Introduction

1

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups1, which are clearly defined
by function.

Congratulations on purchasing your Kramer VP-503xl UXGA Scan Converter
or VP-504xl UXGA/HD Scan Converter. This product is ideal for:

 Multimedia, board rooms, and video conferencing
 Any application where high quality conversion of graphical data signals to

video signals is required

 Set-top box and HD conversion to SD video (VP-504xl)
The package includes the following items:

 VP-503xl UXGA Scan Converter or VP-504xl UXGA/HD Scan Converter
 Power adapter (12V DC Input)
 Windows®-based Kramer control software2
 This user manual3

2 Getting Started

We recommend that you:
 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual
 Use Kramer high performance high resolution cables4

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Downloadable from our Web site at http://www.kramerelectronics.com
3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2

Overview

3

3 Overview

The Kramer VP-503xl is a high quality scan converter for down-scaling
computer graphics (VGA up to UXGA) to PAL or NTSC video.

The Kramer VP-504xl is a high quality scan converter for down-scaling
computer graphics and HD to PAL or NTSC video. It supports VGA up to
UXGA, as well as the HD resolutions: 480p, 576p, 720p and 1080i. The input
color space (RGB or YUV) is selected via a dipswitch1.

The high quality VP-503xl/VP-504xl:
 Has user-friendly front panel buttons for easy control of ProcAmp

functions, flicker-reduction, image optimization, one-touch freezing,
over-scanning and under-scanning

 Can save and recall up to four setups, which include picture setup2, input

setup and output setup, zoom and advanced features

 Outputs high quality composite video and s-Video (Y/C) simultaneously
 Enables you to select the video standard (PAL or NTSC)
 Can be controlled via the front panel buttons and via RS-232
 Is fed from an external 12V DC source, making it suitable for field

operation

To achieve the best performance:
 Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise­levels (often associated with low quality cables)

 Avoid interference from neighboring electrical appliances and position

your Kramer VP-503xl/VP-504xl away from moisture, excessive sunlight
and dust

4 Your VP-503xl/VP-504xl Scan Converter

This section describes the:

 VP-503xl UXGA Scan Converter (see section 4.1)
 VP-504xl UXGA/HD Scan Converter (see section 4.2)

1 See section 6.4
2 Brightness, contrast, saturation and flicker filter

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-503xl/VP-504xl Scan Converter

4

4.1 Your VP-503xl UXGA Scan Converter

Figure 1, Figure 2 and Table 1 describe the VP-503xl:

Top Side Panel

Lower Side Panel

Figure 1: VP-503xl UXGA Scan Converter

Top Side Panel

Lower Side Panel

Figure 2: VP-503xl UXGA Scan Converter (Top and Lower Side Panel)

Your VP-503xl/VP-504xl Scan Converter

5

Table 1: VP-503xl UXGA Scan Converter Features

# Feature Function

1 RS-232 DB 9F Port Connect to the PC or Remote Controller

2 INPUT HD15F Connector Connect to the computer graphics source
3 PAL Dipswitch Select the video standard (ON for PAL, OFF for NTSC)

4 CV OUT BNC Connector Connect to the composite video acceptor

5 Y/C OUT 4p Connector Connect to the s-Video acceptor

6 12V DC +12V DC connector for powering the unit

7 OS LED Lights when the image is over-scanned1

8 FREEZE LED Lights when the FREEZE button is pressed
9 MENU Button Press to enter the menu and adjust the Scan Converter features

10 ENTER / AUTO IMAGE

Button2

Press ENTER to accept the settings; press AUTO IMAGE to acquire
optimal screen display

11 - / FREEZE Button2 Press - to scroll down the menu; press FREEZE to freeze the video

image and features. Press again to disable

12 + / OS/US Button2 Press + to scroll up the menu; press OS/US to toggle between

over-scan1 and under-scan3

4.2 Your VP-504xl UXGA/HD Scan Converter

Figure 3, Figure 4 and Table 2 describe the VP-504xl:

Top Side Panel

Lower Side Panel

Figure 3: VP-504xl UXGA/HD Scan Converter

1 The displayed image, when set correctly, is larger than the screen (see section 6.1.3)
2 This button has dual functionality. When in the MENU mode, it functions according to the labeling above the button. When
not in the MENU mode, the labeling below the button takes precedence
3 The image is smaller than the screen, leaving a border around the image (see section 6.1.3)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-503xl/VP-504xl Scan Converter

