KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
RC-76M/RC-712M
P/N: 2900-300329 Rev 3
RC-76M/ RC-712M – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the RC-76M/RC-712M Room Controllers 5
4 Installing the RC-76M/RC-712M 8
4.1 Configuring the Room Controller Buttons 8
4.2 Mounting the Device 8
4.3 Connecting the Ethernet Port 11
4.4 Connecting the K-NET Port 12
4.5 Mounting the RC-76M/RC-712M onto the Merten Housing 12
5 Operating the RC-76M/RC-712M 16
6 Front Panel Button Labels 17
7 Technical Specifications 20
Figures
Figure 1: RC-76M/RC-712M Room Controller – Front Panel 5
Figure 2: RC-76M/RC-712M Room Controllers – Rear Panel 6
Figure 3: Merten Compatible Housing 9
Figure 4: Connecting the RC-712M 10
Figure 5: K-NET PINOUT Connection 12
Figure 6: Inserting the RC-76M/RC-712M 12
Figure 7: Securing the RC-76M/RC-712M 13
Figure 8: Placing the Frame 13
Figure 9: Button Cap Orientation with Label 14
Figure 10: Placing the Button Caps and Mounting the Device 14
Figure 11: Placing the Faceplates 15
Figure 12: Securing the Frame and Faceplates 15
Figure 13: Sample Button Label Sheet 19
RC-76M/ RC-712M - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer RC-76M and/or RC-712M, which are
ideal for the following typical applications:
Remote control and management of AV equipment in multimedia rooms,
such as classrooms, auditoriums, conference rooms
2
RC-76M/ RC-712M - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check
if firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer RC-76M/RC-712M away from moisture, excessive
sunlight and dust
RC-76M/ RC-712M - Getting Started
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
RC-76M/ RC-712M - Overview
3 Overview
The RC-76M and RC-712M are six and twelve−button configurable room
controllers for multimedia rooms. They control audio components, video
components and other room facilities such as lights and screens. They are
designed to be installed in compatible Merten System M on-wall boxes (frame and
housing).
RC-76M/RC-712M features:
6/12 configurable buttons - RGB backlit, front panel buttons, configured
using the K−Config configuration software
1 GPI/O port that can be configured by K−Config configuration software as a
digital input, digital output or analog input for interfacing with a variety of
devices such as sensors, switches, LEDs, or relays
Kramer Site-CTRL compatibility for network remote control and management
over the Ethernet port
2 bidirectional RS-232 ports for the control of AV equipment such as
projectors, LCD and PDP displays, power amplifiers, switchers and scalers
2 relay contact closure ports for the control of other room items related to an
AV system, such as, raising and lowering drapes, a screen or a projector
2 IR control ports with an IR learning receiver on the front panel that learns
commands from any IR remote
1 RS-485 port
A K-NET™ control channel that connects compatible user interfaces,
supplies power and controls data over a single cable
A USB port located on the front panel to connect to a computer for firmware
upgrade or for uploading the configuration file
Flexible control - via Ethernet and K−NET
Wall Plate Size - 2 gang EU, Merten compatible
RC-76M/ RC-712M - Overview
5
#
Feature
Function
1
6/12 Configurable Buttons
Button function is programmed by the K-Config
Configuration software
2
IR In Built-in IR Receiver
Use to learn the IR commands from a machine’s remote
control transmitter
3
USB Connector
Connect to a computer for firmware upgrade or for
uploading the configuration file
4
Button Cover Plate
Mounting Screw holes (2)
To secure the faceplates and frame to the Merten
compatible housing. Remove to access the USB ports
and IR learner.
