INSTRUCTIONS FOR USE

S –1000

SURROUND PREAMP/PROCESSOR

Owner’s Reference

S–1000

Surround Preamp/Processor Instructions for Use

v 07.0

CONTACT INFORMATION

This product complies with the EMC directive (89/336/EEC) and the low-voltage directive (73/23/EEC).

Krell Industries, Inc. 45 Connair Road Orange, CT 06477-3650 USA

TEL 203-298-4000 FAX 203-891-2028 E-MAIL krell@krellonline.com

EBSITE http://www.krellonline.com

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions.

2. Keep these Instructions.

3. Heed all W

4. Follow all Instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

8. Unplug this apparatus during lightning storms or when unused for long periods of time.

9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally

10. The S –1000 must be placed on a firm, level surface where it is not exposed to dripping or splashing.

11. The ventilation grids on the top and bottom of the S–1000 must be unobstructed at all times during operation. Do not place flammable material above or beneath the preamplifier.

12. Before making connections to the S–1000, ensure that the power is off and other components ar terminations are of the highest quality, free from frayed ends, short circuits, or cold solder joints.

13. THERE ARE NO USER SERVICEABLE PARTS INSIDE THE S–1000 SURROUND PREAMP/ PROCESSOR.

arnings.

, or has been dropped.

e in mute or stand-by mode. Make sur

e all cable

Please contact Kr

DTS Digital Sur played back inside most CD, LD, or DVD players. For this r or DVD player the analog outputs ar

round ™ decoder system must be connected to the digital output (S/PDIF, AES/EBU, or TosLink) of the CD, LD, or DVD player.

Sur

This product is manufactured in the United States of America. Krell Industries, Inc., its subsidiaries, and authorized agents. Krell Smart System Setup™ is a trademark of Krell Industries, Inc. “DTS”, “DTS Digital Surround”, “DTS ES Extended Surround”, and “Neo:6” are registered trademarks of Digital Theater Systems, Inc. TosLink is a trademark of Toshiba Corporation. Manufactured under license fr Unpublished Works. Copyright 1992–1997 Dolby Laboratories, Inc. All rights r trademarks or register

round ™ is a discrete 5.1 channel digital audio format available on CD, LD, and DVD software which consequently cannot be decoded and

, excessive noise will be exhibited. To avoid possible damage to the audio system, proper precautions should be taken by the consumer if

e connected directly to an amplification system. To enjoy DTS Digital Surround ™ playback, an external 5.1 channel DTS Digital

om Dolby Laboratories. "Dolby

ed trademarks of HDMI Licensing LLC.

eason, when DTS-encoded software is played back through the analog outputs of the CD, LD,

," "Pr

ell if you have questions not addressed in this guide.

is a registered trademark of Krell Industries, Inc., and is restricted for use by Krell

o Logic," and the double-D symbol ar

All other trademarks and trade names ar

ved. HDMI, the HDMI logo and High-Definition Multimedia Inter

eser

e trademarks of Dolby Laboratories. Confidential

e r

egister

ed to their r

espective companies.

face ar

Contents

Page

INTRODUCTION 1

DEFINITION OF TERMS 2

UNPACKING 4

PLACEMENT 5

AC Power Guidelines 5

GETTING STARTED 6

FRONT PANEL DESCRIPTION 8

REMOTE CONTROL DESCRIPTION 13

Battery Installation and Removal 13

BACK PANEL DESCRIPTION 16

CONNECTING THE S–1000 TO YOUR SYSTEM 19 First: Connect Analog and Digital Sources 19

Next: Connect Video Sources 20 Last: Connect Amplifiers and Sources 21

OVERVIEW: SYSTEM CONFIGURATION AND NAVIGATION 22

Configuration Steps 22

Navigation Conventions 23

SYSTEM CONFIGURATION 24 Accessing the Main Menu 24 Step 1: Configure Loudspeakers 25 Step 2: Configure Devices 30

Step 3: Configure Level Adjustment 39 Step 4: Operation 47

SAVING AND RECALLING CUSTOMIZED SETTINGS AND RESTORING THE FACTORY DEFAULT SYSTEM SETTINGS 57

OPERATING THE S–1000 58

On/Off/Stand-by 68 Tape Input and Output 58 Simulcast 59

APPENDIX: OPERATING MODES FOR THE

Automatically Detected Modes User Selectable Modes 61

WARRANTY 63

RETURN AUTHORIZATION PROCEDURE 65

SPECIFICATIONS 66-67

S–1000

Krell S–1000 iii

Tables

Illustrations

Page

TABLE 1 S–1000 Connections and Corresponding

Factory Default Decoding Modes, by Device 14

TABLE 2 Krell Music Surround Modes for the S–1000 62

Page

FIGURE 1 The S–1000 Front Panel 7

FIGURE 2 The S–1000 Remote Control 7

FIGURE 5 The S –1000 Back Panel 14

–1000

ell

Introduction

Thank you for your purchase of the Krell S–1000 Surround Preamp/ Processor.

The S–1000 serves as the centerpiece in a Krell HEAT™—High End Audio Theater—system, which applies the fundamental principles of Krell engineering to the creation of a fully integrated high-performance multi-channel sound system. The S–1000 delivers outstanding music and cinema soundtrack reproduction through the use of a full complement of advanced Krell technologies including discrete Class A, direct-coupled circuitry with balanced outputs, user-configurable input assignment, and broadcast-quality video circuitry featuring HDMI™ technology.

The S–1000 features Dolby Digital 5.1, Dolby Digital EX, DTS-ES 6.1, DTS NEO:6, and Dolby Pr proprietary Krell Music Surround modes. This flexibility allows upgrades to software via Flash memory for future surround sound formats and design enhancements.

The owner’s reference manual contains important information on placement, installation, and operation of the Kr read this information carefully details helps ensure satisfactory operation of, and long life for your S–1000 and related system components.

o Logic II processing, in addition to nine

S–1000. Please

ell

. A thor

ough understanding of these

Krell S–1000 1

Definition of Terms

Following are the definitions of key terms used in your owner’s reference manual:

INPUT AND OUTPUT CONNECTIONS

OPERATION

Balanced

A symmetrical input or output circuit that has equal impedance from both input terminals to a common ground reference point. The industry standard for professional and sound recording installations, balanced connections have 6 dB more gain than single-ended connections and allow the use of long interconnect cables. Balanced connections are immune to induced noise from the system or the environment.

Single-ended

A two-wir

e input or output circuit. Use car

e when using single-ended connections as the ground connection is made last and broken first. Turn the system off prior to making or breaking single-ended connections. Single-ended connections are not recommended for con

nections requiring long cable runs.

Off

When the power switch on the back panel is placed in the down position and LEDs turn off, the component is off.

Stand-by Mode

When the S–1000 is connected to AC power and the back panel power switch is on, the power/stand-by LED (2) illuminates in red. This indicates that the component is in stand-by mode, a low power consumption status that keeps the audio and regulator circuits at

ecommends leaving the component in the stand-by mode

idle. Kr

ell r

when it is not playing music.

Operational Mode

When the component is in the stand-by mode, and you press the power button/pre key (1) the power/stand-by LED illuminates in blue. The component is in the operational mode and is ready to play music.

–1000

ell

Definition of Terms, continued

TECHNOLOGY

VIDEO

Krell HEAT

The Krell term HEAT, or High End Audio Theater, is a design application incorporated into Krell components to enhance multi-channel home entertainment systems. A Krell HEAT system is an integrated home theater system consisting of a state-of-the-art Krell preamp/ processor and matching amplifiers that reproduce two channel and multi-channel sources with audiophile sound quality, placing the audience in the middle of a lifelike environment.

HDMI™ High Definition Multimedia Interface (HDMI™) is a digital connection standard designed to provide the highest possible uncompressed video and audio quality over a single cable and connector.

Composite Video

An encoded video signal that transmits luminance (Y) and color (C) information on one wire.

S-Video

Video signal that separately transmits the luminance (Y) and color (C) components of the video signal using one wire.

Component Video

A video signal that uses three wires to convey luminance (Y), red minus luminance (R-Y), and blue minus luminance (B-Y) signals.

essive.

Component video signals may be interlaced or pr

ogr Progressive signals build screen content in one pass rather than the two passes required for standard (interlaced) video. Progressive technology eliminates motion artifacts and produces film-quality pictures. Both your source and video monitor must be equipped with progressive video technology to realize this advantage.

YPbPr

One way of designating color difference signals, in which:

Y = the luminance signal

Pb = blue minus luminance (B-Y) signal

Pr = red minus luminance (R-Y) signal

Krell S–1000 3

Unpacking

Open the box and remove the top layer of foam. You see these items:

1 S–1000 Surround Preamp/processor

1 IEC connector (AC power) cord

1 S–1000 handheld remote control

1 CR2025 lithium battery

1 12 VDC output (12 V trigger) cable

1 packet containing the S–1000 Quick Setup Guide

and the warranty registration card.

Carefully remove the S–1000 and accessories from the box. Remove the foam end caps and protective plastic wrap from the component.

Note

If any of these items are not included in the shipping box, please contact your authorized Krell dealer, distributor, or Krell for assistance. Save all packing materials. If you must ship your S–1000 in the future, repack the unit in its original packaging to prevent damage in transit. See Return

Authorization Procedure, on page 65.

4 Krell S–1000

Placement

Before you install the S–1000 Surround Preamp/processor into your system, review the following guidelines to choose the location for the component. This will facilitate a clean, trouble-free installation.

The S–1000 does not require any type of special rack or cabinet for installation. For the dimensions of your S–1000 see on pages 66-67.

The S–1000 requires at least two inches (5 cm) of clearance on each side and at least two inches (5 cm) of clearance above and below the component to provide adequate ventilation. In addition, the S–1000 requires at least three inches (7 cm) of clearance between other connected components. For installations inside cabinetry, extra ventilation may be necessary.

Specifications,

AC POWER GUIDELINES

e a dedicated

S–1000 has superb regulation and does not r

The AC circuit. Avoid connections through extension cords or multiple AC adapters. High quality 15 amp grounded AC strips are acceptable.

High quality AC line conditioners or filters may be used if they are grounded and meet or exceed the unit’s power supply rating of 100 VA.

Use the S–1000 only with the power cord supplied.

equir

Krell S–1000 5

Getting Started

IMPORTANT: ACCESSING THE ON-SCREEN DISPLAY

The S–1000 Surround Preamp/processor provides a variety of connection and operation options for outstanding music and cinema soundtrack reproduction, and offers a high degree of flexibility via an on-screen menu system. To setup the S –1000 quickly:

1. Connect the S–1000 to the rest of the components in your sys-

tem,

using Figure 3 on page 14 and Table 1 on page 15 as a

guide.

Please note:

On Screen Display (OSD). The S–1000 has three OSD outputs: component, S-video, and composite. There is no OSD available from the HDMI™ output.

To View the Setup Menu. Connect any of the OSD outputs on the S–1000 to the appropriate input on your video display. Press the remote control menu key. The front panel display reads

MENU MODE and all OSD outputs activate simultaneously.

Tune the video display input to match the selected OSD video connection.

2. Enter the setup menu. The MAIN MENU screen appears on the video

display.

