USER MANUAL
MODEL:
VP-439
Video Scaler
P/N: 2900-300415 Rev 3
www.kramerAV.com
VP-439 – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the VP-439 Video Scaler 5
4 Connecting the VP-439 7
5 Operating and Controlling the VP-439 9
5.1 Using the Front Panel Buttons 9
5.2 Using the CONTROL Buttons 9
5.3 Connecting to the VP-439 via RS-232 12
5.4 Operating via Ethernet 12
6 Using the Embedded Web Pages 16
6.1 Browsing the VP-439 Web Pages 17
6.2 The Input Select Page 18
6.3 The Device Settings Page 19
6.4 The Video Settings Page 22
6.5 The Audio Settings Page 23
6.6 The EDID Management Page 24
6.7 The About Page 28
7 Technical Specifications 29
7.1 Default Communication Parameters 30
8 The RS-232/Ethernet (UDP) Communication Protocol 31
8.1 Kramer Protocol 3000 Syntax 31
8.2 Kramer Protocol 3000 – Command List 34
8.3 Kramer Protocol 3000 – Detailed Commands 34
Figures
Figure 1: VP-439 Video Scaler 5
Figure 2: Connecting the VP-439 Video Scaler 8
Figure 3: Local Area Connection Properties Window 13
Figure 4: Internet Protocol Version 4 Properties Window 14
Figure 5: Internet Protocol Version 6 Properties Window 14
Figure 6: Internet Protocol Properties Window 15
Figure 7: The Input Select Page 18
Figure 8: The Device Settings Page 19
Figure 9: The Device Settings Page – Static IP Confirmation 19
Figure 10: The Device Settings Page – Selecting the New Firmware File 20
Figure 11: The Device Settings Page – Uploading the New Firmware File 20
Figure 12: The Device Settings Page – Uploading the New Firmware File 21
Figure 13: The Device Settings Page – New Firmware Updated 21
Figure 14: The Video Settings Page 23
Figure 15: The Audio Settings Page 23
Figure 16: The EDID Page 24
Figure 17: The EDID Page – Copying the Output 25
ii
VP-439 - Contents
Figure 18: The EDID Page –The Copy EDID Results 26
Figure 19: The EDID Page –Copying the Default EDID 27
Figure 20: The About Page 28
VP-439 - Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 14 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP
5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP
7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:
Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and
GROUP 14: Collaboration.
Congratulations on purchasing your Kramer VP-439 Video Scaler, which is ideal
for the following typical applications:
Education, small classrooms
2
VP-439 - Getting Started
Go to http://www.kramerav.com/downloads/VP-439 to check for up-to-date
user manuals, application programs, and to check if firmware upgrades are
available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VP-439 away from moisture, excessive sunlight and
dust
VP-439 - Getting Started
3
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics power supply that is
provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
VP-439 - Overview
3 Overview
The VP−439 is a high−performance digital scaler for computer graphics video,
composite and HDMI signals, including audio. It up− or down−scales the selected
HDMI, CV or computer graphics video/YPbPr input and outputs it to HDMI.
The audio input source is selectable from Web pages– either from the relevant
analog audio input, or de-embedded from the HDMI input. The audio output can
be delayed for lip-sync compensation, and is available on the analog stereo
output, as well as being embedded onto the HDMI output.
More specifically, the VP-439 features:
HDTV compatibility and scales to resolutions up to 1080p/WUXGA
Clean and quiet auto-switching that searches for valid signal when the input
signal is lost with no video glitches or audible clicks or noises
Automatic detection and selection of the audio source for the HDMI input.
Default selection is HDMI – if this is not present, then the machine uses the
audio from the analog input
Auto-power down if no valid input signal is detected for a period of 2 to 3
minutes, the HDMI output is shut down, and the PC output syncs are disabled
HDCP enabling/disabling
Analog audio inputs for the CV, PC and HDMI inputs
Lip sync delay
An On-Screen Display (OSD) for easy setup and adjustment, accessible via
the front-panel buttons
An OSD INFO screen showing the selected input source, input and output
resolutions, HDCP status, firmware version, etc.
A built-in ProcAmp for convenient adjustment of video parameters, such as
brightness, contrast, color, sharpness and hue
A non-volatile memory that retains the last settings used
Convenient setup and control options – front panel buttons, OSD, Web page
VP-439 - Overview
5
5
#
Feature
Function
1
INPUT
SELECT
Buttons
HDMI
Press to select the HDMI input
2
PC
Press to select the PC/VGA input
3
CV
Press to select the composite video input
4
RESET TO XGA/720p Button
Toggles between reset to 720p and reset to XGA.
If the button has not been pressed for more than 30
seconds, the first press resets to 720p
5
MENU Button
Press to activate the on-screen display (OSD). The
button is recessed to prevent unwanted tampering
with the unit (use a small pointed tool)
6
AUTO IMAGE/ENTER Button
Press to enter or confirm menu selections.
When not in the OSD menu, press to auto-position
the image on the screen.
