Page 1

Single Lever Pull Out Kitchen Faucet

KPF-2230

INSTALLATION GUIDE

Page 2

Congratulations on the purchase of your new Kraus plumbing xture!

Please keep teh box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product:

Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com

Have the model number available, and retain a copy of your receipt with purchase date for reference.

If for any reason this product does not meet your expectations, please be sure to repack this product in the original box and packaging material to avoid damage during transit.

DO NOT RETURN TO STORE

Page 3

Prior to Installation:

• Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement

• Turn o the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure

• Flush angle stops to release any debris prior to installing new plumbing

• Pre-drilled hole: 1-3/8” (min)

• Max countertop thickness: 1-3/8”

Tools you will need:

Adjustable Wrench Phillips Screwdriver Pipe Tape

Silicone Sealant

Page 4

1. sprayhead

2. faucet assembly

3. mounting

hardware

A. Rubber Washer

B. Metal Washer

C. Mounting Nut

D.Mounting Screws

4. hose

5. escutcheon

6. hex wrench

7. weight

Diagram and Parts List

Page 5

10 3/16"

(258.5mm)

15 3/16"

(385mm)

6 1/8"

(156mm)

5 3/8"Max

(137mm)Max

6 9/16"Max

(166mm)Max

Ø 2 3/8"

(Ø 60mm)

1 1/4"-18UNEF-2A

2-1/2-14NPSM-2A

check valve

Faucet Dimensions

Page 6

9 3/16"

(234mm)

2 1/2"

(63.4mm)

8 1/8"

(207mm)

11 5/16"

(288mm)

1/16"~1 1/2"

(1mm~38mm)

19º

Faucet Dimensions

Page 7

Step 1: Remove mounting hardware

Remove mounting hardware(3)

Step 2A: Installing the faucet with deck plate

For three-hole installation,

deck plate (5), and silicone

sealant are required

Page 8

Insert the faucet body (2) into

the hole on the countertop or

deck plate assembly (5). Install

rubber washer (3A), metal

washer (3B), and mounting

nut (3C) on the mounting

pipe from underneath the

countertop

Step 3: Install faucet and mounting hardware

Step 2B: Installing the faucet without deck plate

For single-hole installation,

deck plate (5), and silicone

sealant are NOT required

Page 9

Step 4: Attach spray hose and counterweight

Remove the plastic seal cover

from the outlet port prior to

pushing the hose adapter onto

the same port, you will hear

a “click” sound once they are

joined.

Attach metal weight to hose

to prevent hose from twisting

and returns hose to proper

position.

Tighten supply hose ends to

faucet shank and water supply

source.Note: Hand tighten the

supply hose and then tighten

1/4 turn with adjustable

wrench. Overtightening the

supply hose can cause leaking.

Purchase exible supplies or

bull-nose risers separately.

Step 5: Attach supply hose

Page 10

Step 6: Open water

Step 7: Flush faucet

Open the water valve and

check for leaks at supply line

connection.

After installing faucet, remove

pull-down spray and turn on

water to remove any left over

debris. Re-assemble spout

Page 11

Replacement Parts

1. Metal Handle Assembly

2. Locking Nut

3. Ceramic Disc Cartridge

4. Spout Seal Kit

5. Spout Base

6. Spout

7. Hose Guide

8. Hand Spray w/ Check Valve

9. Supply Pipe-Hot

10. Supply Pipe-Cold

11. Supply Pipe

12. Screen Washer

13. Mounting Hardware

14. Hose Adaptor Assembly

15. Cover Plate & Putty Plate

16. Weight

17. Hex Wrench(H2.5 * 19 mm L * 53 mm L)

18. Supply Hose

Care & Maintenance

*To keep the product clean & shining, follow the steps below:

1. Rinse with clean water & dry with a soft cloth

2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners

3. Do not use cloth with a coarse surface

4. Unscrew the aerator and clean when necessary

*This installation manual is subject to change without further notice.

