Kramer Electronics PT-5T User Manual
KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
PT-5T/R
IR Extender/Repeater
P/N: 2900-300010 Rev 3
PT-5T/R – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the PT-5T/R IR Extender/Repeater 4
4 Connecting and Using the PT-5T/R IR Extender/Repeater 6
4.1 Identifying the IR Receiver and IR Emitters 6
4.2 Connecting the PT-5T/R IR Extender/Repeater 6
4.3 Using the PT-5T/R IR Extender/Repeater 7
5 Technical Specifications 8
Figures
Figure 1: PT-5T IR Extender/Repeater 4
Figure 2: PT-5R IR Extender/Repeater 5
Figure 3: IR Receiver and Emitter 6
Figure 4: Connecting the PT-5T/R 7
PT-5T/R - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer PT-5T/R IR Extender/Repeater, which
is ideal for the following typical applications:
High quality home theater installations
Studios, airports, offices and hospitals
Security and military applications