3. Using the video display and the remote, select

SETUP. The LISTENING ROOM SETUP screen appears.

Select

SPEAKER SETUP. The SPEAKER SETUP scr

LISTENING ROOM

een appears. Scr

oll

through the available options and select your loudspeaker setup.

5. Select

SPEAKER DISTANCE and enter information about the placement

of your loudspeakers relative to your listening position.

6. Select

SPEAKER LEVEL and calibrate the volume of your loudspeak-

ers.

After you have connected and configured the S–1000 and are familiar with its basic features, you are ready to play music.

ating the S–1000

6 Krell S–1000

, on page 58.

See Oper-

DVD

SAT

TUNER

AME

TAPE/VCR2

POWER

RECALL

AVE

ALANCE

CENTER

URR/BACK

RE AMP

TEREO

MODE 1

MODE 2

RO LOGIC II

72421 20

19 15 16 17 18262514

10 11 12

271323221 34

8 965

Figure 1 The S –1000 Front Panel

14 8

FRONT PANEL AND REMOTE FUNCTIONS

BASIC OPERATION

1 Power Button/Pre Key 2 Power/Stand-by LED 3 Infrared Sensor

4 Infrared Emitter

INPUT DEVICE SELECTION

5 DVD Button/Key 6 Cable Button/LD Key 7 SAT Button/Key 8 VCR Button/Key 9 TV Button/Key

10 CD Button/Key

11 Tuner Button/LED/Key 12 Aux Button/LED

and Aux1 Key

13 Game Button/LED

and Aux2 Key

14 Tape/VCR2 Button/

LED/Key

PROCESSING MODE

15 Stereo Button/LED/Key 16 Mode 1 Button/LED/Key 17 Mode 2 Button/LED/Key 18 Pro Logic II

Button/LED/Key

19 Preamp Button/LED/Key

DISPLAY WINDOW

20 Front Panel Display

INDIVIDUALIZED CHANNEL TRIM

21 Center Button/Key 22 Surr/Back Button/

Rear Key 23 Sub Button/Key 24 Balance Button/Key

PROCESSOR FUNCTIONS

25 Save Button/Key 26 Volume Knob 27 Recall Button

Figure 2 The S–1000 Remote

REMOTE ONLY

28 Amp Key 29 Menu Key

FUNCTIONS

30 Prev Key 31 Mute Key 32 Enter Key 33 Right Directional Key

All other functions on the

emote contr

r panel functions.

The following keys are not

ol duplicate fr

active on the S–1000 remote:

Krell S –1000 7

MAIN, Z2, THX

Note:

6 The LD key on the remote

corresponds to the cable device button/LED (6) on the front panel.

HOW TO NAVIGATE IN THE MENU MODE

1 Press the menu key (29) to

enter and exit the menu mode from the operational mode.

2 Press the direction keys (33)

ont

to scr

om line to line,

oll fr and to scroll through options within a line.

3 Press the enter key (32) to

select and set an option. Use the directional keys to

scroll to the next line.

5 Press the prev key (30) to

return to the previous screen.

ess the pr

Pr the menu mode and place the S–1000 in the stand-by mode.

e key (1) to exit

Front Panel and Remote Control Description

ee Figures 1 and 2 on page 7

FUNCTIONS

Button = on front panel Key = on remote control

lue LED illuminated = function

B active, except for power/stand-by LED which illuminates red when

n stand-by mode.

Basic Functions

The S–1000 Surround Preamp/processor front panel and remote control access power on and off; input, and processing mode selection; monitoring and display of processor status; and balance and volume control.

For functions accessed only using the remote con-

trol, see page 12.

1 Power Button/Pre Key

The power button or pre key switches the S–1000 from standby to the operational mode.

2 Power/Stand-by LED

Stand-by Mode.

When the AC power cord is plugged into the wall, and the back panel power switch (58) is on, the LED illuminates in red, indicating that the component is in the standby mode.

Operational Mode. When the power button or pr

e key (1) is pressed, the LED illuminates in blue, indicating that the component is in the operational mode.

3 Infrared Sensor

The infrar remote control. For pr

ed sensor receives commands from the S–1000

oper remote control operation, make sur

the infrared sensor is not covered or obstructed.

4 Infrared Emitter

S–1000 remote operation code to a learning remote.

ogram Remote,

on page 51.

Input Device Selection

Emits the See

The S–1000 is equipped with ten input device selection buttons. If properly configured, the S–1000 automatically engages the correct video and audio inputs when you press the device selection button.

5 DVD Button/Key

Press this button or key to select the digital video disc device.

6 Cable Button/LD Key

ess this button or key to select the laser disc device.

7 SAT Button/Key

Press this button or key to select the satellite feed device.

8 VCR Button/Key

ess this button or key to select the VCR device.

8 Krell S–1000

Front Panel Description, continued

Input Device Selection Buttons and LEDs,

ontinued

Decoding Modes

9 TV Button/Key

Press this button or key to select the television device.

10 CD Button/Key

Press this button or key to select the compact disc device.

11 Tuner Button/Key

Press this button or key to select the AM/FM tuner device.

12 Aux Button/Aux1 Key

Press this button or key to select an auxiliary device, such as phono, tape, or an additional DVD, LD, CD, or VCR.

13 Game Button/Aux2 Key

Press this button or key to select a game.

14 Tape/VCR2 Button/St Key

Press this button or key to playback pre-recorded tapes. You may also use this button or key to compare the output signal of an analog tape recorder to an audio source.

and Output,

Stereo Button/LED/Key

ess this button to select stereo decoding. The blue LED illumi-

Pr nates when this featur

on page 58.

e is engaged.

See Tape Input

Krell S –1000

Mode 1 Button/LED/M1 Key

16 17 Mode 2 Button/LED/M2 Key

Use these buttons or keys to select available decoding modes for incoming signals fr

MOVIE.

om an audio source, for example

Mode 1. The default mode for a signal is always selected by Mode 1. The S–1000 activates the default mode assigned in the configure devices menu. In the operational mode, use the mode 1 button or M1 key (16) to view and select or reset the default coding mode.

Mode 2. All modes that can be used for the incoming signal are automatically stor

ed in Mode 2. Use the mode 2 button or M2

key (17) to scroll through these other modes in the display win-

. The last mode displayed in Mode 2 is the selected mode.

dow

S–1000 automatically selects the assigned mode for the

The available signal.

For information on decoding modes, see Table 1 on page 15, and

–1000,

Appendix: Decoding Modes for the

on page 60.

DOLBY PLII

Front Panel Description, continued

Decoding Modes, c

Note

Display Window

ontinued

18 Pro Logic II Button/LED/PL Key

Press this button or key to select the Dolby Pro Logic II modes for Dolby Surround encoded material, including laser discs, videotapes, television broadcasts, and compact discs.

The Dolby Pro Logic II modes are selected automatically if Dolby Digital source material is encoded for Pro Logic. To turn off these modes, press the Pro Logic II button.

19 Preamp Button/LED/Key

Press this button or key to send the signal from an analog input directly to the volume control with no digital processing, using the analog stage of the preamp. This function can be used for components which have a high quality signal.

Audio Inputs,

on page 33, for information on assigning the ana-

log input to one of the device buttons

TUNER, AUX, GAME, TAPE/VCR2).

This feature is only available with a signal from an analog input. If you attempt to use it with a signal from a digital input, The S–1000 onscreen and front panel display will read

See Assign Analog

(DVD, CABLE, SAT, VCR, TV, CD,

NOT ALLOWED.

20 Front Panel Display

The front panel window provides status messages for S–1000 operations, including volume and balance level, decoding mode, and zone infor cal inputs ar of inactivity

mation. When a new device is selected, the physi-

e displayed. The display turns off after 60 seconds

Individualized Channel Trim

Use the center

, surr/back, and sub buttons or keys to make temporary loudspeaker output adjustments of +/- 10 dB. These temporary changes revert to 0 dB when a new device is selected or when the

mation, see

system is power

ed down. For mor

Level Adjustment,

on page 39.

e infor

Configur

21 Center Button/LED/Key

Use this button to adjust the center loudspeaker volume. Pr

ess the center button or key, then use the volume knob or up and down directional keys (26) to make the adjustments.

Phantom Center. Press the center button or key twice to activate. Pr

ess the center button twice again to deactivate. The S–1000 generates a center channel for use when no center channel is used.

–1000

ell

Front Panel Description, continued

Individual Channel

ontinued

Trim,

22 Surr/Back Button/LED/Rear Key

Press the surr/back button or key, then use the direction or level buttons (28) to adjust the volume of the surround loudspeakers. The phrase

SURROUND TRIM appears on the front panel display. To

adjust the back loudspeakers, press the surr/back button again.

BACK appears on the front panel display. Then use the direction

or level buttons to adjust the volume of the back loudspeakers.

23 Sub Button/LED/Key

Press the sub (subwoofer) button or key, then use the volume knob or directional keys (26) to adjust the subwoofer loudspeaker volume.

24 Balance Button/LED/Bal Key

Use this button or key to adjust to the main left/right loudspeaker balance. Press the button or key, then use the volume knob or the up and down directional keys (26) to adjust the balance. Balance levels show numerically on the fr Balance may be adjusted in .5 dB incr

ont panel display (20).

ements, up to 6 dB. The

center position is displayed as BAL 0.

Balance level keys revert to their original function as volume level controls after 3 seconds of inactivity.

ocessor Functions

25 Save Button

Press and hold this button to save system configuration settings. The save button is also used in programming a learning remote. See

Saving and Recalling Customized Settings and

Restoring the Factory Default System Settings,

and

Program Remote, on page 51.

on page 57,

26 Volume Knob/Directional Keys

Use the volume knob or directional keys to scroll through menu selections, adjust the output for the entire system, and adjust balance and volume levels for the center loudspeaker

, sur round/back loudspeakers, and subwoofer. Volume and balance levels appear in the fr

Recall Button

ont panel display (20).

Use this button retrieve your system’s saved settings or to replace all system settings with factory default settings. See

Saving and Recalling Customized Settings and Restoring the Factory Default System Settings,

on page 57.

Krell S–1000 11

Remote Control Only Description

ee Figure 2 on page 7

BATTERY INSTALLATION AND REMOVAL

Notes

The S–1000 remote control uses one CR2025 lithium battery, which is included with the shipment.

To open the battery compartment on the back of the remote control:

1. Place the remote face down on the table.

2. Use your thumbnail or a small jeweler’s or eyeglass screwdriver to move the small tab toward the center of the remote, while using your index fingernail or screwdriver to pull down gently on the slot to the right of the tab. The battery compartment will slide out.

3. Place the battery, plus side up, in the battery tray.

4. Slide battery compartment back into the remote until you hear a click.

The remote control is ready for operation.

Do not use a knife or other sharp objects to open the battery compartment; they will scratch the remote control finish.

Replace batteries when remote control function becomes intermittent.

Remove batteries if the remote control is not to be used for a long period of time. Battery leakage can damage the remote control.

REMOTE ONLY FUNCTIONS

Notes

S–1000 Sur

The

round Pr

access to IR contr

eamp/pr

ollable power amplifiers, accesses the system

ocessor remote control provides

configuration menu and on screen display (OSD), and a special key to engage digital room EQ. Other functions on the remote control duplicate front panel functions.