Page 12

Trouble - Shooting

If you have followed the instructions carefully and your faucet still does not work

properly, take the following corrective steps:

PROBLEM CAUSE ACTION

Leakage under the handle

Locking nut (4) has come loose

Remove index button (2A). Loosen the set screw (2B) with a hex wrench (9). Remove the handle (1) and unscrew cartridge cover (3) by hand. Tighten locking nut (4) with an adjustable wrench

Water will not shut off completely

Cartridge (5) may need to be adjusted or replaced

Remove index button (2A). Loosen the set screw (2B) with a hex wrench (9). Remove the handle (1) and unscrew cartridge cover (3) by hand. Unscrew the locking nut (4) with an adjustable wrench. Remove ceramic disc cartridge (5).Check for cracks, and if O-ring is seated correctly. Reseat cartridge (5)

Leaking between spray head (8) and the hose (12)

Spray head (8) may be loose

Tighten the spray head (8) by hand until snug

The hose (12) does not retract

The weight (11)is not installed correctly

Readjust the weight (11) on the hose (12)

Page 13

Maintenance - Cartridge Replacement

Step 1: Remove the handle button

from the handle. Loosen the set

screw with a hex wrench. Remove

the handle and unscrew cartridge

cover by hand

Step 2: Unscrew the locking

nut with an adjustable wrench.

Remove ceramic disc cartridge

Step 3: Place the new cartridge

in the handle seat. Secure the

cartridge with the locking nut and

assemble the handle

Page 14

Codes / Standards Applicable:

Meets ASME A112.18.1M/A112.18.1

1.75gpm 6.6L/min maximum

GREEN

Water Eciency

LEAD FREE

NSF/ANSI Standard 61 certied by IAPMO

NSF/ANSI Standard 372 certied by IAPMO

FAUCET WARRANTY

Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. (“Kraus”). Kraus extends this warranty to the original purchaser for personal household use of the “Faucet” in its original location. The warranty is non-transferable.

Kraus warrants the structure and nish of the product to be free from defects in material and workmanship under normal usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.

Kraus warrants the mechanical component (sprayhead assembly) of the product to be free from defects in material and workmanship under normal usage for a period of one (1) year. The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user.

Kraus warrants the mechanical component (cartridge) of the product to be free from defects in material and workmanship under normal usage for a period of ve (5) years. The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the ve (5) year term of the original owner or end-user.

Any product reported to the authorized dealer or to Kraus as being defective within the warranty

period will be repaired

or replaced with a product of equal value at the option of Kraus. This warranty

extends to the original owner or

end-user, and is not transferable to a subsequent owner.

RESTRICTIONS

This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at discount outlets, unauthorized dealers, and/or sold on clearance.

This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance, alteration of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using abrasive cleaners such as powders, bleach, ammonia, alcohol, or

chlorine. Avoid using abrasive pads, steel wool, or

wire brushes, as these will damage and wear down the nish.

This warranty does not apply to Products that have not been installed or operated in accordance with instructions supplied by Kraus and all applicable rules, regulations, and legiswlation pertaining to such installations.

This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional. Kraus insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods

This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does not allow recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other consequential damages, and Kraus accepts no liability for such damages.

This warranty does not cover Marine or Outdoor Installation.

Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of

Page 15

merchantability and tness for a particular purpose, or compliance with any code. Shipping charges will be covered for the rst (1) year of the warranted replacement part or product (HI, AK, and Puerto

Rico shipping charges may apply). International shipping fees are not included.

COMMERCIAL WARRANTY

Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use.

All incidental or consequential damages are specically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or tness for a particular purpose.

Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

If you are a homeowner please contact a Kraus Customer Service Representative at:

Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com

If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at:

Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com

If you are an Authorized Partner please contact a Partner Support Representative at:

Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8954 Partnersupport@kraususa.com

In requesting warranty service, please be ready to provide:

1. Proof of purchase.

2. A description of the problem.

Download the Kraus Care & Maintenance Guide at:

http://www.kraususa.com/maintenance

Page 16

IMPORTANT

http://www.kraususa.com/registration

Activate Your Warranty

Access Premium Customer Support

Get Product Information

www.kraususa.com
