Kramer Electronics, Ltd.
USER MANUAL
Models:
VM-8H, 1:8 HDMI Distributor
VM-16H, 1:16 HDMI Distributor
Contents
i
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 3
3.1 Recommendations for Best Performance 4
3.2 Recycling Kramer Products 4
4 Your HDMI Distributors 4
5 Installing the VM-8H/VM-16H in a Rack 8
6 Connecting the VM-8H 1:8 HDMI Distributor 9
6.1 Acquiring the EDID 10
6.1.1 Acquiring the EDID from one Output 10
6.1.2 Acquiring the Default EDID 11
6.1.3 Acquiring the EDID from Several Outputs 11
7 Technical Specifications 12
Figures
Figure 1: VM-8H 1:8 HDMI Distributor 5
Figure 2: VM-16H 1:16 H Distributor 6
Figure 3: Connecting a VM-8H 1:8 HDMI Distributor 9
Tables
Table 1: HDMI Distributor Features 7
Table 2: The EDID Modes 10
Table 3: Technical Specifications of the VM-8H and the VM-16H 12
Introduction
1
1
1
2
3
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront video, audio, presentation, and broadcasting
professionals on a daily basis. In recent years, we have redesigned and
upgraded most of our line, making the best even better! Our 1,000-plus
different models now appear in 11 groups1 that are clearly defined by
function.
Thank you for purchasing your Kramer VM-8H 1:8 HDMI Distributor
and/or VM-16H 1:16 HDMI Distributor. The HDMI distributor is ideal for:
Home theater, presentation and multimedia applications
Rental and staging
Retail store displays
The package includes the following items:
VM-8H 1:8 HDMI Distributor and/or VM-16H 1:16 HDMI
Distributor
Power cord and rack “ears”
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables3
GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
Download up-to-date Kramer user manuals from our Web site at
http://www.kramerelectronics.com/support/product_downloads.asp
The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
1
2.1 Quick Start
This section provides instructions for rack mounting the unit1.
This quick start also applies to the VM-16H which has 16 outputs instead of eight
Overview
3
3
1
2
3
4
3 Overview
The Kramer VM-8H 1:8 HDMI Distributor and the VM-16H 1:16 HDMI
Distributor are high quality distributors that accept an HDMI input and
distribute the signal to 8/16 outputs respectively, allowing one or more of the
outputs to be connected to receiving devices, thus making them a versatile,
reliable component in a video system. The VM-8H/VM-16H distribute
signals having resolutions up to and including 1080p, and all HDTV formats.
In particular, the HDMI distributors feature:
Up to 2.25Gbps bandwidth per graphic channel1
Data reclocking and equalization
A default EDID2 for fast and efficient connection of the unit3
I-EDIDPro™ Kramer Intelligent EDID Processing™, an
intelligent EDID handling and processing algorithm that ensures
Plug and Play operation for HDMI systems
3D pass-through
HDMI Support – HDMI (with Deep Color, x.v.Color™, Lip Sync,
HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS-HD,
CEC)
HDMI connectors4, output status LEDs4, and EDID read and
select buttons
The HDMI distributors are housed in a 19" 1U rack-mountable enclosure,
and are fed from a 100-264V AC universal switching power supply.
Suitable for resolutions up to 1080p, and for all HD resolutions
EDID is Extended Display Identification Data
The default EDID feature lets you connect the VM-8H/VM-16H without having to connect a display to the output
Eight for the VM-8H and 16 for the VM-16H
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your HDMI Distributors
4
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
!
3.1 Recommendations for Best Performance
To achieve the best performance:
Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight
coils
Avoid interference from neighboring electrical appliances and
position your HDMI distributors away from moisture, excessive
sunlight and dust
3.2 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC aims to reduce the amount of WEEE sent for disposal to
landfill or incineration by requiring it to be collected and recycled. To
comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN)
and will cover any costs of treatment, recycling and recovery of waste
Kramer Electronics branded equipment on arrival at the EARN facility. For
details of Kramer’s recycling arrangements in your particular country go to
our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4 Your HDMI Distributors
Figure 1 illustrates the VM-8H 1:8 HDMI Distributor, Figure 2 illustrates
the VM-16H 1:16 HDMI Distributor, and Table 1 defines both the VM-8H
and the VM-16H.
Your HDMI Distributors
5
Figure 1: VM-8H 1:8 HDMI Distributor
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your HDMI Distributors
6
Figure 2: VM-16H 1:16 H Distributor
Your HDMI Distributors
7
#
Feature
Function
1
POWER Switch
Illuminated switch for turning the unit ON or OFF
2
EDID
READ Button
Press to read the EDID of the selected display
3
SELECT Button
Select the desired display for EDID information
4
OUTPUT STATUS LEDs
LEDs light when an output(s) is connected and active; LEDs flash
when selecting the EDID (see Section 6.1)
5
INPUT HDMI Connector
Connects to the HDMI source
6
OUTPUT HDMI Connectors
Connect to the HDMI acceptors1
7
Power Connector with Fuse
AC connector enabling power supply to the unit
1
Table 1: HDMI Distributor Features
For the VM-8H, from 1 to 8; for the VM-16H, from 1 to 16
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Installing the VM-8H/VM-16H in a Rack
8
5 Installing the VM-8H/VM-16H in a Rack
This section provides instructions for rack mounting the unit.