6

Top Side Panel

Lower Side Panel

Figure 4: VP-504xl UXGA/HD Scan Converter (Top and Lower Side Panel)

Table 2: VP-504xl UXGA/HD Scan Converter Features

# Feature Function

1

RS-232 DB 9F Port Connect to the PC or Remote Controller

2 INPUT HD15F Connector Connect to the computer graphics or HD source

3

PAL, YUV Dipswitches

Select the video standard (ON for PAL, OFF for NTSC) and the
color space (ON for YUV, OFF for RGB)

4 CV OUT BNC Connector Connect to the composite video acceptor

5 Y/C OUT 4p Connector Connect to the s-Video acceptor

6 12V DC +12V DC connector for powering the unit

7 OS LED Lights when the image is over-scanned1

8 FREEZE LED Lights when the FREEZE button is pressed

9 MENU Button Press to enter the menu and adjust the Scan Converter features

10 ENTER / AUTO IMAGE

Button2

Press ENTER to accept settings; press AUTO IMAGE to acquire
optimal screen display

11 - / FREEZE Button Press - to scroll down the menu; press FREEZE to freeze the

video image and features. Press again to disable

12 + / OS/US Button Press + to scroll up the menu; press OS/US to toggle between

over-scan1 and under-scan3

1 The displayed image, when set correctly, is larger than the screen (see section 6.1.3)
2 This button has dual functionality. When in the MENU mode, it functions according to the labeling above the button. When
not in the MENU mode, the labeling below the button takes precedence
3 The image is smaller than the screen, leaving a border around the image (see section 6.1.3)

Connecting the VP-503xl/VP-504xl

7

5 Connecting the VP-503xl/VP-504xl

This section describes how to connect the:

 VP-503xl UXGA Scan Converter (see section 5.1)
 VP-504xl UXGA/HD Scan Converter (see section 5.2)

5.1 Connecting your VP-503xl UXGA Scan Converter

To connect your VP-503xl as the example in Figure 5 illustrates, do the
following1:

1. Connect a computer graphics source to the HD15F INPUT connector.

2. Connect the Y/C OUT 4p connector to the Y/C acceptor (for example, an
s-Video recorder) and/or the CV OUT BNC connector to the CV acceptor
(for example, a composite video recorder).

3. If required, connect a PC or controller to the RS-232 port (see section 5.3).

4. Set the dipswitches (see section 6.4.1).

5. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 5).

Adjust the Scan Converter features if required (see section 6.3).

1 Switch OFF the power on each device before connecting it to your VP-503xl. After powering up your VP-503xl, switch on
the power on each device. The VP-504xl connection is similar to that of the VP-503xl

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VP-503xl/VP-504xl

8

s-Video Recorder

Composite Video Recorder

Computer Graphics

Source

RS-232

Figure 5: Connecting the VP-503xl

Connecting the VP-503xl/VP-504xl

9

5.2 Connecting your VP-504xl UXGA/HD Scan Converter

To connect your VP-504xl as the example in Figure 6 illustrates, do the
following1:

1. Connect a high definition source2 to the HD15F INPUT connector (for
example, a set top box).

2. Connect the Y/C OUT 4p connector to the Y/C acceptor (for example, an
s-Video recorder) and/or the CV OUT BNC connector to the CV acceptor
(for example, a composite video recorder).

3. If required, connect a PC or controller to the RS-232 port (see section 5.3).

4. Set the dipswitches (see section 6.4.2).

5. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 6).

Adjust the Scan Converter features if required (see section 6.3).

1 Switch OFF the power on each device before connecting it to your VP-504xl. After powering up your VP-504xl, switch on
the power on each device
2 To connect a high definition source, use a breakout cable such as the Kramer C-GM/3RVF. If you have a VGA to a 5BNC
cable, use the RGB wires only. For direct wiring, see the table in Figure 6

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VP-503xl/VP-504xl

10

s-Video Recorder

Composite Video Recorder

RS-232

Set Top Box

Source

INPUT Connector PINOUT

PIN #

1

Pr

Y

Pb

2
3

Signal

Figure 6: Connecting the VP-504xl

Operating the VP-503xl/VP-504xl

11

5.3 Controlling via RS-232 (for example, using a PC)

To connect a PC to the VP-503xl/VP-504xl unit, using the Null-modem
adapter provided with the machine (recommended):

 Connect the RS-232 DB9 rear panel port on the VP-503xl/VP-504xl unit

to the Null-modem adapter and connect the Null-modem adapter with a
9-wire flat cable to the RS-232 DB9 port on your PC