These keys are not active on the S–1000 remote control: MAIN, Z2, THX.

The LD key (6) on the remote corresponds to the cable button/LED (6) on the front panel.

The following functions are only accessible from the front panel, and are not available on the r

emote contr

ol:

RECALL, SA

VE.

28 Amp Key (Power Amp Key)

Use this key to operate IR controllable power amplifiers, such as all Krell Evolution amplifiers.

29 Menu Key

Use this key to access the setup menu and on-screen menu display

–1000

ell

Front Panel Description, continued

REMOTE ONLY FUNCTIONS,

ontinued

30 Prev Key

Use this key to return to the previously displayed setup menu screen.

31 Mute Key

Use this key to mute the S–1000 output. When this function is active,

VOLUME MUTE appears in the front panel display.

32 Enter Key

Use this key to accept setup menu selections, accept an input device selection, or display current system conditions.

33 Directional Keys

IN THE OPERATIONAL MODE

Right Directional Key. Use this key to engage the Digital Room Equalizer.

Up and Down Directional Keys. Use these keys to select EQ memory.

IN THE MENU MODE

All Directional Keys. Use all four directional keys to navigate the on-screen menus.

Up and Down Directional Keys. Use these keys to adjust volume, balance, and selective volume for the center loudspeaker,

round loudspeakers, and subwoofer.

sur

Krell S–1000 13

OWER

HDMI OUT

HDMI 4

HDMI 3

HDMI 2

DMI 1

2VDC OUT

12VDC

Processor

C-5

SR SBR

0/60 Hz

RS-232

ADE IN USA

IGITAL AUDIO

NALOG AUDIO OUTPUTS

COMPOSITE VIDEO

OSD

OUT

S-VIDEO

OUT

OSD

OMPONENT VIDEO

PrPb

ULTI-CHANNEL INPUTS

CSL

NALOG AUDIO INPUTS

NO USER SERVICEABLE PARTS INSIDE

APE

NOUT

51 50 56 53 5247 46 49 48 55 58

42 36 41 43 4434 37 38 39 40 45 545935

Figure 3 The S–1000 Back Panel

BACK PANEL FUNCTIONS

ANALOG AUDIO INPUTS AND OUTPUTS

34 Balanced Analog

Audio Outputs

35 Single-ended

Analog Audio Outputs

36 Balanced Analog

Audio Inputs 37 Tape In Left and Right 38 Tape Out Left and Right 39 VCR In Left and Right 40 VCR Out Left and Right 41 Single-ended

Analog Audio Inputs 42 7.1 Audio Inputs

DIGITAL AUDIO INPUTS AND OUTPUTS

43 Optical Digital Audio Inputs 44 Coaxial Digital Audio Inputs 45 Digital Audio Output

VIDEO INPUTS AND OUTPUTS

46 S-video Outputs 47 S-video Inputs 48 Composite Video Outputs 49 Composite Video Inputs 50 Component Video Outputs 51 Component Video Inputs

52 HDMI

Output

53 HDMITMInputs

BACK PANEL REMOTE CONTROL CONNECTIONS

54 Comm Port RS-232

Remote Connector 55 RC-5 In 56 12 VDC In and Out 57 DB 25 Out

POWER CONNECTIONS

58 Back Panel Power Switch 59 IEC Connector

14 Krell S–1000

TABLE 1 S–1000 Connections and Corresponding

Factory Default Decoding Modes, by Device

Connect the S–1000 to the rest of the components in your system,

sing this table as a guide.

DEVICE S–1000 CONNECTIONS FACTORY DEFAULT DECODING MODES

Digital Analog Digital Analog

Video Audio Audio Dolby 2.0 Dolby 5.1 DTS 5.1 PCM

DVD Component 1 COAX 1 S1 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII

Dolby PLII Movie Movie Movie Movie

CABLE HDMITM2 COAX 3 S4 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII

Dolby PLII Movie Movie Movie Movie

SAT HDMITM1 OPT 1 S3 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII

Dolby PLII Movie Movie Movie Movie

VCR S-Video 2 Disabled VCR N/A N/A N/A N/A Dolby PLII

Movie

TV Composite 1 COAX 2 S2 Dolby D+ N/A N/A N/A Dolby PLII

Dolby PLII Movie Movie

CD Disabled Disabled B1 N/A N/A N/A N/A Preamp

TUNER Disabled Disabled S5 N/A N/A N/A N/A Preamp

AUX Disabled Disabled 7.1 N/A N/A N/A N/A N/A

GAME Component 2 OPT 2 S6 N/A Dolby D 5.1 DTS 5.1 Dolby PLII Preamp

TAPE Composite 3 Disabled Tape N/A N/A N/A N/A Preamp

Notes

When the S–1000 is in the operating mode, press the mode button or M1 key (16) on the remote control to read the current processing mode in the front panel display. Press the mode button or M2 key (17) to review and select other available modes. See

In the menu mode,

Step 2, Configure Devices screens show available

Decoding Modes, on page 9.

decoding modes, by device. For example, see Assign Digital Audio Inputs, on page 34; DTS Contr

ol,

on page 44; PLII Control, on page 45.

The Appendix: Decoding Modes for the S –1000, on page 60, shows all the decoding modes for the

–1000, and includes a listing of Kr

ell Music

Surround modes.

Krell S–1000 15

Back Panel Description

ee Figure 3 on page 14

FUNCTIONS

Analog Audio Outputs and Inputs

The back panel of the S–1000 Surround Preamp/processor provides all audio and video input and output connections, remote control inputs and outputs, power on and off, and power connection. The back panel functions are described below.

34 Balanced Analog Audio Outputs

The S–1000 is equipped with eight balanced analog audio channel outputs, with XLR connectors, for the left, center, subwoofer, surround left, surround right, back left, and back right.

Single-ended Analog Audio Outputs

The S–1000 is equipped with eight single-ended analog audio channel outputs, with RCA connectors, for the left, center, right, subwoofer, surround left, surround right, back left, and back right.

36 Balanced Analog Audio Inputs

The S–1000 is equipped with one set of balanced inputs with XLR connectors.

37 Tape In Left and Right

The S–1000 is equipped with one set of single-ended tape inputs with RCA connectors.

38 Tape Out Left and Right

The S–1000 is equipped with one set of single-ended tape outputs with RCA connectors.

39 VCR In Left and Right

The S–1000 is equipped with one set of single-ended inputs with RCA connectors, for a VCR audio source.

40 VCR Out Left and Right

The S–1000 is equipped with one set of single-ended outputs with RCA connectors, for a VCR audio source.

41 Single-ended Analog Audio Inputs

The S–1000 is equipped with seven sets of single-ended inputs with RCA connectors.

42 7.1 Audio Inputs

The S–1000 is equipped with eight single-ended 7.1 analog passthrough inputs for multichannel SACD and DVD audio devices.

Digital Audio Inputs and Outputs

16 Krell S –1000

43 Optical Digital Audio Inputs

The S–1000 is equipped with four optical digital EIAJ inputs with

osLink connectors.

Back Panel Description, continued

Digital Audio Inputs and Outputs,

ontinued

Video Inputs and Outputs

44 Coaxial Digital Audio Inputs

The S–1000 is equipped with four coaxial digital audio inputs with RCA connectors.

45 Digital Audio Outputs

The S–1000 is equipped with one digital audio outputs: coaxial with an RCA connector.

46 S-video Outputs

The S–1000 is equipped with two S-video outputs with DIN connectors. The main S-video output (labeled OSD on back panel) includes on-screen display. For dubbing purposes, the second S-video output does not include on-screen display.

47 S-video Inputs

The S–1000 is equipped with four S-video inputs with DIN connectors.

48 Composite Video Outputs

S–1000 is equipped with two composite video outputs with

The RCA connectors. The main composite video output (labeled OSD on back panel) includes on-screen display. For dubbing purposes, the second composite video output does not include on-screen display.

Note

Krell S–1000

49 Composite Video Inputs

The S–1000 is equipped with four RCA composite video inputs with RCA connectors.

50 Component Video Outputs

The S–1000 is equipped with one set of component video outputs with RCA connectors. Component video uses three wires, labeled Y, Pr, and Pb on the back panel, to convey the video signal. These inputs are compatible with all wideband video sources.

On-screen display (OSD) is available for interlaced component video; it is not available for progressive component video.

51 Component Video Inputs

S –1000 is equipped with three sets of component video

The inputs.

52 HDMI™ Output

The S –1000 is equipped with one HDMI™ video output.

Back Panel Description, continued

53 HDMI™ Inputs

The S –1000 is equipped with four HDMI™ video inputs.

Note

Back Panel Remote Control Connections

The S–1000 switches HDMI™ video only. Audio signal is not available via the HDMI™ inputs. On screen display (OSD) is not available from the HDMI™ output. When an HDMI™ input is assigned to a device, and the menu key on the remote is pressed, the on screen menu is available simultaneously from composite, S-video, and component OSD outputs.

Comm Port RS-232 Connector

The S–1000 is equipped with an RS-232 communication port, which sends operational instructions directly to the S–1000 using an external computer control system.

55 RC-5 In

The RC-5 input makes custom installation easy and secure by accepting baseband RC-5 input commands from hardwired remote contr

ollers.

56 12 VDC In and Out

The S–1000 is equipped with four programmable 12 V outputs and one input. Each trigger sends a 12 V power on/of 12 V trigger cable to other Kr

ell components and to other devices

f signal via a

that incorporate 12 V power on/off trigger input. Trigger 1 is enabled for all 10 devices.

Note

When the S–1000 is in the operational mode and a trigger is enabled, the 12 VDC Out pr stand-by mode or off, or if a trigger is not enabled, the DC output is 0 V.

ovides 12 V of DC output. When the S–1000 is in the

57 DB 25 Out

The S–1000 is equipped with a multi-channel audio output via a DB-25 connector

. The DB-25 contains the output connections

for all the output channels (left, center, right, subwoofer, surround

ound right, back left, and back right).

om of

f to stand-by

Power Connections

left, sur

58 Back Panel Power Switch

Use this switch to change the S–1000 fr

59 IEC Connector

–1000 is equipped with a standar

The

, for use with the AC power cor

nector

18 Krell S–1000

d female IEC power con

Connecting the S–1000 to Your System

This section provides information about connecting the S–1000 Surround Preamp/processor to analog and digital sources, video sources, and amplifiers. The S–1000 is equipped with balanced and singleended inputs.

Krell recommends using balanced interconnect cables. Balanced interconnect cables not only can minimize sonic loss but also are immune to induced noise, especially for installations using long cables. Balanced connections have 6 dB more gain than singleended connections. When level matching is critical, keep this specification in mind. Krell recommends that you use balanced inputs for components that will use the preamp mode.

FOLLOW THESE CONNECTION STEPS

First: Connect Analog and Digital Sources

Follow these steps to connect the S–1000 to your system.

TABLE 1, on page 15, for more information on device connections and available decoding modes, including factor modes:

1. Make sure all power sources and components are off before connecting inputs and outputs.

2. Neatly arrange and organize wiring to and from the S–1000 and all components. Separate AC wires from audio cables to prevent hum or other unwanted noise from being introduced into the system.

