Krell Industries Evolution User Manual

EVOLUTION
EVOLUTION AMPLIFIERS
302 AND 402 STEREO
403 THREE-CHANNEL
600 AND 900 MONAURAL
OWNER’S REFERENCE
Evolution 302, 402, 403, 600 and 900 Power Amplifiers O
TEL 203-298-4000 Krell Industries, Inc. 45 Connair Road Orange, CT 06477-3650 USA
FAX 203-891-2028
E-MAIL sales@krellonline.com
WEBSITE http://www.krellonline.com
This product complies with the EMC directive (89/336/EEC) and the low-voltage directive (73/23/EEC).
IMPORTANT SAFETY INSTRUCTIONS
1. Read Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all Instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-
ratus (including amplifiers) that produce heat.
8. Unplug this apparatus during lightning storms or when unused for long periods of time.
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
10. An Evolution amplifier must be placed on a firm, level surface where it is not exposed to drip-
ping or splashing.
11. The ventilation grids on the top of every Evolution amplifier, the ventilation grids on the back of
the Evolution 302 amplifier, and the space underneath every Evolution amplifier must be unob­structed at all times during operation. Do not place flammable material above or beneath an Evolution amplifier
12. Before making connections to an Evolution amplifier, ensure that the power is off and other com-
ponents are in mute or stand-by mode. Make sure all cable terminations are of the highest quali-
om frayed ends, shor
ee fr
, fr
ty
13. THERE ARE NO USER SERVICEABLE PARTS INSIDE AN EVOLUTION AMPLIFIER.
Please contact Krell if you have questions not addressed in this guide.
.
t circuits, or cold solder joints.
This pr
oduct is manufactured in the United States of America. Krell Krell Industries, Inc., its subsidiaries, and authorized agents. CAST Industries, Inc. All other trademarks are registered to their respective companies.
© 2007 by Kr
ell Industries, Inc. All rights reserved P/N 309888
®
is a r
egistered trademark of Krell Industries, Inc., and is restricted for use by
™, Evolution CAST™, and Krell Current Modeare trademarks of Krell
Contents
List of Illustrations, page 4
A Letter from Dan D’Agostino, page 5
SECTION ONE: Evolution Amplifier Features and Technology, page 6
es, Revolutionary Krell CAST Technology,
Featur Definition of T
erms
SECTION
SECTION THREE: Anatomy of the Evolution Amplifier, page 13
SECTION FOUR: Connecting an Evolution Amplifier to Your System, page 21
SECTION FIVE: Evolution Amplifier Operation, page 23
SECTION SIX: Troubleshooting System Noise, page 24
SECTION SEVEN: Questions and Answers, page 26
ARRANTY
W
RETURN AUTHORIZATION PROCEDURE, page 29
TWO: Unpacking and Placement, page 11
Opening the Evolution Amplifier Shipping Carton
Front Panel Description, and Back Panel Description
CAST Connections, Balanced Connections, Single-ended Connections, Evolution DC Protection Circuitry/Using Tube Preamplifiers, Connection Steps
On/Off and Stand-by Operation
How to Evaluate Amplifier Operation, Error Codes
, page 27
SPECIFICATIONS, page 30
3
List of Illustrations
Figure 1, page 13
Evolution Amplifier Front Panel
Figure 2, page 15
Evolution 302 Back Panel
Figure 3, page 16
Evolution 402 Back Panel
Figure 4, page 17
Evolution 403 Back Panel
e 5, page 18
Figur
Evolution Monaural Amplifier Back Panel
4
A Letter from Dan D’Agostino
Dear Audio Enthusiast,
Thank you for your purchase of a Krell Evolution Series amplifier.
Evolution Series amplifiers continue my quest for amplifiers that deliver absolute truth in music reproduction. These four new models utilize Active Cascode Topology, a unique circuit technique that minimizes distortion by applying from 2 to 3 times more active devices to each gain stage. Evolution Series amplifiers bring the real-life dynamics and transparency for which Krell is famous, to a whole new level.
Krell amplifiers are best known for their ability to drive any loudspeaker to sound its best, without regard to impedance or efficiency. I believe that linearity, an amplifier measure of that amplifier’s work. At Krell, I drive amplifier designs toward the com­mon goal of linearity, through the rigorous application of Krell design principles that focus our efforts on four major performance factors: distortion, bandwidth, output impedance, and current capability synthesis of these factors.
’s ability to output an exact duplicate of the input signal, is the ultimate
. The Evolution Series amplifiers are a
The Evolution Series amplifiers use Evolution CAST technology
mance and ver
for
I hope that you enjoy your new Evolution Series amplifier.
Sincerely,
Daniel D’Agostino
Chief Executive Officer
y low noise.
5
, for superior per
-
SECTION ONE
Evolution Amplifier Features and Technology
This section describes the innovative features and technology of the Evolution Series amplifiers, and defines CAST and other key terms used in this reference. There are five amplifier models in the Evolution Series: the 302 Stereo Power Amplifier, the 402 Stereo Power Amplifier, the 403 Three-channel Power Amplifier, the 600 Monaural Power Amplifier, and the 900 Monaural Power Amplifier.
Features
Evolution Series amplifiers are designed with a signal path that incorporates Krell Current Mode and CAST circuitry.
