode).
How can I switch the heating system off during the summer?
In summer you should set the heating controller to the operating mode
“Summer mode”. This mode deactivates heating and the system is
only used for hot water, see page 7 (Set operating mode).
Is it possible to let the heating system run longer in the evening for special occasions such as a party?
For this purpose, set the operating mode to /Eco, see page 11
(Heating time setting/Change duration).
How do I set the heating controller to save energy?
Set the desired room temperature only as high as absolutely necessary. The energy consumption is increased by around 6% for every
degree, see page 6 (Set the desired temperature).
Set your heating program so that it switches the heating off at night
or at times when no-one is home.
Only open you windows briefly to let in fresh air. Avoid tilted windows
over longer periods.
My heating system is not running
Check the selector switch position. The selector switch must be
set to .
Check the operating mode. The display must indicate for Automatic mode 1, or 2 for Automatic mode 2, see page 7 (Set
operating mode).
16
Expert - Installation
Expert - Installation
CAUTION
The minimum distance from surrounding heat sources is to be chosen so that the permitted ambient temperature will not be exceeded
during operation, see page 22 (Technical data).
▷ Installation location:
In the reference or main living space of the heatcircuit, on an
internal wall in the living room
Not in the vicinity of radiators or other devices that give off heat
Anywhere if room sensor influence is switched off.
Remove remote control holder and use the drill holes to affix it to an
internal wall in the living area.
Th Fr SaSo
1 2
Mo TuWe
1
24
18
2
1
6
0
Prog1
/1...7
Prog2
/Eco
Mode
Th Fr SaSo
Mo TuWe
1
24
18
2
1
6
0
Prog1
/1...7
Prog2
/Eco
Mode
3
A
2 3 4
1 5
A
AA
A
58
Ø 3,5
61
17
Expert – Set parameters
Expert - Electrical connections
WARNING
Possible life-endangering electrical shock! Switch the power off to
electrical cables before working on power-carrying parts!
CAUTION
For fixed devices, an isolating mechanism must be installed for
shutting off from the network, in accordance with the installation
guidelines and EN 60335, e.g. with a switch.
The insulation for line conductors is to protected against damage
by overheating, e.g. insulating sleeve.
Electrical socket connection
1 2 3 4 5
SELV, safety extra low voltage
1 OpenTherm
2 OpenTherm
3 + 4 Telephone switch or external sensor
Phone switch
A telephone switch can be used to switch the heating into heating
mode. If a short circuit is detected between terminal 3 and 4, the
heatcircuit assigned switches into heating mode. Hot water preparation is also activated. Once the short circuit is removed, the heating
automatically reverts to the previous operating mode.
Expert – Set parameters
▷
Parameters P01 to P04 for users, see page 13 (User – Set
parameters)
WARNING
Incorrect settings can cause malfunctions and damage the heating
installation! Only a qualified technician may change the parameters
from no. 06.
A CODE-NO must be entered via parameter P05 to change
▷
parameters P06 and higher.
1 Turn selector switch to (parameter setting).
▷ The display shows .
2 Turn the rotary know until the parameter you want to change or
retrieve appears on the left in the display: 06 to 13.
Press the OK button.
▷ Display jumps to 05 0000. The first digit flashes.
4 Enter code no. (factory setting is 0000), set each digit with the
rotary knob and press the OK button.
▷ The display jumps back to the parameter to be changed.
▷
The display flashes if the code no. is correct. (If the code no.
was not entered correctly, the display does not flash. Continue
with step 3.)
5 Use the rotary knob to set the desired value.
▷ A number of parameters can only be displayed.
6 Press the OK button to confirm.
7 After you have made your settings, continue with step 2 if you
want to change further parameters (you do not need to enter
the code no. again), or turn the selector switch back to .
▷ The table - List of parameters P05 to P13 - shows the possible
settings.
18
Expert – Set parameters
▷ Your remote control will only display those parameters for which
there are sensors connected.