7
◄ Button
Press to access the OSD menu, exit the OSD menu
and, when in the OSD menu, move to the previous
level in the OSD screen
8
▲/VOLUME UP/+ Button
Press to move up the menu list and to Increase
numerical values. When not within the OSD menu
mode, press to increase the output volume
9
► Button
Press to access sub-menu items and select from
several settings
10
▼/VOLUME DOWN/– Button
Press to move down the menu list and to decrease
numerical values. When not within the OSD menu
mode, press to reduce the output volume
3.1 Defining the VP-439 Video Scaler
Figure 1: VP-439 Video Scaler
6
VP-439 - Overview
#
Feature
Function
11
HDMI
HDMI IN Connector
Connects to an HDMI source
12
AUDIO 3.5mm Mini
Jack Connector
Connects to an unbalanced stereo audio source
13
VGA
PC IN 15-pin HD
Connector
Connects to a PC graphics source
14
AUDIO 3.5mm Mini
Jack Connector
Connects to an unbalanced stereo audio source
15
CV
CV IN RCA
Connector
Connects to a composite video source
16
LEFT/RIGHT RCA
Connectors
Connects to the left and right unbalanced stereo
audio source
17
HDMI
Output
OUTPUT DVI
Connector
Connects to an HDMI acceptor
18
LEFT/RIGHT RCA
Connectors
Connects to the left and right unbalanced stereo
audio acceptor
19
RS-232 9-pin D-type Connector
Connects to the PC or other controller
20
ETHERNET RJ-45 Connector
Connects to a PC or other controller over a network
21
5V DC Connector
+5V DC connector for powering the unit
VP-439 - Connecting the VP-439
7
7
Always switch off the power to each device before connecting it to your
VP-439. After connecting your VP-439, connect its power and then
switch on the power to each device.
4 Connecting the VP-439
To connect the VP-439 as illustrated in the example in Figure 2:
1. Connect an HDMI source (for example, from a Blu-ray player) to the HDMI
IN HDMI connector.
2. Connect a PC graphics and unbalanced stereo audio source (for example,
from a laptop PC) to the PC IN 15-pin HD and 3.5mm mini jack connectors.
3. Connect a composite video and unbalanced stereo audio source (for
example, from a DVD payer) to the CV IN RCA and LEFT/RIGHT RCA
connectors.
4. Connect the HDMI OUTPUT on a DVI-I connector and the LEFT/RIGHT
unbalanced stereo audio on two RCA connectors to an HDMI acceptor (for
example, to a display with speakers).
5. If desired, connect the ETHERNET RJ-45 connector to a control device (for
example, a PC).
8
VP-439 - Connecting the VP-439
Figure 2: Connecting the VP-439 Video Scaler
VP-439 - Operating and Controlling the VP-439
9
9
5 Operating and Controlling the VP-439
You can operate the VP-439 directly via the front panel buttons (see Section 5.1),
via the OSD menu (see Section 5.2).
5.1 Using the Front Panel Buttons
Press the VP-439 front panel buttons to select:
The required INPUT (HDMI, PC or CV)
A reset RESOLUTION (to XGA/720p)
A control operation, using the MENU, ENTER (when in the OSD menu), +
and – buttons
5.2 Using the CONTROL Buttons
The CONTROL buttons let you control the VP-439 via the OSD menu. Press the:
MENU button to enter the menu
The default timeout is set to 10 seconds.
ENTER (AUTO IMAGE) button to accept changes and to change the menu
settings (a selected value parameter appears yellow and when set, changes
back to blue)
The ENTER function is active when in the OSD menu
Arrow buttons to move through the OSD menu
On the OSD menu, select EXIT to exit the menu.
10
VP-439 - Operating and Controlling the VP-439
LEVEL 1
LEVEL 2
LEVEL 3
SELECTION
Contrast
value
Brightness
value
For the
PC input
Phase
value
Clock
value
H-Position
value
V-Position
Off/Low/Middle/High
FineTune
HDMI
HUE
Sets the color hue
SATURATION
Sets the color saturation
SHARPNESS
Sets the sharpness of the
NOISE
REDUCTION
Selects the noise reduction
level: OFF, HI, LOW and MID
(middle)
PC
PHASE
Sets the clock phase
CLOCK
Sets the clock frequency
H-POSITION
Sets the horizontal position of
the picture
V-POSITION
Sets the vertical position of the
CV
HUE
Sets the color hue
SATURATION
Sets the color saturation
SHARPNESS
Sets the sharpness of the
NOISE
REDUCTION
Selects the noise reduction
level: OFF, HI, LOW and MID
(middle)
H-POSITION
Sets the horizontal position of
the picture
V-POSITION
Sets the vertical position of the
Color
Red
value
Green
value
Blue
value
Input
Source
HDMI, PC/YPbPr, Video (CV)
Output
Size
Full / Over Scan / Under Scan / Letter Box /
Pan Scan /Best Fit
5.2.1 The OSD MENU
This table illustrates the MENU features and functions.