3.1 Defining the RC-76M/RC-712M Room Controllers
Figure 1 defines the front panel of the RC-76M/RC-712M:
Figure 1: RC-76M/RC-712M Room Controller – Front Panel
6
RC-76M/ RC-712M - Overview
#
Feature
Function
5
K-NET Terminal Block Connector
Connect the GND pin to the Ground connection;
pin B (-) and pin A (+) are for RS-485, and the
+12V pin is for powering the unit
6
RS-485 Terminal Block Connector
Pins B (-) and A (+) are for RS-485;
Pin G may be connected to the shield (if required)
7
ETHERNET RJ-45 Connector
Connects to the PC or other serial controller
through computer LAN to control AV products
8
RELAY C1
Connect to low-voltage relay-driven device 1
9
GPIO/GND Terminal Block
Connector
Connect to various sensors, switches, LEDs, or
relays
10
IR 2 Terminal Block Connector
Connect to IR emitter cable 2
11
IR 1 Terminal Block Connector
Connect to IR emitter cable 1
12
Power Supply 2-pin Terminal
Block Connector
Connect +12V to +12V, ground to GND
13
RS-485 Terminator Switch
Slide the DIP-switch up to terminate the RS-485
line with a 120Ω load; down is for no termination
14
K-NET Terminator Switch
Slide the DIP-switch up to terminate the K-Net line
with a 120Ω load; down is for no termination
15
RS-232 (1) Terminal Block
Connector
Connects to a PC or the remote controller
16
RS-232 (2) Terminal Block
Connector
Connects to a PC or the remote controller
17
Program Switch
For technical support use only (should be set
downwards for normal operation)
Figure 2 defines the rear panel of the RC-76M/RC-712M:
Figure 2: RC-76M/RC-712M Room Controllers – Rear Panel
RC-76M/ RC-712M - Overview
7
#
Feature
Function
18
RESET Button
Press to reset to factory default definitions:
IP number 192.168.1.39, Mask – 255.255.0.0,
Gateway – 0.0.0.0
First, disconnect the power supply and then connect it
again while pressing the Reset button. The unit
powers up and loads its memory with the factory
default definitions and erases all stored preset
19
RELAY C2
Connect to low-voltage relay-driven device 2
8
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
We recommend that you configure the buttons before mounting the
device onto the Merten compatible on-wall box.
We recommend that you first detach the male connectors from the rear
panel, connect the relevant wires to them and then reconnect the
assembled male terminals to the unit just before installation in the on-wall
box.
i
i
4 Installing the RC-76M/RC-712M
To install the RC-76M/RC-712M:
Configure the buttons
Connect the cables
Mount the room controller onto the Merten compatible housing
Attach button caps with labels
Place the frame
Attach the faceplates
4.1 Configuring the Room Controller Buttons
Configure the 6 buttons for RC-76M and 12 buttons for RC-712M using the
K−Config configuration software via the USB port that is located on the front panel
on the board or the Ethernet port located on the rear panel. Use the IR learning
receiver on the front panel to read IR commands from any IR remote control. Note
that the device needs to be connected to the power to configure the buttons. The
K-Config user guide is available on our Web site at
http://www.kramerelectronics.com/support/product_downloads.asp
4.2 Mounting the Device
This section describes how to mount the RC-76M/RC-712M onto the Merten
compatible on-wall box (sold by Kramer, P/N: OWB-2G/M).
4.2.1 Connecting the Ports
The following diagrams illustrate a compatible 2 gang on- wall box, but installation
is similar with any compatible wall box.
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
9
Pass the appropriate cables through any of the four housing cable
pass-through openings on the sides of the box (see Figure 3).
Always switch off the power to each device before connecting it to your
RC-76M/RC-712M. After connecting your RC-76M/RC-712M, connect
its power and then switch on the power to each device.
i
i
Figure 3: Merten Compatible Housing
Although the illustration in Figure 4 shows the RC-712M, the following example
applies also to the RC-76M.
To connect the RC-76M/RC-712M as illustrated in the example in Figure 4:
1. Connect the IR outputs as follows:
Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the
DVD player 1
Connect an IR emitter to IR OUTPUT 2 and attach the emitter to the
DVD player 2
2. Connect the RS-232 ports (see Section 4.2.1.1) as follows:
Connect RS-232 port 1 to the projector
Connect RS-232 port 2 to the plasma display
10
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
3. Connect the RELAY terminal block connectors as follows:
Connect RELAY C and 1 to the screen
Connect RELAY C and 2 to the lighting system
4. Connect the GPI/O 1 port to a motion detector.
5. Connect the Ethernet port to a network.
Figure 4: Connecting the RC-712M
4.2.1.1 Connecting RS-232 Devices
You can control up to two AV devices such as a projector or an RS-232 display by
connecting them to the RC-76M/RC-712M via their RS-232 connection.
To connect a device to the RC-76M/RC-712M via RS-232:
Using a straight cable, connect pin 2 to TX, pin 3 to RX and pin 5 to GND on
the RS-232 terminal block connector of the RC-76M
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
11
4.2.1.2 Connecting RS-485 Devices
You can control up to one AV device by connecting it to the RC-76M/RC-712M via
its RS-485 connection.
To connect a device to the RC-76M/RC-712M via RS-485:
Connect the A (+) pin of the device to the A pin on the RS-485 terminal block
of the RC-76M/RC-712M
Connect the B (-) pin of the device to the B pin on the RS-485 terminal block of
the RC-76M/RC-712M
Connect the G pin of the device to the GND pin on the RS-485 terminal block
of the RC-76M/RC-712MRC-76M
If your device is the first or last device on the line, slide the RS-485 termination
switch up, otherwise make sure it is set to down (see Figure 1).
