KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
VM-4 DP
1:4 DisplayPort Distrib utor
P/N: 2900-000732 Rev 2
VM-4DP – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the VM-4DP 1:4 DisplayPort Distributor 4
4 Installing in a Rack 7
5 Connecting the VM-4DP 8
6 Acquiring an EDID 9
6.1 Acquiring the Default EDID 9
6.2 Acquiring the EDID from a Connected Output 9
7 Upgrading the Firmware 10
8 Technical Specifications 11
Figures
Figure 1: VM-4DP 1:4 DisplayPort Distributor Front Panel 5
Figure 2: VM-4DP 1:4 DisplayPort Distributor Rear Panel 6
Figure 3: Connecting the VM-4DP 1:4 DisplayPort Distributor 8
VM-4DP - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VM-4DP 1:4 DisplayPort Distributor,
which is ideal for the following typical applications:
Multimedia applications
PC showrooms
2
VM-4DP - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VM-4DP away from moisture, excessive sunlight and
dust
VM-4DP - Getting Started
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the power cord that is supplied with the unit
Warning:
Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
VM-4DP - Overview
3 Overview
The VM-4DP is a high-quality 1:4 DisplayPort Distributor that accepts a DisplayPort
(DP) input, equalizes and reclocks the data, and distributes the signal to four
DisplayPort outputs.
The VM-4DP features:
One DisplayPort input, four DisplayPort outputs, four output status LEDs, an
active input status LED, as well as EDID read and select buttons
Maximum data rate of 10.8Gps (2.7Gbps per lane)
A maximum resolution of 2560x1600 pixels
Kramer re-Klocking™ and Equalization Technology, which rebuilds the
digital signal to travel longer distances
HDCP compliance
High-resolution and rich colors and transports audio and multiple video
streams
A worldwide power supply – 100-240V AC
A standard 19” rack-mount size - 1U. Rack "ears" are included
3.1 Defining the VM-4DP 1:4 DisplayPort Distributor
This section defines the VM-4DP.
VM-4DP - Overview
5
VM-4DP – Overview
5
#
Feature
Function
1
POWER LED
Illuminates when receiving power
2
ACTIVE LED
Illuminates when the input is active
3
READ Button
Press to read the EDID of the selected display
4
SELECT Button
Select the desired output from which to acquire the EDID information
5
OUTPUT LEDs
LEDs light when an output(s) is connected and active; LEDs flash when selecting EDID (see Section 6)
Figure 1: VM-4DP 1:4 DisplayPort Distributor Front Panel
6
VM-4DP - Overview
#
Feature
Function
6
INPUT DisplayPort Connector
Connects to the DisplayPort source
7
OUTPUT DisplayPort Connectors
Connect to the DP acceptors (from 1 to 4)
8
PROGRAM 9-pin D-sub port
Use to program the unit
9
Power Connector with Fuse
AC connector enabling power supply to the unit
10
POWER Switch
Illuminated switch for turning the unit ON or OFF
6
VM-4DP – Overview
Figure 2: VM-4DP 1:4 DisplayPort Distributor Rear Panel
VM-4DP - Installing in a Rack
7
4 Installing in a Rack
This section provides instructions for rack mounting the unit.
8
VM-4DP - Connecting the VM-4DP
Always switch off the power to each device before connecting it to your
VM-4DP. After connecting your VM-4DP, connect its power and then
switch on the power to each device.
i
5 Connecting the VM-4DP
To connect the VM-4DP as illustrated in the example in Figure 3:
1. Connect a DP source (for example, a computer graphics source) to the DP
INPUT connector.
2. Connect the DP output connectors (not all the outputs need to be
connected), to up to four DP acceptors (for example, displays).
3. Connect the power cord to the mains electricity (not shown in Figure 3).
4. Turn ON the POWER on the rear panel.
5. Acquire the EDID, see Section 6.
Figure 3: Connecting the VM-4DP 1:4 DisplayPort Distributor
VM-4DP - Acquiring an EDID
9
6 Acquiring an EDID
The VM-4DP initially operates with the default EDID. This means that you can turn ON
the power before connecting any of the acceptors or the source.
You can acquire the EDID from:
The default EDID, see Section 6.1
A connected output, see Section 6.2
6.1 Acquiring the Default EDID
To acquire the default EDID, do the following:
1. Press the SELECT button, as required, to reach a disconnected output.
The selected output LED flashes.
2. Press the READ button.
The READ button flashes.
The new EDID of the selected output is stored in the non-volatile memory
and passed to the input when the READ button no longer flashes.
6.2 Acquiring the EDID from a Connected Output
To acquire the EDID, from a selected output, do the following:
1. Press the SELECT button, as required, to reach the desired connected
2. Press the READ button.
output from which you want to acquire the EDID.
The selected output LED flashes.
The READ button flashes.
The new EDID of the selected output is stored in the non-volatile memory
and passed to the input when the READ button no longer flashes.
10
VM-4DP - Upgrading the Firmware
7 Upgrading the Firmware
For instructions on upgrading the firmware see “Upgrading the VM-4DP Firmware
Using the STC Software”.
VM-4DP - Technical Specifications
11
INPUT:
1 DisplayPort connector
OUTPUTS:
4 DisplayPort connectors
MAX. DATA RATE:
10.8Gps (2.7Gbps bandwidth per lane)
COMPLIANCE WITH
STANDARDS:
Supports DisplayPort 1.1 and HDCP 1.3
CONTROLS:
SELECT and READ buttons for selecting and storing
EDID information
INDICATOR LEDs:
OUTPUTS 1 to 4, ACTIVE LED and POWER LED
POWER CONSUMPTION:
100-240V AC, 23VA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
19" x 7" x 1U W, D, H rack mountable
WEIGHT:
2.5kg (5.5lbs) approx.
ACCESSORIES:
Power cord, rack “ears”
Specifications are subject to change without notice at http://www.kramerelectronics.com
8 Technical Specifications
12
VM-4DP - Technical Specifications
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N:
2900-000732
Rev:
2
!
SAFETY WARNIN G
Disconnect the unit from the power
supply before opening and servicing