VP-439 - Operating and Controlling the VP-439
11
11
LEVEL 1
LEVEL 2
LEVEL 3
SELECTION
Output
Resolution
Select the output resolution from the menu:
Resolution:
Appears as:
Resolution:
Appears as:
NATIVE
1600x900
1600x900
640x480
VGA
480i
480I
800x600
SVGA
480p
480P
1024x768
XGA
720p60
720P60
1280x1024
SXGA
1080i60
1080I60
1600x1200
UXGA
1080p60
1080P60
Resolution
continued
1366x768
WXGA
576i
576I 1680x1050
WSXGA
576p
576P
1920x1200
WUXGA
720p50
720P50
1280x800
1280x800
1080i50
1080I50
1440x900
1440x900
1080p50
1080P50
NATIVE - Select NATIVE to select the output resolution from the EDID
of the connected HDMI monitor
Audio
Output Volume
Set the output volume
Input Volume
Set the input volume
Delay
OFF/40ms/110ms/150ms/Auto
Input
Automatic/Analog/Embedded
OSD
H-Position
value
V-Position
value
Timer
Off/5/6/7…/100
Background
Set the transparency of the OSD (100 is fully
transparent)
Display
Info/On/Off
Advanced
HDCP On Input
On/Off (disabled for PC and CV)
Auto SYNC Off
Off/Fast/Slow
Auto Input Scan
Off/On/HDMI+PC/HDMI+CV/CV+PC
Auto Image
On/Off (disabled for HDMI and CV)
Freeze
Freeze+Mute/Mute Only/Freeze Only
Ethernet
IP Mode
DHCP/Static
Static IP
IP Address
xxx.xxx.xxx.xxx
Subnet Mask
xxx.xxx.xxx.xxx
Def. Gateway
xxx.xxx.xxx.xxx
UDP Port
50000
IP Address
xxx.xxx.xxx.xxx
MAC Address
xx:xx:xx:xx:xx:xx
Timing Shift
When ON (recommended), implements a small shift
on the horizontal sync which may resolve instabilities
seen on some displays working at specific
resolutions
12
VP-439 - Operating and Controlling the VP-439
LEVEL 1
LEVEL 2
LEVEL 3
SELECTION
About
Source
The input source
Input
The input resolution
Output
The output resolution
IP Address
xxx.xxx.xxx.xxx
Version
Firmware version: x.xx
Factory
Reset
NO / YES
This type of connection is recommended for identifying the VP-439
with the factory configured default IP address.
5.3 Connecting to the VP-439 via RS-232
You can connect to the VP-439 via an RS-232 connection using, for example, a
PC. Note that a null-modem adapter/connection is not required.
To connect to the VP-439 via RS-232, connect the RS-232 9-pin D-sub rear panel
port on the product unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3,
and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC
5.4 Operating via Ethernet
You can connect to the VP-439 via Ethernet using either of the following methods:
Directly to the PC using a crossover cable (see Section 5.4.1)
Via a network hub, switch, or router, using a straight-through cable (see
Section 5.4.2)
Note: If you want to connect via a router and your IT system is based on IPv6,
speak to your IT department for specific installation instructions.
5.4.1 Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the VP-439 directly to the Ethernet port on
your PC using a crossover cable with RJ-45 connectors.
After connecting the VP-439 to the Ethernet port, configure your PC as follows:
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
VP-439 - Operating and Controlling the VP-439
13
13
3. Highlight the network adapter you want to use to connect to the device and
click Change settings of this connection.
The Local Area Connection Properties window for the selected network
adapter appears as shown in Figure 3.
Figure 3: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet
Protocol Version 4 (TCP/IPv4) depending on the requirements of your IT
system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears
as shown in Figure 4 or Figure 5.
14
VP-439 - Operating and Controlling the VP-439
Figure 4: Internet Protocol Version 4 Properties Window
Figure 5: Internet Protocol Version 6 Properties Window
VP-439 - Operating and Controlling the VP-439
15
15
6. Select Use the following IP Address for static IP addressing and fill in the
details as shown in Figure 6.
For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to
192.168.1.255 (excluding 192.168.1.39) that is provided by your IT
department.
Figure 6: Internet Protocol Properties Window
7. Click OK.
8. Click Close.
5.4.2 Connecting the Ethernet Port via a Network Hub or Switch
You can connect the Ethernet port of the VP-439 to the Ethernet port on a
network hub or using a straight-through cable with RJ-45 connectors.
5.4.3 Configuring the Ethernet Port
You can set the Ethernet parameters via the embedded Web pages.
16
VP-439 - Using the Embedded Web Pages
Operating Systems
Applicable Browser Versions and Higher
Windows 7
Chrome: 25
Internet Explorer: 9
Firefox 19
Opera: 11
Mac (PC)
Chrome: 25
Firefox: 19
Opera: 11
iOS
Chrome: 25
Safari (depends on the IOS version)
Opera: 11
Android OS
Chrome: 25
Opera: 11
6 Using the Embedded Web Pages
The VP-439 can be operated remotely using the embedded Web pages. The Web
pages are accessed using a Web browser and an Ethernet connection.
Before attempting to connect:
Perform the procedures in Section 5.4
Ensure that your browser is supported
The following operating systems and Web browsers are supported:
Note that some features might not be supported by some cellphone operating
systems.
VP-439 - Using the Embedded Web Pages
17
17
6.1 Browsing the VP-439 Web Pages
To browse the VP-439 Web pages:
1. Open your Internet browser.
2. Type the IP number of the device in the Address bar of your browser. For
example, the default IP number:
The Input Select Web page appears.
There are eight Web pages:
The Input Select page (see Section 6.2)
The Device Settings page (see Section 6.3)
The Video Settings page (See Section 6.4)
The Audio Settings page (see Section 6.5)
The EDID Management page (see Section 6.6)
The About page (see Section 6.7)
18
VP-439 - Using the Embedded Web Pages
6.2 The Input Select Page
Figure 7 shows the Input Select page that is also the first Web page. The column
on the left shows the Input Select page selected and below a list of all the other
available Web pages.