4.3 Connecting the Ethernet Port
The Ethernet connection of the RC-76M/RC-712M lets you perform all control
functions of the RC-76M/RC-712M over the Internet using a PC running the
Kramer Site-CTRL control program to control AV devices.
To connect the RC-76M/RC-712M to a network:
1. Connect the Ethernet port of the RC-76M/RC-712M to the Ethernet port on a
network hub or network router, via a straight cable with RJ-45 connectors.
2. At the other end, connect the Internet to a PC running Site-CTRL.
3. After connecting the Ethernet port, you have to install and configure it. For
detailed instructions on how to install and configure your Ethernet port, see
the K-Config Software Guide.
Available from our Web site at
http://www.kramerelectronics.com/support/product_downloads.asp.
12
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
If your device is the first or last
device on the line, slide the
K-NET termination switch up;
otherwise make sure it is set to
down (see Figure 1).
Figure 5: K-NET PINOUT Connection
4.4 Connecting the K-NET Port
The K-NET port is wired as shown in Figure 5.
4.5 Mounting the RC-76M/RC-712M onto the Merten Housing
After the cables are connected you can mount the device onto the housing. Note
that the illustrations in this section do not show the cables that are already
connected to the device and passing through the housing cable openings.
To mount the RC-76M/RC-712M:
1. Reconnect the detachable terminals to the rear panel
2. Gently place the RC-76M/RC-712M inside the housing, making sure that all
cables remain connected.
Figure 6: Inserting the RC-76M/RC-712M
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
13
3. Secure the unit to the housing by screwing the four 3.5x10 conical Philips
screws (supplied with the unit) into their 4 designated holes (see Figure 7).
Figure 7: Securing the RC-76M/RC-712M
4. Mount the frame over the device (see Figure 8).
Figure 8: Placing the Frame
14
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
ON
5. Insert the labels, as required, inside the button caps while holding the button
cap “wings” to the sides, as shown in Figure 9.
Figure 9: Button Cap Orientation with Label
6. Retaining this orientation, place each button cap, with the label to its correct
button (see Figure 10).
Figure 10: Placing the Button Caps and Mounting the Device
7. Place the faceplates over the frame while fitting the buttons in (for the
RC-76M you need to attach one button faceplate and one blank faceplate),
see Figure 11.
RC-76M/ RC-712M - Installing the RC-76M/RC-712M
15
Figure 11: Placing the Faceplates
8. Tighten the two M3x16 screws with Allen key (supplied) to fix the faceplates
and the frame to the housing (see Figure 12).
Note that if you need to reconfigure the buttons, simply remove these two
screws and remove the frame and faceplate to gain access to the IR learner
and USB port.
Figure 12: Securing the Frame and Faceplates
16
RC-76M/ RC-712M - Operating the RC-76M/RC-712M
5 Operating the RC-76M/RC-712M
You can operate your RC-76M/RC-712M via the front panel buttons or remotely by
AUX. keypad over K-NET.
The front panel buttons are configured using the K-Config software. For
instructions on using the software, see the K-Config Software Guide available from
our Web site www.kramerelectronics.com.
RC-76M/ RC-712M - Front Panel Button Labels
17
6 Front Panel Button Labels
The RC-76M/RC-712M are supplied with a button label sheet and 6/8 clear, button
caps to house the labels. Figure 13 illustrates a sample button label sheet.
18
RC-76M/ RC-712M - Front Panel Button Labels
RC-76M/ RC-712M - Front Panel Button Labels
19
Figure 13: Sample Button Label Sheet
20
RC-76M/ RC-712M - Technical Specifications
PORTS:
2 RS-232, 1 RS-485, 1 GPI/O and 1 K-NET on terminal
block connectors; 1 Ethernet on an RJ-45 connector;
1 USB for programming
OUTPUTS:
2 IR, 2 relays (36V AC or DC, 2A, 60VAC maximum on
non-inductive load)
DEFAULT IP SETTINGS:
IP number 192.168.1.39; Mask – 255.255.0.0;
Gateway – 0.0.0.0
POWER CONSUMPTION:
12V DC, 1.25A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
7.9cm x 2.8cm x 12.4cm (3.1" x 1.1” x 4.9") W, D, H
(with wall plate)
WEIGHT:
0.245kg (0.54lbs) approx.
ACCESSORIES:
Power supply, button caps, button labels
OPTIONS
Merten-compatible 2 gang on-wall box (housing and
frame, P/N: OWB-2G/M)
Specifications are subject to change without notice at http://www.kramerelectronics.com
7 Technical Specifications
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N:
2900-300329
Rev:
3
!
SAFETY WARNIN G
Disconnect the unit from the power
supply before opening and servicing
Loading...