List of parameters P05 to P1
P. no.: Parameter Setting range Factory setting Own values
05 Code no. input 0000–9999 0000
06 Code no. change 0000–9999 ---07 Max. boiler temperature 20.0–110.0 °C (depends on boiler) 85.0 °C
08 Min. boiler temperature 10.0–110.0 °C (depends on boiler) 30.0 °C
Outside temperature
09
Frost protection
10 Integral control section
11 Transparent Slave Parameter 01 (see boiler instructions) -255–255 (depends on boiler)
12 Transparent Slave Parameter 02 (see boiler instructions) -255–255 (depends on boiler)
13 Software version and index Display only
----,
-15.0 to +5.0°C
----,
3:00 h to 0:15 min.
0.0 °C
----
Explanation of the parameters
P05 Code no. input
Here the code no. defined via P06 is entered for adjustment of the
Expert parameters.
▷ The default setting for the heating controller is 0000.
P06 Code no. change
Here you can specify your own code no. Remember this code well!
The parameters 06–13 can not be changed without this code no.
Should you forget the code no., the factory settings must be reloaded, and this means that all your settings will be lost, see page
12 (Load factory settings (Reset)).
• Change every digit of the four-digit code no. and confirm by
pressing the OK button.
P07 Maximum boiler temperature
P07 = 20.0–110.0 °C: The heating controller limits the calculated
desired temperature of the heatcircuit to P07 to protect the consumer
from overheating, e.g. when an underfloor heating system is installed.
The max. value can be restricted by the heat source.
P08 Minimum boiler temperature
P08 = 10.0–110.0 °C: The heating controller increases the calculated
desired temperature of the heatcircuit to P08, e.g. when air heating
is installed. The min. value can be restricted by the heat source.
19
Expert – Checklist for commissioning
P09 Outside temperature frost protection
P09 = ----: Frost protection is deactivated.
P09 = -15.0 to +5.0 °C: When the outside temperature drops below the set value, the heatcircuit controller switches the heatcircuit
pumps on.
P10 Integral control section
Integral component for the flow temperature. Enter a time here. If the
room does not reach the required temperature in the time set (from
the start of heating), the flow temperature is gradually increased until
it is sufficient to reach the desired room temperature.
P10 = ----: Function deactivated.
P10 = 3:00 h – 0:15 min: Time to reach desired room temperature
after start of heating time.
P11 Transparent Slave Parameter 01
Setting for internal parameter 01 for heat source.
P11 = -255–255: The values are only accepted by the heat source
if they are within this range.
P12 Transparent Slave Parameter 02
Setting for internal parameter 02 for heat source.
P12 = -255–255: The values are only accepted by the heat source
if they are within this range.
P1 Software version and index (62.00)
P13 = 62.00–62.99:
62 = software number
00–99 = software index
▷ If you have questions about your remote control, always specify
the software version.
Expert – Checklist for commissioning
❑ Remote control properly wired? See page 18 (Electrical socket
connection).
❑ Are the sensors required for the application connected? Sensors
that are not required are not connected.
❑
User parameters configured? Set at least time and day of the
week, see page 13 (User – Set parameters).
❑
Expert parameters configured? See page 18 (Expert – Set
parameters).
❑
Sensors tested for plausible values? See page 7 (Display
actual temperatures).
❑ Operating mode set? See page 7 (Set operating mode).
❑ Selector switch turned to ?
20
Troubleshooting
Accessories
Outside sensor AF
Order no. AF, 5 kΩ: 99 679 030
Scope of supply
Outside sensor, screw and dowel
Position of installation
▷ Ideally on a wall facing north or north-east
▷ Approx. 2.5 m above the ground
▷ Not above windows or air shafts
Installation
1 Pull cover off sensor.
2 Fasten sensor with enclosed screw.
For electrical connections, see page 18 (Expert - Electrical
connections).