All amplifiers feature massive power supplies. The power supply makes use of extensive electrical and magnetic shielding to keep radiated interference out of critical amplifier circuits.
The Evolution 302 design utilizes a 3000 VA power supply. The Evolution 402 and Evolution 600 are equipped with a 5000 VA power supply, and the Evolution 403 and Evolution 900 house 6000 VA power supplies.
nal high-current line conditioning circuitry filters RF noise on the AC mains, as
Inter well as compensating for asymmetrical power waveforms and DC on the mains.
Advanced microprocessor control monitors critical operational parameters. Output current, DC offset, rail voltages, and operating temperature are all continuously monitored.
6
Revolutionary Krell CAST Technology
Current Audio Signal Transmission, termed CAST, is a revolutionary method of connecting analog audio components for unparalleled sonic performance. Innovative engineering combines the new Krell CAST circuitry with existing Krell Current Mode technology to create entire CAST systems that reproduce music with incredible range, tonality, and precision.
The Voltage Signal Transmission and the Traditional Audio System
Traditionally, signal is transmitted in the voltage domain between two components. In an audio system, each component is a discrete entity with unique characteris­tics that act upon the musical signal independently. Each component is unaware of the other components in the system. The cables that connect the components also have their own electrical characteristics, which affect the sonic presentation of the entire system. CAST transmission unifies individual components and inter­connects into an electrically-linked whole. The original signal remains unaltered from sour
CAST Basics
ce to speaker.
Here is how a CAST audio system works. Internally, each CAST source transfers, or amplifies, current using Krell Current Mode circuitry. This current signal is then output using CAST circuitry. When the signal is received by a CAST input, Krell
y again takes over until the signal r
ent Mode cir
r
Cur By maintaining the musical signal in the cur entire CAST system behaves as if it is one component. With CAST, circuit board
ties and signal transmission aber
oper
pr ed. Cable impedances and their ef
cuitr
ent domain fr
r
rations between components ar
fects on the transmitted signal ar
eaches the loudspeaker.
om beginning to end, an
e eliminat
e non-existent.
How CAST and Krell Current Mode Interact
While CAST is a new method of transferring the musical signal between compo­nents, its origin stems from Krell Current Mode, the technology developed to transfer the musical signal within a component. CAST combined with Krell Current Mode circuitry takes signal transmission to the next evolutionary level. In essence,
-
d
7
continue
(SECTION ONE: Evolution Amplifier Features and Technology continued)
Krell Current Mode maintains the integrity of the signal within the component and CAST preserves the transmitted signal between components. Together, CAST and Krell Current Mode technologies unify separate Krell components into a
global circuit.
Krell Current Mode technology enjoys bandwidth increases up to an order of magnitude greater than their voltage based counterparts. This dramatic increase in circuit bandwidth delivers near perfection in the audible band that typi­cally suffers from phase distortions in voltage circuits.
CAST Cable Construction
A CAST system uses cables manufactured by Krell and other manufacturers spe­cially licensed by Krell. Thin and flexible CAST cables ar same build quality as other Krell components and are aesthetically matched to the components that Krell manufactures. An all-metal body and locking connectors with gold contacts ar
e part of the standard no-compromise specification devel-
oped for every CAST cable made.
Evolution CAST
single
e constructed with the
By employing revolutionary current mirror circuitry, the Evolution amplifier compo­nents raises CAST technology to another level. This advanced use of the technol­ogy increases the linearity, transient speed, and bandwidth of the Evolution com­ponents while reducing the distor
tion by an order of magnitude.
The Best Musical Performance
When you operate a CAST system, you will hear significant impr per
mance ar
for
ea: speed, pr
stage, transient impact, tonal balance, har
ecision, dynamic range, depth and width of the sound
monic distor
tion, and mor
CAST is the same company goal used for all Krell products. Krell strives for the
mance of a musical event for you, using the full expr
y of the best per
deliver
for
sion of technology to date.
ovements in every
e. The goal for
es
-
8
Definition of Terms
The following are definitions of key terms used in this owner’s reference:
Inputs and Outputs
Balanced
A symmetrical input or output circuit that has equal impedance from both input terminals to a common ground reference point. The industry standard for profes­sional and sound r gain than single-ended connections and allow the use of long interconnect cables. Balanced connections ar or the environment.
CAST and Evolution CAST
Krell Current Audio Signal Transmission, or CAST, is a proprietary Krell circuit tech­nology for connecting analog components, transmitting the audio waveform between components in the current domain rather than in the voltage domain. The speed and bandwidth pr CAST, yield accurate, realistic music r nents to perform as if they are all part of a single circuit. CAST and Evolution CAST are balanced connections, and reject induced noise.
ecording installations, balanced connections have 6 dB more
e completely immune to induced noise from the system
ovided by Krell CAST and its circuitry update, Evolution
eproduction, enabling connected compo-
Single-ended
A two-wire input or output circuit. Single-ended connections are not recommend­ed for connections requiring long cable runs. Use care when using single-ended connections, because the ground connection is made last and broken first. Turn the system off/on prior to making or breaking single-ended connections.