The model name, FW version and IP number appear on the lower left side of the
main page. The lower part of the screen lets you save the settings and upload a
saved setting.
Figure 7: The Input Select Page
Use the freeze icon ( ) to freeze a selected input and the blank button ( ). Use
VP-439 - Using the Embedded Web Pages
19
19
6.3 The Device Settings Page
The device Settings window (Figure 8) lets you upgrade the firmware and set the
Ethernet parameters.
Figure 8: The Device Settings Page
Any change in the device settings requires confirmation, as illustrated in the
example in Figure 9.
Figure 9: The Device Settings Page – Static IP Confirmation
20
VP-439 - Using the Embedded Web Pages
6.3.1 Firmware Upgrade
You can upgrade the firmware via the Device Settings page. To do so:
1. Choose the firmware file by clicking the Choose File button in the Firmware
upgrade line.
Figure 10: The Device Settings Page – Selecting the New Firmware File
2. Click the Upgrade button.
The new firmware is uploaded:
Figure 11: The Device Settings Page – Uploading the New Firmware File
VP-439 - Using the Embedded Web Pages
21
21
3. Once the file is uploaded follow the instructions on the Web page:
The new firmware is uploaded:
And then:
Figure 12: The Device Settings Page – Uploading the New Firmware File
4. After restarting the system you need to upload the Web page once again.
5. Make sure that the new version appears on the Web page lower left side:
Figure 13: The Device Settings Page – New Firmware Updated
22
VP-439 - Using the Embedded Web Pages
6.4 The Video Settings Page
Figure 14 shows the Output Settings page which varies for each selected input:
For the HDMI input:
For the PC input:
For the CV (Video) input:
VP-439 - Using the Embedded Web Pages
23
23
Figure 14: The Video Settings Page
The output settings, include the Resolution and Size, the Finetune items (which
are enabled for VGA inputs), and the picture settings.
6.5 The Audio Settings Page
The audio settings page lets you define the input audio level separately for each
input and the output level, you can set the Freeze state, the Delay and for the
HDMI input set the audio source (automatic, analog or embedded).
Figure 15: The Audio Settings Page
24
VP-439 - Using the Embedded Web Pages
6.6 The EDID Management Page
The EDID page lets you copy a selected resolution from the DVI output or the
default resolution (Default HDMI or Default VGA) to one or both inputs (HDMI and
PC).
Figure 16: The EDID Page
Figure 17 shows how to select a resolution (the DVI output in this example) and
select one or both inputs. To copy, click the Copy button:
VP-439 - Using the Embedded Web Pages
25
25
Figure 17: The EDID Page – Copying the Output
The EDID page displays the machine name, selected resolution, the audio
channels and deep color support.
After clicking the Copy button, the EDID page shows the copy EDID results:
26
VP-439 - Using the Embedded Web Pages
Figure 18: The EDID Page –The Copy EDID Results
Click Close to complete the EDID procedure.
In the same way you can read the default EDID:
VP-439 - Using the Embedded Web Pages
27
27
Figure 19: The EDID Page –Copying the Default EDID
28
VP-439 - Using the Embedded Web Pages
6.7 The About Page
The VP-439 About page lets you view the Web page version and Kramer
Electronics Ltd details.
Figure 20: The About Page
VP-439 - Technical Specifications
29
29
INPUTS:
1 HDMI with unbalanced stereo on a 3.5mm mini jack,
1 PC/HD (RGBHV/YPbPr) on a 15-pin HD connector with
unbalanced stereo on a 3.5mm mini jack,
1 composite video on an RCA connector with unbalanced
stereo on 2 RCA connectors
OUTPUTS:
1 HDMI on a DVI-I connector with unbalanced stereo on
2 RCA connectors
PORTS:
1 Ethernet on an RJ-45 connector, 1 RS-232 on a 9-pin
D-sub connector
OUTPUT COLORSPACE:
RGB/YPbPr
OUTPUT RESOLUTIONS:
1080i, 1080p, 576i, 576p, 720p, 1080i, 1080p, WXGA,
WSXGA, WUXGA, 1280x800, WXGA+, SXGA+,
NATIVE, VGA, SVGA, XGA, SXGA, UXGA, 480i, 480p,
1600x900
OUTPUT REFRESH RATE:
60Hz for computer graphics resolutions, 50/60Hz for
HDTV resolutions
PROCESSING DELAY:
30ms approx.
CONTROLS:
Front panel buttons, menu-driven OSD control, Web
page
POWER CONSUMPTION:
5V DC, 1.1A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
21.5cm x 16.1cm x 4.36cm (8.46” x 6.34” x 1.7”) W, D, H
WEIGHT:
1.1kg (2.43lb) approx.
