INSTALLATION GUIDE

Novis™ Single Handle Vessel Faucet

KVF-1220

www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. OCT 24, 2019

Congratulations on the purchase of your new

Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:

DO NO T RETU RN TO STORE

Please contact our Customer Service Team
1-800-775-0703 / [e-mail]

Have the model number available, and retain a copy of your receipt
with purchase date for reference.

If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.

1

Prior to Installation:

13

Make sure you have all necessary parts by checking the diagram and parts list. If

t

any part is missing or damaged, please contact Kraus Customer Service at 800-775-

0703 for a replacement

t

Turn off the hot and cold water lines at the angle stops and turn on the old faucet

to release any built-up pressure

t

Pre-drilled countertop hole size requirement: 1-3/8”(min)

t Max countertop thickness: 2 1/2”

Tools you will need:

Wrench Phillips Screwdriver

Pipe Tape

Silicone Sealant

(optional)

Safety Goggles

2

Diagram and Parts List

B

H

I

A

C

D

E
F

G

A. Faucet Body
B. Aerator
C. Flange
D. Plastic Washer
E. Metal Washer

3

F. Mounting Nut
G. Screws
H. Hex Wrench

I. Drain

Faucet Dimension

12 7/8"

[327.5mm]

2 1/2"

[61.9mm]

Ø2 1/4"

[57.0mm]

7 3/4"

[196.4mm]

6 1/4"

[159.4mm]

8 3/4"

[223.0mm]

Installer Tip:

9/16-24UNEF-2B

4

Drain Dimension

6 3/4"

5/8"~2 3/8"

[172.5mm]

2 3/4"

[69.0mm]

[15.8mm~61.6mm]

Ø2 3/8"

[61.1mm]

G1 1/4-11

Installer Tip:

5

Ø1 1/4"

[31.7mm]

Step 1: Remove washers and mounting nut

Shut off the water supply. Remove the
old faucet. Clean the mounting surface.

A

Remove the mounting nut & screws (F&G),
metal washer (E) and plastic washer (D)
from the faucet (A).

D
E

F&G

Step 2: Installing the faucet

A

Place faucet (A) through the hole in countertop.
Secure the faucet (A) to the countertop using
the plastic washer (D), metal washer (E) and
mounting nut (F) provided. Tighten screws (G).

D

E

F

G

G

6

Step 3: Connect waterlines to main valve

Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)

Step 4: Install Press pop-up assembly

Unscrew the nut (6) from the pop-up
body (2), move over the tail pipe (7)

1
2

and washer (5), then unscrew the
coupling nut (4) and remove the
washer (3).

3

4

5

6

7

7

Step 4: Install Press pop-up assembly

1
2

3

4

5

6
7

Place the washer (1) underneath the
flange of the pop-up body (2). Slide
the pop-up body (2) down through
the drain hole on the vessel or basin.
From underside, slide the washer (3)
against the bottom of the vessel or
basin, thread on the coupling nut (4)
and tighten. Do not overtighten.

Slide the nut (6) over the tail pipe (7).
Place the washer (5) into the nut and
tighten. Do not overtighten.

Step 5: Flush faucet

B

After installing faucet, remove aerator (B)
with a coin. Turn water on for 30 seconds
to remove any debris. Reassemble aerator (B).

8

Replacement Parts

13

1

2

3

4

5

6

7

12

Replacement Parts List Part #

1. Cover Button

2. Set Screw

3. Handle

4. Cap & O-ring

5. Bonnet Nut

6. Cartridge

7. Aerator

8. Flange

9. Plastic Washer

10. Metal Washer

11. Mounting Nut & Screw

8

12. Hex Wrench

9

13. Drain KP27059

10

14. Filter Washer KP27167

11

Finish / Color

GR, BL*

SFS, MB,
GM, SFBG*

SFS, MB,
GM, SFBG*

SFS, MB,
GM, SFBG*

SFS, MB,
GM, SFBG*

KP27159

KP27158

KP27157

KP27160

KP27161

KP27162

KP27163

KP27164

KP27146

KP27147

KP27148

KP27166

14

*Denotes faucet component color options:
SFS - Spot Free Stainless Steel
MB - Matte Black
GM - Gunmetal
SFBG - Spot Free Brushed Gold
GR - Grey
BL - Black

9

Trouble - Shooting

Hot
Water

Cold
Water

Push

If you have followed the instructions carefully and your faucet still does not work
properly, take the following coorective steps:

PROBLEM CAUSE ACTION

Leakage under the
handle

Aerator drips or has
inconsistent water
flow pattern

Water will not shut off
completely

There is leaking from the
sink drain at the base of
the sink.

There is a low flow of
water.

Bonnet nut (5) has
come loose

Aerator (7) is dirty or
not seated properly

Cartridge may need to
be adjusted or replaced

The sink has a rough or
irregular surface.

The filter washer in the
hose connectors is dirty.

Remove the cover button (1).
Loosen set screw (2) with hex
wrench (12). Remove the
handle (3). Unscrew cap (4) (by
hand only). Tighten bonnet nut
(5) with an adjustable wrench

Unscrew aerator (7) with
a coin and clean out debris

Remove the cover button (1).
Loosen set screw (2) with hex
wrench (12). Remove the
handle (3). Unscrew cap (4) (by
hand only). Tighten bonnet nut
(5) with an adjustable wrench.
Remove the cartridge (6).
Check for cracks

Apply additional silicone
sealant to the beveled side of
the drain flange. Retighten
and test for leaks

Turn off the water supply at
water valve and unscrew the
hose connectors from water
supply lines. Clean the filter
washer in the water lines with
hot water, removing any debris
or calcium build up

Care & Maintenance

*To keep the product clean & shining, follow the steps below：

1. Rinse with clean water & dry with a soft cloth

2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners

3. Do not use cloth with a coarse surface

4. Unscrew the aerator and clean when necessary

*This installation manual is subject to change without further notice.

10

Codes/Standards Applicable:

LEAD FREE

NSF/ANSI 372

I

A

P

M

O

R

&

NSF/ANSI 61

T

ASME A112.18.1

1.2GPM 4.5L/min maximum

Faucet Warranty

Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. (”Kraus”).
Kraus extends this warranty to the original purchaser for personal household use of the “Faucet” in its original location.
The warranty is non-transferable.
Kraus warrants the structure and finish of the product to be free from defects in material and workmanship under
normal usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or
trade professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.

Kraus warrants the mechanical components such as but not limited to sprayhead assembly (includes engine, aerators,
structure, restrictors, back flow preventers, sprayer hoses, braided supply line hoses which encompasses nylon,silicon
and stainless steel, etc) of the product to be free from defects in material and workmanship under normal usage for a
period of one (1) year. The warranty commences from the initial date of purchase by the owner or trade professional,
from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user.

Kraus warrants the mechanical component (cartridge) of the product to be free from defects in material and
workmanship under normal usage for a period of five (5) years. The warranty commences from the initial date of
purchase by the owner or trade professional, from an authorized Kraus dealer, through the five (5) years term of the
original owner or end-user.

Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be
repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or
end-user, and is not transferable to a subsequent owner.

Restrictions

This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at
discount outlets, unauthorized dealers, and/or sold on clearance.

This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard
water or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance,
alteration of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using
abrasive cleaners such as powders, bleach, ammonia, alcohol, or chlorine. Avoid using abrasive pads, steel wool, or wire
brushes, as these will damage and wear down the finish.
This warranty does not apply to Products that have not been installed or operated in accordance with instructions
supplied by Kraus and all applicable rules, regulations, and legislation pertaining to such installations.

This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional.
Kraus insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods.

This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does
not allow recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other
consequential damages, and Kraus accepts no liability for such damages.
This warranty does not cover Marine or Outdoor Installation.

Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of
merchantability and fitness for a particular purpose, or compliance with any code.

11

Shipping charges will be covered foe the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.

Commercial Warranty

Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and
business use.

All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are
given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long
an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state.

If you are a homeowner please contact a Kraus Customer Service Representative at:

Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[e-mail]

If you are a plumbing contractor or trade professional please contact a Kraus
Pro Representative at:

Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[e-mail]

If you are an Authorized Partner please contact a Partner Support Representative at:

Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[e-mail]

In requesting warranty service, please be ready to provide:

1. Proof of purchase.

2. A description of the problem.

Download the Kraus Care & Maintenance Guide at:

http://www.kraususa.com/maintenance