Operation
Off
When the power status indicator is not illuminated, the amplifier is of
Stand-by
A low-power-consumption status that keeps the audio and power supply circuits at idle. The power status indicator is illuminated in red, when the amplifier is in stand-by mode. Krell recommends leaving the amplifier in stand-by mode when it is not playing music.
Operation
When the power button is pressed, and the power status indicator is illuminated in blue, the amplifier is in operational mode and ready to play music.
f.
d
9
continue
(SECTION ONE: Definition of Terms continued)
Technology
Active Cascode Topology
A unique circuit technique that minimizes distortion by applying from 2 to 3 times more active devices to each gain stage thereby reducing the load on individual devices and improving circuit-wide linearity.
Krell Current Mode
A proprietary Krell circuit topology in which the audio gain stages of a component operate in the current domain rather than the voltage domain. This unique technol­ogy provides the component with exceptional speed, and a wide bandwidth.
10
SECTIONTWO
Unpacking and Placement
This section describes the procedures for safely unpacking and placing your Evolution amplifier. The amplifier and accessories are shipped in 1 carton. The dimensions of the amplifier are shown in the specifications section starting on page 30.
wo people are needed to remove the Evolution amplifier from its shipping box
T safely and easily.
Opening the Evolution Amplifier Shipping Carton
1. Open the shipping carton and remove the top layer of foam. The carton con-
tains these items:
1 Evolution amplifier chassis 1 20 amp AC power cord 1 12 VDC (12 V trigger) cable 1 Packet containing the Quick Setup Guide and the warranty registration card
2. Orient the shipping box so that one person stands at the front of the amplifier
and one person stands at the back of the amplifier. Both people need to grab a pair of the cardboard handle cutouts (one pair located at the front of the amplifier and one pair located at the back of the amplifier) and simultaneously lift the amplifier straight up, out of the car not your back.
ton. Bend and lift with your knees,
3. Place the amplifier in a safe location, and remove the protective plastic wrap-
ping.
ote
N
Save all packing materials. If you need to ship the Evolution amplifier in future, repack the unit in its original packaging to prevent shipping damage.
11
continue
d
(SECTION TWO: Unpacking and Placement continued)
Placement
Before you install an Evolution amplifier into your system, please follow the guide­lines in this section to select a location for your component. This will facilitate a clean, trouble-free installation.
Place the amplifier on a firm, level surface, away from excessive heat, humidity, or moisture. Each Evolution amplifier requires at least two inches (5 cm) of clearance on each side and at least eight inches (20 cm) of clearance above the component to provide adequate ventilation.
If you place the amplifier in a closed cabinet, you may need to modify shelf spac­ing or use small fans to increase ventilation. When the front and back of a cabinet are open, the air space between the chassis and shelf must be unobstructed.
Place the amplifier(s) as close to the loudspeakers as possible. While Evolution CAST technology permits long interconnect cable lengths, keep loudspeaker cable lengths to a minimum.
AC Power Guidelines
The Evolution amplifier requires a dedicated AC circuit rated at a minimum of 20 amps. Do not use extension cords, multiple AC adapters, or AC power strips.
Note
Do not operate the Evolution amplifiers with any device designed to alter or condition AC power.
12
SECTION THREE
Anatomy of an Evolution Amplifier
This section describes Evolution amplifier functions.
Figure 1 Evolution Amplifier Front Panel (Evolution 402 shown)
Power
1 Power Button 2 Power Status Indicator
13
continue
d
SECTION THREE: Anatomy of an Evolution Amplifier continued)
(
Front Panel Description
See Figure 1 on the previous page
Evolution amplifier front panel functions are described below:
Power
1 Power Button
Press this button to place the Evolution amplifier in operational mode.
2 Power Status Indicator
The power status indicator is illuminated in red when the amplifier is in stand­by mode. The indicator illuminates in blue when the amplifier is in operational mode. If there is no illumination, please check the following items:
—The power cord is connected to the amplifier —The power cord is plugged into a live AC power supply —The back panel power breaker switch (10) is set to the on position —The back panel backlight switch (8) is set to the on/ext position.
14
Figure 2 Evolution 302 Stereo Amplifier Back Panel
Outputs Inputs
Remote
Power
3 Loudspeaker Binding Posts 4 CAST Inputs 5 Single-ended Inputs 6 Balanced Inputs
12 VDC Out/In (12 V Trigger)
7 8 Backlight Control
IEC Power Cord Receptacle
9
Power Breaker Switch
10
15
continue
d
Figure 3 Evolution 402 Stereo Amplifier Back Panel
Outputs Inputs
Remote
Power
3 Loudspeaker Binding Posts 4 CAST Inputs 5 Single-ended Inputs 6 Balanced Inputs
12 VDC Out/In (12 V Trigger)
7 8 Backlight Control
IEC Power Cord Receptacle
9
Power Breaker Switch
10
16
SECTION THREE: Anatomy of an Evolution Amplifier continued)
(
Figure 4 Evolution 403 Multi-channel Amplifier Back Panel
Outputs Inputs
Remote
Power
3 Loudspeaker Binding Posts 4 CAST Inputs 5 Single-ended Inputs 6 Balanced Inputs 7 12 VDC Out/In (12 V Trigger) 8 Backlight Control 9 IEC Power Cord Receptacle
10
Power Br
eaker Switch
17
continue
d
Figure 5 Evolution Monaural Amplifier Back Panel (Evolution 600 shown)
Outputs Inputs
Remote
Power
3 Loudspeaker Binding Posts 4 CAST Input 5 Single-ended Input 6 Balanced Input 7 12 VDC Out/In (12 V Trigger) 8 Backlight Control 9 IEC Power Cord Receptacle
10 Power Br
eaker Switch
18
SECTION THREE: Anatomy of an Evolution Amplifier continued)
(
Back Panel Description
See Figure 2, 3, and 4 on the previous pages
The amplifier back panel provides access to the input and output connections, 12 V trigger inputs and outputs, and the AC power connection and switch. Back panel features and their descriptions follow:
Outputs
3 Loudspeaker Binding Posts (one pair per channel)
Each channel has one positive and one negative binding post. They accept spade lugs only.