3. Connect the right and left outputs of your source components to the inputs on the S–1000.

Stereo analog input sources. The S–1000 is equipped with nine pairs of single-ended analog audio inputs (S-1 through S-7 (41), tape (37), and VCR (39) via RCA connectors and one set of balanced analog audio inputs (36) via XLR connectors.

Multi-channel analog sources. (For example, multi-channel SACD and DVD audio players). Connect the outputs of your source component to the 7.1 inputs (42) on the back panel.

y default decoding

Refer to

Digital audio sources. Connect the digital audio output of your source components to the digital inputs on the S–1000. The S–1000 is equipped with four coaxial digital audio inputs (44) via RCA connectors and four EIAJ optical digital inputs (43) via TosLink connectors.

Krell S–1000 19

Connecting the S–1000 to Your System, continued

Next: Connect Video Sources

4. Connect the video source outputs to the appropriate video inputs on the S–1000.

Component video inputs. Use the component connection when the source device (DVD) and output device (TV) both feature component connections. Component video signals use three wires that convey luminance (Y), red minus luminance [R – Y] (Pr), and blue minus luminance [B – Y] (Pb) signals. See the user manuals included with these devices for more information. The S–1000 is equipped with 4 sets of component video inputs (51).

S-video inputs. S-video cables transmit the color and luminance components of the video signal separately. The S –1000 is equipped with 3 sets of S-video inputs (47).

Composite video inputs. The S–1000 is equipped with four composite video inputs (49).

HDMI™ video inputs. The S –1000

is equipped with four

HDMI™ video inputs (53).

5. Connect the video outputs of the S–1000 to the inputs of your video monitor and/or video recorder

The S–1000 is equipped with one set of component video outputs (50), two S-video outputs (46), two composite video outputs (48), and one HDMI™ output.

Note

ANT

IMPOR

T ACCESSING THE ON-SCREEN DISPLAY

S-video inputs can be seen only on S-video outputs. Composite inputs can be seen only on composite outputs. Component inputs can be seen only on component outputs.

On screen display (OSD). The S–1000 features one OSD output for each category of video connection: component, Svideo, and composite. There is no OSD available from the HDMI™ output.

To view the setup menu. Connect any of the OSD outputs on the S–1000 to the corresponding input on your video display. Press the remote control menu key (29). The front panel display r

eads

MENU MODE and all OSD outputs activate simultane

ously. Tune the video display input to match the selected OSD video connection.

–1000

ell

Connecting the S–1000 to Your System, continued

Last: Connect Amplifiers and Sources

IMPORTANT

The S–1000 has balanced outputs with XLR connectors and singleended outputs with RCA connectors. Both outputs are active at all times, allowing simultaneous connection to separate amplifiers. Connect only one of these output formats to a single amplifier.

6. Connect the outputs of the S–1000 to the input(s) of your power amplifier(s).

7. Connect the AC power cord to the IEC connector (59) on the S–1000 and to the AC wall receptacle.

Move the back panel power switch (58) into the up (on) position. The red power/stand-by LED (2) on the front panel illuminates. The words

PLEASE WAIT, INITIALIZING appear in the front panel display

(20). When the initializing message disappears, the S–1000 is ready to switch to the operational mode.

9. Use either the front panel power button or the remote con-

e key (1) to power on the S–1000. The blue power LED (2)

trol pr on the front panel illuminates. The S–1000 is now in the operational mode and ready to be configured.

Make sure that all source devices are off when you configure the S–1000.

Krell S–1000 21

Overview: System Configuration and Navigation

This section briefly outlines S–1000 Surround Preamp/processor configuration menus and introduces menu navigation features.

CONFIGURATION STEPS

IMPORTANT: FOR BEST RESULTS FOLLOW THESE STEPS

The easy-to-follow, step-by-step configuration menus let you set up your S–1000 for optimum performance. Detailed instructions begin on page 24. Krell recommends that you configure your component in the sequence outlined on the main menu screen:

1. LISTENING ROOM SETUP, see pages 24-29

The SPEAKER SETUP menu enables you to define the number and type of loudspeakers in your system and allows you to select the bass range for each loudspeaker, control the subwoofer output and set the crossover frequency.

The

SPEAKER DISTANCE menu enables you to define the exact loca-

tion of each loudspeaker in the system, so that the S–1000 can synchronize the output to all loudspeakers, no matter where they are located in the room.

The

CALIBRATE VOLUME menu enables you to set the volume to a

reference level, to match the sensitivities of different loudspeakers and amplifiers in your system.

2. CONFIGURE DEVICES, see pages 30-38

The configure devices menu enables you to assign each device inputs and configure modes and triggers using the setup menus

CONFIGURE VIDEO, CONFIGURE AUDIO, and CONFIGURE TRIGGER.

for

3. CONFIGURE LEVEL ADJUSTMENT

see pages 39-46

The configure level menu enables you to set master volume trims for the components in your system. These fixed positive or negative volume offsets maintains level matching while switching between inputs with different output levels. The setup menus include: DEVICE TRIM, ANALOG INPUT TRIM, MUSIC MODE SUB TRIM, DTS CONTROL

TRIM, PLII CONTROL TRIM,

OPERA

TION,

and MAXIMUM VOLUME LIMIT.

see pages 47-56

The operation menu enables you to select screen position and display time for the on-screen display (OSD) using the

TION set up menu; enables you to set audio modes using the AUDIO OPERATION set up menu and configure the 7.1 input using

7.1 INPUT SETUP menu; enables you to program a learning

the

emote contr

r you to display system information using the

ol using the

PROGRAM REMOTE setup menu; enables

SYSTEM INFORMATION

OSD OPERA-

setup menu; and enables you to adjust frequency response

ough the

thr

22 Krell S–1000

ROOM EQ SETUP menu.

Overview: System Configuration and Navigation, continued

NAVIGATION CONVENTIONS

The remote control is the main input device for configuring the S–1000. For all menu mode options, use the following keys to navigate through the configuration menu screens:

29 Menu Key

Press this key once to enter the configuration menu. The front panel display reads

MENU MODE. The MAIN MENU screen appears.

Press this key again to exit the configuration menu. The S–1000 reverts to the operational mode.

33 Direction or Level Keys

Use all four directional keys to navigate the on-screen menus.

32 Enter Key

Press this key once to select a highlighted item. Once an item is selected, use the direction or level keys (33) to scroll through available options within a line. T

o select a highlighted option

within a line, press the enter key again.

ev Key

30 Pr

Press this key once to r

eturn to the previous screen within the

configuration menu.

1 Pre Key

The power key for the S–1000 is marked: Pre on the remote. In the menu mode it is used to exit the configuration menu. Press this key once. The S–1000 reverts to the stand-by mode.

To Select and Enter Menu Options

When a menu screen first appears, and there is a cursor blinking at one menu item, press the enter key (32) to select the menu item. If the item is configurable, the entire selection blinks along with the cursor.

Then use the direction keys (33) to scroll through the options that are blinking. Press the enter key to set your selection. After you have set the selection, the selection stops blinking and only the cursor at the menu item is blinking. Use the direction keys to move the cursor to the next menu item.

Krell S–1000 23

System Configuration

The S–1000 Surround Preamp/processor is shipped with factory default selections in the configuration menus. For correct operation and maximum performance, use the sequence starting below,

page,

menus. These menus are structured to guide you through the setup process for your loudspeakers and for each device in your surround sound system.

Configure the S–1000 loudspeaker positions in the listening room first, then configure each source device connected to your system completely, before configuring the next source device.

To save your new configuration menus, or revert to the factory defaults, see

Restoring the Factory System Settings,

on this

to configure the S–1000 through the interactive on-screen

Saving and Recalling Customized Settings, and

on page 57.

ACCESSING THE MAIN MENU

Main Menu Screen

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

Press the menu key. The front panel display reads MENU MODE. The

enu

MAIN MENU screen appears.

24 Krell S–1000

System Configuration, continued

Step 1, Listening Room Setup

STEP 1 LISTENING ROOM SETUP

Speaker Main Menu Screen

The first option on the main menu screen, LISTENING ROOM SETUP, lets you define the number and type of loudspeakers in your system and select the bass range for each loudspeaker. It also allows you to control the subwoofer output and set the crossover frequency.

Select

LISTENING ROOM SETUP, on the MAIN MENU. The SPEAKER MAIN MENU

screen appears.

Configur

Speaker Setup Screen

Krell S–1000

e Speakers

Select

CONFIGURE SPEAKERS. The SPEAKER SETUP screen appears. Using

this screen, you can enable loudspeakers that are in your system in the left column and select loudspeaker characteristics in the far right column.

System Configuration, continued

Step 1, Listening Room Setup

Configure Speakers,

ontinued

Note

FRONT

CENTER

SURROUND

BACK

5.1 SURR

If you have a 5.1 system, select NO BACK (loudspeakers). If you have a 6.1 system, select

2 BACK.

When 1 BACK is selected, the signal is present at the left back output.

FULL RANGE

1 BACK. If you have a 7.1 system, select

Sends 20Hz to 20KHz signals to the loudspeaker.

LIMITED

Sends information from the crossover frequency to 20KHz to the loudspeaker.

See CROSSOVER, below, on this page. The frequencies below the crossover frequency are sent to the subwoofer if present; otherwise, these low frequencies are sent to the full range loudspeakers in the system.

Select

SURROUND, BACK, or BOTH to choose which loudspeakers in a

6.1 or 7.1 system receive surround information when playing a Dolby Digital 5.1 or DTS 5.1 encoded software.

SURROUND

Sends surround channel information to surround loudspeakers only

BACK

Sends surround channel information to the back loudspeakers only.

SUB

CRSOVR

BOTH

Sends surround channel information to the surround and back loudspeakers simultaneously.

Select

NORMAL or ENHANCED to choose the amount of bass infor

sent to the subwoofer.

NORMAL

Sends the low fr

equencies fr

om the limited speakers and the .1 (or

LFE) signal to the subwoofer.

ENHANCED

Sends additional bass information from the left and right loudspeakers to the subwoofer in addition to the low fr

equencies fr

om the lim

ited loudspeakers and the .1 (or LFE) signal.

ossover selections ar

e 120, 100, 80, 60, and 40 Hz. The standar setting is 80 Hz. Choose the crossover frequency appropriate for your loudspeakers. The fr

e sent to the subwoofer if present; otherwise, these low frequen-

equencies below the cr

ossover frequency

cies are sent to the full range loudspeakers in the system.

After selecting the appr

opriate loudspeaker configuration for your system, press the previous key (30) once to return to the speaker main menu.

mation

–1000

ell

System Configuration, continued

Step 1, Listening Room Setup

Speaker Distance

Room Setup Screen

The second option on the speaker main menu screen, SPEAKER DIS-

, allows you to tell the S–1000 the exact location of each loud-

TANCE

speaker in your system.

Select

SPEAKER DISTANCE on the SPEAKER MAIN MENU. The ROOM SETUP

screen appears:

Note

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

When you access the ROOM SETUP screen, the cursor is blinking at the

LEFT loudspeaker

. Use the dir

ection and enter keys to navigate the screen, select loudspeakers, and enter the correct distance (0 to 30 feet) from the main listen position to the loudspeaker.

