USER MANUAL
Model:
TP-219HD, XGA/HD Line Transmitter/Switcher
TP-220HD, XGA/HD Line Receiver/DA
Page 2
Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 3
3.1 About the Power Connect Feature 3
3.2 Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP) 4
4 Your XGA/HD Line Transmitter/Switcher and Receiver/DA 5
4.1 Your TP-219HD 5
4.2 Your TP-220HD 7
5 Connecting the TP-219HD and TP-220HD 8
5.1 Connecting an HD System 11
5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 11
6 Technical Specifications 12
Figures
Figure 1: TP-219HD XGA/HD Line Transmitter/Switcher 5
Figure 2: TP-219HD (Underside Panel) 6
Figure 3: TP-220HD XGA/HD Line Receiver/DA 7
Figure 4: TP-220HD (Underside Panel) 8
Figure 5: Connecting the TP-219HD/TP-220HD XGA System 10
Figure 6: Connecting an HD Source 11
Figure 7: CAT 5 PINOUT 11
Tables
Table 1: TP-219HD XGA/HD Line Transmitter/Switcher Features 5
Table 2: TP-219HD (Underside Panel) Features 6
Table 3: TP-220HD XGA/HD Line Receiver/DA Features 7
Table 4: TP-220HD (Underside Panel) Features 8
Table 5: CAT 5 PINOUT 11
Table 6: Technical Specifications of the TP-219HD and TP-220HD Setup 12
Page 3
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly
defined by function.
Thank you for purchasing the Kramer TOOLS TP-219HD XGA/HD Line
Transmitter/Switcher and Kramer TOOLS TP-220HD XGA/HD Line
Receiver/DA which are ideal for:
• Presentation and multimedia applications
• Long range graphics distribution for schools, hospitals, security, and
stores
The package includes the following:
• TP-219HD and/or TP-220HD
• Power supply (12V DC)
• This user manual
2
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high performance high-resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; G ROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
Page 4
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
Step 1: Connect the inputs and outputs - see section 5
Step 2: Connect the power
1
3
TP-219HD: Connect the
inputs
TP-220HD: Connect the
outputs
Connect the TP-219 to
the TP-220 via the CAT 5
cable
TP-219HD: Connect the
inputs
TP-220HD: Connect the
outputs
Connect the TP-219 to
the TP-220 via the CAT 5
cable
m
m
Adjust the EQ. and LEVEL on the RP-220HD
Set the SYNC Polarity switches on the undersides of the units
m
m
Adjust the EQ. and LEVEL on the RP-220HD
Set the SYNC Polarity switches on the undersides of the units
If required:
Long CAT 5 cable
TP-220HD
XGA/HD Line Receiver/ DA
O2
UTPUT
O1
UTPUT
LI
INE N
Display 2
Display 1
TP-219HD
XGA/HDLine Transmitter/Switcher
I2
NPUT
I
NPUT
1
LO
INE UT
Computer
Graphics
Source 1
Computer
Graphics
Source 2
VGA
VGA
VGA
VGA
TP-220HD
TP-219HD
1
2
2
3
Step 3: Select the input - see section 5
Page 5
Overview
3
3 Overview
The TP-219HD is a high-performance twisted pair transmitter for computer
graphics signals with resolutions ranging from VGA through UXGA and
higher as well as HDTV signals up to 1080p. It takes one of two inputs as
selected by the user and converts it to a twisted pair signal.
The TP-220HD is a high-performance twisted pair receiver for computer
graphics signals with resolutions ranging from VGA through UXGA and
higher as well as HDTV signals up to 1080p. It converts a twisted pair
signal back into two identical signals in the original format.
The TP-219HD XGA/HD Line Transmitter/Switcher:
• Has a transmission range of more than 300 feet (more than 100 meters)
• Includes two XGA
1
/YUV2 inputs on 15-pin HD connectors
• Features an INPUT SELECTOR button to select between INPUT 1 and
INPUT 2
• Can change the polarity of encoding H and V Sync for XGA graphics
• Can power or be powered by the receiver over the same CAT 5 cable
(see section 3.1
)
• Is 12V DC fed
The TP-220HD XGA/HD Line Receiver/DA:
• Has two XGA/YUV
2
outputs on 15-pin HD connecto rs
• Can change the polarity of decoding H and V Sync for XGA graphics
• Includes EQ. and LEVEL controls
• Can power or be powered by the transmitter over the same CAT 5 cable
(see section 3.1
)
• Is 12V DC fed
3.1 About the Power Connect Feature
The
Power Connect feature applies as long as the cable can carry power.