Inputs
4 CAST Inputs (one per channel)
These are CAST inputs with 4-pin bayonet connectors, for use with Krell CAST-equipped preamplifiers and components.
5 Single-ended Inputs (one per channel)
These are single-ended analog inputs with RCA connectors.
6 Balanced Inputs (one per channel)
These ar
e balanced analog inputs with XLR connectors.
19
continue
d
Remote Connections
7 12 VDC In/Out (12 V Trigger)
The 12 V trigger allows you to turn the Evolution amplifier on or off, or to and from stand-by, from other components. Out. The output sends 12 VDC (12 V trigger) power on/off signals to other Krell components and other devices that incorporate a 12 V trigger, allowing whole systems or parts of systems to be easily controlled remotely. Mono 3.5 mm connectors are used in the following configuration: Tip = +12 V, Sleeve = GND.
Notes
When an Evolution amplifier is in the operational mode, the 12 V trigger provides 12 Volts of DC output. When the amplifier is in the stand-by mode or off, the DC output is 0 Volts. A maximum of 30 mA is available from the 12 V trigger output.
Consult the owner's reference of the components used in a custom installation to take full advantage of the remote capabilities of an Evolution amplifier.
8 Backlight Control
Ext In.
power status indicator (2) using a remote control. The switch must be set to On/Ext, in order for this to function (see below).
Connect a 12 V trigger to the Ext In input connector to turn off the
Power
10
On/Ext. This activates the power status indicator. (This is the factory default
position.) Off. This turns off the power status indicator, during normal operation. The
power status indicator remains illuminated for ten seconds after the power but­ton is pr
9 IEC Power Cord Receptacle
The power r only the power cord supplied with your Evolution amplifier.
Power Br
Place this switch in the up position to put the amplifier in stand-by mode. Place the switch in the down position to turn off the amplifier.
essed.
eceptacle is for use with the pr
eaker Switch
ovided 20 amp AC power cor
d. Use
20
SECTION FOUR
Connecting an Evolution Amplifier to Your System
This section describes Evolution amplifier connections. Each Evolution amplifier channel has a CAST 4-pin connector, a balanced input via an XLR connector, a single-ended RCA connector, and a pair of loudspeaker binding posts. The rear panel also has 12 VDC trigger input and outputs, and a backlight remote trigger input. All inputs and outputs ar Maintain the cor
rect left/right orientation, when hooking up your system.
CAST Connections
Krell recommends using its proprietary Krell CAST system for unparalleled sonic performance for connections between the Evolution amplifier and other CAST­equipped components. Krell CAST uses flexible interconnecting cables that can be drawn through tight spaces and concealed.
Balanced Connections
e located on the Evolution amplifier back panel.
The Evolution amplifier also offers balanced operation. The circuitry and connec­tions associated with balanced operation not only can minimize sonic loss but also are immune to induced noise, especially for installations using long cables.
XLR Pin Configuration
Pin 1 Ground Pin 2 Non-inverting (0 Pin 3 Inverting (180
O
)
O
)
Single-ended Connections
Each Evolution amplifier channel has one single-ended input. If connecting a tube
eamplifier
pr jumpers between pins 1 and 3 of the XLR connectors when using single-ended inputs.
, use the single-ended inputs only (see below). Connect the u-shaped
21
continue
d
Evolution DC Protection Circuitry/Using Tube Preamplifiers
The high DC output of tube preamplifiers may exceed the active DC protection circuitry of the Evolution amplifiers. Excessive DC level in a signal can damage amplifiers, loudspeakers, or both. The single-ended inputs of the Evolution ampli­fiers are capacitor-coupled and DC does not pass through. Therefore, if connect­ing a tube preamplifier, use the single-ended inputs only. For more information about DC protection circuitry features,
see Error Codes on page 25.
Connection Steps
Position the amplifier where you intend to use it in your system.
The following steps describe how to connect an Evolution amplifier to your sys­tem:
1. Turn off all power sources and components before connecting inputs and out-
puts.
2. Neatly arrange and organize wiring to and from the Evolution amplifier and all
components. Separate AC wires from audio cables to prevent hum or other unwanted noise from being introduced into the system.
3. Connect the outputs of your preamplifier to the appropriate CAST (4), balanced
(6), or single-ended inputs (5) on the Evolution amplifier.