INCLUDED ACCESSORIES:
Power supply
OPTIONAL ACCESSORIES:
RK-1 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
7 Technical Specifications
30
VP-439 - Technical Specifications
RS-232
Baud Rate:
9,600
Data Bits:
8
Stop Bits:
1
Parity:
None
Ethernet
To reset the IP settings to the factory reset values go to : Menu-> Factory-> RESET->Change
the option to YES and press Enter
IP Address:
192.168.1.39
Subnet mask:
255.255.255.0
Default gateway:
192.168.0.254
Default UDP Port #:
50000
Maximum UDP Ports:
1
Full Factory Reset
OSD
Go to : Menu-> Factory-> RESET->Change the option to YES and
press Enter
RS-232/Ethernet (UDP) Command Protocol
Command Format:
ASCII protocol 3000
Example (Route the video input to the output):
#ROUTE 12,1,2<cr>
7.1 Default Communication Parameters
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
31
31
Start
Address (optional)
Body
Delimiter
#
Destination_id@
Message
CR
Start
Body
Delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
Start
Address
Body
Delimiter
#
Destination_id@
Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3 Parameter3_1,Parameter3_2,…|…
CR
Start
Address (optional)
Body
delimiter
~
Sender_id@
Message
CR LF
Start
Address (optional)
Body
Delimiter
~
Sender_id@
Command SP [Param1 ,Param2 …] result
CR LF
8 The RS-232/Ethernet (UDP) Communication
Protocol
The VP-439 can be operated using serial commands from a PC, remote controller,
or touch screen. The unit communicates using the default Kramer Protocol 3000.
Kramer Protocol 3000 syntax (see Section 8.1)
Kramer Protocol 3000 commands (see Section 8.2)
Kramer Protocol 3000 detailed commands (See Section 8.3)
8.1 Kramer Protocol 3000 Syntax
Protocol 3000 communicates at a data rate of 9,600 baud, no parity, 8 data bits
and 1 stop bit.
8.1.1 Host Message Format
Simple Command
Command string with only one command without addressing:
Command String
Formal syntax with commands concatenation and addressing:
8.1.2 Device Message Format
Device Long Response
Echoing command:
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
32
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
SP = Space (ASCII 32 = 0x20)
8.1.3 Command Terms
Command
A sequence of ASCII letters ('A'-'Z', 'a'-'z' and '-').
Command and parameters must be separated by at least one space.
Parameters
A sequence of alphameric ASCII characters ('0'-'9','A'-'Z','a'-'z' and some special
characters for specific commands). Parameters are separated by commas.
Message string
Every command entered as part of a message string begins with a message
starting character and ends with a message closing character.
Note: A string can contain more than one command. Commands are separated by
a pipe ( '|' ) character.
Message starting character
'#' – For host command/query
'~' – For machine response
Device address (Optional, for K-NET)
K-NET Device ID followed by '@'
Query sign
'?' follows some commands to define a query request.
Message closing character
CR – For host messages; carriage return (ASCII 13)
CRLF – For machine messages; carriage return (ASCII 13) + line-feed (ASCII 10)
Command chain separator character
When a message string contains more than one command, a pipe ( '|' ) character
separates each command.
Spaces between parameters or command terms are ignored.
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
33
33
8.1.4 Entering Commands
You can directly enter all commands using a terminal with ASCII communications
software, such as HyperTerminal, Hercules, etc. Connect the terminal to the serial
or Ethernet port on the Kramer device. To enter CR press the Enter key.
( LF is also sent but is ignored by command parser).
For commands sent from some non-Kramer controllers like Crestron,
some characters require special coding (such as, /X##). Refer to the
controller manual.
8.1.5 Command Forms
Some commands have short name syntax in addition to long name syntax to allow
faster typing. The response is always in long syntax.
8.1.6 Command Chaining
Multiple commands can be chained in the same string. Each command is
delimited by a pipe character ( '|' ). When chaining commands, enter the message
starting character and the message closing character only once, at the
beginning of the string and at the end.
Commands in the string do not execute until the closing character is entered.
A separate response is sent for every command in the chain.
8.1.7 Maximum String Length
64 characters
34
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command
Short Form
Description
# Protocol handshaking
#HELP
List of commands
#BUILD-DATE?
Read device build date
#FACTORY
Reset to factory default configuration
#MODEL?
Read device model
#PROT-VER?
Read device protocol version
#VERSION?
Read device firmware version
#NET-MAC?
NTMC?
Get MAC address
#NET-IP
NTIP
Set device IP address
#NET-IP?
NTIP?
Get device IP address
#NET-GATE
NTGT
Set Gateway IP
#NET-GATE?
NTGT?
Get Gateway IP
#NET-MASK
NTMSK
Set device subnet mask
#NET-MASK?
NTMSK?
Get device subnet mask
#NET-DHCP
NTDH
Set DHCP mode
#NET-DHCP?
NTDH?
Get DHCP mode
#ROUTE
Set input source
#ROUTE?
Get input source
#DISPLAY?
Get output HPD status
#HDCP-MOD
Set input HDCP
#HDCP-MOD?
Display input HDCP status
#VID-RES
Set input/output resolution
#VID-RES?
Get input/output resolution
#VFRZ
Set freeze
#VFRZ?
Display freeze status
#AUD-LVL
Set audio level
#AUD-LVL?
Get audio level
#MUTE
Set audio mute
#MUTE?
Display audio mute status
#SCLR-AS
Set auto sync mode
#SCLR-AS?
Display auto sync status
#IMAGE-PROP
Set size mode
#IMAGE-PROP?
Display size status
#SCLR-AUDIO-DELAY
Set audio delay mode
#SCLR-AUDIO-DELAY?
