KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
VM-2 HDCP xl
1:2 DVI Distributor
P/N: 2900-000510 Rev 3
VM-2HDCPxl – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the VM-2HDCPxl 1:2 DVI Distributor 5
4 Connecting the VM-2HDCPxl 6
4.1 Acquiring the EDID 7
5 Technical Specifications 9
Figures
Figure 1: VM-2HDCPxl 1:2 DVI Distributor 5
Figure 2: Connecting the VM-2HDCPxl 1:2 DVI Distributor 7
VM-2HDCPxl - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VM-2HDCPxl 1:2 DVI Distributor,
which is ideal for the following typical applications:
Multiple screen applications
Rental and staging
2
VM-2HDCPxl - Getting Started
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VM-2HDCPxl away from moisture, excessive sunlight
and dust
VM-2HDCPxl - Getting Started
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
VM-2HDCPxl - Overview
3 Overview
The Kramer VM-2HDCPxl is an HDCP (High-Bandwidth Digital Content
Protection) compatible 1:2 distribution amplifier for DVI-D (Digital) signals. Since
high-resolution DVI signals are very sensitive to cable quality and to PCB layout,
the VM-2HDCPxl uses a uniquely designed PCB which includes all buffering,
conditioning and amplifying circuitry to provide two high-level output signals.
In particular, the VM-2HDCPxl features:
Distribution of signals having resolutions up to WUXGA, including all HDTV
formats
A maximum data rate of 6.75Gbps (2.25Gbps per graphic channel)
Support for the DDWG DVI 1.0 standard
A built-in re-clocking block that re-generates the DVI signal, so that several
units may be cascaded
Reading and storage, in non-volatile memory, of the EDID block from one of
the outputs, so it can then provide the EDID information to the DVI source
even if the display device is not connected
I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID
handling and processing algorithm that ensures Plug and Play operation for
HDMI systems
Three DVI-I connectors, which are compatible with all types of DVI cables
A cost-effective solution for distributing the TMDS signals used for DVI, and
uses state-of-the-art line drivers on both outputs
VM-2HDCPxl - Overview
5
#
Feature
Function
1
EDID Button
Press to read the EDID of the selected display (see
section 4.1)
2
INPUT DVI Connector
Connect to the DVI source
3
IN LED
Lights when the input is active; flashes when the input is
not valid
4
OUTPUTS 1 LED
LED lights when OUTPUT 1 is connected and active;
LED flashes when selecting the EDID (see section 4.1)
5
OUTPUTS 2 LED
LED lights when OUTPUT 2 is connected and active;
LED flashes when selecting the EDID (see section 4.1)
6
ON LED
Lights when the unit is powered
7
OUTPUT 1 DVI Connector
Connect to the DVI acceptor 1
8
OUTPUT 2 DVI Connector
Connect to the DVI acceptor 2
9
5V DC
+5V DC connector for powering the unit
3.1 Defining the VM-2HDCPxl 1:2 DVI Distributor
This section defines the VM-2HDCPxl.
Figure 1: VM-2HDCPxl 1:2 DVI Distributor
6
VM-2HDCPxl - Connecting the VM-2HDCPxl
Always switch off the power to each device before connecting it to your
VM-2HDCPxl. After connecting your VM-2HDCPxl, connect its power
and then switch on the power to each device.
i
4 Connecting the VM-2HDCPxl
To connect the VM-2HDCPxl as illustrated in the example in Figure 2:
1. Connect a computer graphics source to the INPUT connector.
2. Connect the OUTPUT connectors to one or both DVI acceptors, as follows:
You do not have to connect both outputs.
OUTPUT 1 connector to DVI acceptor 1 (for example, a display)
OUTPUT 2 connector to DVI acceptor 2 (for example, a projector)
3. Connect the 5V DC power adapter (wall transformer) to the 5V DC socket
and connect the transformer to the mains electricity.
4. Acquire the EDID (see section 4.1).
VM-2HDCPxl - Connecting the VM-2HDCPxl
7
Figure 2: Connecting the VM-2HDCPxl 1:2 DVI Distributor
4.1 Acquiring the EDID
Initially, the VM-2HDCPxl operates with the factory default EDID. This lets you
connect the power before connecting one of the acceptors or the source.
This is usually done only once, when the machine is being set up in an installation. Once
acquired, the EDID is saved in non-volatile memory and further acquisition is not necessary
You can acquire the EDID from:
One output (the relevant output illuminates)
The default EDID (both output LEDs flash)
Two connected outputs, the auto-mix mode (both output LEDs illuminate)
The EDID acquired is a weighted average of all the connected outputs. For example, if
several displays with different resolutions are connected to the outputs, the acquired
EDID supports all the resolutions, as well as other parameters included in the EDID.
8
VM-2HDCPxl - Connecting the VM-2HDCPxl
When pressing the EDID button briefly, the OUTPUT LEDs indicate which type of
EDID was last acquired. If the:
OUTPUT 1 LED illuminates, the OUTPUT 1 EDID was stored in the
non-volatile memory
OUTPUT 2 LED illuminates, the OUTPUT 2 EDID was stored in the
non-volatile memory
OUTPUT 1 and OUTPUT 2 LEDs illuminate, the Auto-Mix EDID was stored
in the non-volatile memory
OUTPUT 1 and OUTPUT 2 LEDs flash, the Default EDID is stored in the
non-volatile memory
To acquire the EDID, do the following:
1. Connect the power.
2. Connect the output or outputs from which you want to acquire the EDID.
3. Press and hold the EDID button to select the desired EDID.
The OUTPUT LEDs illuminate in the following cycle: OUTPUT 1, OUTPUT
2, both illuminate (auto-mix) and both flash (default).
4. Release the button when reaching the desired set up.
The EDID is now acquired.
If you set the machine to acquire the EDID from an output that is not connected, the
default EDID is acquired.
VM-2HDCPxl - Technical Specifications
9
INPUT:
1 DVI, 1.2Vpp on a DVI Molex 24-pin female connector;
DDC signal 5Vpp (TTL)
OUTPUTS:
2 DVI, 1.2Vpp on DVI Molex 24-pin female connectors;
DDC signal 5Vpp (TTL)
COMPLIANCE WITH
STANDARDS:
Supports DVI 1.1 and HDCP
MAX RESOLUTION:
Up to WUXGA (1920x1200), 1080p
BANDWIDTH:
6.75Gbps (2.25Gbps per graphic channel)
CONTROLS:
EDID button for selecting and storing EDID information
POWER CONSUMPTION:
5V DC, 1.1A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.2cm x 2.4cm (4.7" x 2.8" 1.0") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-3T 19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
5 Technical Specifications
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N:
2900-000510
Rev:
3
!
SAFETY WARNIN G
Disconnect the unit from the power
supply before opening and servicing