To connect a PC to the VP-503xl/VP-504xl unit, without using a Null-modem
adapter:

 Connect the RS-232 DB9 port on your PC to the RS-232 DB9 rear panel

port on the Master VP-503xl/VP-504xl unit, as Figure 7 illustrates

Female DB9 (From PC)
PIN 4 Connected to PIN 6
PINS 8, 7, 1 Connected together

If a Shielded cable is used, connect the shield to PIN 5

PIN 5 Connected to PIN 5 (Ground)
PIN 3 Connected to PIN 2
PIN 2 Connected to PIN 3

Male DB9

Figure 7: Connecting a PC without using a Null-modem Adapter

6 Operating the VP-503xl/VP-504xl

You can operate your VP-503xl/VP-504xl via the front panel buttons, which
are dual-purpose buttons1 that function as:

 Quick-set buttons: AUTO IMAGE, FREEZE and OS/US, or
 Menu buttons: MENU, ENTER, – and +

This section describes how to:

 Use the Quick set buttons (see section 6.1)
 Use the set of menu buttons (see section 6.2)
 Use the Menu screen (see section 6.3)
 Set the dipswitches (see section 6.4)

1 Except for the MENU button

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Operating the VP-503xl/VP-504xl

12

6.1 Using the Quick-Set Buttons

The following sections describe the VP-503xl and VP-504xl quick set-buttons.

6.1.1 Using the AUTO IMAGE Button

The VP-503xl/VP-504xl assesses the image and improves its quality, by
automatically adjusting the phase, frequency and position, when the AUTO
IMAGE button is pressed.

For example, if your computer application switches resolutions (and frequency),
press the AUTO IMAGE button to automatically improve the picture quality.

6.1.2 Using the FREEZE Button

Press the FREEZE button to freeze the picture on the screen. The frozen picture is
displayed regardless of the signal on the input to the unit. This allows you, for
example, to change the programs on the PC, and set up the next image.

By pressing the FREEZE button again, the frozen image will be replaced by
the most current image on the input to the unit.

6.1.3 Using the OS/US Button

Press the OS/US button to toggle between over-scan and under-scan:
 Over-scan omits the border. The displayed image, when set correctly, is

larger than the screen1

 Under-scan (sometimes know as the Compress mode) leaves a border

around the image2

Over-scan Under-scan

Figure 8: Over-scanned and Under-scanned images

1 Making the data bigger and easier to read but running the risk of having some of it run off the edge of the screen
2 The image appears reduced in size with a margin around it so that none of the data gets lost

Operating the VP-503xl/VP-504xl

13

6.2 Adjusting the Display via the Menu Buttons

The set of menu buttons (MENU, ENTER,  and +) let you adjust the screen
settings. Use the menu buttons as follows:

 Press the MENU1 button to display the menu on the screen
 Press the MENU button again each time you want to return to the

previous menu level or exit the menu

 Press the + or - buttons to move up or down the menu respectively
 Press ENTER to accept changes
 Before exiting the menu, you can save settings2

6.3 Using the Menu

Using the main menu, you can adjust the screen display3. After pressing the
MENU button4, the main Menu5 appears on the screen. Use the menu buttons
to scroll through the menu and make the required adjustments. Table 3
defines the menu items.

Table 3: VP-503xl/VP-504xl Menu Items

Menu Items Function

Picture Setup Set the Contrast, Brightness, Sharpness and Saturation levels;

Set the Flicker Filter for flicker reduction6

TV Output Setup Set the H Center, H Width, V Center and V Height levels

VGA Input Setup Set the VGA Left, VGA Width, VGA Top and VGA Bottom levels

Zoom Set the zoom to ON to zoom the image; when the zoom is selected, pan the H and V

position

Advanced Select from seven different Test Patterns (for example, see Figure 9);

Select a test pattern to appear when no input is connected; and
Save up to 4 setups2 and recall them

Information Verifies the V Total Line, the H Timing, the V Timing, and the software version

1 Pressing the MENU button disables the quick-set buttons (AUTO IMAGE, FREEZE and OS/US)
2 See section 6.3.1.2
3 Screen adjustments apply to both CV and Y/C displays
4 Quick set-buttons are disabled
5 The menu times-out after 20 seconds of inactivity
6 The flicker filter essentially blends the value of vertically adjacent pixels to decrease the differences in adjacent odd/even
lines. This dramatically reduces the noticeable image flicker, but it also reduces the level of the vertical detail

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Operating the VP-503xl/VP-504xl

14

6.3.1 The Advanced Menu

The Advanced menu lets you select Test Patterns and Save and Recall setups.