After all the distances are set, press the previous key (30) once to

n to the speaker main menu.

etur

Any speaker not configured in the SPEAKER SETUP menu displays N/A (not available) on the ROOM SETUP screen.

Krell S–1000 27

System Configuration, continued

Step 1, Listening Room Setup

Calibrate Volume

Note

Calibrate Room Setup Screen

The third option on the speaker main menu screen, CALIBRATE VOLUME, allows you to calibrate each channel using the internal noise generator of the S–1000.

A sound pressure level (SPL) meter is required for this procedure.

Select CALIBRATE VOLUME on the MAIN MENU. The CALIBRATE ROOM SETUP screen appears:

Auto Noise Sequence

CALIBRATION screen appears:

AUTO NOISE SEQUENCE. The AUTO

ess the enter key to choose

Auto Calibration Screen

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

28 Krell S–1000

System Configuration, continued

Step 1, Listening Room Setup

AUTO NOISE SEQUENCE

ontinued

Note

Manual Noise Sequence

Set the SPL meter to C weighting and slow response. After initializing, the

LEFT channel dB setting on the screen blinks, and you hear

band limited white noise through the left loudspeaker. This noise continues for two seconds and then moves clockwise to the next loudspeaker in the system.

While the individual channel on screen is blinking, use the direction keys to adjust each loudspeaker’s setting until the SPL meter reads 75 dB.

Repeat this process with the remaining loudspeakers. When all the loudspeakers are adjusted, press the previous key twice to return to the main menu screen.

The adjustments must be made while the channel on screen is blinking.

Set the SPL meter to C weighting and slow r ing, the cursor at the Press enter

. You hear banded white noise through the left loudspeak

LEFT channel dB setting on the screen blinks.

esponse. After initializ-

er.

While the individual channel on screen is blinking, use the direction keys to adjust each loudspeaker’s setting until the SPL meter reads 75 dB.

Note

Program Material Option

Press enter to set each selection, then use the direction keys to move to the next loudspeaker. Repeat this process for all loudspeakers.

ess the previous key twice to return to the main menu screen.

Any loudspeaker not configured in the SPEAKER SETUP menu displays N/A (not available) for the dB specification.

The program material option uses the same screen as the automatic or manual noise sequence, but requires external program material such as a test disc. The source plays, simultaneously, from all config-

ed loudspeakers. Use the enter and dir

ection keys to individually adjust loudspeaker levels based on your listening preferences rather than SPL readings. If all channels are not present in the source material, they will not be heard during this process.

Krell S–1000 29

System Configuration, continued

Step 2, Configure Devices

IMPORTANT: PLEASE READ BEFORE STARTING STEP 2, CONFIGURE DEVICES

The S–1000 is shipped with pre-selected connections for each device, as well as factory default decoding modes for analog and digital inputs.

See Table 1, on page 15.

To illustrate the method of selecting configuration options available through the S–1000,

Step 2, Configure Devices, uses one source device as an example: a DVD player. Configure each source device connected to your system completely, before configuring the next source device, following the steps outlined in this manual. Audio factory defaults for the S–1000 do not need to be configured if your system matches the factory defaults.

IMPORTANT

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

Some S–1000 configurations are designed for digital only, and some are designed for analog only. If you try to format an analog source device using a digital configuration, the menu will not let you proceed.

30 Krell S–1000

System Configuration, continued

Step 2, Configure Devices

STEP 2 CONFIGURE DEVICES

Configure Devices Screen

The second option on the main menu screen, CONFIGURE DEVICES, allows you to assign video and audio inputs to source devices and configure triggers for devices in the system.

Select

CONFIGURE DEVICES on the MAIN MENU. The CONFIGURE DEVICES

screen appears:

Assign Video Input

Assign Video Input Screen

assigned input=input on back panel

Select CONFIGURE VIDEO from the CONFIGURE DEVICES menu. The ASSIGN

een appears.

VIDEO INPUT

scr

The ASSIGN VIDEO INPUT screen lets you select the device, configure it, and assign an input to the device.

Krell S–1000 31

System Configuration, continued

Step 2, Configure Devices

Assign Video Inputs,

ontinued

PREVIOUS or DISABLED

For devices that do not use a video input, for example, a CD player, there are two options:

PREVIOUS or DISABLED. PREVIOUS allows the last

active video input to continue to be displayed, as long as a previous selection has been made.

NTSC or PA L

DISABLED turns off the video outputs.

Choose a standard video format.

OFF, MENU ONLY, or MENU AND STATUS

Select one of these options for component video inputs, based on your video source and monitor capabilities.

When using a progressive or high definition (HD) video source, select

OFF or MENU ONLY in order to pass the video signal properly. The

S–1000 can only display on-scr

een text in NTSC or PAL. If the monitor cannot automatically switch between progressive or HD video and standard definition (NTSC or PAL) video, you must select

OFF.

Then, in addition, connect the composite or S-video OSD output to the monitor, in or

HDMI

der to disploay the setup menu.

Select this option for multi-channel output.

Use the enter (32) and directional (33) keys to navigate the menu and set selections.

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

When all selections are entered, press the previous key (30) once to

return to the

CONFIGURE DEVICES menu.

32 Krell S –1000

System Configuration, continued

Step 2, Configure Devices

Assign Analog Audio Inputs

Assign Audio Inputs Screen

Assign Analog Audio Input Screen

Select CONFIGURE AUDIO from the CONFIGURE DEVICES menu. The ASSIGN

AUDIO INPUTS

screen appears:

Select ANALOG. The ASSIGN ANALOG AUDIO INPUT screen appears.

Use the direction and enter keys to scroll through and select the device you want to configure, select the

MIGRATION/REC input, and

choose the analog mode, if mode options are available.

Krell S–1000 33

System Configuration, continued

Step 2, Configure Devices

Assign Analog Audio Inputs,

ontinued

Assign Digital Audio Inputs

Assign Digital Audio Input Screen

AUTO-MIGRATION ON allows the S –1000 to switch to the analog input

automatically, if no digital input is present. This function is particularly useful for SACD players.

The analog signal must be assigned, not

DISABLED, in order for auto-

migration to be active.

After the selections for analog audio inputs are entered, press the previous key. The

The ASSIGN DIGITAL AUDIO INPUT

ASSIGN AUDIO INPUTS screen appears. Select DIGITAL.

screen appears.

ough and select the dig

Use the dir

ection and enter keys to scr

oll thr ital device you want to configure, select the digital input, and choose the default mode for the four major surround sound digital formats:

DOLBY DIGITAL 2.0, DOLBY DIGITAL 5.1, DTS 5.1, and PCM. You can choose a

decoding preference for each of these signals under

e infor

Notes

PREFERENCE

S–1000,

IS.

For mor

on page 60.

The digital input must be set to DISABLED to use the analog input.and it must be set to DISABLED to use pr

PREVIOUS holds the last selected digital input.

DOLBY DIGITAL EX, DTS-ES DISCRETE 6.1, and DTS-EX MATRIX 6.1 operating

The modes are available only when your system has 6 or 7 channels.

When the device is configured, press the previous key (30) to return

to the

34 Krell S–1000

ASSIGN AUDIO INPUTS menu.

mation, see

eamp mode.

Decoding Modes for the

YOUR DECODE

System Configuration, continued

Step 2, Configure Devices

Assign Lip Synch Delay

Assign Lip Synch Delay Screen

The lip synchronization screen allows you to add an adjustable amount of delay, from 0 to 200 ms, to the digital audio signal decoding process.

LIP SYNC is used to synchronize a digital audio source

(DVD, satellite, or cable decoder) with a display (LCD, plasma TV, or projector), when the image is delayed by video processing in the display.

Select

DELAY

LIP SYNCH from the assign audio inputs screen. The LIP SYNCH

screen appears.

Use the direction and enter keys to scroll through and select the device you want to configure for lip synchronization. Make sure that the device is already configured for the digital audio source and display you intend to synchronize. Power on the source and display, and star

Select ef

t playing a pr

DELAY and the delay time (0-200 ms). Select APPLY to hear the

fect. Continue to adjust the delay time and use the

ogram.

APPL

function

until you are satisfied with the synchronization.

When the device is configured, press the previous key (30) to return

to the

Krell S–1000 35

ASSIGN AUDIO INPUTS menu.

System Configuration, continued

Step 2, Configure Devices

Assign EQ Memory

Assign EQ Memory Screen

The ASSIGN EQ MEMORY screen allows you to link any one of four EQ memories, or

OFF, to any one of 10 devices. Once a link is made, the

selected EQ memory loads automatically every time the device is chosen.

For more information on Room EQ, see pages 53-56.

Select EQ MEMORY from the assign audio inputs screen. The ASSIGN

EQ MEMORY screen appears.

Use the direction and enter keys to scroll through and select the device to which you want to assign EQ memory. Select EQ memory 1,2,3,or 4 or select

When the device is configur

return to the

HOW TO NAVIGATE

THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

3 Press the enter key (32) to select and

set an option. Use the dir

the next line.

5 Press the prev key (30) to return to the

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

ectional keys to scr

36 Krell S–1000

oll to

OFF.

ess the pr

ed, pr

CONFIGURE DEVICES menu.

evious key (30) twice to

System Configuration, continued

Step 2, Configure Devices

Configure Trigger

Configure Trigger Screen

The final option on the CONFIGURE DEVICES menu is CONFIGURE TRIGGER. This option allows you to customize the operation of the four remote output 12 VDC (12 Volt trigger) connectors (54) on the back panel.

Select

CONFIGURE TRIGGER screen appears:

CONFIGURE TRIGGER from the CONFIGURE DEVICES menu. The

Use the direction and enter keys to select the sour Select

SELECTIVE to configure triggers individually. The delay is only avail-

ALL TRIGGERS to configur

able when a trigger is set to after you select

f immediately when you select

ns of

tur

ALL TRIGGERS

ENABLED, before the trigger turns on. The trigger

e all triggers at once, or choose

ENABLED. Ther

e is a three second delay

DISABLED

ce device.

This option sets all 4 triggers on for all devices. When ALL TRIGGERS is active, the selected mode and delay applies to all four triggers.

When the device is configur

return to the

MAIN MENU.

ed, press the previous key (30) twice to

Krell S–1000 37

System Configuration, continued

Step 2, Configure Devices

Configuring Additional Inputs

For each of the other devices available to your system (CABLE, SAT,

VCR, TV, CD, TUNER, AUX, GAME,

Step 2, Configure Devices, pages 31-37. Configure each source

or TAPE/VCR2), follow the procedure outlined

device completely, before configuring the next source device.

When you have configured all the devices you want the S–1000 to recognize, press the previous button (74) twice to return to the main menu.

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

38 Krell S–1000

System Configuration, continued

Step 3, Configure Level Adjustment

STEP 3 CONFIGURE LEVEL ADJUSTMENT

Note

Configure Levels Screen

Use the third option on the main menu, CONFIGURE LEVEL ADJUSTMENT to set trims, adjust modes, and set the main volume limit.

Trims add a fixed positive or negative volume offset that allows you to compensate for devices with different volume levels. After adjusting the volume trim, you can easily switch between these inputs without changes in volume levels.

The master volume control has a numerical range from 0 to 152. Number 31 is the Dolby reference level. The center loudspeaker, surround loudspeakers, and subwoofer volume trims have a range of +/- 15 dB.

Select CONFIGURE LEVEL ADJUSTMENT from the main menu. The CONFIG-

URE LEVELS screen appears:

Krell S–1000 39

System Configuration, continued

Step 3, Configure Level Adjustment

Device Trim

Device Trim Screen

The DEVICE TRIM is a master volume trim that is activated when an input device is selected; it has a range of +/- 15 dB.

Select

DEVICE TRIM from the CONFIGURE LEVELS menu. The DEVICE TRIM

screen appears:

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

Use the direction and enter keys to select the devices for which you want to set trims, and the trim level for each.

When you have made your selections, press the previous key (30)

once to r

eturn to the

CONFIGURE LEVELS scr

een.

40 Krell S–1000

System Configuration, continued

Step 3, Configure Level Adjustment

IMPORTANT: PLEASE READ BEFORE CONFIGURING ANALOG INPUT TRIM

An analog device must be selected in order for the analog input trim option to function. The following screen appears if an analog device is not selected:

To select an analog device, first exit the menu program by pr

essing the menu key (29). Then press the analog device key [for example, the tape key (14 )] on the r

emote contr

ol. The front panel displays the device selection. Enter the menu program and follow the procedure for selecting analog input trim described on the next page.

Krell S–1000 41

System Configuration, continued

Step 3, Configure Level Adjustment

Analog Input Trim

nalog Input Trim Screen

Use the ANALOG INPUT TRIM menu to adjust the level of an analog input source to the S–1000.

Select

INPUT TRIM screen appears:

Use the dir or OFF) and the input gain decibel level. Kr anti-clip

ANALOG INPUT TRIM from the CONFIGURE LEVELS menu. The ANALOG

ection keys (75) to select the anti-clip option you want (

ell recommends leaving

ON.

ANTI-CLIP

The anti-clip function measures the signal level and prevents the input signal from overloading (clipping) the analog-to-digital converters.

OFF

Disengages the anti-clip function. This may result in distorted sound.

INPUT GAIN

Boost weaker signals by increasing the input gain value. Use the direction and enter keys to select the number of dB.

o maximize your system’

s signal-to-noise ratio without clipping, increase the input gain value applied to the signal until you see the clip indicator illuminate on the screen; then back the input gain value off one step. The optimal signal gain value will vary from source to

ce.

sour

After selecting the anti-clip and input gain options for your analog

devices, press the previous key (30) once to return to the

LEVELS menu.

42 Krell S–1000

CONFIGURE

System Configuration, continued

Step 3, Configure Level Adjustment

Music Mode Sub Trim Use the MUSIC MODE SUB TRIM menu to adjust the trim for the subwoofer,

during music mode playback. The adjustment range is -10 to +10 dB. Music mode sub trim is active when using the

FRONT ROW, ON STAGE, ENHANCED STEREO, ORCHESTRA, MEZZANINE, FULL RANGE +

and DTS NEO:6 modes.

SUB,

PARTY, GENERAL ADMISSION,

Select MUSIC MODE SUB TRIM from the CONFIGURE LEVELS menu. The MUSIC

MODE SUB TRIM screen appears:

Music Mode Sub Trim Screen

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

After setting the selection, pr

to the

CONFIGURE LEVELS menu scr

ess the pr

een.

evious key (30) once to retur

Krell S–1000 43

System Configuration, continued

Step 3, Configure Level Adjustment

DTS Control

DTS Control Screen

Use the DTS CONTROL menu to adjust the signal for DTS Neo:6 music mode. The center gain adjusts the amount of center channel information present in the left and right loudspeakers. The adjustment range is 0 (no center channel information subtracted (wide sound field) to 5 (maximum level of center channel information subtracted from the left and right channels (focused sound field).

Select

CONTROL

DTS CONTROL TRIM from the configure levels menu. The DTS

screen appears:

After setting the selection, press the previous key (30) once to return

CONFIGURE LEVELS screen.

e information on DTS Neo:6 Modes, see

User Selectable Modes on

Note

to the

DTS Neo:6 music mode derives a 6.0 signal from two-channel material. For mor page 61.

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

44 Krell S–1000

eturn to the

System Configuration, continued

Step 3, Configure Level Adjustment

PLII Control

PLII Control Screen

Use the PLII CONTROL menu to adjust the signal for Dolby Pro Logic II music mode, which derives a 5.0 signal from two-channel material.

DIMENSION

You can adjust the sound field toward the front or rear loudspeakers, to achieve a more suitable balance from all loudspeakers with certain recordings. The adjustment range is 0 (maximum surround) to 6 (center). The default setting is 3 (neutral).

CENTER WIDTH

You can adjust how much of the center output signal is spread to the left and right channel outputs. The adjustment range is from 0 (maximum center channel signal) to 7 (lowest signal; effectively mutes the center channel).

Select scr

PLII CONTROL from the CONFIGURE LEVELS menu. The PLII CONTROL

een appears:

After setting your selections, press the previous key (30) once to

return to the

Krell S–1000 45

CONFIGURE LEVELS screen.

System Configuration, continued

Step 3, Configure Level Adjustment

Maximum Volume Limit

Maximum Volume Limit Screen

Use the MAXIMUM VOLUME LIMIT menu to set the maximum volume for your system, from 0-152.

Select

MUM VOLUME LIMIT screen appears:

MAXIMUM VOLUME LIMIT from the CONFIGURE LEVELS menu. The MAXI-

After setting your selection, press the previous key once to return to

CONFIGURE LEVELS screen.

the

e Levels Adjust-

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

PrevPrev

When

MAXIMUM VOLUME LIMIT is set, Step 3, Configur

ment, is complete. Press the pr

MAIN MENU screen.

evious key (30) twice to return to the

46 Krell S–1000

System Configuration, continued

Step 4, Operation

STEP 4 OPERATION

Operation Screen

The final option on the main menu screen, OPERATION, lets you select position and display time for on-screen display (OSD), set audio operation, program a learning remote control, adjust lip synchronization, and adjust frequency response using the Krell Digital Room Equalizer.

Select OPERATION from the MAIN MENU. The OPERATION MENU screen appears, with the cursor blinking at

OSD OPERATION:

OSD Operation

OSD Operation Screen

Krell S–1000

ess enter to access the

OSD OPERATION scr

een:

System Configuration, continued

Step 4, Operation

OSD Operation, c

ontinued

Audio Operation

Audio Operation Screen

The on-screen display feature allows you to customize on-screen display options.

OSD ON TIME

Choose the number of seconds (0-10) that the on-screen display information remains on the screen.

LINE NUMBER

Choose the location (from 1, top line, to 10, bottom line) at which the on-screen display appears.

After setting your selections, press the previous key (30) once to

return to the

OPERATION menu.

The next item in the OPERATION menu, AUDIO OPERATION, allows you to customize audio operation such as mute, mode holds, auto-switching, and dynamic range.

Select

AUDIO OPERATION fr

om the

OPERATION menu. The AUDIO OPERATION

screen appears:

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

Use the direction and enter keys to scroll through and select options for audio operation:

MUTE MODE

The mute mode lets you select FULL mode in which the output is completely silenced or -20 dB in which the output is reduced by 20 dB and may still be audible.

–1000

ell

System Configuration, continued

Step 4, Operation

Audio Operation, c

ontinued

DOLBY MODE HOLD

Dolby mode hold sets the time your S–1000 remains in Dolby Digital mode when the incoming bitstream is interrupted. Bitstreams are interrupted in some devices when you press and release fast forward, track back/forward, or change channels for a compact disc, video disc, or satellite receiver. The adjustment range is 0 (no hold) to 30 seconds.

DTS MODE HOLD

DTS mode hold sets the time your S–1000 remains in DTS mode when the incoming bitstream is interrupted. Bitstreams are interrupted in some devices when you press and release fast forward, track back/forward, or change channels for a compact disc, video disc, or satellite receiver. The adjustment range is 0 (no hold) to 30 seconds.

EX AUTO SWITCHING

When ENABLED, the S–1000 will automatically engage Dolby Digital Surround EX decoding if it r this format. When this feature is

eceives a bitstream that is encoded in

DISABLED, you must manually select

Dolby Digital Surround EX decoding.

DYNAMIC RANGE

Use the dynamic range scr

een to adjust the dynamic range of the

S–1000. Options are:

NORMAL

11 dB of compr

MAX

ession

no compression

NIGHT

22 dB of compr

After setting your selections, press the previous key (30) once to

return to the

Krell S–1000 49

OPERATION menu.

ession

System Configuration, continued

Step 4, Operation

7.1 Input Setup

7.1 Input Setup Screen

7.1 INPUT SETUP menu allows you to select the 7.1 inputs that are

The connected.

Select

7.1 INPUT SETUP from the OPERATION menu. The 7.1 INPUT SETUP

screen appears:

HOW TO NAVIGATE IN THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

ess the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to r

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

eturn to the

ACTIVE INPUTS

Use the direction keys to find the input combination that matches your connections. Press enter to set the selection.

ACTIVE SW

Select YES if subwoofer is present and NO if it is not.

After setting your selections, pr

n to the

etur

OPERA

TION

ess the pr

menu.

evious key (30) once to

50 Krell S –1000

System Configuration, continued

Step 4, Operation

Program Remote

Note

ogram Remote Screen A

The PROGRAM REMOTE menu allows you to program a learning remote control to operate the S–1000.

The infrared sensor on the front panel is inactive until programming is complete.

Select PROGRAM REMOTE from the OPERATION menu. The first PROGRAM

REMOTE screen appears:

After you select START, the second PROGRAM REMOTE screen appears:

Program Remote Screen B

Krell S–1000 51

System Configuration, continued

Step 4, Operation

Program Remote,

ontinued

System Information

1. Rotate the knob (26) on the front panel to select a command.

The command appears on the front panel display window (20).

2. Place the programmable remote in program mode (see the learn-

ing remote user manual).

3. Place the infrared sensor of the programmable remote so that it

faces the infrared emitter (4) on the S–1000 front panel.

4. Press and hold the save button (25) on the S–1000 front panel

until the programmable remote has learned the code (see the learning remote user manual for information on the time needed to learn the code).

5. Select and save as many commands as desired.

6. To exit the program mode, press the recall button (27) on the

front panel to revert to Program Remote Screen A from Program

rev

Remote Screen B. Press the previous button (30) to return to the operation menu from Program Remote Screen A.

The

SYSTEM INFORMATION menu displays AC line fr

of softwar about the

e that your component is currently using, and infor

EEPROM.

equency, the version

mation

System Information Screen

Select SYSTEM INFORMATION from the OPERATION menu. The SYSTEM INFOR-

MATION screen appears:

After reviewing the system information screen, press the previ-

n to the operation menu.

ous key (30) once to r

etur

52 Krell S–1000

System Configuration, continued

Step 4, Operation

IMPORTANT: PLEASE READ BEFORE CONFIGURING ROOM EQ SETUP

The Room EQ Setup accesses the Digital Room Equalizer, a feature designed by Krell to provide every adjustment from simple bass and treble to comprehensive room correction. The Digital Room Equalizer enables you to adjust frequency response through three discrete bands (I, II, and III). The four adjustable parameters available are filter type, frequency, shape, and level.

