Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years,
we have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/VP-427X or www.kramerav.com/downloads/VP-

427X to check for up-to-date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

Achieving Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference from neighboring electrical appliances that may adversely influence signal

quality.

• Position your Kramer VP-427X away from moisture, excessive sunlight and dust.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.

• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which is located on the bottom of the unit.

Kramer Electronics Ltd.

VP-427X – Introduction

2

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to
reduce the amount of WEEE sent for disposal to landfill or incineration by requiring it to be
collected and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment
on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your
particular country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

Congratulations on purchasing your Kramer VP-427X 4K HDBT/HDMI Receiver Scaler

Switcher.
VP-427X is a high−performance auto−switcher receiver with integrated scaler for 4K

HDMI™ over long−reach HDBaseT, with a local HDMI input and an HDMI output. VP-427X
receives the HDBaseT signal from a compatible transmitter, converts it to an HDMI signal

and up− or down−scales the picture to any resolution up to 4K@60Hz (4:4:4) set by the user

or automatically matching the resolution of the display connected to the HDMI output.

Exceptional Quality

• Auto Switcher Ease of Use — Automatically plays the switched source signal on the
connected display according to user–configured preferences, such as auto-scan or
last–connected input. When the user manually switches, by pressing a button, the auto
switching is overridden.

• Fast and clean AV Switching — Clean and instantaneous switching between inputs,
with smooth, fade-through-black, uninterrupted transitions between presented content
on the display, greatly enhancing end–users presentation experience.

• High–Performance Scaling Experience — Built–in ProcAmp high–resolution scaling
technology for optimal up or down image scaling and video signal auto–adjustment with
output–connected display capabilities to gain end–users valuable high presentation
experience.

• HDMI Signal Switching — HDCP 2.2 compliant, supporting deep color, x.v.Color™,
CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K,
and 3D as specified in HDMI 2.0.

• I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling,
processing, locking and pass–through algorithm ensures plug & play operation for
HDMI source and display systems.

Advanced and User-friendly Operation

• Display On/Off Operation — Meeting presentation is simplified by automatically turning
ON/OFF a CEC–enabled display when the presentation source is plugged in /
unplugged.

• Convenient Unit Control and Configuration Options — Local control via front panel

Kramer Electronics Ltd.

VP-427X – Introduction

3

source switching buttons and OSD menu. Distance control via RS–232 serial
commands transmitted by a PC, touch screen system or other serial controller.

• Easy, Cost–effective Maintenance — Local firmware upgrade via USB connector.

• Easy and Elegant Installation — Compact MegaTOOLS™ fan–less enclosure for

dropped–ceiling mounting, or side–by–side mounting of 2 units in a 1U rack space with
the recommended rack adapter

Flexible Connectivity

• Wired and Wireless Auto Switcher — When the receiver is connected to a wireless
connectivity device such as Kramer VIA, can automatically select between a wired
source at the transmitter or the wireless source at the receiver.

• High Performance Standard Extension — Professional HDBaseT extension for
providing long–reach signals over twisted–pair copper infrastructures. VP-427X is a
standard receiver that can be connected to any market–available HDBaseT–compliant
extension product. For optimum extension reach and performance, use recommended
Kramer cables.

• Audio De–embedding — The digital audio signal passing–through to the HDMI output,
is de–embedded, converted to an analog signal and sent to the stereo balanced analog
audio output. This enables playing the audio on a locally connected professional audio
system (such as DSP) and speakers, in parallel to playing it on the speakers connected
to the AV acceptor device (such as TVs with speakers).

• Bidirectional RS–232 Extension — Serial interface data flows in both directions,
allowing data transmission and device control.

Typical Applications

VP-427X is ideal for the following typical applications:

• Classrooms and lecture halls

• Meeting rooms

• Training facilities

• Collaborative classrooms

• Any space where BYOD support is required

Kramer Electronics Ltd.

VP-427X – Defining VP-427X

4

Defining VP-427X

This section defines VP-427X.

Figure 1: VP-427X 4K HDBT/HDMI Receiver Scaler Switcher Front Panel

#

Feature

Function

PROG USB Connector

Connect to a USB stick to perform firmware upgrades.

INPUTS

SELECT Button

Press to select the input (HDBT or HDMI).

HDBT LED

Lights blue when the HDBT input is selected.

HDMI LED

Lights blue when the HDMI input is selected.

MENU Button

Press to enter/exit the on-screen display (OSD) menu. Press
together with the – button to reset the output to 1080p resolution.

ENTER Button

In OSD, press to choose the highlighted menu item. Press together
with the FREEZE/+ button to reset the output to XGA resolution
(1024x768).

–

In OSD, press to move back through menus or decrement
parameter values.

FREEZE/+ Button

In OSD, press to move forward through menus or increment
parameter values. When not in OSD, press to freeze the display.

LINK LED

Lights blue when a link is established with the transmitter.

ON LED

Lights green when device is powered.

1 2 3 4 5 6 7 8 9

10

Kramer Electronics Ltd.

VP-427X – Defining VP-427X

5

Figure 2: VP-427X 4K HDBT/HDMI Receiver Scaler Switcher Rear Panell

#

Feature

Function

INPUTS

HDBT RJ-45
Connector

Connect to a transmitter (for example, the Kramer TP-580T).
HDMI Connector

Connect to an HDMI source (for example, kramer VIA GO2).

OUTPUT

HDMI Connector

Connect to an HDMI acceptor.

AUDIO 5-pin
Terminal Block
Connector

Connect to a balanced stereo audio acceptor.

REMOTE Contact-Closure
4-pin Terminal Block
Connector

Connect to contact closure switches, an occupancy sensor and/or
toggle switches (contact between the desired pin and GND pin), to
turn the display on or off (see Connecting the Remote-Control

Switches on page 11).

RS-232

CONTROL 3-pin
Terminal Block
Connector

Connect to a serial controller or PC to control device.

DATA 3-pin
Terminal Block
Connector

Connect to a serially controller or serially controlled device for
connectivity to the extended RS-232 port.

RELAY 3-pin Terminal Block
Connector

Relay contact pins: normally open (NO), normally closed NC and
common (C). Connect to a device to be controlled by a relay (for
example, a motorized projection screen).

12V DC Connector

Connect to the supplied power adapter.

11

12

13

14

15

16

17

18

19

Kramer Electronics Ltd.

VP-427X – Mounting VP-427X

6

Mounting VP-427X

This section provides instructions for mounting VP-427X. Before installing, verify that the
environment is within the recommended range:

• Operation temperature – 0 to 40C (32 to 104F).

• Storage temperature – -40 to +70C (-40 to +158F).

• Humidity – 10% to 90%, RHL non-condensing.

Caution:

• Mount VP-427X before connecting any cables or power.

Warning:

• Ensure that the environment (e.g., maximum
ambient temperature & air flow) is compatible
for the device.

• Avoid uneven mechanical loading.

• Appropriate consideration of equipment

nameplate ratings should be used for avoiding
overloading of the circuits.

• Reliable earthing of rack-mounted equipment
should be maintained.

• Maximum mounting height for the device is 2
meters.

Mount VP-427X in a rack

• Use the recommended rack adapter

(see www.kramerav.com/product/VP-427X).

Mount VP-427X on a surface using one of
the following methods:

• Attach the rubber feet and place the unit on a
flat surface.

• Fasten a bracket (included) on each side of the
unit and attach it to a flat surface
(see www.kramerav.com/downloads/VP-427X).

Kramer Electronics Ltd.

VP-427X – Connecting the 4K HDBT/HDMI Receiver Scaler Switcher

7

Connecting the 4K HDBT/HDMI Receiver Scaler Switcher

Always switch off the power to each device before connecting it to your VP-427X. After
connecting your VP-427X, connect its power and then switch on the power to each device.

Figure 3: Connecting to VP-427X

To connect VP-427X as illustrated in the example in Figure 3:

1. Connect an HDBT transmitter (for example, Kramer TP-780T) to the INPUT HDBT
RJ-45 port on the rear panel. The transmitter is connected to a BYOD laptop.

