USER MANUAL

Model:

VP-201xl

2x1 High Resolution VGA Switcher

Contents

Contents

1

Introduction 1

2

Getting Started 1

3

Overview 1

4

Your VP-201xl 2x1 High Resolution VGA Switcher 2

5

Using the VP-201xl 2x1 High Resolution VGA Switcher 3

5.1 Connecting the VP-201xl as a 2x1 VGA Switcher 3

5.2 Connecting the VP-201xl as a 1x2 VGA Switcher 3

6

Technical Specifications 4

Figures

Figure 1: VP-201xl 2x1 High Resolution VGA Switcher 2
Figure 2: Connecting the VP-201xl as a 2x1 High Resolution VGA Switcher 3
Figure 3: Connecting the VP-201xl as a 1x2 High Resolution VGA Switcher 4

Tables

Table 1: Features and Functions of the VP-201xl 2x1 High Resolution VGA Switcher 2
Table 2: Technical Specifications of the VP-201xl 2x1 High Resolution VGA Switcher 4

i

Introduction

1 Introduction

Dedication by Kramer Electronics since 1981, to the development and
manufacture of high quality video/audio equipment, makes the Kramer line
an integral part of the finest production and presentation facilities in the
world. In recent years, Kramer has redesigned and upgraded most of the line,
making the best even better! The Kramer line of professional video/audio
electronics is one of the most versatile and complete available, and is a true
leader in terms of quality, workmanship, price/performance ratio and
innovation. In addition to our high quality switchers and matrices, we also
offer excellent distribution amplifiers, remote controllers, presentation
processors, interfaces and computer-related products.

Congratulations on purchasing your Kramer TOOLS VP-201xl 2x1 High
Resolution VGA Switcher. The VP-201xl is ideal for:

 Any presentation system requiring simple two-way VGA switching

 Schools, churches

The package includes the following items:

 VP-201xl 2x1 High Resolution VGA Switcher

 This user manual1 and the Kramer concise product catalog/CD

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables2

3 Overview

The high quality Kramer VP-201xl is a 2x1 mechanical switcher designed for
VGA/XGA/UXGA signals, using high-density 15 pin HD connectors.

In addition, the VP-201xl:

 Is a new ergonomically redesigned version of the Kramer VP-201, using

1 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com/manuals.html

2 The complete list of Kramer cables is on our Web site at http://www. kramerelectronics.com (click “Cables and Connectors”

in the Products section)