This feature is available when using STP cable and the distance does not
exceed 50m on standard CAT 5 cable. For longer distances, heavy gauge
cable should be used
3
. For units which are connected via RJ-45 connectors,
make sure that the shield of the STP cable is connected to the metal casing
1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an HD15 connector
having a resolution from VGA up to UXGA
2 Also known as Y, Cb, Cr, or Y, B-Y, R-Y, or Y, Pb, Pr
3 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances
Page 6
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
of the connectors on both ends of the cable. For units which are connected
via terminal block connectors, the shield of the STP cable must be
connected to a ground terminal on the units at both ends (use the ground
terminal of the power supply connection if necessary).
For a CAT 5 cable exceeding a distance of 50m, separate power supplies
should be connected to the transmitter and to the receiver simultaneously.
3.2 Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP)
We
recommend that you use Shielded Twisted Pair (STP) cable. There are
different levels of STP cable available, and we advise you to use the best
quality STP cable that you can afford. Our non-skew-free cable, Kramer
BC-STP is intended for analog signals where skewing is not an issue. For
cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP,
may be used. Bear in mind, though, that we advise using STP cables where
possible, since the compliance to electromagnetic interference was tested
using those cables.
Although Unshielded Twisted Pair (UTP) cable might be preferred for long
range applications, the UTP cable should be installed far away from electric
cables, motors and so on, which are prone to create electrical interference .
However, since the use of UTP cable m ight cause inconformity to
electromagnetic standards, Kramer does not commit to meeting the standard
with UTP cable.
To achieve the best performance:
• Use only good quality connection cables
1
to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables).
• Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer products
away from moisture, excessive sunlight and dust
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
Page 7
Your XGA/HD Line Transmitter/Switcher and Receiver/DA
5
4 Your XGA/HD Line Transmitter/Switcher and Receiver/DA
This section describes the:
• TP-219HD XGA/HD – Line Transmitter/Switcher, see section 4.1
• TP-220HD XGA/HD – Line Receiver/DA, see section 4.2
4.1 Your TP-219HD
Figure 1
and Table 1 define the TP-219HD:
1
1
6
6
2
2
4
4
3
3
5
5
Figure 1: TP-219HD XGA/HD Line Transmitter/Switcher
Table 1: TP-219HD XGA/HD Line Transmitter/Switcher Features
# Feature Function
1 LINE OUT RJ-45 Connector Connect1 to the LINE IN RJ-45 connector on the TP-220HD
2 INPUT 1 15- pi n HD Connector Connect to the first XGA/HD source
3 INPUT 2 15- pi n HD Connector Connect to the second XGA/HD source
4
12V DC
+12V DC connector for powering the unit
5 INPUT SELECTOR button Press to select IN 2; release to select IN 1
6 ON LED Illuminates when receiving power
1 Using a UTP CAT5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Table 5 and Figure 7)
Page 8
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your XGA/HD Line Transmitter/Switcher and Receiver/DA
6
Figure 2 and Table 2 define the TP-219HD underside panel:
Figure 2: TP-219HD (Underside Panel)
Table 2: TP-219HD (Underside Panel) Features
# Feature Function
1 HS Switch Slide the switch up (to NORMAL) to retain the polarity
Slide the switch down
1
to change the HS polarity to NEGATIVE polarity2
2 VS Switch Slide the switch up (to NORMAL) to retain the polarity
Slide the switch down
1
to change the VS polarity to NEGATIVE polarity2
1 By default, both switches are set to NORMAL
2 Downgoing syncs
Page 9
Your XGA/HD Line Transmitter/Switcher and Receiver/DA
7
4.2 Your TP-220HD
Figure 3
and Table 3 define the TP-220HD:
Figure 3: TP-220HD XGA/HD Line Receiver/DA
Table 3: TP-220HD XGA/HD Line Receiver/DA Features
# Feature Function
1 LINE IN RJ-45 Connector Connect1 to the LINE OUT RJ-45 connector on t he TP-219HD
2 OUTPUT 1 15-pi n HD Connector Connect to the first XGA/HD acceptor
3 OUTPUT 2 15-pi n HD Connector Connect to the second XGA/HD acceptor
4
12V DC
+12V DC connector for powering the unit
5 EQ. Trimmer Adjust2 the cable compensation equalization level
6 LEVEL Trimmer Adjust2 the output signal level
7 ON LED Illuminates when receiving power
1 Using a UTP CAT5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Table 5 and Figure 7)
2 Insert a screwdriver into the small hole and carefully rotate it, to trim the appropriate level
1
1
6
6
7
7
2
2
4
4
3
3
5
5
Page 10
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the TP-219HD and TP-220HD
8
Figure 4 and Table 4 define the TP-220HD underside panel:
Figure 4: TP-220HD (Underside Panel)
Table 4: TP-220HD (Underside Panel) Features
# Feature Function
1 HS Switch Slide the switch up1 (to INVERTED) to invert the HS polarity
Slide the switch down (to NORMAL) to retain the polarity
2 VS Switch Slide the switch up1 (to INVERTED) to invert the VS polarity
Slide the switch down (to NORMAL) to retain the polarity
5 Connecting the TP-219HD and TP-220HD
You can use the TP-219HD XGA/HD – Line Transmitter/Switcher with the
TP-220HD XGA/HD – Line Receiver/DA to configure an XGA/HD DA
system. This will let you transmit one selected computer graphics/HD signal
to two displays via long line CAT 5 UTP cabling.
To connect th e TP-219HD to the TP-220HD, as the example in Figure 5
illustrates, do the following:
1. On the TP-219HD, connect
2
:
An XGA
3
source (for example, Computer Graphics Source 1) to
the INPUT 1 15-pin HD connector
An XGA
3
source (for example, Computer Graphics Source 2) to
the INPUT 2 15-pin HD connector
2. If necessary, set the HS and VS switches on the TP-219HD underside
4
.
1 By default, both switches are set to NORMAL
2 You do not have to connect both inputs
3 Alternatively, you can connect an HD source, see section 5.1
4 By default, both switches are set to normal (see Figure 2
and Table 2)
Page 11
Connecting the TP-219HD and TP-220HD
9
3. On the TP-220HD, connect1 the:
OUTPUT 1 15-pin HD connector to a n XG A
2
acceptor (for
example, Display 1)
OUTPUT 2 15-pin HD connector to a n XG A
2
acceptor (for
example, Display 2)
4. If necessary, set the HS and VS switches on the TP-220HD underside
3
.
5. Connect the LINE OUT RJ-45 connector on the TP-219HD to the LINE IN
RJ-45 connector on the TP-220HD, via CAT 5 cabling, see sect ion 5.2
.
6. Connect the 12V DC power adapter to the power socket and c onnect the
adapter to the mains electricity on both
4
the TP-219HD and the TP-220HD
(not shown in Figure 5
).
The selected signal from the XGA/HD source is transmitted via CAT 5
cable, decoded and converted at the OUTPUT 1 and OUTPUT 2 15-pin
HD connectors to the XGA acceptors simultaneously.
1 You do not have to connect both outputs
2 Alternatively, you can connect an HD acceptor, see section 5.1
3 By default, both switches are set to normal (see Figure 4
and Table 4)
4 If you cannot connect the power to both the TP-219HD and TP-220HD, you can just connect the power to one of them
Page 12
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the TP-219HD and TP-220HD
10
Figure 5: Connecting the TP-219HD/TP-220HD XGA System
Long CAT 5 cable
TP-220HD
XGA/HD Line Receiver/ DA
O2
UTPUT
O1
UTPUT
LI
INE N
Display 2
Display 1
TP-219HD
XGA/HD Line Transmitter/Switcher
I2
NPUT
I
NPUT
1
LO
INE UT
Computer
Graphics
Source 1
Computer
Graphics
Source 2
VGA
VGA
VGA
VGA
TP-220HD
TP-219HD
Page 13
Connecting the TP-219HD and TP-220HD
11
5.1 Connecting an HD System
When connecting a high definition source, as illustrated in Figure 6
, use a
breakout cable such as the Kramer C-GM/3RVF. If you have a VGA to a
5BNC cable, use the RGB wires only.