Note
Connect the u-shaped jumpers between pins 1 and 3 of the XLR connectors when using single-ended inputs.
4. Connect the loudspeaker cables to the loudspeaker binding posts (7) on the
Evolution amplifier. The binding posts accept spade lugs only. Take care to observe the correct polarity when making connections: The positive (+) output connects to the positive input of the loudspeaker. The negative (-) output con­nects to the negative input of the loudspeaker.
5. Connect the supplied AC power cord to the AC power cord receptacle (9).
6. Plug the AC power cord into AC power.
Note
Use only the power cord provided with the Evolution amplifier to make the connection to AC power. Operation with a power cord other than the one supplied by Krell could induce noise, limit current, or otherwise impair the ability of the amplifier to perform optimally.
22
SECTION FIVE
Evolution Amplifier Operation
The Evolution amplifiers are easy to operate.
IMPORTANT When powering up any system, turn the amplifier on last. When powering down, turn it off first. This will prevent any turn-on and turn-off thumps in your loudspeakers.
Always mute or fully attenuate the preamplifier level when switching sources. Do not change input connections to the amplifier when the amplifier is on.
Krell amplifiers have large reserves of clean power that can safely drive loudspeakers to higher sound pressure levels than other amplifiers. Use care when setting high play­back levels, and lower the volume level at the first sign of loudspeaker distress.
On/Off and Stand-by Operation
1. Move the back panel power breaker switch (10) to the up position to place the
amplifier in stand-by mode. The power status indicator (2) illuminates in red.
2. Press the silver power button (1) on the amplifier front panel. The power status
indicator (2) illuminates in blue. The initial power-up phase lasts approximately 30 seconds from the moment
the back panel power breaker switch is placed in the up position. If the power button is pressed during this period, the power status indicator flashes blue for the remainder of the initial power-up phase. When the initial power-up phase is complete, the power indicator illuminates in blue and is no longer flashing. The amplifier is in the operational mode.
3. With the preamplifier muted or its volume completely lowered, select a source.
4. Increase the volume control to the desired listening level.
n the amplifier to stand-by
etur
o r
5. T
The power status indicator tur mode.
It is now safe to place the r
ess the power button on the fr
, pr ed, and the amplifier is in the stand-by
ns r
est of the system in stand-by
.
ont panel.
Powering Off
Krell recommends leaving Evolution amplifiers powered down (in the stand-by mode, with the back panel power breaker switch on) between listening sessions. Turn the amplifier off using the power breaker switch (10), and disconnect the amplifier from AC power when the system is not being used for an extended peri­od of time.
23
SECTION SIX
Troubleshooting System Noise
AC grounding becomes critical when connecting high-performance audio compo­nents. When you mix and match high-performance audio components, each with its own ground potential, a low frequency hum may occur in one or both loud­speakers. This often occurs when introducing a new component into a system.
If this happens when you place the Evolution amplifier into your system, follow these simple troubleshooting steps.
Note During these steps, the back panel power breaker switch remains in the on position.
1. Check that all input and output connections are of sound construction.
2. With the amplifier in stand-by mode, remove the interconnect cables, then turn
the amplifier on. If the hum disappears, turn the amplifier into stand-by mode again, and reinsert one of the interconnect cables. Turn the amplifier back on. Repeat this process for each cable.
3. If the hum reappears with one or both interconnect cables reinserted, the cable
needs to be checked.
4. If the interconnect cables are sound, you may be experiencing a ground loop.
Please contact your authorized Krell dealer, distributor, or Krell for suggestions on how to eliminate the ground loop.
How to Evaluate Amplifier Operation
otected by a series of non-intr
The amplifiers ar evaluate the amplifier input or output, and short circuits. The protection circuitry in an Evolution amplifier is designed to pr defective components, faulty wiring, system mishandling, or amplifier failur
e pr
s operation. This circuitry protects against damaging DC
event damage to the amplifiers or loudspeakers caused by other
usive cir
cuits that constantly
e.
24
SECTION SIX: Troubleshooting continued)
(
Error Codes
In the event of a problem, the power status indicator (2) will flash error code(s) in red. Errors are identified by a sequence of 3, 4, or 5 flashes. There is a pause between codes, and in the case where there is only one error code, the same code is repeated.
Diagnostic Code Possible Condition Course of Action
3 flashes Excessive cur
4 flashes Excessive temperature Allow the amplifier to
5 flashes Excessive DC at input Check the preamplifier
rent draw
Check loudspeaker and cables for short circuits. If you are driving more than one loudspeaker per channel, check that the combined load does not drop below 2 Ohms. The power breaker switch must be shut off to reset the fault condi­tion.
cool, and increase venti­lation. If the problem persists, please call the
.
y
factor
output and sour puts for excessive DC voltage. If you are using a tube preamplifier, use only the single-ended inputs, as they ar coupled.
ce out
e capacitor
-
25
SECTION SEVEN
Questions and Answers
Q. Should I leave my Evolution amplifier on at all times?
A. For maximum amplifier performance, leave the back panel power breaker
switch on at all times. This places the amplifier in stand-by mode. Evolution amplifiers are designed to be powered on and off from stand-by, using the front panel power button. This eliminates “cold start” degradation. The amplifi­er will operate at full performance within minutes.
