1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer SPK-WA511 On-Wall Active
Speakers, which are ideal for the following typical applications:
• Boardrooms • Presentation venues
• Conference rooms • Home theater
• Educational classrooms
The package includes one of each of the following items:
• A pair of SPK-WA511 Active Speakers
• An RCA cable (2 meters)
• A speaker cable for connecting the active speaker to the passive speaker (4
meters)
• An AC power cord (3 meters)
• A pair of U-shaped rotating mounting brackets with 4 mounting bracket
screws
• This user manual
SPK-WA511 - Introduction 1
i
i
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance high-resolution cables
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables (such as the Kramer BC-2S) to
avoid interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack into tight coils
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your Kramer SPK-WA511 away from moisture, excessive sunlight
and dust
To ensure that you obtain the best sound results, do not open the
housing of the passive speaker or the active speaker.
2 SPK-WA511 - Getting Started