2. Connect an HDMI source (for example, Kramer VIA GO2) to the HDMI INPUT
connector .

3. Connect the HDMI OUT connector to an HDMI Acceptor (for example, a projector).

4. Connect the AUDIO OUT 5-pin terminal block connector to a balanced stereo audio
acceptor (for example, Kramer Tavor 5-O active speakers).

5. Connect the serially-controlled projector to the RS-232 DATA 3-pin terminal block
connector for control via RS-232 from the HDBT transmitter.

6. Connect the REMOTE 4-pin terminal block connector to remote buttons.

7. Connect the RELAY 3-pin terminal block connector to a projector screen

8. Connect the power adapter to the VP-427X and plug the adaptor to the mains
electricity (not shown in Figure 3).

11

12

13

14

16

15

18

Kramer Electronics Ltd.

VP-427X – Connecting the 4K HDBT/HDMI Receiver Scaler Switcher

8

Connecting the Output to a Balanced/Unbalanced

Stereo Audio Acceptor

The following are the pinouts for connecting the output to a balanced or unbalanced stereo
audio acceptor:

Figure 4: Connecting to a Balanced Stereo Audio

Acceptor

Figure 5: Connecting to an Unbalanced Stereo

Audio Acceptor

Connecting to VP-427X via RS-232

You can connect to VP-427X via an RS-232 connection using, for example, a PC.

VP-427X features an RS-232 3-pin terminal block connector to extend RS-232 signals via
VP-427X transmitter and receiver.

Connect the RS-232 terminal block on the rear panel of VP-427X to a device, as follows:
From the RS-232 9-pin D-sub serial port connect:

• Pin 2 to the TX pin on the VP-427X RS-232 terminal block

• Pin 3 to the RX pin on the VP-427X RS-232 terminal block

• Pin 5 to the G pin on the VP-427X RS-232 terminal block

RS-232 Device VP-427X

13

Kramer Electronics Ltd.

VP-427X – Connecting the 4K HDBT/HDMI Receiver Scaler Switcher

9

Wiring RJ-45 Connectors

This section defines the HDBT pinout, using a straight pin-to-pin cable with RJ-45
connectors.

It is recommended that the cable ground shielding be connected/soldered to the connector
shield.

EIA /TIA 568B

PIN

Wire Color

1

Orange / White

2

Orange

3

Green / White

4

Blue

5

Blue / White

6

Green

7

Brown / White

8

Brown

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

10

Operating and Controlling VP-427X

Principles of Operation

Flexible Auto Switching Policy

Set the switching policy to:

• Manual – Select an input manually and switching occurs whether a live signal is
present on the input or not.

• Auto – Auto Switching selection is performed according to either the Last Connected or
the Auto Scan policy.

See Setting Switching Mode on page 17.

OSD Configuration & Operation

Convenient OSD (On Screen Display) menus for easy configuration and switcher operation.
See Using the OSD Menu on page 11.

Auto Display On/Off via CEC

Auto display shut-down and wake-up, via HDMI CEC communication, for energy expenses
savings.

See Defining CEC on page 17.

Operating and Controlling the Device

Operate and control VP-427X by:

• Using the Front Panel Buttons on page 10.

• Connecting the Remote-Control Switches on page 11.

Using the Front Panel Buttons

Use VP-427X front panel buttons enable performing the following actions:

• Pressing the INPUT to cycle through and select an input.

• Using the MENU, ENTER (when in the OSD menu), + and – buttons to control the

device (see Using the OSD Menu on page 11).

• Pressing MENU and - to reset the resolution to 1080p.

2 5 7

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

11

• Pressing ENTER and + to reset the resolution to XGA.

• Pressing FREEZE to freeze the image.

Connecting the Remote-Control Switches

Control the display status via remote control switches

Momentarily connect the desired pin to the GND pin to select an input:

Pin Name

Function

TOGL

One button toggles between display on and display off (instead
of using two separate buttons for on and off). Alternatively,
using the VP-427X OSD, configure turning the display on and
off according to whether a switch is open or closed, for example,
using an occupancy sensor

OFF

Turn off the display (via CEC).

ON

Turn on the display (via CEC).

Using the OSD Menu

VP-427X enables controlling and defining the device parameters via the OSD, using the

front panel MENU buttons.

To enter and use the OSD menu buttons:

1. Press MENU.

2. Press:

▪ ENTER to accept changes and to change the menu settings.
▪ Arrow buttons to move through the OSD menu, which is displayed on the video

output.

▪ EXIT to exit the menu.

The default OSD timeout is set to 10 seconds.

OSD Values Table

Default values appear in bold in the following table.

Mode

Function


CONTRAST

Set the contrast (0~60) (30)

BRIGHTNESS

Set the brightness (0~60) (30)

FINETUNE

Connector

Function

Parameter

HDBT/HD
MI

HUE

0~60 (30)

SATURATION

0~60 (30)

SHARPNESS

0~63 (0)

6 8 8

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

12

Mode

Function

NOISE
REDUCTION

OFF, LOW, MIDDLE, HIGH,
AUTO

COLOR

Set the red, green, and blue shades 0 to 1023 (512)

INPUT

SOURCE

Select the source: HDBT, HDMI

OUTPUT

SIZE

Select the size of display: OVER SCAN, FULL, BEST FIT, PAN
SCAN, LETTER BOX, UNDER 2, UNDER 1, FOLLOW IN

RESOLUTION

Select the output resolution from the menu (Default, NATIVE)

640x480 @60Hz

800x600 @60Hz

1024x768 @60Hz

1280x768 @60Hz

1280x800 @60Hz

1280x1024 @60Hz

1360x768 @60Hz

1400x1050 @60Hz

1440x900 @60Hz

1600x1200 @60Hz

1680x1050 @60Hz

1920x1200 @60Hz RB

2560x1600 @60Hz
RB

1920x1080 @60Hz

1280x720 @60Hz
2048x1080 @50Hz

2048x1080 @60Hz

2560x1440 @60Hz RB

3440x1440 @30Hz

3440x1440 @60Hz

720x480P @60Hz

720x576P @50Hz

1280x72P @50Hz

1280x720P @60Hz

1920x1080P
@24Hz

1920x1080P
@25Hz

1920x1080P @30Hz

1920x1080P
@50Hz

1920x1080P
@60Hz

2560x1080P @50Hz

2560x1080P
@60Hz

3840x2160P
@24Hz

3840x2160P @25Hz

3840x2160P
@30Hz

3840x2160P
@50Hz

3840x2160P @60Hz
Native

AUDIO

DELAY

OFF,40ms, 110ms, 150ms (40ms)

OUTPUT
VOLUME

Value 0 ~ 100, (80 = 0db)

OSD

OFF by default.
Set the OSD parameters: H-POSITION; V-POSITION; TIMER 5~60 seconds, OFF

(20sec); TRANSPARENCY; DISPLAY (INFO/ON/OFF).

ADVANCED

HDCP ON
HDBT INPUT

ON/OFF

HDCP ON HDMI
INPUT

ON/OFF
HDCP(OUT)

FOLLOW INPUT/FOLLOW OUTPUT

AUTO SYNC
OFF

DISABLE/SLOW/FAST
AUTO SWITCH

OFF/AUTO SCAN/LAST CONNECTED

FREEZE

FREEZE + MUTE / ONLY FREEZE / ONLY MUTE

EDID MANAGE

Port

EDID Value

HDBT EDID

Def. 1080P

Def. 4K2K(3G)

Def. 4K2K(3G-4:2:0)

USER1

USER2

OUTPUT

HDMI EDID

Def. 1080P

Def. 4K2K(3G)

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

13

Mode

Function

Def. 4K2K(3G-4:2:0)

Def. 4K2K(6G)

USER1

USER2

OUTPUT

EDID UPLOAD

USER EDID UPLOAD

TOGGLE PIN

EDGE /ON /OFF / INPUT SELECT

RELAY

ON/OFF

OUTPUT CEC
BYPASS

ON/OFF
INFORMATION

Displays the source, the input and output resolution, and the software version.