Display audio delay status
8.2 Kramer Protocol 3000 – Command List
8.3 Kramer Protocol 3000 – Detailed Commands
This section describes the detailed commands list (see Section 8.3.3) as well as
the output resolutions key (see Section 8.3.1) and the input resolutions key (see
Section 8.3.2).
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
35
35
Resolution
Key
Resolution
Key
Resolution
Key
640x480
200
1440x900
208
1080i60
216
800x600
201
1400x1050
209
1080p60
217
1024x768
202
1680x1050
210
576p
218
1280x768
203
1600x1200
211
720p50
219
1360x768
204
1920x1080
212
1080i50
220
1280x720
205
1920x1200
213
1080p50
221
1280x800
206
480p
214
Native
222
1280x1024
207
720p60
215
Resolution
CV
PC
HDMI
YPbPr
Key
NTSC
0
PAL
1
640x480 @60Hz (VGA)
6 640x480 @72Hz (VGA)
8
640x480 @75Hz (VGA)
9 800x600 @56Hz (SVGA)
11
800x600 @60Hz (SVGA)
12
800x600 @72Hz (SVGA)
14
800x600 @75Hz (SVGA)
15
1024x768 @60Hz (XGA)
20
1024x768 @70Hz (XGA)
21
1024*768 @75Hz (XGA)
23
1152x864 @75Hz (XGA+)
27
1280x720 @60Hz
30
1280x768 @60Hz
33
1280x960 @60Hz
36
1280x1024 @60Hz
40
1280x1024 @75Hz
41
1360x768 @60Hz
43
1400x1050 @60Hz (SXGA+)
48
1440x900 @60Hz (WXGA+)
51
1600x1200 @60Hz (UXGA)
56
1680x1050 RB @60Hz (WSXGA)
61
1920x1080 @60Hz
65
1920x1200 RB @60Hz
66
1280x800 @60Hz
70
480I
74
576I
76
8.3.1 Output Resolutions Key
8.3.2 Input Resolutions Key
36
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Resolution
CV
PC
HDMI
YPbPr
Key
480P
75
576P
77
720P@50Hz
78
720P@60Hz
79
1080I@50Hz
80
1080I@60Hz
81
1080P@24Hz
82
1080P@30Hz
87
1080P@50Hz
84
1080P@60Hz
85
Command – HELP
Command Type – System-mandatory
Command Name
Permission
Transparency
Set: - - - Get:
HELP
End User
-
Description
Syntax
Set: - -
Get :
Get command list or help for specific
command
2 options:
1. #HELP␍
2. #HELP␠ command_name␍
Command – BUILD-DATE
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
BUILD-DATE
End User
-
Get: - -
-
Description
Syntax
Set:
Read device build date
#BUILD-DATE?␍
Get : - -
Response
~nn @BUILD-DATE␠ date␠ time␍␊
Parameters
date – Format: YYYY/MM/DD where YYYY = Year, MM = Month, DD = Day
time – Format: hh:mm:ss where hh = hours, mm = minutes, ss = seconds
8.3.3 The Commands
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
37
37
Command – FACTORY
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
FACTORY
End User
-
Get: - -
-
Description
Syntax
Set:
Reset device to factory defaults configuration
#FACTORY␍
Get : - -
Response
~nn @FACTORY␠ OK␍␊
Notes
This command deletes all user data from the device. The deletion can take some time.
Command – MODEL?
Command Type – System-mandatory
Command Name
Permission
Transparency
Set: - - - Get:
MODEL?
End User
-
Description
Syntax
Set: - -
Get :
Get device model
#MODEL?␍
Response
~nn @MODEL␠ model_name␍␊
Parameters
model_name – String of up to 19 printable ASCII chars
Command – PROT-VER?
Command Type – System-mandatory
Command Name
Permission
Transparency
Set: - - - Get:
PROT-VER?
End User
-
Description
Syntax
Set: - -
Get :
Get protocol version
#PROT-VER?␍
Response
~nn @PROT-VER␠ 3000:version␍␊
Parameters
Version – Format: XX.XX where X is a decimal digit
38
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command –VERSION?
Command Type – System-mandatory
Command Name
Permission
Transparency
Set: - - - Get:
VERSION?
End User
-
Description
Syntax
Set: - -
Get :
Get version number
#VERSION?␍
Response
~nn@VERSION␠ firmware_version␍␊
Parameters
firmware_version – Format: XX.XX.XXXX where the digits group are: major.minor.build version
Command – NET-MAC?
Command Type – Communication
Command Name
Permission
Transparency
Set: - - - Get:
NET-MAC?
End User
-
Description
Syntax
Set:
Get :
Get MAC address
#NET-MAC?␍
Response
~nn @NET-MAC␠ mac_address␍␊
Parameters
mac_address – Unique MAC address. Format: XX-XX-XX-XX-XX-XX where X is hex digit.
Command – NET-IP
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-IP
Administrator
-
Get:
NET-IP?
End User
-
Description
Syntax
Set:
Set device IP address
#NET-IP␠ P1 ␍
Get :
Get device IP address
#NET-IP?␍
Response
Set: ~nn @ NET-IP ␠ ip_address ␠OK␍␊
Get: ~nn @ NET-IP ␠ ip_address ␍␊
Parameters
P1 (valid IP address)= xxx.xxx.xxx.xxx
Notes
For proper settings consult your network administrator.
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
39
39
Command – NET-GATE
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-GATE
Administrator
-
Get:
NET-GATE?
