Kramer Electronics FC-14 User Manual
Kramer Electronics, Ltd.
USER MANUAL
Model:
FC-14
RGBHV to Component Transcoder
Contents
Contents
1
Introduction 1
2
Getting Started 1
3
Overview 1
4
Your RGBHV to Component Transcoder 2
5
Using Your RGBHV to Component Transcoder 3
5.1 Converting an RGB Source 4
5.2 Converting an RGBS Source 5
5.3 Converting an RGBHV Source 6
5.4 Converting a VGA Source 7
6
Technical Specifications 8
Figures
Figure 1: FC-14 RGBHV to Component Transcoder 2
Figure 2: Converting from an RGB Camera to a BETACAM VCR 4
Figure 3: Converting from an RGBS Workstation to a Plasma Monitor 5
Figure 4: Converting from a High Resolution Graphics Source to a Plasma Monitor 6
Figure 5: Converting from a VGA Graphics Source to a Plasma Monitor 7
Tables
Table 1: Front Panel FC-14 RGBHV to Component Transcoder 3
Table 2: Rear Panel FC-14 RGBHV to Component Transcoder 3
Table 3: Technical Specifications of the FC-14 RGBHV to Component Transcoder 8
i
Introduction
1 Introduction
Dedication by Kramer Electronics since 1981, to the development and
manufacture of high quality video/audio equipment, makes the Kramer line
an integral part of the finest production and presentation facilities in the world.
In recent years, Kramer has redesigned and upgraded most of the line, making
the best even better! The Kramer line of professional video/audio electronics
is one of the most versatile and complete available, and is a true leader in
terms of quality, workmanship, price/performance ratio and innovation. In
addition to our high quality transcoders, we also offer excellent switchers and
matrices, distribution amplifiers, remote controllers, processors, interfaces
and computer-related products.
Congratulations on purchasing your Kramer FC-14 RGBHV to Component
Transcoder.
This product is ideal for displaying RGB video on:
Plasma monitors
Other display devices equipped with component video inputs
The package includes the following items:
FC-14 RGBHV to Component Transcoder
Power supply
This user manual and the Kramer concise product catalog/CD
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
3 Overview
The high quality Kramer FC-14 RGBHV to Component Transcoder is an
adjustment-free, multi-standard converter that converts RGB video to
component video (Y, B-Y, R-Y, sometimes called YUV or Y, Pb, Pr).
The FC-14 supports different sync variants on the RGB inputs:
Separate H & V (RGBHV)
Separate composite sync (RGBS)
Sync-on-green (RGsB)
Sync-on-all (RsGsBs)
1
Your RGBHV to Component Transcoder
In addition, the FC-14:
Recognizes any sync polarity and is compatible with both video level
(0.3V) and TTL level syncs
Transcodes any RGB video (progressive scan or interlaced) to component
format, making it ideal for standard definition video as well as for
high-definition video (VGA, SVGA and XGA)
Uses high quality analog circuitry – eliminating the artifacts associated
with digitizing and allowing the unit to operate with any video resolution!
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise levels
(often associated with low quality cables)
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer FC-14 in a
location free from moisture and away from excessive sunlight and dust
4 Your RGBHV to Component Transcoder
Figure 1 illustrates the front and rear panels of the FC-14. Tables 1 and 2
define the front and rear panels of the FC-14, respectively.
Figure 1: FC-14 RGBHV to Component Transcoder
2