Q. When I turn on the amplifier there is a loud hum through the loudspeakers.
What should I do?
A. When a new component is introduced, a low frequency hum may occur in one
or both loudspeakers. Check all input and output connections and cables, making sure they are of sound construction. See
Noise,
experiencing a ground loop. This can often be easily eliminated. Please con­tact your authorized Krell dealer, distributor, or Krell for suggestions on how to solve this problem.
on page 24. If the interconnects and cables are sound, you may be
Troubleshooting System
Q. My loudspeakers are rated for 150 Watts. Are the Evolution models too power-
ful for them?
A. No. A loudspeaker seldom is damaged fr
occurs when an amplifier that lacks sufficient power is asked to handle heavy demand situations such as high playback levels. These amplifiers may have very high 8 Ohm power ratings, but in heavy demand situations they can be driven into clipping (in which high power, high frequency harmonics go to the loudspeakers, due to loss of amplifier power). Clipping can damage loud speakers. Avoid damage to your loudspeakers by reviewing your loudspeak­er’s specifications, and exercise caution in heavy demand situations.
om overdriving. Mor
e often, damage
-
26
Warranty
Krell products have a limited warranty. Amplifiers, preamplifiers, preamp/processors, and receivers carry a limited warranty of five years for parts and labor on circuitry. Loudspeakers carry a limited warranty of five years for parts and labor. CD and DVD players carry a limited warranty of five years for parts and labor on circuitry, and three years for parts and labor on mechanical parts.
Should the product fail to perform at any time during the warranty, Krell will repair it at no cost to the owner, except as set forth in this warranty.
This warranty does not apply to damage caused by acts of God or nature. This warranty shall be in lieu of any other warranty, expressed or implied, including,
but not limited to, any implied warranty of merchantability or fitness for a particular purpose. There are no warranties which exceed beyond those described in this document, if the product does not perform as warranted herein, the owner’s sole remedy shall be repair. In no event will Krell be liable for incidental or consequential damages arising from purchase, use, or inability to use the product, even if Krell has been advised of the possibility of such damages.
IMPORTANT The single-ended inputs on the Evolution amplifiers are cap-coupled. Use these inputs whenever you are connecting a tube preamplifier.
Proof of purchase in the form of a bill of sale or receipted invoice substantiating that the product is within the warranty period must be presented to obtain warranty service. The warranty begins on the date of the original retail purchase, as noted on the bill of sale or r
eceipted invoice fr
om an authorized Kr
ell dealer or distributor. Previously owned equipment, when re-purchased from an authorized Krell dealer or distributor, has the balance of the original warranty, based on the original date of manufacture. Krell dealers and distributors are not authorized to sell current prod­ucts on the Internet. Current products purchased via the Internet do not have any
.
transfer
rable war
ranty
The warranty for a Krell product is valid only in the country to which it was originally
, and at the factory.
shipped, thr
ough the authorized Kr
ell distributor for that countr
y There may be restrictions on or changes to the Krell warranty because of regula­tions within a specific countr
y. Please check with your distributor for a complete
understanding of the warranty in your country.
27
continue
d
If the product is serviced by a distributor who did not import the unit, there may be a charge for service, even if the product is within the warranty period.
Freight to the factory is your responsibility. Return freight within the United States (U.S.A.) is included in the warranty. If you have purchased your Krell product out­side the U.S.A. and wish to have it serviced at the factory, all freight and associated charges to the factory are your responsibility. Krell will pay return freight to the U.S.A.-based freight forwarder of your choice. Freight and other charges to ship the product from the freight forwarder to you are also your responsibility.
Krell is not responsible for any damage incurred in transit. Krell will file claims for damages as necessary for a product damaged in transit to the factory. You are responsible for filing claims for shipping damages during the retur
n shipment.
Krell does not supply r
eplacement parts and/or products to the owner of the prod­uct. Replacement parts and/or products will be furnished only to the distributor performing service on this product on an exchange basis only; any parts and/or products returned to Krell for exchange become the property of Krell.
No expressed or implied warranty is made for any Krell product damaged by acci­dent, abuse, misuse, natural or personal disaster, or unauthorized modification.
Any unauthorized voltage conversion, disassembly, component replacement,
foration of chassis, updates, or modifications performed to the product
per will void the warranty.
The operating voltage of the product is determined by the factory and can only be changed by an authorized Krell distributor or at the factory. The voltage for this product in the U.S.A. cannot be changed until six months from the original pur­chase date.
In the event that Kr
eceives a pr
ell r
oduct for war
ranty ser
vice that has been modi
fied in any way without Krell authorization, all warranties on that product will be
ned to original factory layout specifications at the
void. The pr owner
oduct will be r
s expense before it is repaired. All repairs required after the product has
etur
been returned to original factory specifications will be charged to the customer, at current parts and labor rates.
