Kramer Electronics VP-32K User Manual
Kramer Electronics, Ltd.
USER MANUAL
Model:
VP-32K
3x1 PC / Audio Switcher
Contents
Contents
1
Introduction 1
2
Getting Started 1
2.1 Quick Start 1
3
Overview 3
4
Your VP-32K 3x1 PC / Audio Switcher 4
5
Connecting theVP-32K 3x1 PC / Audio Switcher 5
5.1 Connecting the Balanced/Unbalanced Stereo Audio Input/Output 7
5.2 Controlling via the REMOTE Connector 8
6
Technical Specifications 9
Figures
Figure 1: VP-32K 3x1 PC / Audio Switcher 4
Figure 2: Connecting the VP-32K 3x1 PC / Audio Switcher 6
Figure 3: Connecting the Balanced Stereo Audio Input/Output 7
Figure 4: Connecting the Unbalanced Stereo Audio Input 7
Figure 5: Connecting the Unbalanced Stereo Audio Output 7
Figure 6: Connecting the REMOTE Connector 8
Tables
Table 1: Front Panel VP-32K 3x1 PC / Audio Switcher Features 4
Table 2: Technical Specifications of the VP-32K 3x1 PC/ Audio Switcher 9
i
Introduction
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have redesigned
and upgraded most of our line, making the best even better! Our 1,000-plus
different models now appear in 11 groups1 that are clearly defined by
function.
Congratulations on purchasing your Kramer VP-32K 3x1 PC / Audio Switcher.
The VP-32K is ideal for:
Display and presentation systems that require three way switching to two
displays
Multimedia applications
Computer graphics and balanced stereo audio distribution
The package includes the following items:
VP-32K 3x1 PC / Audio Switcher
Power adapter (5V DC Input)
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