Figure 6: Connecting an HD Source
You can also connect an HD acceptor (for example, a plasma display) using
the same PINOUT.
5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Conne
ctors
Table 5
and Figure 7 define the UTP CAT 5 PINOUT, using a straight pin
to pin cable with RJ-45 connectors:
Table 5: CAT 5 PINOUT
Figure 7: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN Wire Color PIN Wire Color
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8 Pair 4 7 and 8
Set Top Box
Source
PIN#
1
Pr
Y
Pb
2
3
Signal
XGA Connector PINOUT
TP-219HD
XGA/HD Line Transmitter/Switcher
I2
NPUT
I
NPUT
1
LO
INE UT
Page 14
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
12
6 Technical Specifications
Table 6 includes the technical specifications1.
Table 6: Technical Specifications of the TP-219HD and TP-220HD Setup
TP-219HD TP-220HD
INPUTS: 2 XGA/HD on 15-pin HD connectors 1 CAT 5 IN on an RJ-45 connector
OUTPUTS: 1 CAT 5 OUT on an RJ-45 connector 2 XGA/HD on 15-pin HD connectors
MAX . O U T P U T LEVEL: 1.5Vpp
RESOLUTION: Up to UXGA, up to 1080p
DIFF. GAIN: 2.3%
DIFF. PHASE: 0.2°
K-FACTOR: 0.1%
S/N RATIO: 70dB @5MHz
CROSSTALK (all hostile): -45dB
CONTROLS: Input selector button Level: -9.2dB to +2.1dB
EQ.: 0 to +29.5dB @50MHz
COUPLING: AC DC2
POWER SOURCE: 12V, 300mA, when feeding TP-220HD 12V, 300mA, when feeding TP-219HD
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx. each
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 The TP-219HD causes the setup to be AC
Page 15
13
LIMITED WARRANTY
WHO IS PROTECTED?
WHA T IS COVERED AND WH AT IS NOT CO VERED
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PA Y FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Krame r El e ct ronics (hereafter ) warrants this pr oduct free from defects i n m at e r ial a nd workm anship under the
following terms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
W e will p ay labor an d mate rial expen ses for c overed i tems. We will n ot pay for the follo wing:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not b e liabl e for :
This warranty gives you specific legal rights, and you may also have other rights, which vary from p lace to place.
All produ cts returned to Kramer for service must have prior ap proval. This may be obtained from your dealer .
This equipment has been tested to determine com pliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Resi dential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity stand ard.
Part 1: Residential, commercial and light industry environment".
CFR-47: F CC* Rules and Regula tions:
Part 15: “Radio frequency devices
Subpart B Unintentional radi ators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. A ny product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
T AMPERED sticker has been torn,
3. Dama ge, dete rioration o r malfun ction r esulting f rom:
i) Accide nt, misus e, abuse, n eglect, fi re, water , lightn ing or oth er acts of nature
ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair o r attemp ted repai r by anyo ne not auth orized by Kramer
iv) Any shipment of the product (claims must be pres ented to the carrier)
v) Removal or insta llation of the prod uct
vi) Any other cau se, which does not relate t o a product d efect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
1. Removal or installations charges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
respon sibili ty of the Kr amer dea ler from whom the produc t was pur chased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length o f this warranty.
1. Damage to o ther prop erty cause d by defect s in this product, damages ba sed upon i nconven ience, lo ss of use of the produ ct, loss
of time, commercial loss; or:
2. Any othe r da mages , w hether inc iden tal, conse quen tial or o the rwise. Som e co untr ies m ay n ot allow lim itati ons o n how l ong an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limit ation s and e xclus ions ma y no t apply to yo u.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of t he manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed powe r to the machine.
Please use recommended interconnection cables to connect the machi ne to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approved u sing STP cable ( for twisted pa ir produc ts)
NOTE:
Part 1:
Page 16
Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N: 2900-000208 REV 2
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
P/N:
2900- 000208
Rev:
2
Loading...