-
All operational featur
es, functions, and specifications and policies are subject to
change without notification.
egister your pr
o r
T Warranty Registration Card enclosed in the shipping box within 15 days of pur­chase. Thank you.
oduct for warranty benefits, please complete and return the
28
Return Authorization Procedure
How to Expedite Service
If you believe there is a problem with your component, please contact your deal­er, distributor, or the Krell factory to discuss the problem component for repair. To expedite service, you may wish to complete and e-mail the Service Request Form in the Service section of our website at:
http://www.krellonline.com
To contact the Krell Service Department:
TEL 203-298-4020, Monday-Friday
9:00 AM to 5:00 PM EST FAX 203-795-2287 E-MAIL service@krellonline.com
WEBSITE http://www.krellonline.com
How to Return a Product
To return a product to Krell, please follow this procedure so that we may serve you better:
before you return the
1. Obtain a Return Authorization Number (R/A number) and shipping address
from the Krell Service Department.
2. Insure and accept all liability for loss or damage to the product during shipment
to the Krell factory and ensure that all freight (shipping) charges are prepaid.
The product may also be hand delivered if arrangements with the Service
tment have been made in advance. Pr
Depar
oof of pur
warranty validation at the time of hand delivery.
ANT
IMPOR Use the original packaging to ensure the safe transit of the product to the factory, dealer, or distributor. Krell may, at its discretion, return a product in new packaging and bill the owner for such packaging if the pr standard packaging or if the original packaging was so damaged that it was unusable. If Kr the product is returned.
How to Pur
T
ell deter
oduct r
mines that new packaging is required, the owner will be notified before
chase Additional Packing
To purchase additional packing, please contact your authorized Krell dealer, dis­tributor
, or the Krell Service Department for assistance.
chase will be required for
eceived by Kr
ell was boxed in non
-
29
Specifications
Measurement Evolution 302 Amplifier Evolution 402 Amplifier FREQUENCY RESPONSE 20 Hz to 20 kHz +0, –0.10 dB
<0.5 Hz to 180 kHz +0, –3 dB
SIGNAL-TO-NOISE RATIO
Wideband, unweighted, referred to full power output “A” weighted
>107 dB
>117 dB
GAIN 25.5 dB 25.4 dB TOTAL HARMONIC DISTORTION <0.02% at 1 kHz, at 300 W, 8 Ohms
<0.15% at 20 kHz, at 300 W, 8 Ohms
INPUT IMPEDANCE
Single-ended Balanced CAST
100 kOhms 200 kOhms
75 Ohms
INPUT SENSITIVITY
Single-ended or balanced CAST
OUTPUT POWER
All channels driven
2.60 V rms
2.60 mA rms 300 W rms at 8 Ohms
600 W rms at 4 Ohms 1200 W rms at 2 Ohms
OUTPUT VOLTAGE 139 V peak-to-peak
49 V rms
OUTPUT CURRENT 35 A peak 37 A peak SLEW RATE 120 V/µs 100 V/µs OUTPUT IMPEDANCE <0.040 Ohms at 20 Hz
<0.053 Ohms, 20 Hz to 20 kHz
DAMPING FACTOR
Referred to 8 Ohms
>200 at 20 Hz >150, 20 Hz to 20 kHz
POWER CONSUMPTION
Stand-by Idle Maximum
150 W 320 W
3400 W
HEAT OUTPUT
Stand-by Idle Maximum
510 BTU/hr 1100 BTU/hr 5500 BTU/hr.
.
.
INPUTS 2 single-ended via RCA connector
2 balanced via XLR connector 2 CAST via 4-pin bayonet connector
OUTPUTS 2 pairs Kr
ell binding posts
DIMENSIONS 17.3 in. W x 9.8 in. H x 20.7 in. D
438 mm W x 248 mm H x 525 mm D
WEIGHT
Shipping Unit only
138 lb., 62.4 kg 120 lb., 54.3 kg
20 Hz to 20 kHz +0, –0.18 dB <0.5 Hz to 120 kHz +0, –3 dB
>106 dB
>116 dB
<0.02% at 1 kHz, at 400 W, 8 Ohms <0.15% at 20 kHz, at 400 W, 8 Ohms
100 kOhms 200 kOhms
70 Ohms
3.04 V rms
3.04 mA rms 400 W rms at 8 Ohms
800 W rms at 4 Ohms 1600 W rms at 2 Ohms
160 V peak-to-peak
57 V rms
<0.055 Ohms at 20 Hz <0.064 Ohms, 20 Hz to 20 kHz
>145 at 20 Hz >125, 20 Hz to 20 kHz
370 W 570 W
3800 W
890 BTU/hr
1300 BTU/hr
. .
6400 BTU/hr. 2 single-ended via RCA connector
2 balanced via XLR connector 2 CAST via 4-pin bayonet connector
2 pairs Kr
ell binding posts
17.3 in. W x 9.8 in. H x 22.1 in. D 438 mm W x 248 mm H x 550 mm D
150 lb., 67.9 kg 135 lb., 61.1 kg
All operational features, functions, specifications, and policies are subject to change without notification.
