WP-2UT US PANEL SET Quick Start
P/N:
2900- 301412QS
Rev:
1
Scan for full manual
WP-2UT US PANEL SET Quick Start Guide
This guide helps you install and use your WP-2UT US PANEL SET for the first time.
Go to www.kramerav.com/downloads/WP-2UT
Step 1: Check what’s in the box
1 US-D faceplate, 1 US-D frame bracket and 1 US-D frame
1 Quick start guide
Step 2: Install the WP-2UT US PANEL SET
After mounting the device (see www.kramerav.com/downloads/WP-2UT) mount the faceplates (US) and frames as
shown in the illustrations below:
DECORA® design or similar frames are included in US-D models.
DECORA® is a registered trademark of Leviton Manufacturing Co., Inc.
We recommend that you use any of the following standard 1 Gang in-wall junction boxes (or their equivalent):
• US-D: 1 Gang US electrical junction boxes.