Sensor values
Temperature
[°C]
-40 167835 10 9952
-30 88340 20 6247
-20 48487 25 5000
-10 27648 30 4028
0 16325 40 2662
5 kΩ NTC:
[Ω]
Temperature
[°C]
50 1801
5 kΩ NTC:
[Ω]
Troubleshooting
? Fault
! Cause
• Remedy
When a fault occurs, the error number is indicated in the display
(Example: E 81).
You can find the error numbers in the heat source instructions.
? The display shows an error no. between E001 and E255.
! Boiler error. If there is an arrow in the display pointing to “Reset”,
the error can be deleted using the remote control.
• Turning the rotary knob sends a reset telegram to the OT boiler.
The boiler is automatically restarted.
! If there is another arrow pointing to Water pressure too low,
the water pressure can be raised using the remote control.
• Turning the rotary knob tops up the water in the boiler. (Condition: The boiler supports the “Water Filling Procedure”, see heat
source instructions.)
? The display shows error no. E 81.
! EEPROM error. An invalid parameter has been replaced by the
default value.
• Check parameter values.
• Switch mains power off and on again to reset the error no.
21
Technical data
? When displaying the actual values on the remote control, you
realise that the indicated value does not match the real one. For
example, the actual hot water temperature is 20 °C, but the
display shows 65 °C (or vice versa).
! An incorrect sensor is connected.
• Only use sensors with identical characteristic curves.
? The hot water stays cold during summer mode.
! Parameter 04 = 03 set (hot water 1h before heating)
• Set P04 = 01 or 02.
Should the actions described above fail to help, please
contact your heating engineer.
▷ Please have ready the software version (parameter P13).
Technical data
Voltage supply via BUS 15–18 V DC
Bus communication: OpenTherm
Protection class according to DIN EN 60529: IP 40
Protection class according to DIN EN 60730: III
Reserve power of clock: >10 h.
Permissible ambient temperature during operation: 0 to 50 °C
Permissible ambient temperature during storage: -20 to 60 °C
Permissible relative humidity, not condensing: 95%r.H.
Sensor resistances: NTC 5 kΩ (AF),
Tolerance in ohms: ±1 % at 25 °C,
Temperature tolerance: ±0.2 °K at 25 °C.
22
Declaration of conformity
Glossary
Flow temperature
The flow temperature is the temperature to which the heat source
heats the water that transfers the heat to the consumer (e.g. radiator).
Desired and actual temperature
The desired temperature (or setpoint temperature) describes the
desired temperature for a room or for hot water.
The actual temperature denotes the actual temperature that prevails.
The heating controller has the task to adjust the actual temperature
to the desired temperature.
Setback temperature
The setback temperature is the desired temperature to which the
heating system heats outside heating times (e.g. at night). It should
be set so that the rooms do not cool down too much while saving
energy.
Heat source
Heat source is generally the designation for the heating boiler. It may
also be a buffer storage tank however.
Heating time
In the heating programs you can define up to three heating times per
day, one for the morning, one for lunchtime, and one for the evening
for example. During a heating time, the temperature is controlled to the
desired room temperature. Between heating times the temperature
is controlled to the setback temperature.
Declaration of conformity
We the manufacturer declare the product LagoFB is in conformity
with the fundamental requirements of the following directives and
standards.
Directives:
– 2004/108/EC,
– 2006/95/EC
Standards:
– EN 60730-1
– EN 60730-2-9
The manufacture is subject to the quality management system in
accordance with DIN EN ISO 9001.
Elster GmbH
Scan of the declaration of conformity (D, GB) –
see www.docuthek.com
23
Contact
Heating circuit allocation
For the installation expert
Please enter which rooms the heating circuits are assigned to here.
Direct heating circuit Mixed heating circuit
Contact
Contact
Printed in Germany
If you have any technical questions, please contact your local branch
office/agent. The addresses are available on the Internet or from ElsterGmbH.
We reserve the right to make technical modifications in the interests of
progress.
24
Elster GmbH
Geschäftssegment Comfort Controls
Kuhlmannstraße 10 · 31785 Hameln
www.kromschroeder.de
EN 6.6702.643-00 0112
Loading...
