Kramer Electronics, Ltd.
USER MANUAL
Model:
VM-30CA
1:3 Video Component / Audio Distributor
Contents
Contents
1
Introduction 1
2
Getting Started 1
2.1 Quick Start 1
3
Overview 3
4
Your VM-30CA 1:3 Video Component / Audio Distributor 4
5
Connecting the VM-30CA 5
6
Technical Specifications 7
Figures
Figure 1: VM-30CA 1:3 Video Component / Audio Distributor 4
Figure 2: Connecting the VM-30CA 1:3 Video Component / Audio Distributor 6
Tables
Table 1: VM-30CA 1:3 Video Component / Audio Distributor Features 4
Table 2: Technical Specifications of the VM-30CA 7
i
Introduction
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups1, which are clearly defined
by function.
Congratulations on purchasing your Kramer VM-30CA 1:3 Video Component
/ Audio Distributor, which is ideal for the following applications:
Duplication studios
Broadcasting, production, or presentation systems requiring high quality
signal distribution
Retail outlets or sports bars
The package includes the following items:
VM-30CA 1:3 Video Component / Audio Distributor
Power adapter (12V DC Input)
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables3
2.1 Quick Start
This Quick start chart summarizes the basic setup and operation:
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Download up-to-date Kramer user manuals from our Web site: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
1
Getting Started
2
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
3 Overview
The Kramer VM-30CA 1:3 Video Component / Audio Distributor is a high
performance 1:3 distributor for component video signals (HDTV compatible),
digital audio (S/PDIF) signals, and unbalanced stereo audio signals.
The VM-30CA accepts one:
Component video1 signal and distributes the signal to three identical outputs
using RCA connectors
Digital audio (S/PDIF) input and distributes it to three digital audio
(S/PDIF) outputs using RCA connectors
Unbalanced stereo audio input and distributes it to three unbalanced stereo
audio outputs using 3.5mm jacks
In addition, the VM-30CA features:
A video bandwidth of 400MHz that ensures transparent operation at the
highest resolutions
Front panel trimmers to control the level and EQ. of the Y, PB/CB, and
PR/CR video components
Audio level control for the unbalanced stereo audio outputs
The VM-30CA is housed in a desktop-sized enclosure, and is 12V DC fed.
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer VM-30CA
away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit2.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 Sometimes called YUV, or Y, B-Y, R-Y, or Y, Pb, Pr, or Y, Cb, Cr
2 For example: model number AD2512C, part number 2535-000251
3
Your VM-30CA 1:3 Video Component / Audio Distributor
4 Your VM-30CA 1:3 Video Component / Audio Distributor
Figure 1 and Table 1 define the front and rear panels of the VM-30CA:
Figure 1: VM-30CA 1:3 Video Component / Audio Distributor
Table 1: VM-30CA 1:3 Video Component / Audio Distributor Features
# Feature Function
1 POWER Switch Illuminated switch supplying power to the unit
2 LEFT Trimmer Adjust1 the left audio signal output level
3
4 LEVEL Trimmer Adjust1 the PR/CR output signal level
5
6 LEVEL Trimmer Adjust1 the PB/CB output signal level
7
8 LEVEL Trimmer Adjust1 the Y output signal level
9
10 Y RCA Connector
11 PB/CB RCA Connector Connect to the component video source
12
13 Y RCA Connectors
14 PB/CB RCA Connectors Connect to the component video acceptors (from OUT 1 to OUT 3)
15
16 S/PDIF INPUT RCA Connector Connects to the digital audio source
17 ANALOG AUDIO INPUT
3.5m Socket
18 S/PDIF OUT RCA Connector Connects to the digital audio acceptor (from 1 to 3)
19 ANALOG AUDIO OUT 3.5m
Socket
20 12VDC +12V DC connector for powering the unit
1 Insert a screwdriver into the small hole and carefully rotate it, to trim the appropriate level
4
RIGHT Trimmer Adjust1 the right audio signal output level
/Cr
R
EQ. Trimmer Adjust1 the PR/CR cable compensation equalization level
P
EQ. Trimmer Adjust1 the PB/CB cable compensation equalization level
Pb/Cb
Y
EQ. Trimmer Adjust1 the Y cable compensation equalization level
IN
PR/CR RCA Connector
OUT
PR/CR RCA Connectors
Connect to the unbalanced audio source
Connect to the unbalanced audio acceptor (from 1 to 3)
KRAMER: SIMPLE CREATIVE TECHNOLOGY
LEVEL
AUDIO
Connecting the VM-30CA
5 Connecting the VM-30CA
To connect a VM-30CA unit as the example in Figure 2 illustrates, do the
following1:
1. Connect a component video source (for example, an HDTV satellite receiver)
to the Y, PB/CB, and PR/CR IN RCA connectors, and to the S/PDIF INPUT
RCA connector.
