Kramer Electronics RC-63DLN User Manual
KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
RC-6 3D LN
Room Controller
P/N: 2900-300317 Rev 1
RC-63DLN – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 The RC-63DLN Room Controller Front Panel 5
3.2 The RC-63DLN Room Controller Rear Panel 6
4 Connecting the RC-63DLN Room Controller 10
4.1 Connecting RS-232 Devices 11
4.2 Connecting the K-NET Port 11
4.3 Grounding the RC-63DLN 11
5 Operating the RC-63DLN 13
5.1 Reset to Default Settings 13
6 Front Panel Button Caps and Labels 14
6.1 Installing the Front Panel Button Caps and Labels 17
7 Technical Specifications 19
Figures
Figure 1: RC-63DLN Front Panel 5
Figure 2: RC-63DLN Rear Panel for the USA 6
Figure 3: RC-63DLN Rear Panel for Europe 7
Figure 4: RC-63DLN European Version, Reset to Default Button 8
Figure 5: Connecting the RC-63DLN 10
Figure 6: K-NET PINOUT Connection 11
Figure 7: Grounding Connection Components 11
Figure 8: Sample Button Label Sheet 16
Figure 9: Button Cap Orientation without/with Label for USA version 17
Figure 10: Placing the Button Cap (Left – EU version, Right – US version) 17
RC-63DLN – Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined by
function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer RC-63DLN Room Controller which is
designed to let you remotely control an A/V system with ease, in a multimedia
classroom or conference room.
2
RC-63DLN - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer RC-63DLN away from moisture, excessive sunlight and
dust
2.2 Safety Instructions
RC-63DLN – Getting Started
3
K-NET™ is a proprietary Kramer protocol for interconnecting Kramer
units.
i
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims
to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country go
to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
RC-63DLN - Overview
3 Overview
The Kramer RC-63DLN is available as a 2 Gang wall plate for the USA or a 2 Gang
wall plate for Europe. It features 6 front panel buttons designed in two groups; one
group of 2 buttons, and another group of 4 buttons. Each group can be
programmed according to the user's requirements. The RC-63DLN has two LCD
labels, letting you program the required group label, as well as rolling text on the
display.
The RC-63DLN also includes:
A configurable digital volume control adjustment knob with five LEDs
Two relays for the simplified and centralized control of room functions (such
as lighting, closing blinds, screen settings, and so on)
An IR output, a bidirectional RS-232 port, and two K-NET ports
An IR-learner for the customized control of external sources, memorizing the
IR commands from different remote transmitters
A USB port is included for programming the RC-63DLN via a computer.
RC-63DLN – Overview
5
#
Feature
Function
1
6 Configurable
Buttons
A 2-button group and a 4-button group. Function is programmed
by the K-Config Configuration software
2
2 LCD Labels
LCD on a blue background, displays up to 8 characters at once
(programmed via the USB port). Set by the K-Config configuration
software
3
VOLUME LED
Lights red, indicating maximum volume
4
VOLUME LEDs
Light green, indicating volume level
3.1 The RC-63DLN Room Controller Front Panel
This section defines the front panel of the RC-63DLN.
Figure 1: RC-63DLN Front Panel
