Kramer Electronics VP-311DVI User Manual
KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
VP-3 11 DV I
Automatic DVI/Audio Switcher
P/N: 2900-000120 Rev 3
VP-311DVI – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Terminology Used in this User Manual 5
3.2 Defining the VP-311DVI Automatic DVI/Audio Switcher 6
4 Connecting the VP-311DVI 7
4.1 Setting the DIP-switches 8
4.2 Connecting the Contact Closure Remote Control Pins 9
4.3 Connecting to the VP-311DVI via RS-232 10
4.4 Controlling via the ETHERNET 11
5 Technical Specifications 15
Figures
Figure 1: VP-311DVI Automatic DVI/Audio Switcher 6
Figure 2: Connecting the VP-311DVI Automatic DVI/Audio Switcher 8
Figure 3: VP-311DVI DIP-switches 8
Figure 4: Connecting the Contact Closure Remote Control PINS 10
Figure 5: Crossed Cable RS-232 Connection 10
Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter 11
Figure 7: Local Area Connection Properties Window 12
Figure 8: Internet Protocol Version 4 Properties Window 13
Figure 9: Internet Protocol Version 6 Properties Window 13
Figure 10: Internet Protocol Properties Window 14
VP-311DVI - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VP-311DVI Automatic DVI/Audio
Switcher, which is ideal for the following typical applications:
Systems requiring automatic DVI routing
Presentation and multimedia applications
2
VP-311DVI - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VP-311DVI away from moisture, excessive sunlight
and dust
VP-311DVI - Getting Started
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