There are four Room EQ setup memories, each of which saves every parameter set for every filter, for every channel. Each setup memory can save a configuration, for example, one for stereo music, one for multichannel music, one for movie surround, and one for video game software.

You can adjust the filters for S–1000 channels globally or individually. Up to three filters can be configured to act equally on all seven channels of audio. Alternatively, each filter can be configured separately for each individual channel.

ADJUSTABLE PARAMETERS

HOW TO NAVIGATE

THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

3 Press the enter key (32) to select and

set an option. Use the dir

the next line.

5 Press the prev key (30) to return to the

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

ectional keys to scr

oll to

TYPE

Six filter types are available for each filter: Notch Filter, Peaking Filter, High Shelf Filter, Low Shelf Filter

, High Pass Filter (HPF) and Low Pass Filter (LPF). Each of the filter types available has a unique effect on frequency response.

The following thr

ee parameters for filters may be configured,

depending on the filter type selected:

FREQ

The center/cutoff frequency can be specified for all six filter types,

om 20 Hz to 16 kHz in 1/3 octave increments.

SHAPE

Shape controls the bandwidth of the filter and is adjustable on the Notch and Peaking filter types, from 0.4 to 9 octaves. Shape is fixed at a 6 dB / octave slope for the High and Low Pass Filters. This parameter is not available for the High and Low Shelf Filters.

LEVEL

Level is adjustable on the Peaking, High Shelf and Low Shelf filters, from -12 dB to +6 dB. Level is fixed for the Notch Filter at - 90 dB. This parameter is not available for the High and Low Pass Filters.

Krell S–1000 53

System Configuration, continued

Step 4, Operation

CHANNEL SELECTION

IMPORTANT

APPLYING YOUR CONFIGURATIONS

SAVING ROOM EQ SETUP MEMORY

When the channel field is set to ALL, the ROOM EQ SETUP menu displays the filter settings which apply to all channels and all of the channels are filtered in the same manner. When the channel parameter selection is set to only one of the channels (L, C, R, LS, RS, LB, RB, S), the filter settings apply to each of the channels individually.

The selection ALL overrides individually configured channels.

Your configurations take effect only when you press enter in the

APPLY field. APPLY allows you to hear the effect of the selections you

have made without leaving the menu, if you have a source device playing.

e are four selectable memories associated with the

Ther

SETUP menu. Values are saved automatically when you enter a selec-

ROOM EQ

tion.

Room EQ settings ar

e stored in the

S–1000 memory in the same manner as all of the other software settings, for example the selections for loudspeaker setup and device configuration.

See Saving and Recalling Customized Settings and Restoring the Factory Default System Settings,

on page 57, for more information.

USING ROOM EQ SETUP IN THE OPERATIONAL MODE

HOW TO NAVIGATE IN THE MENU MODE

1 Press the menu key (29) to enter and

exit the menu mode from the operational mode. Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

3 Press the enter key (32) to select and

set an option.

4 Use the directional keys to scroll to

the next line.

5 Press the prev key (30) to return to the

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

When the S–1000 is in the operational mode, access the saved EQ configurations by pressing the right dir

ectional key (33) on the remote. Use the up and down directional keys (26) to scan through the four memories and

OFF.

54 Krell S–1000

System Configuration, continued

Step 4, Operation

Room EQ Setup The final item on the OPERATION menu, ROOM EQ SETUP, allows you to

adjust your loudspeaker to your listening area using the Krell Digital Room Equalizer. Select

ROOM EQ SETUP screen appears, with the cursor blinking at OFF:

Room EQ Setup Screen

ROOM EQ SETUP from the OPERATION menu. The

IMPORTANT

Use the direction and enter keys on the S–1000 remote control to

oll through and select the following step-by-step options for

scr audio operation:

MEMORY

Navigate to one of the four memory locations and enter your selection. When

e disabled.

CHANNEL

MEMORY is set to OFF (the factory default), all of the filters

Navigate to CHANNEL and select ALL to apply your configurations to all channels at once or select any individual channel to apply your configurations to that channel. Enter your selection.

The selection ALL overrides individually configured channels.

Krell S–1000 55

System Configuration, continued

Step 4, Operation

oom EQ Setup

ontinued

TYPE

Navigate to TYPE, and configure one, two, or all of the three bands (I, II, III) for

FREQ, SHAPE, and LEVEL.

Note

It is not necessary to configure all three filters, you may configure only one or two filters.

Not all parameters are adjustable for all filter types.

APPLY

Select APPLY and set the selection, if you want to hear your configuration. The Room EQ Setup configurations you have just selected audible if you have a source device playing.

After selecting the appropriate loudspeaker configuration for your

rev

system, press the previous key (30) twice to return to the main configuration menu.

Exit the main configuration menu by pressing the menu key (29) on

the remote. The S–1000 is now in the operational mode.

HOW TO NAVIGATE

THE MENU MODE

ess the menu key (29) to enter and

exit the menu mode from the operational mode.

2 Press the direction keys (33) to scroll

from line to line, and to scroll through options within a line.

3 Press the enter key (32) to select and

set an option. Use the dir

the next line.

5 Press the prev key (30) to return to the

previous screen.

6 Press the pre key (1) to exit the menu

mode and place the S–1000 in the stand-by mode.

ectional keys to scr

oll to

56 Krell S–1000

Saving and Recalling Customized Settings and Restoring the Factory Default System Settings

SAVING CUSTOMIZED SETTINGS

RECALLING CUSTOMIZED SETTINGS

RESTORING THE FACTORY DEFAULT SYSTEM SETTINGS

To save the customized settings that you have entered, press and hold the save button (25) for approximately four seconds. The front panel displays

SAVING SETUP while the settings are being stored in the

nonvolatile memory of the S–1000 Surround Preamp/processor.

To retrieve your system’s saved settings, press and hold the recall button (27) for approximately four seconds. The front panel displays

RECALL SETUP while the settings are being retrieved from the non-

volatile memory of the S–1000. Any settings that have been saved will be available through recalling system setup.

To replace all system settings with the factory default settings, follow these steps:

1. Press the front panel power button or power pre key (1) to put

your system into the operational mode.

2. Simultaneously press the recall button (27) and the power button or

e key (1). The fr

RECALL SETUP

and then the fr

S–1000 VERSION 1.0 60 HZ

ont panel first displays:

ont panel displays:

Customized settings for the S–1000 revert to the factory default settings.

Note

Krell S-1000 57

If you save your settings, they are still in memory after you restore the factory default system settings. Follow Recalling Customized Settings above to

etrieve your customized settings.

Operating the S–1000

ON/OFF/STAND-BY

After the S–1000 Surround Preamp/Processor is connected to source devices and amplifiers, and the system setup configured, the S–1000 is ready for operation.

1. Insert the AC power cord into the IEC connector (59) on the

S–1000. Insert the other end into the AC wall receptacle.

2. Move the back panel power switch (58) into the up (on) position.

3. The red stand-by LED on the front panel illuminates. The words

LEASE WAIT, INITIALIZING

the initializing message disappears, the

appear in the front panel display (20). When

S–1000 is ready to be

powered on.

The front panel display shows volume, input information, and selected mode. After five seconds of inactivity, the display becomes blank.

4. Use either the front panel power button or power pre key (1) to

power on the S–1000. The blue power LED (2) on the fr

ont

panel illuminates. The S–1000 is now in the operational mode.

5. To return to stand-by, pr

ess the front panel power button or

power pre key again.

Note

TAPE INPUT AND OUTPUT

Krell recommends that the back panel power switch remain up (on) at all

times

S–1000 has a discrete tape input and output. The tape output

The is used to send an input signal fr (S-1 thr

ough S-7, B-1, or VCR) to a recording device or processor.

om any analog input

You can use the tape feature in three ways:

Use the tape input to playback pr

e-r

ded tapes.

ecor

2. Use the tape input to compare the output signal of a three-head

analog tape recorder to the output signal of an audio source. Press the tape button or key (14) to switch between the tape

der output (LED illuminated) and the input sour

ecor

ce (LED not

illuminated).

58 Krell S-1000

Operating the S–1000, continued

Tape Input and Output,

ontinued

Notes

SIMULCAST

3. Use the tape output to create a processor loop, when the S–1000

is connected to a graphic equalizer or other ancillary equipment. Connect the equipment to the S–1000 tape outputs (34) as described in the equipment manufacturer’s manual. Press the tape button (15) or key (64) to switch between the processor output (LED illuminated) and the input source (LED not illuminated).

The tape output functions only with analog sources.

There is no tape output from the 7.1 multi-channel input.

When changing sources, lower the volume to off or mute the output. This ensures that the next source played does not damage your system with a high output transient.

When you are listening to or viewing different devices that have different trigger settings (configured through the setup menus), you can retain a trigger setting using the previous (30) key.

For example, you have configured the S–1000 to turn on the TV monitor when trigger 4 is on and the CD player is set for TRIGGER 4

OFF. You want to watch TV and listen to a CD at the same time. If

you press the TV button or key followed by the CD button or key, the TV monitor will turn off.

To keep the monitor on and turn on the CD player, follow these steps:

1. Press the TV button or key (9) to select the device. Begin playing

the device.

ess the pr

ess the CD button or key (10). Begin playing the device.

ev key (30).

Krell S–1000 59

Appendix: Decoding Modes for the S–1000

AUTOMATICALLY DETECTED MODES

The S–1000 Surround Preamp/processor automatically engages the appropriate decoding mode for the following signals:

DOLBY DIGITAL 2.0 OR DOLBY DIGITAL 2.0 + DOLBY PRO LOGIC

Select a Dolby Digital 2.0 or Dolby Digital 2.0 + Dolby Pro Logic default mode using the configuration menu. All modes listed under Dolby Digital 2.0, including the default mode you have selected, can be accessed using the mode 2 button or M2 key (17).

DOLBY DIGITAL 5.1

Select a Dolby Digital 5.1 default mode using the configuration menu. All modes listed under Dolby Digital 5.1, including the default mode you have selected, can be accessed using mode 2 button or M2 key (17). .

DOLBY DIGITAL EX

Dolby Digital EX creates six full-bandwidth output channels from

5.1-channel sources. This is done using a matrix decoder that derives thr

ee surround channels fr ing. For best r soundtracks r

esults, Dolby Digital EX should be used with movie

ecorded with Dolby Digital Surround EX. All modes list-

om the two in the original record-

ed under Dolby Digital EX, including the default mode you have selected, can be accessed using the mode 2 button or M2 key (17).

Note

DTS 5.1

Select a DTS 5.1 default mode using the configuration menu. All modes listed under DTS 5.1, including the default mode you have selected, can be accessed using the mode 2 button or M2 key (17).

