Introduction
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solution s to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly
defined by function.
Congratulations on purchasing your PT-101Hxl HDMI Repeater, which is
ideal for:
• Multimedia installations
• Home cinema installations
The package includes the following items:
• PT-101Hxl HDMI Repeater
• Power adapter (5V DC)
• This user manual
2
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high performance high resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialt y AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
1
Getting Started
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
2
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
3 Overview
The Kramer Pico TOOLS PT-101Hxl is a high-quality repeater for HDMI
signals that connects between an HDMI source and an HDMI display. For
1080p resolution, it extends the transmission range up to 15m (50ft).
The PT-101Hxl features:
• A maximum data rate of 2.25Gbps
• HDTV compatibility
• HDMI and HDCP compliance
• Kramer Equalization & re-Klocking™ Technology that rebuilds
the digital signal to travel longer distances.
To achieve the best performance:
• Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching,
and elevated noise levels (often associated with low quality
cables)
• Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
PT-101Hxl away from moisture, excessive sunlight and dust
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all digital
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality. Note
that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.
1 Ensuring an all-digital rendering of video without the losses associat ed with analog interfac es and their unnecessar y digitalto-analog conversions
1
3
Overview
In particular, HDMI:
• Provides a simple
1
interface between any audio/video source, such as
a set-top box, DVD player, or A/V receiver and video monitor, such
as a digital flat LCD / plasma television (DTV), over a single
lengthy
• Supports standard, enhanced, high-definition video, and multi-
channel digital audio
2
cable
3
on a single cable
• Transmits all ATSC HDTV standards and supports 8-channel digital
audio, with bandwidth to spare to accommodate future enhancements
and requirements
• Benefits consumers by providing su perior, uncompressed digital
video quality via a single cable
4
, and user-friendly connector
• Is backward-compatible with DVI (Digital Visual Interface)
• Supports two-way communication between the video source (such as
a DVD player) and the digital television, enabling new functionality
such as automatic configuration and one-button play
HDMI has the capacity to support existing high-definition video formats
(720p, 1080i, and 1080p/60), as well as standard definition formats such as
NTSC or PAL.
3.2 About HDCP
gh-Bandwidth Digital Conte nt Prot ection (HDCP) standard
The Hi
digital video and audio signals transmitted over DVI or HDMI connections
between two HDCP-enabled devices to eliminate the reproduction of
copyrighted material. To protect copyright holders (such as movie studios)
from having their programs copied and shared, the HDCP standard provides
for the secure and encrypted transmission of digital signals.
5
, protects
1 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
2 HDMI technology has been designed to use standard copper cable construction at up to 15m
3 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
4 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
5 Developed by Intel
4
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your PT-101Hxl HDMI Repeater
4 Your PT-101Hxl HDMI Repeater
Figure 1 and Table 1 define the PT-101Hxl HDMI Repeater:
Figure 1: PT-101Hxl HDMI Repeater
Table 1: PT-101Hxl HDMI Repeater Features
# Feature Function
1 OUTPUT Connector Connects to the HDMI acceptor
2 ON LED Illuminates when receiving power. The POWER LED is colored:
3 INPUT Connector Connects to the HDMI source
4
5V DC
Green, when the 5V DC power source is connected but no input signal is
received,
Red, when an input signal is received and the 5V DC power source is
disconnected,
Orange, when both the 5V DC power source is connected and an input signal
is received
+5V DC connector for powering the unit
5
Connecting a PT-101Hxl HDMI Repeater
5 Connecti n g a PT-101Hxl HD MI Repeater
To connect the PT-101Hxl, as shown in the example in Figure 2, do the
following:
1. Con n e c t the HDMI source (for example, a BluRay DVD player) to the
INPUT connector.
2. Connect the OUTPUT connector to an HDMI acceptor (for example,
an HDMI display).
3. Connect the 5V DC power adapter to the power socket on the
PT-101Hxl and connect the adapter to the mains electricity.
The PT-101Hxl can be powered from the HDMI source, but for
maximum performance we recommend using the power supply
(supplied).
Figure 2: Connecting the PT-101Hxl HDMI Repeater
6
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
6 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications1 of the PT-101Hxl
INPUT: 1 HDMI connector
OUTPUT: 1 HDMI connector
BANDWIDTH: Supports up to 2.25Gbps bandwidth
COMPLIANCE WITH STANDARDS: Supports HDMI, HDCP
POWER SOURCE: 5V DC , 280mA
DIMENSIONS: 6.2cm x 5.2cm x 2.4cm (2.5" x 2.1" x 1.0") W, D, H
WEIGHT: 0.07kg (0.16lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-4PT rack adapter, Kramer HDMI cables2
1 Specifications are subject to change without notice
2 For best results, use Kramer cables such as the C-HM/HM series, the C-HM- DM series and/or our HDMI over f iber optics
C-FOHM/FOHM series
