Kramer Electronics, Ltd.
USER MANUAL
Model:
VM-2DVI
High Resolution / Dual Link 1:2 DVI Distributor
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor 4
5
Connecting the VM-2DVI 5
6
Technical Specifications 7
Figures
Figure 1: VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor 4
Figure 2: Connecting a VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor 6
Tables
Table 1: VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor Features 4
Table 2: Technical Specifications of the VM-2DVI 7
Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups1, which are clearly defined
by function.
Congratulations on purchasing your Kramer VM-2DVI High Resolution /
Dual Link 1:2 DVI Distributor.
The VM-2DVI is ideal for audio video duplication studios, as well as rental
and staging. Each package includes the following items:
VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor
Power adapter (12V DC Input)
This user manual2
A single DVI LINK has a data transmission rate of 1.65Gbps per color. If you
need higher resolution, use DUAL LINK technology, which is supported by
the VM-2DVI High Resolution / Dual Link 1:2 DVI Distributor.
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
