Introduction
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have redesigned
and upgraded most of our line, making the best even better! Our 1,000-plus
different models now appear in 11 groups1 that are clearly defined by
function.
Congratulations on purchasing your Kramer DigiTOOLS TP-551 HDMI Line
Transmitter and Kramer DigiTOOLS TP-552 HDMI Line Receiver which are
ideal for:
Home theater, presentation and multimedia applications
Rental and staging
The package includes the following:
TP-551 and/or TP-552
Power adapter (12V DC Input)
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories
and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
1
Getting Started
Connect the
2
DVD Player
Display
Connect the
input to the
2
1
Connect the
STP CAT5
cables
1
TP-551
TP-552
Plasma
TP-552 to
output
the
TP-551
2
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
3 Overview
The Kramer TP-551 and the TP-552 constitute a high quality HDMI line
transmitter / receiver system using two STP CAT 5e 24AWG cables1. The
transmission range between the HDMI source and the HDMI acceptor can be
extended to up to 60m (200ft)@1080i and 40m (130ft)@1080p.
This transmitter / receiver pair:
Supports up to 1.65Gbps bandwidth
Features enhanced EDID2 recall - the unit automatically stores and recalls
EDID settings in non-volatile memory from the output3, allowing
convenient and reliable connection to the source
Passes the HPD4 and CEC5 signals from the source to the display device
using the CAT 5e cables
The TP-551 HDMI Line Transmitter features:
An HDMI input and a pair of RJ-45 CAT 5 output connectors
Three status LEDs (input, output and power)
A high / low output gain selection button
The TP-552 HDMI Line Receiver features:
An HDMI output and a pair of RJ-45 CAT5 input connectors
Three status LEDs (input, output and power)
Four EQ. levels to enhance performance
1 You can also use CAT 6 cables. Using UTP (Unshielded Twisted Pair) might reduce the system range
2 Extended Display Identification Data
3 If an output is not connected, the unit recalls the internal default EDID
4 Hot Plug Detect
5 Consumer Electronics Control
3
Overview
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital1
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality.
In particular, HDMI2:
Provides a simple3 interface between any audio/video source, such as a
set-top box, DVD player, or A/V receiver and video monitor, such as a
digital flat LCD / plasma television (DTV), over a single lengthy4 cable
Supports standard, enhanced, high-definition video, and multi-channel
digital audio5 on a single cable
Transmits all ATSC HDTV standards and supports 8-channel digital
audio, with bandwidth to spare to accommodate future enhancements and
requirements
Benefits consumers by providing superior, uncompressed digital video
quality via a single cable6, and user-friendly connector
Is backward-compatible with DVI (Digital Visual Interface)
Supports two-way communication between the video source (such as a
DVD player) and the digital television, enabling new functionality such
as automatic configuration and one-button play
HDMI has the capacity to support:
Existing high-definition video formats (720p, 1080i, and 1080p/60), as
well as standard definition formats such as NTSC or PAL
1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
2 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
3 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
4 HDMI technology has been designed to use standard copper cable construction at up to 15m
5 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
6 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
4
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your HDMI Line Transmitter / Receiver
3.2 Defining EDID
The Extended Display Identification Data (EDID1) is a data-structure, provided by
a display, to describe its capabilities to a graphics card (that is connected to the
display’s source). The EDID enables the TP-551/TP-552 to “know” what kind of
monitor is connected to the output. The EDID includes the manufacturer’s name,
the product type, the timing data supported by the display, the display size,
luminance data and (for digital displays only) the pixel mapping data.
3.3 Recommendations for Achieving the Best Performance
To achieve the best performance:
Connect only good quality connection STP CAT 5e 24AWG cables, thus
avoiding interference, deterioration in signal quality due to poor matching,
and elevated noise-levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position your
TP-551/TP-552 away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit2.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
4 Your HDMI Line Transmitter / Receiver
This section describes the:
TP-551 HDMI Line Transmitter, see section 4.1
TP-552 HDMI Line Receiver, see section 4.2
4.1 Your TP-551 HDMI Line Transmitter
Figure 1, Figure 2, and Table 1 define the TP-551:
1 Defined by a standard published by the Video Electronics Standards Association (VESA)
2 For example: model number AD2512C, part number 2535-000251
5
Your HDMI Line Transmitter / Receiver
Top Side Panel
Lower Side Panel
Top Side Panel
Lower Side Panel
Figure 1: TP-551 HDMI Line Transmitter
1 HDMI IN Connector Connect to the HDMI source
2 A
3
4 12V DC +12V DC connector for powering the unit
5 INPUT LED Lights when an input is connected
6 OUTPUT LED Lights when an output is detected
7 POWER LED Lights when receiving power
8 OUTPUT GAIN
6
Figure 2: TP-551 (Top Side and Lower Side Panels)
Table 1: TP-551 HDMI Line Transmitter Features
# Feature Function
CAT 5 OUT RJ-45
Connector
(HIGH/LOW) Pushbutton
Connect to the CAT 5 IN A RJ-45 connector on the TP-552
Connect to the CAT 5 IN B RJ-45 connector on the TP-552
B
Press to select low output gain (for short cable lengths)
Release to select high output gain (for long cable lengths)
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your HDMI Line Transmitter / Receiver
Top Side Panel
Lower Side Panel
Top Side Panel
Lower Side Panel
4.2 Your TP-552 HDMI Line Receiver
Figure 3, Figure 4, and Table 2 define the TP-552:
Figure 3: TP-552 HDMI Line Receiver
# Feature Function
1 A
2
3 HDMI OUT Connector Connect to the HDMI acceptor
4 12V DC +12V DC connector for powering the unit
5 INPUT LED Lights when an input is detected
6 OUTPUT LED Lights when an output is connected
7 POWER LED Lights when receiving power
8 EQ. SELECT Pushbutton Adjust the cable compensation equalization level (see section 5.1)
CAT 5 IN RJ-45
Connector
Figure 4: TP-552 (Top Side and Lower Side Panels)
Table 2: TP-552 HDMI Line Receiver Features
Connect to the CAT 5 OUT A RJ-45 connector on the TP-551
Connect to the CAT 5 OUT B RJ-45 connector on the TP-551
B
7
Connecting the TP-551 and TP-552
5 Connecting the TP-551 and TP-552
You can use the TP-551 HDMI Line Transmitter with the TP-552 HDMI Line
Receiver to configure an HDMI transmitter/receiver system.
