TP-121xl/TP-122xl – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 About the Power Connect™ Feature 3
2.4 Shielded Twisted Pair/Unshielded Twisted Pair 3
2.5 Recycling Kramer Products 3
3 Overview 4
4 Defining the TP-121xl Transmitter and TP-122xl Receiver 5
4.1 Defining the TP-121xl UXGA/Audio Line Transmitter 5
4.2 Defining the TP-122xl UXGA/Audio Line Receiver 7
5 Connecting the TP-121xl Transmitter and TP-122xl Receiver 8
6 Operating the TP-121xl and TP-122xl 10
6.1 Capturing the EDID 10
6.2 Adjusting the Level and Equalization on the TP-122xl 10
7 Wiring the Twisted Pair RJ-45 Connectors 11
8 Technical Specifications 12
Figures
Figure 1: TP-121xl UXGA/Audio Line Transmitter Front Panel 5
Figure 2: TP-121xl UXGA/Audio Line Transmitter Rear Panel 6
Figure 3: TP-122xl UXGA/Audio Line Receiver Front Panel 7
Figure 4: TP-122xl UXGA/Audio Line Receiver Rear Panel 7
Figure 5: Connecting the TP-121xl Transmitter and TP-122xl Receiver 8
Figure 6: TP Pinout Wiring 11
TP-121xl/TP-122xl - Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Thank you for purchasing the Kramer TOOLS® TP-121xl UXGA/Audio Line
Transmitter and/or TP-122xl UXGA/Audio Line Receiver that are ideal for:
Presentation and multimedia applications
Long range graphics distribution for schools, hospitals, stores and security
applications
2
TP-121xl/TP-122xl - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check
if firmware upgrades are available (where appropriate)
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the power cord that is supplied with the unit
Warning:
Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer TP-121xl and TP-122xl away from moisture,
excessive sunlight and dust
2.2 Safety Instructions
TP-121xl/TP-122xl - Getting Started
3
3
2.3 About the Power Connect™ Feature
The Power Connect™ feature here means that only one unit in a system, the
transmitter or receiver, needs to be connected to a power source when the
devices are within 60m (197ft) of each other. The Power Connect™ feature
applies as long as the cable can carry power and the distance does not exceed
60m on standard TP cable. (Heavier gauge cable may be used to extend the
Power Connect™ range.)
2.4 Shielded Twisted Pair/Unshielded Twisted Pair
We recommend that you use Shielded Twisted Pair (STP) cable, and stress that
the compliance to electromagnetic interference was tested using STP cable.
There are different levels of STP cable available, and we advise you to use the
best quality STP cable that you can afford. Our non-skew-free cable, Kramer
BC-STP is intended for analog signals where skewing is not an issue.
In cases where there is skewing, our Unshielded Twisted Pair (UTP) skew-free
cable, Kramer BC-XTP, may be advantageous, and UTP cable might also be
preferable for long range applications. In any event when using UTP cable, it is
advisable to ensure that the cable is installed far away from electric cables, motors
and so on, which are prone to create electrical interference.
2.5 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