End User
-
Description
Syntax
Set:
Set Gateway IP
#NET-GATE␠ P1 ␍
Get :
Get Gateway IP
#NET-GATE?␍
Response
Set: ~nn @ NET-GATE ␠ P1 ␠OK␍␊
Get: ~nn @ NET-GATE ␠ ip_address ␍␊
Parameters
P1 (valid IP address)=xxx.xxx.xxx.xxx
Notes
A network gateway connects the device via another network and maybe over the Internet. Be careful of
security problems. For proper settings consult your network administrator
Command – NET-MASK
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-MASK
Administrator
-
Get:
NET-MASK?
End User
-
Description
Syntax
Set:
Set device subnet mask
#NET-MASK␠ net_mask ␍
Get :
Get device subnet mask
#NET-MASK? ␍
Response
Set: ~nn @NET-MASK ␠ P1 ␠ OK␍␊
Get: ~nn @NET-MASK ␠ net_mask ␍␊
Parameters
P1 (valid IP address)=xxx.xxx.xxx.xxx
Response triggers
The subnet mask limits the Ethernet connection within the local network.
For proper settings consult your network administrator.
40
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command – NET-DHCP
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-DHCP
Administrator
-
Get:
NET-DHCP?
End User
-
Description
Syntax
Set:
Set DHCP mode
#NET-DHCP␠ P1 ␍
Get :
Get DHCP mode
#NET-DHCP?␍
Response
Set: ~nn @ NET-DHCP ␠ P1 ␠OK␍␊
Get: ~nn @ NET-DHCP ␠ mode ␍␊
Parameters
P1 – 0=Static IP; 1=DHCP
0 – Use static IP.
1 – Use DHCP. If unavailable, use IP as above.
Notes
Connecting Ethernet to devices with DHCP may take more time in some networks.
To connect with a randomly assigned IP by DHCP, specify the device DNS name (if available) using the
command “NAME”. You can also get an assigned IP by direct connection to USB or RS -232 protocol port
if available.
For proper settings consult your network administrator.
Command – ROUTE
Command Type –
Command Name
Permission
Transparency
Set:
ROUTE
End User
-
Get:
ROUTE?
End User
-
Description
Syntax
Set:
Set layer routing
# ROUTE ␠ P1,P2,P3 ␍
Get :
Get layer routing
# ROUTE? ␠ P1,P2 ␍
Response
~ nn @ ROUTE ␠ P1,P2,P3 ␍␊
Parameters
P1 (Layer number) –12=Video+Audio
P2 – 1=Scaler
P3 – video inputs (0~2) – 0=HDMI; 1=PC; 2=Video (CV);
Notes
This command replaces all other routing commands.
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
41
41
Command – DISPLAY?
Command Type - System
Command Name
Permission
Transparency
Set : - - - Get
DISPLAY?
End User
Public
Description
Syntax
Set: - -
Get:
Get output HPD status
#DISPLAY? ␠P1 ␍
Response
~ nn @DISPLAY ␠ P1 ␍␊
Parameters
P1 (Output number) – 0=DVI
Response triggers
After execution, response is sent to the com port from which the Get was received
Response is sent after every change in output HPD status ON to OFF
Response is sent after every change in output HPD status OFF to ON and ALL parameters (new EDID,
etc.) are stable and valid
Command – HDCP-MOD
Command Type – System
Command Name
Permission
Transparency
Set:
HDCP-MOD
Administrator
Public
Get:
HDCP-MOD?
End User
Public
Description
Syntax
Set:
Set HDCP mode
#HDCP-MOD ␠ P1,P2,P3 ␍
Get :
Get HDCP mode
#HDCP-MOD? ␠ P1,P2 ␍
Response
Set / Get : ~ nn @HDCP-MOD ␠ P1,P2,P3 ␍␊
Parameters
P1 (Input/Output) – 0=Input
P2 (Scaler number) –0=HDMI
P3 (Status) – Input: 0=Off; 1=On
Response triggers
Response is sent to the com port from which the Set (before execution) / Get command was received
Response is sent to all com ports after execution if HDCP-MOD was set any other external control device
(button press, device menu and similar) or genlock status changed
Notes
Set HDCP working mode on device input :
HDCP supported – HDCP_ON [default]
HDCP not supported – HDCP OFF
HDCP support changes following detected sink – MIRROR OUTPUT
42
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command – VID-RES
Command Type - Video
Command Name
Permission
Transparency
Set:
VID-RES
End User
Public
Get
VID-RES?
End User
Public
Description
Syntax
Set:
Set video resolution
#VID-RES ␠ P1,P2,P3,P4 ␍
Get:
Get video resolution
#VID-RES? ␠ P1,P2,P3 ␍
Response
~ nn @VID-RES ␠ P1,P2,P3,P4 ␍␊
Parameters
P1 –0=Input; 1=Output
P2 – 1=Scaler
P3 – 0
P4 - video resolutions – see output resolutions in Section 8.3.1 and input resolutions in Section 8.3.2
Response triggers
After execution, response is sent to the com port from which the Set /Get was received
After execution, response is sent to all com ports if VID-RES was set by any other external control device
(button press, device menu and similar)
Notes
1. “Set” command is only applicable for stage=Output
2. “Set” command with is_native=ON sets native resolution on selected output (resolution index sent = 0).
