KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
6505
:5 S/PDIF Distributor
1
P/N: 2900-000420 Rev 2
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
3 Overview 3
3.1 Defining the 6505 1:5 S/PDIF Distributor 3
4 Connecting the 6505 4
5 Technical Specifications 5
Figures
UFigure 1: 6505 1:5 S/PDIF DistributorU 3
UFigure 2: Connecting the 6505 1:5 S/PDIF DistributorU 4
6505 – Contents i
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer 6505 1:5 S/PDIF Distributor, which is
ideal for the following typical applicat i ons:
• Video and audio production facilities
• Recording studios, for connecting a source to several acceptors
6505 - Introduction 1
i
!
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance, high-resolution cables
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables to avoid interference, deterioration
in signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack into tight coils
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your Kramer 6505 away from moisture, excess i ve sunlight and dus t
Caution: No operator serviceable parts inside the unit
Warning:
Warning:
2 6505 - Getting Started
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Disconnect the power and unplug the unit from the wall
before installing