FACTORY

Reset to factory default parameters (resolution is set to Native).

EXIT

Select to exit the menu.

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

14

Use the OSD menu to perform the following operations:

• OSD Values Table on page 11.

• Adjusting Image Parameters on page 14.

• Selecting an Input Signal on page 14.

• Setting Output Parameters on page 15.

• Setting Audio Parameters on page 15.

• Setting OSD Parameters on page 15.

• Managing EDID via OSD on page 15.

• Setting HDCP on page 16.

• Setting Sleep Mode on page 16.

• Setting Switching Mode on page 17.

• Defining FREEZE Button Operation Mode on page 17.

• Defining CEC on page 17.

• Configuring TOGGLE Pin Behavior on page 18.

• Viewing Device Information on page 18.

• Performing a Reset on page 18.

Adjusting Image Parameters

VP-427X enables adjusting the image parameters such as contrast, brightness and so on.

To adjust the image parameters:

1. On the front panel press MENU. The menu appears.

2. Click Picture and define the image parameters according to the information in the OSD
Values table (see OSD Values Table on page 11).

Image parameters are adjusted.

Selecting an Input Signal

Select the VP-427X input source via the OSD menu.

To set the input source:

1. On the front panel press MENU. The menu appears.

2. Click Input and select the Source: HDBT (default) or HDMI.

An input signal is selected.

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

15

Setting Output Parameters

VP-427X enables setting output parameters such as the size of the image and output

resolution via the OSD MENU buttons.

To set the output parameters:

1. On the front panel press MENU. The menu appears.

2. Click Output and define the output parameters according to the information in the
table.

Image size and output resolution are defined.

Setting Audio Parameters

VP-427X enables defining the audio delay time and output volume.

To set the audio:

1. On the front panel press MENU. The menu appears.

2. Click Audio and define the following:

▪ Set the audio delay time (lip sync) to off, 40ms (default),110ms or 150ms.
▪ Set the AUDIO OUT output volume (default is 80 = 0dB).

Audio parameters are defined.

Setting OSD Parameters

VP-427X enables adjusting OSD parameters for your convenience via the OSD MENU

buttons.

To set the OSD parameters:

1. On the front panel press MENU. The menu appears.

2. Click OSD and define the OSD parameters according to the information in the OSD
Values table (see OSD Values Table on page 11).

OSD parameters are set.

Managing EDID via OSD

VP-427X enables managing the EDID via the OSD MENU buttons.

Uploading the EDID

To upload EDID:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select EDID Manage. Select the parameters according to the
information in the OSD Values table (see OSD Values Table on page 11).

The selected EDID is sent to the input.

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

16

Uploading EDID from an External File

To select the EDID from an external file:

1. Save an EDID file via the EDID webpage.

2. On the front panel press MENU. The OSD menu appears.

3. Click Advanced and select EDID Manage.

4. Select an HDMI input and then select File.
The external EDID file (as stored via the EDID embedded page) is stored.

An external EDID file is sent to a selected input.

Setting HDCP

VP-427X enables setting the HDCP on the inputs and on the output via the front panel

MENU buttons.

To set the HDCP on the inputs and output:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and define the HDCP parameters according to the information in the
OSD Values table (see OSD Values Table on page 11).

HDCP is set on the input/output.

Setting Sleep Mode

Auto Sync Off turns off the output after a period of not detecting a valid video signal on the
input(s) until a valid input is again detected or any keypad button is pressed.

VP-427X enables configuring the Auto Sync Off delay time when a connected display enters

sleep mode.

To set Auto Sync Off:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select Auto Sync Off.

3. Define Auto Sync Off according to the information in the following table:

Menu Item

Function

Off (default)

Leave the outputs active always.

Fast

Disable the outputs after ~ 10 seconds of no input detection.

Slow

Disable the outputs after ~ 2 minutes of no input detection.

Immediate

Disable the outputs immediately.

Sleep mode is defined.

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

17

Setting Switching Mode

VP-427X enables configuring for automatic switching of the input source upon signal loss or

when a source is plugged in.

To set the switching mode:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select Auto Switching.

3. Select the switching mode according to the information in the following table:

Menu Item

Function

Off

For manual switching.

Auto Scan

Scans for a valid input when no signal is found on the selected input.

Last Connect

Automatically switches to the last connected input and reverts to the
previously selected input after that input is lost.

Switching mode is defined.

Defining FREEZE Button Operation Mode

VP-427X enables defining the function of the FREEZE front panel button .

To define the FREEZE button operation mode:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select Freeze.

3. Set freeze mode according to the information in the following table:

Menu Item

Function

Freeze + Mute

Freeze the image and mute the audio output.

Only Mute

Mute the audio output.

Only Freeze

Freeze the image.

When pressed, FREEZE button functions as defined.

Defining CEC

VP-427X can be configured to automatically send CEC on/off commands to the connected

display (default) or to pass CEC commands from the connected source to the connected
display.

To set the CEC (Consumer Electronic Control) functionality:

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select Output CEC Bypass.

3. Select:

▪ Off – Automatically send CEC commands to shut down the output display after a

timeout period when no input signal is found and to power up the display when the
input returns.

▪ On – Pass CEC commands from the source to the display.

CEC functionality is defined.

8

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

18

Configuring TOGGLE Pin Behavior

VP-427X enables defining the function of the REMOTE pin on the rear panel.
To configure the TOGGLE pin (see Connecting the Remote-Control Switches on page 11):

1. On the front panel press MENU. The menu appears.

2. Click Advanced and select Toggle Pin.

3. Select the TOGGLE pin configuration:

▪ Edge = (toggle on/off).
▪ Input Select.
▪ GND=Off / Hi=On
▪ GND=On / Hi=Off
▪ Hi=Off

Viewing Device Information

Device information includes the selected source, the input and output resolutions, and the
software version.

To view the information:

1. On the front panel press MENU. The menu appears.

2. Click INFO and view the input resolution, output resolution and software version.
Information is displayed.

Performing a Reset

VP-427X enables performing either a soft reset or a full reset via the front panel MENU

buttons.

To reset the device:

1. On the front panel press MENU. The menu appears.

2. Click Factory and select either Reset (full reset) or a Soft Reset (reset device
information excluding Ethernet parameters), then click Yes.
Wait for completion of factory reset (resolution is set to Native).

Device is reset.

15

Kramer Electronics Ltd.

VP-427X – Operating and Controlling VP-427X

19

Controlling VP-427X via the RS-232 Port

Connect the RS-232 port to a system controller to control the VP-427X.

To control VP-427X via RS-232:

1. Connect a controlling system to the RS-232 CONTROL port
(see Connecting to VP-427X via RS-232 on page 8).

Figure 6: Local Scaler Control

RS-232 port is used to control the VP-427X.

Kramer Electronics Ltd.

VP-427X – Upgrading Firmware

20

Upgrading Firmware

Upgrade the firmware in any of the following ways:

• Connecting the device to your PC and using Kramer K-UPLOAD software.

• Via PROG USB port (see USB Firmware Upgrade (USB Format FAT32)

on page 20).

USB Firmware Upgrade (USB Format FAT32)

To update the firmware via PROG USB port:

1. Save VP_427X bin. file (for example, VP_427X_all_V*.bin) in USB flash driver and plug
into PROG USB port.

2. Press and hold MENU+ENTER buttons for about 3 seconds until both HDBT/HDMI
INPUT LEDs blink.

3. Continue holding buttons until both LEDs are lit consistently (this could take up to 60
seconds).

4. Set the unit to factory reset (MENU>FACTORY>RESET ALL).

5. Power off and remove the USB flash driver.

If the device is in USB mode but can’t read the firmware file or if the USB flash driver is not

connected, it reboots automatically after 10 seconds and exits the USB mode.

If the power drops during firmware upgrade, it automatically starts upgrading once the power
is back.

If the power drops in the early stages of firmware upgrade, you need to start firmware
upgrade again.

