Kramer Electronics, Ltd.
USER MANUAL
Model:
VM-114H2C
2 Input 1:4 HDMI DA/2x CAT5 Outputs
Contents
i
Contents
1 Introduction 1
2 Getting Starte d 1
2.1 Achieving the Best Performance 1
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 2
2.4 Quick Start 2
3 Overview 4
3.1 Using Shielded Twisted Pair Cable 5
3.2 About the Power Connect™ Feature 5
4 Defining the VM-114H2C 6
5 Operating the VM-114H2C 8
5.1 Connecting the VM-114H2C 8
5.2 Acquiring the EDID 9
5.2.1 Disabling/Enabling Deep Color Support 10
5.3 Connecting to the VM-114H2C via RS-232 10
5.4 RS-232 and IR Control and Pass-through 10
5.4.1 RS-232 Control and Pass-through Using the VM-114H2C 11
5.4.2 Local IR Control and IR Pass-through Using the VM-114H2C 11
6 Wiring the Twisted Pair RJ-45 Connectors 15
7 Technical Specifications 16
8 Default Communication Parameters 16
9 Default EDID 17
10 Kramer Protocol 2000 18
Figures
Figure 1: VM-114H2C Front Panel 6
Figure 2: VM-114H2C Rear Panel 7
Figure 3: Connecting the VM-114H2C 8
Figure 4: VM-114H2C RS-232 Control and Pass-through 11
Figure 5: VM-114H2C IR Control and Pass-through Example One 12
Figure 6: VM-114H2C IR Control and Pass-through Example Two 13
Figure 7: VM-114H2C IR Control and Pass-through Example Three 14
Figure 8: TP Pinout Wiring 15
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Contents
ii
Tables
Table 1: VM-114H2C Front Panel Features 6
Table 2: VM-114 H2C Rear Panel Features 7
Table 3: Technical Specifications of the VM-114H2C 16
Table 4: Default Communication Parameters 16
Table 5: Protocol Definitions 18
Table 6: Instruction Codes for Protocol 2000 19
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of o ur line, ma king the best eve n better! Our 1,000-plus different models now
appear in 11 groups
1
Congratulations on purchasing your Kramer Desktop VM-114H2C 2 Input 1:4
HDMI DA/2x CAT5 Outputs. The VM-114H2C is ideal for:
that are clearly defined by function.
• Home theater, presentatio n and multimedia applications
• Rental and stagi ng
The package includes the following items:
• VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs
• Power adapter (12V DC)
• Kramer RC-IR3 infrared remote control transmitter (including the required
batteries and a separate user manual
2
)
• This user manual
2
2 Getting Started
We recommend that you:
• Unpack t he equip ment carefully and s ave the original box and packaging
materials for possible fut ure shipment
• Review the contents of this user manua l
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack int o tight coils
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control Systems; GROUP 4: Format/Standards
Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and Scalers;
GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra
Products
2 Download up-to-date Kramer user manuals from
http://www kramerelectronics com
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
• Avoid interference from neighboring electrical appliances that may
adversely influence signal quality
• Position your Kramer VM-114H2C away from moisture, excessi ve sunlight
and dust
!
This equipment is to be used only inside a building. It may be
connected only to other equipment that is installed inside a building.
2.2 Sa fety Instructions
!
Caution: No operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical a nd Electronic Equipment (WE E E) Directive 2002/9 6/EC
aims to reduce the amount o f WEEE sent for disposal to la ndfill or incineration b y
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangement s in your particular countr y
go to our recycling pages at
http://www.kramerelectronics.com/support/recycling/.
2.4 Quick Start
This quick start chart summarizes the basic setup and operation steps of the
VM-114H2C.
Getting Started
3
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
3 Overview
The high quality VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs is a
switcher/distribution amplifier for HDMI and TP (Twisted Pair) signals. It re c locks
and equalizes one of two selectable input signals and distributes it to two HDMI
and two TP outputs.
In particular, the VM-114H2C:
• Supports up to 2.25Gbps bandwidth per graphic channel (HDMI), 1.65Gbps
bandwidth per graphic channel (DGKat)
• Can read and store in non-volatile memory the defaul t EDID or the EDID
1
block from one or a mix
2
• Features I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent
EDID hand ling & pr ocessing algorithm ensur es Plug and Play operatio n for
HDMI systems
of the output display devices, so it can then
provide the EDID information to the source even if the displ ay device is not
connected
• Supports HDMI (V1.4 w 3D, Deep Color
3
• Is HDCP compliant
, x.v.Color™ and 7.1
uncompressed audio channels (Dolby TrueHD, DTS-HD))
• Features LEDs indicating the selected input and active output
• Supports IR remote control and has a remote IR 3.5mm mini jack
• Is 12V DC fed and is housed in a Kramer desktop enclosure
The VM-114H2C supports a range of:
• Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on shielded
BC-DGKat524 cable
• Up to 90m (295ft) at 1080i, or up to 70m (230ft) at 1080p on shielded
BC-DGKat623 cable
• Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded
BC-DGKat7a23 cable
1 EDID is Extended Display Identification Data
2 The EDID acquired is a weighted average of all the connected outputs For example, if several displays with different resolutions are
connected to the outputs, the acquired EDID supports all the resolutions, as well as other parameters included in the EDID
3 On the HDMI input
Overview
5 5
3.1 Using Shielded Twisted Pair Cable
Kramer engineers have developed special twisted pair cables to best match our
digital twisted pair pr oducts; the Kramer: BC-DGKat524 (CAT 5 24 AWG) , the
Kramer BC-DGKat623 (CAT 6 23 AWG), and the Kramer BC-DGKat7a23 (CAT
7a 23 AWG) cables. These specially built cables significantly outperform regular
CAT 5/CAT 6 /CAT 7a cables.
3.2 About the Power Connect™ Feature
The Power Connect™ feature here means that only the transmitter needs to be
connected to a power source when the devices are within 90m (270ft) of each
other. The Power Connect™ feature applies as long as the cable can carry power.
The distance does not exceed 90m on standard CAT 5 cable. For longer dis tances,
heavier gauge cable should be used
1
!
.
Warning:
Using a TP cable that is incorrectly wired will
cause permanent damage to the device
1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances
