Kramer VP-410 User Manual

Kramer Electronics, Ltd.

USER MANUAL

Model:

VP-410

Video-Audio to HDMI Scaler

Contents

i

Contents

1 Introduction 1
2 Getting Started 1

2.1 Quick Start 2

3 Overview 3

3.1 About HDMI 3

4 Defining the VP-410 Video-Audio to HDMI Scaler 5
5 Connecting the VP-410 Video-Audio to HDMI Scaler 6
6 Controlling the VP-410 Video-Audio to HDMI Scaler 6

6.1 Controlling the Output Resolution 7

6.2 Using the OSD to Change the Display Parameter Values 7

7 Technical Specifications 8

Figures

Figure 1: VP-410 Video-Audio to HDMI Scaler Front and Rear Panels 5
Figure 2: Connecting the VP-410 Video-Audio to HDMI Scaler 6

Tables

Table 1: VP-410 Video-Audio to HDMI Scaler Front and Rear Panel Features 5
Table 2: The Display Menu and Parameters 7
Table 3: The OSD Settings Menu and Parameters 8
Table 4: Technical Specifications of the VP-410 Video-Audio to HDMI Scaler 8

Introduction

1 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models now
appear in 11 groups

1

Congratulations on purchasing your Kramer VP-410 Video-Audio to HDMI Scaler.
This product is ideal for:

that are clearly defined by function.

• Projection systems in conference rooms, boardrooms, hotels and churches

• Home theater up-scaling

The package includes the following items:

• VP-410 Video-Audio To HDMI Scaler

• Power adapter (+5V DC output)

• This user manual

2

2 Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

• Review the contents of this user manual

• Use Kramer high performance high resolution cables

3

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan

Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack

Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

3 The complete list of Kramer cables is available from http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2

2.1 Quick Start

This Quick Start chart summarizes the basic setup and operation steps.