1

Kramer Electronics Ltd.

VP-427X – Technical Specifications

21

Technical Specifications

Inputs
HDBaseT

On an RJ-45 female connector

HDMI

On a female HDMI connector

Outputs

HDMI

On a female HDMI connector

Balanced Analog Stereo Audio

On a 5-pin terminal block connector

Ports

1 Control RS−232

On a 3–pin terminal block connector for
device control

1 Data RS−232

On a 3–pin terminal block connector for
serial extension

3 Remote Contact−Closure

On a 4 pin terminal block connector

1 Relay

On a 3–pin terminal block connector

1 Program USB

On a USB–A connector for firmware upgrade

Video

Max. Data rate

18Gbps

Max. Resolution

4K @60Hz (4:4:4)

Max Frame Latency

2

Content Protection

HDCP 2.2, 1.4

Max Inputs Switching Time

2.5sec (constant output sync)

Output Resolutions

640x480@60Hz, 800x600@60Hz,
1024x768@60Hz, 1280x768@60Hz,
1280x800@60Hz, 1280x1024@60Hz,
1360x768@60Hz, 1400x1050@60Hz,
1440x900@60Hz, 1600x1200@60Hz,
1680x1050@60Hz, 1920x1200@60Hz RB,
2560x1600@60Hz RB, 1920x1080@60Hz,
1280x720@60Hz, 2048x1080@50/60Hz,
2560x1440@60Hz RB, 720x480p@60Hz,
720x576p@50Hz, 1280x720p@50/60Hz,
1920x1080p@24/25/30/50/60Hz,
2560x1080p@50/60Hz,
2K@24/25/30/50/60Hz,
4K@24/25/30/50/60Hz

Compliance

4K60, CEC, xvYCC color per HDMI 2.0

Extension Line

Reach

4K@60Hz (4:2:0): 40m (130ft)
1080p@60Hz: 70m (230ft)

Max Data Rate

10Gbps

Max. Resolution

4K @60Hz (4:2:0)

Compliance

HDBaseT 1.0

Audio

Output Impedance

500Ω

S/N Ratio

>95dB (A-Weighted)

THD+Noise

<0.003% @1kHz at 1Vpp

Crosstalk

<-94dB @1kHz

Output coupling

DC

Maximum Output Level

14dBu

Extended RS-232

Baud Rate

300 to 115200

Control RS-232

Baud Rate

115200 baud

Power
Source

2A/12V

Consumption

1A

Enclosure

Size

MegaTOOLS®

Type

Aluminum

Cooling

Convection Ventilation

Operating Temperature

0° to +40°C (32° to 104°F)

Kramer Electronics Ltd.

VP-427X – Technical Specifications

22

Environmental
Conditions

Storage Temperature

-40° to +70°C (-40° to 158°F)

Humidity

10% to 90%, RHL non-condensing

Regulatory
Compliance

Safety

CE, FCC

Environmental

RoHs, WEEE

General

Net Dimensions (W, D, H)

18.8cm x 14.5cm x 2.54cm (7.4" x 5.7" x 1")

Shipping Dimensions (W, D, H)

35.1cm x 21.2cm x 7.2cm (13.8" x 8.4" x

2.8")

Net Weight

0.9kg (2.0lbs) approx.

Shipping Weight

1.1kg (2.4lbs) approx.

Accessories

Included

Power cord and adapter

Specifications are subject to change without notice at www.kramerav.com

Kramer Electronics Ltd.

VP-427X – Technical Specifications

23

Default Communication Parameters

RS-232

Baud Rate:

115,200

Data Bits:

8

Stop Bits:

1

Parity:

None

Command Format:

ASCII

Example (Route video HDBT INPUT to HDMI OUTPUT):

#ROUTE1,1,1<CR>

Ethernet

To reset the IP settings to the factory reset values go to: Menu->Setup -> Factory Reset-> press Enter
to confirm

IP Address:

192.168.1.39

Subnet mask:

255.255.0.0

Default gateway:

192.168.0.1

TCP Port #:

5000

UDP Port #:

50000

Default username:

Admin

Default password:

Admin

Factory Reset

OSD

Go to: Menu > Factory > select either Reset (full reset) or a Soft Reset (reset
device information excluding Ethernet parameters).

Front panel buttons

Press the Reset to XGA/1080p Button while plugging the power to reset the
machine.

Embedded web pages

Device Settings > Soft Factory Reset.

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

24

Protocol 3000 for VP-427X

Kramer devices can be operated using Kramer Protocol 3000 commands sent via serial or
Ethernet ports.

Understanding Protocol 3000

Protocol 3000 commands are a sequence of ASCII letters, structured according to the
following.

• Command format:

Prefix

Command Name

Constant (Space)

Parameter(s)

Suffix

#

Command



Parameter

<CR>

• Feedback format:

Prefix

Device ID

Constant

Command Name

Parameter(s)

Suffix

~

nn @ Command

Parameter

<CR><LF>

• Command parameters – Multiple parameters must be separated by a comma (,). In
addition, multiple parameters can be grouped as a single parameter using brackets ([
and ]).

• Command chain separator character – Multiple commands can be chained in the
same string. Each command is delimited by a pipe character (|).

• Parameters attributes – Parameters may contain multiple attributes. Attributes are
indicated with pointy brackets (<…>) and must be separated by a period (.).

The command framing varies according to how you interface with VP-427X. The following
figure displays how the # command is framed using terminal communication software (such
as Hercules):

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

25

Protocol 3000 Commands

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

#

Protocol handshaking.

Validates the
Protocol 3000
connection and gets the
machine number.

Step-in master products
use this command to
identify the availability
of a device.

COMMAND

#<CR>

FEEDBACK

~nn@ok<CR><LF>

#<CR>
AUD-LVL

Set volume level.

COMMAND

#AUD-LVLio_mode,io_index,vol_level<CR>

FEEDBACK

~nn@AUD-LVLio_mode,io_index,vol_level<CR><LF>

io_mode – Input/Output

1 – Output

io_index – Number that indicates

the specific input or output port:

1 – AUDIO OUTPUT

vol_level – Volume level 0 to

100;

++ (increase current value by 1);

-- (decrease current value by 1)

Set AUDIO OUTPUT level to
50:

#AUD-LVL1,1,50<CR>
AUD-LVL?

Get volume level.

COMMAND

#AUD-LVL?io_mode,io_index<CR>

FEEDBACK

~nn@AUD-LVLio_mode,io_index,vol_level<CR><LF>

io_mode – Input/Output

1 – Output

io_index – Number that indicates

the specific input or output port:

1 – AUDIO OUTPUT

vol_level – Volume level 0 to 100

Get AUDIO OUT 1 level

#AUD-LVL?1,1<CR>

AV-SW­MODE

Set input auto switch
mode (per output).

COMMAND

#AV-SW-MODElayer_type,out_index,connection_mode<CR>

FEEDBACK

~nn@AV-SW-MODElayer_type,out_index,connection_mode<CR><

LF>

layer_type – Number that

indicates the signal type:

1 – Video

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

connection_mode – Connection

mode

0 – manual
1 – auto scan
2 – last connected

Set input auto switch mode
(per output) for audio 1 to
manual:

#AV-SW-MODE1,1,0<CR>

AV-SW­MODE?

Get input auto switch
mode (per output).

COMMAND

#AV-SW-MODE?layer_type,out_index<CR>

FEEDBACK

~nn@AV-SW-MODElayer_type,out_index,connection_mode<CR><

LF>

layer_type – Number that

indicates the signal type:

1 – Video

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

connection_mode – Connection

mode

0 – manual
1 – auto scan
2 – last connected

Get the input audio switch
mode for HDBT Out:

#AV-SW-MODE?1,1<CR>

BUILD­DATE?

Get device build date.

COMMAND

#BUILD-DATE?<CR>

FEEDBACK

~nn@BUILD-DATEdate,time<CR><LF>

date – Format: YYYY/MM/DD

where

YYYY = Year
MM = Month
DD = Day

time – Format: hh:mm:ss where

hh = hours
mm = minutes
ss = seconds

Get the device build date:

#BUILD-DATE?<CR>

CEC

Set display to ON/OFF

COMMAND

#CECstate<CR>

FEEDBACK

~nn@CECstate<CR><LF>

state – CEC state

0 – Off
1 – On

Set display to OFF via CEC:

#CEC-ON<CR>

CEC-PASS

Set CEC device bypass.

COMMAND

#CEC-PASSstate<CR>

FEEDBACK

~nn@CEC-PASSstate<CR><LF>

state – CEC state

0 – Off
1 – On

Bypass device:

#CEC-PASS1<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

26

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

CPEDID

Copy EDID data from
the output to the input
EEPROM.

Destination bitmap
size depends on device
properties (for 64 inputs
it is a 64-bit word).

Example: bitmap
0x0013 means inputs
1,2 and 5 are loaded
with the new EDID.

In certain products
Safe_mode is an
optional parameter.
See the HELP
command for its
availability.

COMMAND

#CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR>

or

#CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_mode<CR>

FEEDBACK

~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR><LF>

~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_mode<

CR><LF>

edid_io – EDID source type

(usually output)

1 – Output

src_id – Number of chosen

source stage

1=Def. 1080P
2=Def. 4K2K(3G)
3=Def. 4K2K(3G-4:2:0)
4=USER1
5=USER2
6=OUTPUT
7= Def. 4K2K(6G) – for HDMI

only (not relevant for HDBT)

edid_io – EDID destination type

(usually input)

0 – Input

dest_bitmap – Bitmap

representing destination IDs.

Format: XXXX…X, where X is hex

digit. The binary form of every hex
digit represents corresponding
destinations.

0 – indicates that EDID data is not

copied to this destination.

1 – indicates that EDID data is

copied to this destination.

safe_mode – Safe mode

0 – device accepts the EDID as is

without trying to adjust

1 – device tries to adjust the EDID

(default value if no parameter
is sent)

Copy the EDID data from
USER1 to the Input:

#CPEDID1,4,0,0x01<CR

>

Copy the EDID data from the
default EDID source to the
Input:

#CPEDID1,1,0,0x01<CR

>

DISPLAY?

Get output HPD status.

COMMAND

#DISPLAY?out_index<CR>

FEEDBACK

~nn@DISPLAYout_index,status<CR><LF>

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

status – HPD status according to

signal validation

0 – Signal or sink is not valid
1 – Signal or sink is valid
2 – Sink and EDID is valid

Get the output HPD status of
HDMI OUTPUT:

#DISPLAY?1<CR>

FCT-SN

Set serial number.

COMMAND

#FCT-SNserial_num<CR>

FEEDBACK

~nn@FCT-SNserial_num<CR><LF>

serial_num – 14 decimal digits

Set serial number:

#FCT-SN1976384058112

3<CR>

HDCP-MOD

Set HDCP mode.

Set HDCP working
mode on the device
input:

HDCP supported ­HDCP_ON [default].

HDCP not supported ­HDCP OFF.

HDCP support changes
following detected sink

- MIRROR OUTPUT.
When you define 3 as

the mode, the HDCP
status is defined
according to the
connected output in the
following priority: OUT
1, OUT 2. If the
connected display on
OUT 2 supports HDCP,
but OUT 1 does not,
then HDCP is defined
as not supported. If
OUT 1 is not
connected, then HDCP
is defined by OUT 2.

COMMAND

#HDCP-MODin_index,mode<CR>

FEEDBACK

~nn@HDCP-MODin_index,mode<CR><LF>

in_index – Number that indicates

the specific input:

1 – HDBT INPUT
1 – HDMI INPUT

mode – HDCP mode:

0 – HDCP Off
1 – HDCP On

Set the input HDCP-MODE
of HDBT INPUT to Off:

#HDCP-MOD1,0<CR>

HDCP-MOD?

Get HDCP mode.

Set HDCP working
mode on the device
input:

HDCP supported ­HDCP_ON [default].

HDCP not supported ­HDCP OFF.

HDCP support changes
following detected sink

- MIRROR OUTPUT.

COMMAND

#HDCP-MOD?in_index<CR>

FEEDBACK

~nn@HDCP-MODin_index,mode<CR><LF>

in_index – Number that indicates

the specific input:

1 – HDBT INPUT
2 – HDMI INPUT

mode – HDCP mode:

0 – HDCP Off
1 – HDCP On

Get the input HDCP-MODE
of HDMI INPUT:

#HDCP-MOD?2<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

27

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

HELP

Get command list or
help for specific
command.

COMMAND

#HELP<CR>

#HELPcmd_name<CR>

FEEDBACK

1. Multi-line:

~nn@Devicecmd_name,cmd_name…<CR><LF>

To get help for command use: HELP (COMMAND_NAME)<CR><LF>

~nn@HELPcmd_name:<CR><LF>

description<CR><LF>

USAGE:usage<CR><LF>

cmd_name – Name of a specific

command

Get the command list:

#HELP<CR>

To get help for
AV-SW-TIMEOUT:
HELPav-sw-timeout<C

R>

MODEL?

Get device model.

This command
identifies equipment
connected to VP-427X
and notifies of identity
changes to the
connected equipment.
The Matrix saves this
data in memory to
answer REMOTE-INFO
requests.

COMMAND

#MODEL?<CR>

FEEDBACK

~nn@MODELmodel_name<CR><LF>

model_name – String of up to 19

printable ASCII chars

Get the device model:

#MODEL?<CR>

MUTE

Set audio mute.

COMMAND

#MUTEout_index,mute_mode<CR>

FEEDBACK

~nn@MUTEout_index,mute_mode<CR><LF>

out_index – Number that

indicates the specific output:

1 – AUDIO OUTPUT

mute_mode – On/Off

0 – Off
1 – On

Set AUDIO OUTPUT to
mute:

#MUTE1,1<CR>

MUTE?

Get audio mute.

COMMAND

#MUTE?out_index<CR>

FEEDBACK

~nn@MUTEout_index,mute_mode<CR><LF>

out_index – Number that

indicates the specific output:

1 – AUDIO OUTPUT

mute_mode – On/Off

0 – Off
1 – On

Get mute status of AUDIO
OUTPUT

#MUTE1?<CR>

PROT-VER?

Get device protocol
version.

COMMAND

#PROT-VER?<CR>

FEEDBACK

~nn@PROT-VER3000:version<CR><LF>

version – XX.XX where X is a

decimal digit

Get the device protocol
version:

#PROT-VER?<CR>

RELAY­STATE

Set relay state.

COMMAND

#RELAY-STATErelay_id,state<CR>

FEEDBACK

~nn@RELAY-STATErelay_id,state<CR><LF>

relay_id – Relay number 1
state – Relay state

0 – (open)
1 – (close)

Set relay to closed:

#RELAY-STATE1,1<CR>

RELAY­STATE?

Get relay state.

COMMAND

#RELAY-STATE?relay_id<CR>

FEEDBACK

~nn@RELAY-STATErelay_id,relay_state<CR><LF>

relay_id – Relay number 1
relay_state – Relay state

0 – (open)
1 – (close)

Get relay state:

#RELAY-STATE?1<CR>

RESET

Reset device.

To avoid locking the
port due to a USB bug
in Windows, disconnect
USB connections
immediately after
running this command.
If the port was locked,
disconnect and
reconnect the cable to
reopen the port.

COMMAND

#RESET<CR>

FEEDBACK

~nn@RESETok<CR><LF>

Reset the device:

#RESET<CR>
ROUTE

Set layer routing.

This command
replaces all other
routing commands.

COMMAND

#ROUTElayer_type,out_index,in_index<CR>

FEEDBACK

~nn@ROUTElayer_type,out_index<CR><LF>

layer_type Layer Enumeration

1 – Video

out_index (both selections are

identical)

1 – HDMI OUTPUT
* – ALL

in_index – Source id

1 – HDBT INPUT
2 – HDMI INPUT

Route video HDBT INPUT to
HDMI OUTPUT:

#ROUTE1,1,1<CR>

ROUTE?

Get layer routing.

This command
replaces all other
routing commands.

COMMAND

#ROUTE?layer_type,out_index<CR>

FEEDBACK

~nn@ROUTElayer_type,out_index,in_index<CR><LF>

layer_type Layer Enumeration

1 – Video

out_index (both selections are

identical)

1 – HDMI OUTPUT
* – ALL

in_index – Source id

1 – HDBT INPUT
2 – HDMI INPUT

Get the layer routing:

#ROUTE? 1,*<CR>

SCLR-AS

Set auto-sync features.

Sets the auto sync
features for the
selected scaler.

COMMAND

#SCLR-ASscaler_index,sync_speed<CR>

FEEDBACK

~nn@SCLR-ASscaler_index,sync_speed<CR><LF>

scaler_index – Scaler Number:

1 – Scaler1

sync_speed – 0, 1 or 2

0 – off
1 – fast
2 – slow

Set auto-sync feature to fast:

#SCLR-AS1,1<CR>

SCLR-AS?

Get auto-sync features.

Gets the auto sync
features for the
selected scaler.

COMMAND

#SCLR-AS?scaler_index<CR>

FEEDBACK

~nn@SCLR-ASscaler_index,sync_speed<CR><LF>

scaler_index – Scaler Number:

1 – Scaler1

sync_speed – 0, 1 or 2

0 – off
1 – fast
2 – slow

Get auto-sync features:

#SCLR-AS?1<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

28

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

SCLR­AUDIO­DELAY

Set the scaler audio
delay.

Sets the audio delay
for the selected audio
output.

COMMAND

#SCLR-AUDIO-DELAYscaler_index,delay<CR>

FEEDBACK

~nn@SCLR-AUDIO-DELAYscaler_index,delay<CR><LF>

scaler_index – Audio output

number

1 – Scaler1

delay –

0 – Off
1 – 40ms
2 – 110ms
3 – 150ms

Set the scaler audio delay
40ms:

#SCLR-AUDIO-DELAY1,1

<CR>

SCLR­AUDIO­DELAY?

Get the scaler audio
delay.

Gets the audio
delay for the selected
audio output.

COMMAND

#SCLR-AUDIO-DELAY?scaler_index<CR>

FEEDBACK

~nn@SCLR-AUDIO-DELAYscaler_index,delay<CR><LF>

scaler_index – Audio output

number

1 – Scaler1

delay –

0 – Off
1 – 40ms
2 – 110ms
3 – 150ms

Get the scaler audio delay:

#SCLR-AUDIO-DELAY?1<

CR>

SIGNAL?

Get input signal status.

COMMAND

#SIGNAL?in_index<CR>

FEEDBACK

~nn@SIGNALin_index,status<CR><LF>

in_index – Number that indicates

the specific input:

1 – HDBT INPUT
2 – HDMI INPUT

status – Signal status according

to signal validation:

0 – Signal or sink is not valid (Off)
1 – Signal or sink is valid (On)

Get the input signal lock
status of HDBT INPUT 1:

#SIGNAL?1<CR>

SN?

Get device serial

number.

COMMAND

#SN?<CR>

FEEDBACK

~nn@SNserial_num<CR><LF>

serial_num – 14 decimal digits,

factory assigned

Get the device serial
number:

#SN?<CR>

VERSION?

Get firmware version
number.

COMMAND

#VERSION?<CR>

FEEDBACK

~nn@VERSIONfirmware_version<CR><LF>

firmware_version –

XX.XX.XXXX where the digit groups
are: major.minor.build version

Get the device firmware
version number:

#VERSION?<CR>

VFRZ

Set freeze on selected
output.

COMMAND

#VFRZout_index,freeze_flag<CR>

FEEDBACK

~nn@VFRZout_index,freeze_flag<CR><LF>

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

freeze_flag – On/Off

0 – Off
1 – On

Set freeze on HDMI
OUTPUT:

#VFRZ1,1<CR>

VFRZ?

Get output freeze
status.

COMMAND

#VFRZ?out_index<CR>

FEEDBACK

~nn@VFRZout_index,freeze_flag<CR><LF>

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

freeze_flag – On/Off

0 – Off
1 – On

Get output freeze status:

#VFRZ?1<CR>

VID-RES

Set output resolution.

“Set” command with
is_native=ON sets
native resolution on
selected output
(resolution index sent =

0). Device sends as
answer actual VIC ID of
native resolution.

To use “custom
resolutions” (entries

100-105 In View
Modes), define them
using the DEF-RES
command.

COMMAND

#VID-RESio_mode,io_index,is_native,resolution<CR>

FEEDBACK

~nn@VID-RESio_mode,io_index,is_native,resolution<CR><LF

>

io_mode – Input/Output

1 – Output

io_index – Number that indicates

the specific output port:

1 – HDMI OUTPUT

is_native – Native resolution flag

1 – On

resolution – Resolution index

0=Native
1=640x480@60
2=800x600@60
3=1024x768@60
4=1280x768@60
5=1280x800@60
6=1280x1024@60
7=1360x768@60
8=1400x1050@60
9=1440x900@60
10=1600x1200@60
11=1680x1050@60
12=1920x1200@60 RB
13=2560x1600@60 RB
14=1920x1080@60
15=1280x720@60
16=2048x1080@50
17=2048x1080@60
18=2560x1440@60 RB
19=3440x1440@30
20=3440x1440@60
21=720x480P@60
22=720x576P@50
23=1280x720P@50
24=1280x720P@60
25=1920x1080P@24
26=1920x1080P@25
27=1920x1080P@30
28=1920x1080P@50
29=1920x1080P@60
30=2560x1080P@50
31=2560x1080P@60
32=3840x2160P@24
33=3840x2160P@25
34=3840x2160P@30
35=3840x2160P@50
36=3840x2160P@60

Set HDMI OUTPUT
resolution to 1440x900:

#VID-RES1,1,1,9<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

29

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

VID-RES?

Get output resolution.

“Get” command with
is_native=ON returns
native resolution VIC,
with is_native=OFF
returns current
resolution.

To use “custom
resolutions” (entries

100-105 In View
Modes), define them
using the DEF-RES
command.

COMMAND

#VID-RES?io_mode,io_index,is_native<CR>

FEEDBACK

~nn@VID-RES?io_mode,io_index,is_native,resolution<CR><L

F>

io_mode – Input/Output

1 – Output

io_index – Number that indicates

the specific output port:

1 – HDMI OUTPUT

is_native – Native resolution flag

1 – On

resolution – Resolution index

0=Native
1=640x480@60
2=800x600@60
3=1024x768@60
4=1280x768@60
5=1280x800@60
6=1280x1024@60
7=1360x768@60
8=1400x1050@60
9=1440x900@60
10=1600x1200@60
11=1680x1050@60
12=1920x1200@60 RB
13=2560x1600@60 RB
14=1920x1080@60
15=1280x720@60
16=2048x1080@50
17=2048x1080@60
18=2560x1440@60 RB
19=3440x1440@30
20=3440x1440@60
21=720x480P@60
22=720x576P@50
23=1280x720P@50
24=1280x720P@60
25=1920x1080P@24
26=1920x1080P@25
27=1920x1080P@30
28=1920x1080P@50
29=1920x1080P@60
30=2560x1080P@50
31=2560x1080P@60
32=3840x2160P@24
33=3840x2160P@25
34=3840x2160P@30
35=3840x2160P@50
36=3840x2160P@60

Set output resolution:

#VID-RES?1,1,1<CR>

VMUTE

Set enable/disable
video on output.

Video mute
parameter 2 (blank
picture) is not
supported.

COMMAND

#VMUTEout_index,flag<CR>

FEEDBACK

~nn@VMUTEout_index,flag<CR><LF>

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

flag – Video Mute

0 – Video disabled, +5V low
1 – Video enabled, +5V high
2 – Blank picture, +5V high

Disable the video output on
HDMI OUTPUT:

#VMUTE1,0<CR>

VMUTE?

Get video on output
status.

Video mute
parameter 2 (blank
picture) is not
supported.

COMMAND

#VMUTE?out_index<CR>

FEEDBACK

~nn@VMUTEout_index,flag<CR><LF>

out_index – Number that

indicates the specific output:

1 – HDMI OUTPUT

flag – Video Mute

0 – Video disabled, +5V low
1 – Video enabled, +5V high
2 – Blank picture, +5V high

Get video on HDMI OUTPUT
status:

#VMUTE?1<CR>

X-AUD-LVL

Set audio level of a
specific signal.

This is an Extended
Protocol 3000
command.

COMMAND

#X-AUD-LVL<direction_type>. <port_format>. <port_index>.

<signal_type>. <index>,audio_level<CR>

FEEDBACK

~nn@X-AUD-LVL<direction_type>. <port_format>.

<port_index>. <signal_type>. <index>,audio_level<CR><LF>

The following attributes comprise
the signal ID:

▪ <direction_type> –

Direction of the port:

o OUT – Output

▪ <port_format> – Type of

signal on the port:

o ANALOG_AUDIO

▪ <port_index> – The port

number as printed on the front
or rear panel:1

▪ <signal_type> – Signal ID

attribute:

o AUDIO

▪ <index> – Indicates a specific

channel number when there
are multiple channels of the
same type

audio_level – Audio level (range

between 0 to +100)

Set the AUDIO OUT level to
10:

#X-AUD-LVLout.analog

_audio.1.audio.1,10<C

R>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

30

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

X-AUD­LVL?

Get audio level of a
specific signal.

This is an Extended
Protocol 3000
command.

COMMAND

#X-AUD-LVL?<direction_type>. <port_format>. <port_index>.

<signal_type>. <index><CR>

FEEDBACK

~nn@X-AUD-LVL<direction_type>. <port_format>.

<port_index>. <signal_type>. <index>,audio_level<CR><LF>

The following attributes comprise
the signal ID:

▪ <direction_type> –

Direction of the port:

o OUT – Output

▪ <port_format> – Type of

signal on the port:

o ANALOG_AUDIO

▪ <port_index> – The port

number as printed on the front
or rear panel:1

▪ <signal_type> – Signal ID

attribute:

o AUDIO

▪ <index> – Indicates a specific

channel number when there
are multiple channels of the
same type

audio_level – Audio level (range

between 0 to +100)

Get the audio level of a
specific signal:

#X-AUD-LVL?out.analo

g_audio.1.audio.1<CR>

X-ROUTE

Send routing command
to matrix.

It is recommended
to use the command
#SIGNALS-LIST to get
the list of all signal IDs
available in the system
and which can be used
in this command.

Video 1 is the default
port in this command
and is implied even if
not written:

#X­ROUTEout.sdi.5,i

n.sdi.1<CR>

is interpreted as:

#X­ROUTEout.sdi.5.v

ideo.1,in.sdi.1.v
ideo.1<CR>

This is an Extended
Protocol 3000
command.

COMMAND

#X-ROUTE<direction_type1>. <port_type1>. <port_index1>.

<signal_type1>. <index1>,<direction_type2>. <port_type2>.
<port_index2>. <signal_type2>. <index2><CR>

FEEDBACK

~nn@X-ROUTE<direction_type1>. <port_type1>.

<port_index1>. <signal_type1>. <index1>,<direction_type2>.
<port_type2>. <port_index2>. <signal_type2>.
<index2><CR><LF>

The following attributes comprise
the signal ID:

▪ <direction_type> –

Direction of the port:

o IN – Input
o OUT – Output

▪ <port_format> – Type of

signal on the port:

o HDMI
o HDBT

▪ <port_index> – The port

number as printed on the front
or rear panel:

For the output:
1 – HDMI OUTPUT
For the input:
1 – HDBT INPUT
2 – HDMI INPUT

▪ <signal_type> – Signal ID

attribute:

o VIDEO

▪ <index> – Indicates a specific

channel number when there
are multiple channels of the
same type: 1

Route HDMI INPUT to HDMI
OUTPUT:

#X-ROUTEout.hdmi.1.v

ideo.1,in.hdmi.2.vide
o.1<CR>

X-ROUTE?

Get routing status.

It is recommended
to use the command
#SIGNALS-LIST to get
the list of all signal IDs
available in the system
and which can be used
in this command.

VIDEO.1 are the default
<signal_type> and
<index> in this

command and are
implied even if not
written:

#X­ROUTEout.sdi.5,i

n.sdi.1<CR>

is interpreted as:

#X­ROUTEout.sdi.5.v

ideo.1,in.sdi.1.v
ideo.1<CR>

This is an Extended
Protocol 3000
command.

COMMAND

#X-ROUTE?<direction_type1>. <port_type1>. <port_index1>.

<signal_type1>. <index1><CR>

FEEDBACK

~nn@X-ROUTE<direction_type1>. <port_type1>.

<port_index1>. <signal_type1>. <index1>,<direction_type2>.
<port_type2>. <port_index2>. <signal_type2>.
<index2><CR><LF>

The following attributes comprise
the signal ID:

▪ <direction_type> –

Direction of the port:

o IN – Input
o OUT – Output

▪ <port_format> – Type of

signal on the port:

o HDMI
o HDBT

▪ <port_index> – The port

number as printed on the front
or rear panel:
For the output:
1 – HDMI OUTPUT
For the input:
1 – HDBT INPUT
2 – HDMI INPUT

▪ <signal_type> – Signal ID

attribute:

o VIDEO

▪ <index> – Indicates a specific

channel number when there
are multiple channels of the
same type: 1

Get the routing status:

#X-ROUTE?out.hdmi.1.

video.1<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

31

Functi
on

Description

Syntax

Parameters/Attribut
es

Example

X-SIGNAL?

Get input signal status.

This is an Extended
Protocol 3000
command.

COMMAND

#X-SIGNAL?<direction_type>. <port_format>. <port_index>.

<signal_type>. <index><CR>

FEEDBACK

~nn@X-SIGNAL<direction_type>. <port_format>.

<port_index>. <signal_type>. <index>,status<CR><LF>

The following attributes comprise
the signal ID:

▪ <direction_type> –

Direction of the port:

o IN – Input

▪ <port_format> – Type of

signal on the port:

o HDMI
o HDBT

▪ <port_index> – The port

number as printed on the front
or rear panel:

1 – HDBT INPUT
2 – HDMI INPUT

▪ <signal_type> – Signal ID

attribute:

o VIDEO

▪ <index> – Indicates a specific

channel number when there
are multiple channels of the
same type: 1

status – Input Signal Status

0 – No signal
1 – There is a signal

#X­SIGNAL?in.hdbt.1.vid

eo.1<CR>

Kramer Electronics Ltd.