DTS-ES DISCRETE 6.1

The S–1000 engages DTS-ES Discrete 6.1 decoding. All of the following modes, plus mode 2 button or M2 key (17) :

5.1 MUSIC.

DTS-ES MA

TRIX 6.1

DTS-ES DISCRETE 6.1 can be accessed using the

DTS-ES MATRIX 6.1, DTS 5.1 MOVIE, and DTS

The S–1000 engages DTS ES Matrix 6.1 decoding. The following modes plus ton or M2 key (17):

The DOLBY DIGITAL EX, DOLBY D 5.1, DTS-ES DISCRETE 6.1, and DTS-EX MATRIX 6.1 operating modes are available only when your system has 6 or 7 channels.

DTS-ES MATRIX 6.1 can be accessed using the mode 2 but-

DTS 5.1 MOVIE and DTS 5.1 MUSIC.

60 Krell S–1000

Appendix: Additional Decoding Modes for the S–1000, continued

USER SELECTABLE MODES

Dolby Pro Logic II Modes

User selectable modes available on the S–1000 are listed below:

Dolby Pro Logic II is the next generation in Dolby Surround decoding. The Pro Logic II decoder takes 2 channels in and 5 channels out. It is designed specifically to decode all existing Dolby Surround programs with improved spatiality and directionality. Pro Logic II is also designed for use with stereo music recordings that are not encoded. This feature draws the listener into a three-dimensional space rather than hearing a flat, two-dimensional presentation.

There are 4 modes in which the Pro Logic II decoder can operate:

DOLBY PLII MOVIE

The movie mode is the improved counterpart to the original Pro Logic decoder. It is the choice for the majority of Dolby Surround encoded material.

DOLBY PLII MUSIC

The music mode is for use with unencoded stereo music recordings. The music mode features dimension and center width controls, see

PLII Contr

DOLBY PLII MATRIx

ol,

on page 45, to enhance the music sur

round experience.

The matrix mode is useful for monaural recordings.

DTS Neo:6 Modes

DOLBY PRO LOGIC

The Dolby Pro Logic mode provides the same surround processing as the original Pr

o Logic and is best used with sour

ce content that is

not of optimum quality.

DTS Neo:6 pr

ovides up to six full-bandwidth channels of information from stereo encoded material. 7.1 and 6.1 systems will derive six channels from the signal while 5.1 systems will derive five channels from the signal. DTS Neo:6 includes two modes: two channel matrixed movie material and

DTS NEO:6 MUSIC for stereo

DTS NEO:6 CINEMA for

encoded music material.

Krell S–1000 61

Appendix: Additional Decoding Modes for the S–1000, continued

Krell Music Surround Modes

TABLE 6 Krell Music Surround Modes

or the S–1000

Krell Music Surround Modes simulate different soundfield experiences when listening to music. The table below lists the modes and the loudspeakers that operate within each mode:

OPERATING MODES ACTIVE LOUDSPEAKERS

GENERAL ADMISSION L/R/S/RR

FRONT ROW L/R/S/RR

ON STAGE L/R/C/S/RR

ENHANCED STEREO L/R/C/S

ORCHESTRA L/R/C/S/RR

MEZZANINE L/R/C/S/RR

FULL RANGE + SUB L/R/C/S/RR

MONOPHONIC C/S

PARTY L/R/C/S/RR

62 Krell S –1000

Warranty

To register your product for warranty benefits, please

omplete and return the

c Warranty Registration Card enclosed in the shipping box

ithin 15 days of purchase.

Thank you.

Krell products have a limited warranty. Amplifiers, preamplifiers, preamp/ processors, and receivers carry a limited warranty of five years for parts and labor on circuitry. Loudspeakers carry a limited warranty of five years for parts and labor. CD and DVD players carry a limited warranty of five years for parts and labor on circuitry, and three years for parts and labor on mechanical parts.

Should the product fail to perform at any time during the warranty, Krell will repair it at no cost to the owner, except as set forth in this warranty.

This warranty does not apply to damage caused by acts of God or nature.

This warranty shall be in lieu of any other warranty, expressed or implied, including, but not limited to, any implied warranty of merchantability or fitness for a particular purpose. There are no warranties which exceed beyond those described in this document, if

oduct does not perform as war

the pr remedy shall be repair. In no event will Kr

ranted herein, the owner’s sole

ell be liable for incidental or consequential damages arising from purchase, use, or inability to use the product, even if Krell has been advised of the possibility of such damages.

Proof of purchase in the form of a bill of sale or receipted invoice substantiating that the product is within the warranty period must be presented to obtain warranty service. The warranty begins on the date of the original retail purchase, as noted on the bill of sale or receipted invoice from an authorized Krell dealer or distributor. Previously owned equipment, when re-purchased from an authorized Krell dealer or distributor, has the balance of the original war-

ell dealers and

, based on the original date of manufactur

ranty

e. Kr distributors are not authorized to sell current products on the Internet. Current products purchased via the Internet do not have any transferrable warranty.

The warranty for a Krell product is valid only in the country to which it was originally shipped, through the authorized Krell distributor for that countr

, and at the factor

. Ther

e may be r

estrictions on or changes to Krell’s warranty because of regulations within a specific country. Please check with your distributor for a complete under-

standing of the war

ranty in your countr

If the product is serviced by a distributor who did not import the unit, ther

e may be a char

ge for service, even if the product is within

the warranty period.

Krell S–1000 63

Warranty, continued

Freight to the factory is your responsibility. Return freight within the United States (U.S.A.) is included in the warranty. If you have purchased your Krell product outside the U.S.A. and wish to have it serviced at the factory, all freight and associated charges to the factory are your responsibility. Krell will pay return freight to the U.S.A.based freight forwarder of your choice. Freight and other charges to ship the product from the freight forwarder to you are also your responsibility.

Krell is not responsible for any damage incurred in transit. Krell will file claims for damages as necessary for a product damaged in transit to the factory. You are responsible for filing claims for shipping damages during the return shipment.

Krell does not supply replacement parts and/or products to the owner of the product. Replacement parts and/or products will be

nished only to the distributor per

fur on an exchange basis only; any par

forming ser

vice on this pr

ts and/or products returned to

oduct

Krell for exchange become the property of Krell.

No expressed or implied warranty is made for any Krell product damaged by accident, abuse, misuse, natural or personal disaster, or unauthorized modification.

Any unauthorized voltage conversion, disassembly, component replacement, perforation of chassis, updates, or modifications performed to the product will void the warranty.

The operating voltage of the pr

oduct is deter

mined by the factory and can only be changed by an authorized Krell distributor or at the factory. The voltage for this product in the U.S.A. cannot be changed until six months from the original purchase date.

In the event that Krell receives a product for warranty service that has been modified in any way without Krell authorization, all warranties on that pr

oduct will be void. The pr

oduct will be r

eturned to original factory layout specifications at the owner’s expense before it is repaired. All repairs required after the product has been returned to original factory specifications will be charged to the customer, at current parts and labor rates.

All operational features, functions, and specifications and policies are subject to change without notification.

Krell S–1000

Return Authorization Procedure

HOW TO EXPEDITE SERVICE

ACCESSING THE SERVICE REQUEST FORM

CONTACT THE

TO KRELL SERVICE DEPARTMENT

HOW TO RETURN A PRODUCT

If you believe there is a problem with your component, please contact your dealer, distributor, or the Krell factory to discuss the problem

before you return the component for repair. To expedite service, you may wish to complete and e-mail the Service Request Form in the Service section of our website.

Simply click on the Service Request Form in the navigation tier on the Krell home page at http://www.krellonline.com

TEL 203-298-4020

Monday-Friday, 9:00 am to 5:00 pm EST FAX 203-795-2287 E-MAIL service@krellonline.com WEBSITE

http://www.krellonline.com

To return a product to Krell, please follow this procedure so that we may serve you better:

1. Obtain a Return Authorization Number (R/A number) and shipping address from the Krell website.

2. Insure and accept all liability for loss or damage to the product during shipment to the Krell factory and ensure all freight (ship-

e prepaid.

ping) char

ges ar

The product may also be hand delivered if arrangements with the

vice Department have been made in advance. Proof of purchase

Ser will be required for warranty validation at the time of hand delivery.

IMPORTANT

HOW TO PURCHASE ADDITIONAL P

ACKING

SERIAL NUMBER

Krell S–1000 65

Use the original packaging to ensur the factory, dealer, or distributor. Krell may, at its discretion, return a product in new packaging and bill the owner for such packaging if the product received by Krell was boxed in nonstandard packaging or if the original packaging was so damaged that it was unuseable. If Krell determines that new packaging is required, the owner will be notified before the product is returned.

o purchase additional packaging, please contact your authorized

Krell dealer, distributor, or the Krell Service Department.

Your S–1000 Surround Preamp/processor product serial number is:

e the safe transit of the product to

Specifications

SIGNAL-TO-NOISE RATIO

OTAL HARMONIC

ISTORTION (THD

)

INPUTS

OUTPUTS

"A" WEIGHTED 94 dB

NWEIGHTED 20 Hz-20 kHz, -88 dB

ANALOG AUDIO 1 pair balanced via XLR connectors

7 pairs single-ended via RCA connectors 8 7.1 via RCA connectors

DIGITAL AUDIO 4 coaxial via RCA connectors

4 EIAJ optical via TosLink connectors

VIDEO 4 S-video via DIN connectors

4 composite via RCA connectors 3 component via RCA connector

ANALOG TAPE 2 pair single-ended via RCA connectors

HDMI

4 via

HDMI

connectors

ANALOG CHANNEL 8 balanced via XLR connectors (one per channel) 8 single-ended via RCA connectors

ANALOG TAPE 1 pair single-ended via RCA connectors

DIGITAL 1 coaxial via RCA connector

1 EIAJ optical via TosLink connectors

VIDEO 2 S-video via DIN connector, 1 with OSD

2 composite via RCA connectors, 1 with OSD 1 component via RCA connectors with OSD

HDMI

1 via

HDMI

connectors

REMOTE CONTROL 1 infrared

REMOTE CONNECTORS

REMOTE

1 RS-232 1 RC-5 input 4 12 VDC OUT (12 V trigger) 1 12 VDC IN (12 V trigger)

Dolby Pro Logic II Dolby Digital 5.1

DECODING MODES

Dolby Digital EX DTS 5.1 DTS ES Discrete 6.1 DTS ES Matrix 6.1 DTS Neo:6

66 Krell S –1000

Specifications, continued

SURROUND ENHANCEMENT MODES

POWER CONSUMPTION

DIMENSIONS

WEIGHT

KRELL MUSIC SURROUND General Admission

ront Row

F On Stage Enhanced Stereo

rchestra

O Mezzanine Full Range + Sub Monophonic Party

35 W

INCHES 17.3w x 5.7h x 16.5d

CENTIMETERS 43.8w x 14.4h x 41.8d

SHIPPING 25 lb. 11.3 kg

UNIT ONLY 19.3 lb. 8.8 kg

All operational features, functions, specifications, and policies are subject to change without notification.

Krell S–1000 67

rell Industries, Inc.

K 45 Connair Road Orange, CT 06477-3650 USA

TEL 203-298-4000 FAX 203-891-2028 E-MAIL krell@krellonline.com WEBSITE http://www.krellonline.com

–1000

SURROUND PREAMP/PROCESSOR

v 07.0

Krell Industries S-1000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