Device sends as answer actual VIC ID of native resolution
3. “Get” command with is_native=ON returns native resolution VIC, with is_native=OFF returns current
resolution
4. To use “custom resolutions” (entries 100-105), define them using command DEF-RES
Command - VFRZ
Command Type - Multiviewer
Command Name
Permission
Transparency
Set:
VFRZ
End User
Public
Get
VFRZ?
End User
Public
Description
Syntax
Set:
Set freeze on selected output
#VFRZ␠ P1,P2␍
Get:
Get output freeze status
#VFRZ?␠ P1␍
Response
~ nn @VFRZ␠P1, P2 ␍␊
Parameters
P1 – 1=Scaler
P2 – 0=Off; 1=On
Response Triggers
After execution, response is sent to the com port from which the Set/Get was received
After execution, response is sent to all com ports if VFRZ was set by any other external control device
(button press, device menu and similar)
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
43
43
Command – AUD-LVL
Command Type – Audio
Command Name
Permission
Transparency
Set:
AUD-LVL
End User
-
Get:
AUD-LVL?
End User
-
Description
Syntax
Set:
Set audio level in specific amplifier stage
#AUD-LVL␠ P1,P2,P3 ␍
Get :
Get audio level in specific amplifier stage
#AUD-LVL?␠ P1,P2 ␍
Response
~nn @AUD-LVL␠ P1,P2 ␍␊
Parameters
P1 (Input/Output)– 0=Input; 1=Output
P2 N/A
P3 – Input=0 to 100, ++/--; Output=0 to 110, ++/--
Command – Mute
Command Type – [Audio]
Command Name
Permission
Transparency
Set:
MUTE
End User
Public
Get:
MUTE?
End User
Public
Description
Syntax
Set:
Mute the selected output
# MUTE ␠ P1,P2 ␍
Get :
Mute the selected output
# MUTE? ␠ P1 ␍
Response
Set / Get : ~ nn @ MUTE ␠ P1,P2. ␍␊
Parameters
P1 – 1=Scaler
P2 – 0=Off; 1=On
Response triggers
Response is sent to the com port from which the Set (before execution) / Get command was received
After execution, response is sent to all com ports if CMD-NAME was set any other external control
device (button press, device menu and similar) or genlock status was changed
Notes
Mutes the selected audio output
44
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command – Scaler As?
Command Type – [Audio]
Command Name
Permission
Transparency
Set:
SCLR-AS
End User
Public
Get:
SCLR-AS?
End User
Public
Description
Syntax
Set:
Set the auto sync off timer
# SCLR-AS ␠ P1,P2 ␍
Get :
Get the auto sync off timer
definition
# SCLR-AS? ␠ P1 ␍
Response
Set / Get : ~ nn @ SCLR-AS ␠ P1,P2…. ␍␊
Parameters
P1 (Scaler Number) –1=Scaler
P2 (Off/On) – 0=Off; 1=Fast; 2=Slow
Response triggers
Response is sent to the com port from which the Set (before execution) / Get command was received
After execution, response is sent to all com ports if CMD-NAME was set any other external control
device (button press, device menu and similar) or genlock status was changed
Notes
Sets the Auto Sync features for the selected Scaler
Command – IMAGE PROP
Command Type – [Video]
Command Name
Permission
Transparency
Set:
IMAGE-PROP
End User
Public
Get:
IMAGE-PROP?
End User
Public
Description
Syntax
Set:
Set the image size
# IMAGE-PROP ␠ P1 ␍
Get :
Get the image size
# IMAGE-PROP? ␠ P1,…,P6 ␍
Response
Set / Get : ~ nn @ IMAGE-PROP ␠ P1,P2…. ␍␊
Parameters
P1 (Scaler number) – 1=Scaler
P2 (Status) – 0=Full; 1=Over Scan; 2=Under Scan; 3=Letter Box; 4=PanScan; 5=Best Fit
Response triggers
Response is sent to the com port from which the Set (before execution) / Get command was received
After execution, response is sent to all com ports if CMD-NAME was set any other external control
device (button press, device menu and similar) or genlock status was changed
Notes
Sets the image properties of the selected scaler
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
45
45
Command – SCALER-AUDIO-DELAY
Command Type – [Audio]
Command Name
Permission
Transparency
Set:
SCLR-AUDIO-DELAY
End User
Public
Get:
SCLR-AUDIO-DELAY?
End User
Public
Description
Syntax
Set:
Set the scaler audio delay
# SCLR-AUDIO-DELAY ␠ P1,P2 ␍
Get :
Get the scaler audio delay
# SCLR-AUDIO-DELAY? ␠ P1 ␍
Response
Set / Get : ~ nn @ SCLR-AUDIO-DELAY ␠ P1,P2 ␍␊
Parameters
P1 (Audio output number) –1=Scaler
P2 (Level selection) – 0=Off; 1=40ms; 2=110ms; 3=150ms; 4=Auto
Response triggers
Response is sent to the com port from which the Set (before execution) / Get command was received
After execution, response is sent to all com ports if CMD-NAME was set any other external control
device (button press, device menu and similar) or genlock status was changed
Notes
Sets the audio delay for the selected audio output
P/N:
2900-300415
Rev:
3
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
www.kramerAV.com
info@kramerel.com
Loading...