To connect the TP-551 to the TP-552, as illustrated in the example in Figure
5, do the following:
1. Connect the CAT 5 OUT A and B RJ-45 connectors on the TP-551 to the
CAT 5 IN A and B RJ-45 connectors on the TP-552 respectively, via two
STP CAT 5e 24AWG cables (see section 5.2).
2. On the TP-552, connect the HDMI OUT connector to an HDMI acceptor (for
example, a plasma display).
3. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity on both1 the TP-551 and the TP-552 (not
shown in Figure 5).
4. On the TP-551, set the OUTPUT GAIN2 to LOW or HIGH according to the
length of the CAT5 cables.
5. On the TP-551, connect an HDMI source (for example, a DVD player) to the
HDMI IN connector.
6. On the TP-552, adjust the equalization level (see section 5.1).
5.1 Adjusting the EQ. Level
To adjust the EQ. according to the cable length:
1. Press the EQ. SELECT button for about 3 seconds to enter the setup mode.
The INPUT or OUTPUT LEDs blink3.
2. Keep the EQ. SELECT button pressed to cycle through the four equalization
states, as defined in Table 3.
Table 3: Equalization Levels Setup
LED STATUS
INPUT LED OUTPUT LED
Blinking Off Short cable length
Blinking On Medium cable length
Off Blinking Long cable length
On Blinking Extra long cable length
Equalization Level Suitable for:
1 The TP-551/TP-552 does not include the Kramer power connect feature
2 Set to LOW for short cables and to HIGH for long cables
3 According to their current setup
8
KRAMER: SIMPLE CREATIVE TECHNOLOGY
DVD Player
Plasma
Connecting the TP-551 and TP-552
Display
Figure 5: Connecting the TP-551 / TP-552 HDMI Line Transmitter/Receiver
9
Connecting the TP-551 and TP-552
5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors
Table 4 and Figure 6 define the STP CAT5 PINOUT1, using a straight pin-topin cable with RJ-45 connectors:
Table 4: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN Wire Color PIN Wire Color
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8
Pair 4 7 and 8
Figure 6: CAT5 PINOUT
1 CAT 6 or similar (heavier gauge) cabling can also be used
10
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
6 Technical Specifications
Table 5 includes the technical specifications1.
Table 5: Technical Specifications of the TP-551 and TP-552
INPUTS: 1 HDMI connector 2 CAT5 IN on RJ-45 connectors
OUTPUTS: 2 CAT5 OUT on RJ-45 connectors 1 HDMI connector
BANDWIDTH: Supports up to 1.65Gbps bandwidth per graphic channel
SYSTEM RANGE: Up to 60m (200ft)@1080i and 40m (130ft)@1080p
CABLE TYPE: Dual STP CAT 5e 24AWG cables, CAT 6 cables can also be used
COMPLIANCE WITH
HDMI STANDARD:
POWER SOURCE: 12V DC, 440mA 12V DC, 330mA
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply
TP-551 TP-552
Using UTP (Unshielded Twisted Pair) might reduce the system range
Supports HDMI 1.2 and HDCP
1 Specifications are subject to change without notice
11
LIMIT ED WARRANT Y
Except as below, this warranty covers all defects in materia l or workmanship in this product. The following are not covered
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
initial technical adjustments (set-up), including adjustment of user co ntrols or programming. These costs are the
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
HOW LONG IS T HE WARRA NTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
WHO IS PROTECT ED?
Only the first purchase customer may enforce this warranty.
WHAT IS COVERED AND WHAT IS NOT COVERED
Kramer
by the wa rranty:
1. Any product which is n ot distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
www.kramerelectronics.com.
2. Any product, on which th e serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
IF reattached, removed or otherwise interfered with.
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) An y shipment of the product (claims must be presented to the carrier)
v) Removal or installation of the product
vi) An y other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories u sed in conjunction with the product
WHAT WE WILL PAY FO R AND WHAT WE WILL NOT PAY FOR
We will pay labor and material expenses for covered items. We will not pay for the following:
1. Removal or installations charg es.
2. Costs of
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
HOW YOU CA N GET WARRANTY SERVIC E
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the origina l dated invoice (or a copy) must be presented as proof of warranty
coverage, and shoul d be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authori zed dealer.
LIMITATIO N OF IMP LIED WARRANTI ES
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
EXCLUSION OF DAM AGES
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
1. Damage to other propert y caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss
of time, commercial loss; or:
2. Any other damages, whether incidental, cons equential or otherwise. Some count ries may not allow limitations on how long an
limitations and exclu sions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
NOTE:
This equipment has been tested to determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.
CFR-47: FCC* Rules and Regulations:
CAUTI ON!
generic emission standard.
Part 1:
Part 1: Residential, commercial and light industry environment".
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operat e t he
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
* FCC and CE approved using STP cable (for twisted pair products)
12
KRAMER: SIMPLE CREATIVE TECHNOLOGY
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
Caution
Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N: 2900-000225 REV 6
Loading...