VP-427X – Protocol 3000 for VP-427X

32

Result and Error Codes

Syntax

In case of an error, the device responds with an error message. The error message syntax:

• ~NN@ERR XXX<CR><LF> – when general error, no specific command

• ~NN@CMD ERR XXX<CR><LF> – for specific command

• NN – machine number of device, default = 01

• XXX – error code

Error Codes

Error Name

Error
Code

Description

P3K_NO_ERROR

0

No error

ERR_PROTOCOL_SYNTAX

1

Protocol syntax

ERR_COMMAND_NOT_AVAILABLE

2

Command not available

ERR_PARAMETER_OUT_OF_RANGE

3

Parameter out of range

ERR_UNAUTHORIZED_ACCESS

4

Unauthorized access

ERR_INTERNAL_FW_ERROR

5

Internal FW error

ERR_BUSY

6

Protocol busy

ERR_WRONG_CRC

7

Wrong CRC

ERR_TIMEDOUT

8

Timeout

ERR_RESERVED

9

(Reserved)

ERR_FW_NOT_ENOUGH_SPACE

10

Not enough space for data (firmware, FPGA…)

ERR_FS_NOT_ENOUGH_SPACE

11

Not enough space – file system

ERR_FS_FILE_NOT_EXISTS

12

File does not exist

ERR_FS_FILE_CANT_CREATED

13

File can’t be created

ERR_FS_FILE_CANT_OPEN

14

File can’t open

ERR_FEATURE_NOT_SUPPORTED

15

Feature is not supported

ERR_RESERVED_2

16

(Reserved)

ERR_RESERVED_3

17

(Reserved)

ERR_RESERVED_4

18

(Reserved)

ERR_RESERVED_5

19

(Reserved)

ERR_RESERVED_6

20

(Reserved)

ERR_PACKET_CRC

21

Packet CRC error

ERR_PACKET_MISSED

22

Packet number isn't expected (missing packet)

ERR_PACKET_SIZE

23

Packet size is wrong

ERR_RESERVED_7

24

(Reserved)

ERR_RESERVED_8

25

(Reserved)

ERR_RESERVED_9

26

(Reserved)

ERR_RESERVED_10

27

(Reserved)

ERR_RESERVED_11

28

(Reserved)

ERR_RESERVED_12

29

(Reserved)

ERR_EDID_CORRUPTED

30

EDID corrupted

ERR_NON_LISTED

31

Device specific errors

ERR_SAME_CRC

32

File has the same CRC – not changed

ERR_WRONG_MODE

33

Wrong operation mode

ERR_NOT_CONFIGURED

34

Device/chip was not initialized

The warranty obligations of Kramer Electronics Inc. (“Kramer Electronics”) for this product are limited to the terms set forth below:

What is Covered

This limited warranty covers defects in materials and workmanship in this product.

What is Not Covered

This limited warranty does not cover any damage, deterioration or malfunction resulting from any alteration, modification, improper or unreasonable use or
maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper packing and shipping (such claims must be presented to the carrier),
lightning, power surges, or other acts of nature. This limited warranty does not cover any damage, deterioration or malfunction resulting from the installation or
removal of this product from any installation, any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by Kramer Electronics
to make such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship of this product. This limited warranty does not
cover cartons, equipment enclosures, cables or accessories used in conjunction with this product.
Without limiting any other exclusion herein, Kramer Electronics does not warrant that the product covered hereby, including, without limitation, the technology
and/or integrated circuit(s) included in the product, will not become obsolete or that such items are or will remain compatible with any other product or technology
with which the product may be used.

How Long this Coverage Lasts

The standard limited warranty for Kramer products is seven (7) years from the date of original purchase, with the following exceptions:

1. All Kramer VIA hardware products are covered by a standard three (3) year warranty for the VIA hardware and a standard three (3) year
warranty for firmware and software updates; all Kramer VIA accessories, adapters, tags, and dongles are covered by a standard one (1) year
warranty.

2. Kramer fiber optic cables, adapter-size fiber optic extenders, pluggable optical modules, active cables, cable retractors, ring mounted
adapters, portable power chargers, Kramer speakers, and Kramer touch panels are covered by a standard one (1) year warranty. Kramer
7-inch touch panels purchased on or after April 1st, 2020 are covered by a standard two (2) year warranty.

3. All Kramer Calibre products, all Kramer Minicom digital signage products, all HighSecLabs products, all streaming, and all wireless products
are covered by a standard three (3) year warranty.

4. All Sierra Video MultiViewers are covered by a standard five (5) year warranty.

5. Sierra switchers & control panels are covered by a standard seven (7) year warranty (excluding power supplies and fans that are covered for
three (3) years).

6. K-Touch software is covered by a standard one (1) year warranty for software updates.

7. All Kramer passive cables are covered by a lifetime warranty.

Who is Covered

Only the original purchaser of this product is covered under this limited warranty. This limited warranty is not transferable to subsequent purchasers or owners of
this product.

What Kramer Electronics Will Do

Kramer Electronics will, at its sole option, provide one of the following three remedies to whatever extent it shall deem necessary to satisfy a proper claim under
this limited warranty:

1. Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and
labor to complete the repair and restore this product to its proper operating condition. Kramer Electronics will also pay the shipping costs
necessary to return this product once the repair is complete.

2. Replace this product with a direct replacement or with a similar product deemed by Kramer Electronics to perform substantially the same
function as the original product. If a direct or similar replacement product is supplied, the original product’s end warranty date remains
unchanged and is transferred to the replacement product.

3. Issue a refund of the original purchase price less depreciation to be determined based on the age of the product at the time remedy is sought
under this limited warranty.

What Kramer Electronics Will Not Do Under This Limited Warranty

If this product is returned to Kramer Electronics or the authorized dealer from which it was purchased or any other party authorized to repair Kramer Electronics
products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume
all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re-installation of this product from or
into any installation. Kramer Electronics will not be responsible for any costs related to any setting up this product, any adjustment of user controls or any
programming required for a specific installation of this product.

How to Obtain a Remedy Under This Limited Warranty

To obtain a remedy under this limited warranty, you must contact either the authorized Kramer Electronics reseller from whom you purchased this product or the
Kramer Electronics office nearest you. For a list of authorized Kramer Electronics resellers and/or Kramer Electronics authorized service providers, visit our web
site at www.kramerav.com or contact the Kramer Electronics office nearest you.
In order to pursue any remedy under this limited warranty, you must possess an original, dated receipt as proof of purchase from an authorized Kramer Electronics
reseller. If this product is returned under this limited warranty, a return authorization number, obtained from Kramer Electronics, will be required (RMA number).
You may also be directed to an authorized reseller or a person authorized by Kramer Electronics to repair the product.
If it is decided that this product should be returned directly to Kramer Electronics, this product should be properly packed, preferably in the original carton, for
shipping. Cartons not bearing a return authorization number will be refused.

Limitation of Liability

THE MAXIMUM LIABILITY OF KRAMER ELECTRONICS UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID
FOR THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY LAW, KRAMER ELECTRONICS IS NOT RESPONSIBLE FOR DIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL
THEORY. Some countries, districts or states do not allow the exclusion or limitation of relief, special, incidental, consequential or indirect damages, or the limitation
of liability to specified amounts, so the above limitations or exclusions may not apply to you.

Exclusive Remedy

TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE MAXIMUM EXTENT
PERMITTED BY LAW, KRAMER ELECTRONICS SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF KRAMER ELECTRONICS CANNOT LAWFULLY DISCLAIM OR
EXCLUDE IMPLIED WARRANTIES UNDER APPLICABLE LAW, THEN ALL IMPLIED WARRANTIES COVERING THIS PRODUCT, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY TO THIS PRODUCT AS PROVIDED UNDER APPLICABLE LAW.
IF ANY PRODUCT TO WHICH THIS LIMITED WARRANTY APPLIES IS A “CONSUMER PRODUCT” UNDER THE MAGNUSON -MOSS WARRANTY ACT (15
U.S.C.A. §2301, ET SEQ.) OR OTHER APPLICABLE LAW, THE FOREGOING DISCLAIMER OF IMPLIED WARRANTIES SHALL NOT APPLY TO YOU, AND
ALL IMPLIED WARRANTIES ON THIS PRODUCT, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR THE PARTICULAR PURPOSE,
SHALL APPLY AS PROVIDED UNDER APPLICABLE LAW.

Other Conditions

This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state.
This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer
Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller. If you are unsure whether a reseller is an authorized Kramer
Electronics reseller, visit our web site at www.kramerav.com or contact a Kramer Electronics office from the list at the end of this document.
Your rights under this limited warranty are not diminished if you do not complete and return the product registration form or complete and submit the online product
registration form. Kramer Electronics thanks you for purchasing a Kramer Electronics product. We hope it will give you years of satisfaction.

www.kramerav.com
[e-mail]

P/N:

2900-301615

Rev:

1

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information on our products and a list of Kramer distributors, visit our website where
updates to this user manual may be found.

We welcome your questions, comments, and feedback.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
All brand names, product names, and trademarks are the property of their respective owners.