6.3.1.1 Test Patterns

The VP-503xl/VP504xl stores seven test patterns. From the Advanced menu,
you can select a test pattern (from 1 to 7) to show on screen. Figure 9 shows
test pattern number 1.

Figure 9: Test Pattern Number 1

You can set a test pattern to appear on the screen when there is no input
connected to the VP-503xl/VP504xl. To do so, enter the Advanced menu,
select No Input and set a test pattern number. This test pattern will appear when
there is no input connected. For example, set No Input to 1 if you want test
pattern 1 (as in Figure 9) to appear when there is no input connected to the unit.

6.3.1.2 Save and Recall

The VP-503xl/VP-504xl lets you save and recall up to 4 setups (from setup 0
to setup 3). The Save mode stores all the menu settings1 in the selected setup
memory (0 to 3).

Saving Through the Advanced Menu

To save setup 1, for example:

1. Adjust the Picture Setup, the VGA Input Setup, the TV Output Setup, the
Zoom and panning, and the No Input number.

2. In the Advanced menu, select Save and set to number 1.

3. Press ENTER.
The setup is saved.

Recalling a Setup

To recall a setup select Recall from the advanced menu and select the setup
number you want to recall.

1 The Save mode saves the Picture setup, the TV Output setup, the VGA Input Setup, the Zoom setup, and the advanced setup
(test patterns)

Operating the VP-503xl/VP-504xl

15

6.4 Setting the Dipswitches for VP-503xl and VP-504xl

The following sections describe the dipswitch settings for the VP-503xl and
VP-504xl.

6.4.1 VP-503xl Dipswitch Settings

Figure 10 and Table 4 describe the factory default dipswitches setting for the
VP-503xl:

NTSC

N.U.

PAL

N.U.

ON

1 2

Figure 10: VP-503xl Dipswitches

Table 4: VP-503xl Dipswitch Settings

DIP Function Description

1 PAL/NTSC Determines the video standard to be used:

Set to OFF to select NTSC
Set to ON to select PAL

2 N.U Not Used

6.4.2 VP-504xl Dipswitch Settings

Figure 11 and Table 5 describe the factory default dipswitches setting for the
VP-504xl:

NTSC

RGB

PAL

YUV

ON

1 2

Figure 11: VP-504xl Dipswitches

Table 5: VP-504xl Dipswitch Settings

DIP Function Description

1 PAL/NTSC Determines the video standard to be used:

Set to OFF to select NTSC
Set to ON to select PAL

2 YUV/RGB Determines the input color space to be used:

Set to OFF to select RGB
Set to ON to select YUV

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

16

7 Technical Specifications

Table 6 includes the technical specifications.

Table 6: Technical Specifications1 of the VP-503xl/VP-504xl

INPUTS:

VP-503xl: 1 x VGA/ UXGA on an HD15F connector
VP-504xl: 1 x VGA/ UXGA, analog component HD on an HD15F connector

OUTPUTS:

1 composite video 1Vpp/75 on a BNC connector
1 Y/C (s-Video) 1Vpp / 75 ohms (Y), 0.3Vpp / 75 ohms (C) on a 4p

connector

MAX. OUTPUT LEVEL: 1Vpp

INPUT RESOLUTIONS:

VP-503xl: VGA up to UXGA
VP-504xl: VGA up to UXGA; 480p, 576p, 720p, 1080i (for 1080i, does not

support 50Hz)

CONTROLS: Front panel, RS-232 and OSD: ProcAmp video controls, Freeze,

Underscan / Overscan, Auto-image, 8 color bars

POWER SOURCE: 12VDC, 310mA

DIMENSIONS: 18.8cm x 11.4cm x 2.4cm (7.41" x 4. 5" x 0.95", W, D, H)

WEIGHT: 0.4 kg. (0.88 lbs.) approx.
ACCESSORIES: Power supply, mounting bracket

OPTIONS: VGA to 3RCA breakout cable C-GM/3RVF

1 Specifications are subject to change without notice

VP-503xl / VP-504xl Communication Protocol

17

8 VP-503xl / VP-504xl Communication Protocol

Set Command: YControl_TypeFunctionParamCR
 Reply: ZControl_TypeFunctionParamCRDoneCR

Get Command: YControl_TypeFunctionCR
Reply : ZControl_TypeFunctionParamCR

Example:

1. "Y0731CR" -> set Contrast value as 31
"Z0731CR"

2. "Y17CR" -> get current Contrast value
"Z1731CR" -> current Contrast value is 31
 : ASCII Code 0x20
CR : Ascii Code 0xD or 0xA
Table 7 defines the Set Commands:

Table 7: Set Commands

Control Type

Set Get

Function

Param Description

Keypad

0 N/A 0 N/A Menu

0 N/A 1 N/A Enter

0 N/A 2 N/A -

0 N/A 3 N/A +

0 N/A 4 N/A Auto Image

0 1 5

0: Off
1: On

Freeze

0 1 6

0: OS
1: US

OS/US

Picture Setup

0 1 7 -32~31 Contrast

0 1 8 -32~31 Brightness

0 1 9

0: Off
1: On

Sharpness

0 1 10 0~8 Flicker Filter

0 1 11 -32~31 Saturation

KRAMER: SIMPLE CREATIVE TECHNOLOGY

VP-503xl / VP-504xl Communication Protocol

18

Control Type

Set Get

Function

Param Description

TV Output Setup

0 1 12 -16~16 H Center

0 1 13 -16~16 H Width

0 1 14 -10~10 V Center

0 1 15 -10~10 V Height

VGA Input Setup

N/A 1 16 By input signal Max VGA Left

N/A 1 17 By input signal Min VGA Left

0 1 18

Max VGA Left ~
Min VGA Left

VGA Left

N/A 1 19 By input signal Max VGA Width

N/A 1 20 By input signal Min VGA Width

0 1 21

Max VGA Width ~
Min VGA Width

VGA Width

N/A 1 22 By input signal Max VGA Top

N/A 1 23 By input signal Min VGA Top

0 1 24

Max VGA Top ~
Min VGA Top

VGA Top

N/A 1 25 By input signal Max VGA Bottom

N/A 1 26 By input signal Min VGA Bottom

0 1 27

Max VGA Bottom ~
Min VGA Bottom

VGA Bottom

Zoom

0 1 28

0: Off
1: On

Zoom

N/A 1 29 By input/output signal Max Pan H-Pos

N/A 1 30 By input/output signal Min Pan H-Pos

0 1 31

Max Pan H-Pos ~
Min Pan H-Pos

Pan H-Pos

N/A 1 32 By input/output signal Max Pan V-Pos

N/A 1 33 By input/output signal Min Pan H-Pos

0 1 34

Max Pan V-Pos ~
Min Pan V-Pos

Pan V-Pos

Information

N/A 1 35 By input signal V total Line

N/A 1 36 By input signal H Timing

N/A 1 37 By input signal V Timing

N/A 1 38 Version

19

LIMITED WARRANTY

Kramer Electronics (hereafter Kramer) warrants this product free from defects in material and workmanship under the
following terms.

HOW LONG IS THE WARRANTY

Labor and parts are warranted for seven years from the date of the first customer purchase.

WHO IS PROTECTED?

Only the first purchase customer may enforce this warranty.

WHAT IS COVERED AND WHAT IS NOT COVERED

Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:

1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.

2. Any product, on which the serial number has been defaced, modified or removed.

3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature

ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presented to the carrier)
v) Removal or installation of the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product

WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR

We will pay labor and material expenses for covered items. We will not pay for the following:

1. Removal or installations charges.

2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.

3. Shipping charges.

HOW YOU CAN GET WARRANTY SERVICE

1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.

2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty coverage,
and should be included in any shipment of the product. Please also include in any mailing a contact name, company, address, and
a description of the problem(s).

3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.

LIMITATION OF IMPLIED WARRANTIES

All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.

EXCLUSION OF DAMAGES

The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer
shall not be liable for:

1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss
of time, commercial loss; or:

2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
NOTE: All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
This equipment has been tested to determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);

generic emission standard.
Part 1: Residential, commercial and light industry"

EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.

Part 1: Residential, commercial and light industry environment".

CFR-47: FCC Rules and Regulations:

Part 15: “Radio frequency devices
Subpart B – Unintentional radiators”

CAUTION!

Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or modifications to

the unit without the expressed approval of the manufacturer will void user authority to operate the equipment.

Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.

Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: [e-mail]

P/N: 2900-000198 REV 1

For the latest information on our products and a list of Kramer

distributors, visit our Web site: www.kramerelectronics.com,

where updates to this user manual may be found.

We welcome your questions, comments and feedback.

Caution

Safety Warning:

Disconnect the unit from the power supply before
opening/servicing.