30
Specifications continued)
(
Measurement Evolution 403 Amplifier
REQUENCY RESPONSE
F
0 Hz to 20 kHz +0, –0.18 dB
2 <0.5 Hz to 120 kHz +0, –3 dB
IGNAL-TO-NOISE RATIO
S
Wideband, unweighted, referred to full power output “A” weighted
>106 dB
>116 dB
GAIN 25.4 dB TOTAL HARMONIC DISTORTION <0.02% at 1 kHz, at 400 W, 8 Ohms
<0.15% at 20 kHz, at 400 W, 8 Ohms
INPUT IMPEDANCE
Single-ended Balanced CAST
100 kOhms 200 kOhms
70 Ohms
INPUT SENSITIVITY
Single-ended or balanced CAST
3.04 V rms
3.04 mA rms
OUTPUT POWER 400 W rms at 8 Ohms
800 W rms at 4 Ohms
1600 W rms at 2 Ohms
OUTPUT VOLTAGE 160 V peak-to-peak
57 V rms
OUTPUT CURRENT 37 A peak SLEW RATE 100 V/µs OUTPUT IMPEDANCE <0.055 Ohms at 20 Hz
<0.064 Ohms, 20 Hz to 20 kHz
DAMPING FACTOR
Referred to 8 Ohms
>145 at 20 Hz >125, 20 Hz to 20 kHz
POWER CONSUMPTION
Stand-by Idle Maximum
370 W
570 W
5000 W
HEAT OUTPUT
Stand-by Idle Maximum
1270 BTU/hr. 1950 BTU/hr. 7700 BTU/hr
.
INPUTS 3 single-ended via RCA connector
3 balanced via XLR connector 3 CAST via 4-pin bayonet connector
OUTPUTS 3 pairs Kr
ell binding posts
DIMENSIONS 17.3 in. W x 9.8 in. H x 26.1 in. D
438 mm W x 248 mm H x 662 mm D
WEIGHT
Shipping Unit only
190 lb., 86 kg 175 lb., 79.2 kg
All operational featur
es, functions, specifications, and policies ar
e subject to change without notification.
31
continue
d
Specifications continued)
(
Measurement Evolution 600 Amplifier Evolution 900 Amplifier
REQUENCY RESPONSE
F
IGNAL-TO-NOISE RATIO
S
Wideband, unweighted, referred to full power output “A” weighted
0 Hz to 20 kHz +0, –0.18 dB
2 <0.5 Hz to 120 kHz +0, –3 dB
>110 dB
>119 dB
0 Hz to 20 kHz +0, –0.18 dB
2 <0.5 Hz to 120 kHz +0, –3 dB
>113 dB
>122 dB
GAIN 25.4 dB 25.4 dB TOTAL HARMONIC DISTORTION <0.02% at 1 kHz, at 600 W, 8 Ohms
<0.15% at 20 kHz, at 600 W, 8 Ohms
<0.02% at 1 kHz, at 900 W, 8 Ohms <0.15% at 20 kHz, at 900 W, 8 Ohms
INPUT IMPEDANCE
Single-ended Balanced CAST
100 kOhms 200 kOhms
70 Ohms
100 kOhms 200 kOhms
70 Ohms
INPUT SENSITIVITY
Single-ended or balanced CAST
OUTPUT POWER 600 W rms at 8 Ohms
OUTPUT VOLTAGE 196 V peak-to-peak
3.72 V rms
3.72 mA rms
1200 W rms at 4 Ohms 2400 W rms at 2 Ohms
69 V rms
4.55 V rms
4.55 mA rms 900 W rms at 8 Ohms
1800 W rms at 4 Ohms 3600 W rms at 2 Ohms
240 V peak-to-peak
85 V rms
OUTPUT CURRENT 49 A peak 60 A peak SLEW RATE 100 V/µs 90 V/µs OUTPUT IMPEDANCE <0.030 Ohms, 20 Hz to 20 kHz <0.023 Ohms, 20 Hz to 20 kHz DAMPING FACTOR
Referred to 8 Ohms
>270, 20 Hz to 20 kHz >350, 20 Hz to 20 kHz
POWER CONSUMPTION
Stand-by Idle Maximum
260 W 410 W
3800 W
440 W 650 W
5000 W
HEAT OUTPUT
Stand-by Idle Maximum
INPUTS 1 single-ended via RCA connector
890 BTU/hr.
1400 BTU/hr
.
5500 BTU/hr.
1 balanced via XLR connector 1 CAST via 4-pin bayonet connector
1500 BTU/hr. 2200 BTU/hr
.
7700 BTU/hr. 1 single-ended via RCA connector
1 balanced via XLR connector 1 CAST via 4-pin bayonet connector
OUTPUTS 1 pair Krell binding posts 1 pair Krell binding posts DIMENSIONS 17.3 in. W x 9.8 in. H x 22.1 in. D
438 mm W x 248 mm H x 560 mm D
17.3 in. W x 9.8 in. H x 26.1 in. D
438 mm W x 248 mm H x 662 mm D
WEIGHT
Shipping Unit only
150 lb., 67.9 kg 135 lb., 61.1 kg
190 lb., 86 kg 175 lb., 79.2 kg
All operational featur
es, functions, specifications, and policies ar
e subject to change without notification
32
.
VOLUTION AMPLIFIERS
E
302 AND 402 STEREO
403 THREE-CHANNEL
600 AND 900 MONAURAL
WNER’S REFERENCE
O
V07.0
KRELL INDUSTRIES, INC.
45 CONNAIR ROAD
ORANGE, CT 06477-3650 USA
TEL: 203-298-4000 • FAX: 203-891-2028
E-MAIL: sales@krellonline.com
http://www.krellonline.com
Loading...