2. Connect2 the:
Y, PB/CB, and PR/CR OUT 1 RCA connectors to the component video
acceptor (for example, a plasma display), and the digital audio S/PDIF3
OUT 1 RCA connector to an AV-Receiver
Y, PB/CB, and PR/CR OUT 3 RCA connectors and the digital audio
S/PDIF3 OUT 3 RCA connector to a home theater system (to which a
projector and speakers are connected)
3. Connect a 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2).
4. If required, adjust4 the audio level, the Y, PB/CB, and/or PR/CR output
signal level, and/or the Y, PB/CB, and/or PR/CR cable compensation
equalization level.
1 Switch OFF the power on each device before connecting it to your VM-30CA. After connecting your VM-30CA, switch on
its power and then switch on the power on each device
2 You can connect three component video output connectors to up to three component video acceptors. When less than three
outputs are required, connect only those outputs of the VM-30CA that are required, and leave the other outputs unconnected
3 Alternatively, connect the ANALOG AUDIO 3.5m socket (not shown in Figure 2)
4 Insert a screwdriver into the small hole and carefully rotate it, trimming the level
5
Connecting the VM-30CA
Figure 2: Connecting the VM-30CA 1:3 Video Component / Audio Distributor
6
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
6 Technical Specifications
Table 2 includes the technical specifications.
Table 2: Technical Specifications1 of the VM-30CA
INPUTS:
OUTPUTS:
MAX. OUTPUT LEVEL: VIDEO: 2.3Vpp AUDIO: 1.8pp (S/PDIF); 25dBm (analog)
BANDWIDTH (-3dB): VIDEO: 400MHz,
DIFF. GAIN: 0.03%
DIFF. PHASE: 0.03 Deg
K-FACTOR: <0.05%
S/N RATIO: VIDEO: 74dB AUDIO: 87dB (analog)
CONTROLS: Level: –4.1dB to +6.4dB; Equalization: 0dB to +6.3dB; Audio: –70dB to +6.2dB
COUPLING: VIDEO: DC AUDIO: Input: AC; Output: DC
AUDIO THD + NOISE: 0.065%
AUDIO 2nd HARMONIC: 0.002%
POWER SOURCE: 12V DC 500mA
DIMENSIONS: 21.5cm x 16.3cm x 4.4cm (8.4” x 6.4” x 1.7”) W, D, H
WEIGHT: 3.7 kg (8.2 lbs.) approx.
ACCESSORIES: Power supply
OPTIONS: RK-1 Rack adapter
1 component video (Y, Pb/Cb, Pr/Cr) 1Vpp, 0.7Vpp, 0.7Vpp / 75 on RCA connectors
1 digital audio (S/PDIF) 75 on RCA connectors
1 unbalanced stereo audio +4dBm (nominal)/50k on RCA connectors
3 component video (Y, Pb/Cb, Pr/Cr) 1Vpp, 0.7Vpp, 0.7Vpp / 75 on RCA connectors
3 digital audio (S/PDIF) 75 on RCA connectors
3 unbalanced stereo audio +4dBm (nominal)/150 on RCA connectors
AUDIO: >100kHz
Fully Loaded
1 Specifications are subject to change without notice
7