Connecting the VM-8H 1:8 HDMI Distributor
9
1
2
6 Connecting the VM-8H 1:8 HDMI Distributor
To connect the VM-8H 1:8 HDMI distributor1, do the following:
1. Connect an HDMI source (for example, a DVD player) to the INPUT
connector.
2. Connect the eight OUTPUT connectors to eight2 HDMI acceptors (for
example, plasma displays).
3. Connect the power cord to the mains electricity.
4. Turn ON the POWER.
5. Acquire the EDID (see Section 6.1).
Figure 3: Connecting a VM-8H 1:8 HDMI Distributor
From this section on, all the information is relevant to both the VM-8H and the VM-16H, unless noted otherwise
As required. Up to 8 outputs can be connected on the VM-8H and up to 16 outputs can be connected on the VM-16H. Not
all outputs need to be connected
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VM-8H 1:8 HDMI Distributor
10
Current
EDID Mode
Appearance
To cycle to the
Default EDID
To cycle to the
Auto-mix EDID
To cycle to the One output
EDID
One output
The selected output
LED illuminates
Press the SELECT
button once again after
selecting output 8 (for
VM-8H) or output 16
(for VM-16H). The
output LEDs flash
Default
The output LEDs
flash
Press the SELECT
button once
Auto-mix
The output LEDs
flash in sequence
Press the SELECT button to
select the required output.
The selected output flashes
1
6.1 Acquiring the EDID
The VM-8H initially operates with the default EDID. This means that you can
turn ON the power before connecting any of the acceptors or the source.
You can acquire the EDID from:
One Output (the selected output LED illuminates)
The Default EDID (all the output LEDs flash)
Several connected outputs, the Auto-mix Mode1, (the output
LEDs flash in sequence)
To cycle between the different modes (One Output, Default and Auto-mix),
press the SELECT button, as defined in Table 2.
Table 2: The EDID Modes
To acquire or change the EDID of a new output display from:
One output, see Section 6.1.1
The default EDID, see Section 6.1.2
Several connected outputs, see Section 6.1.3
6.1.1 Acquiring the EDID from one Output
To acquire the EDID of a new output display, do the following:
1. Press the SELECT button.
The currently selected OUTPUT LED illuminates.
2. Press the SELECT button again to cycle from one output to another
until reaching the desired output.
3. Press the READ button.
The flashing ceases and the button illuminates. The VM-8H accesses
The EDID acquired is a weighted average of all the connected outputs. For example, if several displays with different
resolutions are connected to the outputs, the acquired EDID supports all the resolutions, as well as other parameters included
in the EDID
Connecting the VM-8H 1:8 HDMI Distributor
11
the EDID of the connected output.
The EDID of the selected output is stored in the non-volatile memory
when the READ button no longer illuminates.
6.1.2 Acquiring the Default EDID
To acquire the default EDID, do the following:
1. Press the SELECT button.
The OUTPUT LEDs flash simultaneously.
2. Press the READ button.
The flashing ceases and the button illuminates. The VM-8H accesses
the default EDID.
The EDID of the selected output is stored in the non-volatile memory
when the READ button no longer illuminates.
6.1.3 Acquiring the EDID from Several Outputs
To acquire or change the EDID via several connected outputs, do the
following:
1. Press the SELECT button.
The OUTPUT LEDs flash in sequence.
2. Press the READ button.
The flashing ceases and the button illuminates. The VM-8H accesses
the EDID of the connected outputs.
The EDID is stored in the non-volatile memory when the READ
button no longer illuminates.
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
12
VM-8H
VM-16H
INPUT:
HDMI connector
OUTPUTS:
8 HDMI connectors
16 HDMI connectors
BANDWIDTH:
Supports up to 2.25Gbps per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
CONTROLS:
SELECT and READ buttons for selecting and storing EDID information
INDICATOR LEDs:
OUTPUT STATUS 1 to 8
OUTPUT STATUS 1 to 16
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
100-264V AC, 50/60Hz, 28VA
100-264V AC, 50/60Hz, 48VA
DIMENSIONS:
19" x 7" x 1U W, D, H rack mountable
WEIGHT:
3.5kg (7.7lbs) approx.
4.5kg (9.9lbs) approx.
ACCESSORIES:
Power cord, rack“ears”
OPTIONS:
HDMI/HDMI male-to-male cables
1
7 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications1 of the VM-8H and the VM-16H
Warning:
This is a class A product, for professional applications and environments only
Specifications are subject to change without notice
13
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
PN:
2900-000661
Rev:
4
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N: 2900-000661 REV 4
Loading...
