Kramer TOOLS 903 User Manual

Kramer Electronics, Ltd.

USER MANUAL

Model:

903

Personal Stereo Amplifier

Contents

i

Contents

1

Introduction 1

2

Getting Started 1

3

Your Personal Stereo Amplifier 1

4

Using the Personal Stereo Amplifier 4

4.1

Connecting the Personal Stereo Amplifier 4

4.2

Operating the Personal Stereo Amplifier 4

5

Technical Specifications 6

Figures

Figure 1: 903 Personal Stereo Amplifier 3
Figure 2: Connecting the 903 Personal Stereo Amplifier 5

Tables

Table 1: Features and Functions of the 903 Personal Stereo Amplifier 3
Table 2: Technical Specifications of the 903 Personal Stereo Amplifier 6

Introduction

1

1 Introduction

Dedication by Kramer Electronics since 1981, to the development and
manufacture of high quality video/audio equipment, makes the Kramer line
an integral part of the finest production and presentation facilities in the
world. In recent years, Kramer has redesigned and upgraded most of the line,
making the best even better! The Kramer line of professional video/audio
electronics is one of the most versatile and complete available, and is a true
leader in terms of quality, workmanship, price/performance ratio and
innovation. In addition to our high quality accessories, like the Kramer
TOOLS 903 Personal Stereo Amplifier, we also offer excellent switchers and
matrices, distribution amplifiers, presentation processors, interfaces, remote
controllers and computer-related products. Congratulations on purchasing
your Kramer 903 Personal Stereo Amplifier. This product is ideal for:

 Presentation rooms and multimedia applications for quick, local audio

amplification

 Personal audio listening (for example, PC and portable CD player)

The package includes the following items:

 903

Personal Stereo Amplifier

 Power adapter (12V DC Input)
 This user manual1

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

3 Your Personal Stereo Amplifier

The high performance 903 Personal Stereo Amplifier can output up to
20 Watts RMS2, as it uses the latest Class “D” technology for highly efficient
conversion3 to the pair of loudspeakers with the absolute minimum power
loss.

1 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com/manuals.html
2 More than is needed for personal and small presentation applications
3 This prevents the 903 from over-heating. The 903 can generate its maximum power output from a 12V power supply

Your Personal Stereo Amplifier

KRAMER ELECTRONICS, LTD.

2

The 903 includes:

 Control knobs to adjust volume, bass, mid, treble and stereo balance
 4 INPUT SELECTOR switches
 Outputs for a headphone set and for a pair of loudspeakers1
 3 stereo inputs on standard RCA connectors
 An additional input on a mini 3.5 mm socket for easy interface with a

sound card or any music player2

 A LOUD switch for automatic equalization in low volume listening3

Achieving the best performance means:

 Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)

 Avoiding interference from neighboring electrical appliances and
positioning your Kramer 903 away from moisture, excessive sunlight and dust

1 Plugging in the headphone set automatically disconnects the loudspeakers
2 Portable CD player, minidisk player, Walkman®
3 Pressing the LOUD switch compensates for what the ear does not hear in noisy environments, or with a low volume.
Pressing the LOUD switch with a high volume has little effect

Your Personal Stereo Amplifier

3

Figure 1 and Table 1 define the 903 Personal Stereo Amplifier:

Figure 1: 903 Personal Stereo Amplifier

Table 1: Features and Functions of the 903 Personal Stereo Amplifier

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 SPEAKERS OUT (L+L- R+R-)

Terminal Block Connectors

Connect to the pair of loudspeakers

3 INPUT 4 (Left) RCA Connector Connects to the left stereo audio line level source 4

4 INPUT 4 (Right) RCA Connector Connects to the right stereo audio line level source 4

5 INPUT 3 (Left) RCA Connector Connects to the left stereo audio line level source 3

6 INPUT 3 (Right) RCA Connector Connects to the right stereo audio line level source 3

7 INPUT 2 (Left) RCA Connector Connects to the left stereo audio line level source 2

8 INPUT 2 (Right) RCA Connector Connects to the right stereo audio line level source 2
9 INPUT 1 Mini 3.5 mm Socket Connects to an interface with a sound card or other player

10 INPUT SELECTOR Switches Pushing in selects the appropriate input (from 1 to 4)

11 Treble Control Knob Controls the treble (high frequencies)

12 MID Control Knob Controls the mid frequencies

13 Bass Control Knob Controls the bass (low frequencies)

14 Volume Control Knob Controls the signal output level
15 Balance Control Knob Adjusts the balance between the right and left channels

16 LOUD Switch Boosts equalization for low volume listening environments

17 ON LED Illuminates when receiving power

18 PHONES connector Connects to the headphone set

Using the Personal Stereo Amplifier

KRAMER ELECTRONICS, LTD.

4

4 Using the Personal Stereo Amplifier

Sections 4.1 and 4.2 describe how to connect and how to operate your 903
Personal Stereo Amplifier, respectively.

4.1 Connecting the Personal Stereo Amplifier

Connect your 903, as the example in Figure 2 illustrates:

1. Connect a stereo audio source to the Left and Right RCA connectors for

up to 3 inputs (that is, INPUT 2, INPUT 3 and INPUT 4)1

2. Connect a music player to the 3.5 mm socket (INPUT 1)1

3. Connect one or both of the following outputs:

 The SPEAKERS OUT connector to a pair of loudspeakers, by connecting
the left loudspeaker to the “L+” and the “L-” terminal block connectors, and
the right loudspeaker to the “R+” and the “R-” terminal block connectors
Do not Ground the loudspeakers

 The PHONES connector to a headphone set (plugging in a headphone set
to the PHONES connector disconnects the loudspeakers)

4. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity.

4.2 Operating the Personal Stereo Amplifier

Operate your 903, as Figure 2 illustrates:

1. Choose the active audio source via an INPUT SELECTOR switch.

2. Adjust the volume, bass, mid, treble and balance controls as required.

3. Select the LOUD switch setting as required.

1 Unused inputs may be left unconnected

Using the Personal Stereo Amplifier

5

Figure 2: Connecting the 903 Personal Stereo Amplifier

Technical Specifications

KRAMER ELECTRONICS, LTD.

6

5 Technical Specifications

Table 2: Technical Specifications1 of the 903 Personal Stereo Amplifier

Inputs: 3 stereo inputs on RCA connectors

1 stereo input on mini 3.5 mm socket

Outputs:

Stereo loudspeakers (4 speakers or higher) on terminal block; Headphones

Bandwidth: 20 kHz -3dB
S/N Ratio: 77 dB unweighted

THD + Noise: 0.5% @ 1kHz, 60mV

Controls: 4 input selector switches, volume, bass, mid, treble and balance control knobs

Output Power: Up to 20 Watts RMS

Dimensions: 12 cm x 7.5 cm x 2.5 cm (4.7" x 2.95" x 0.98", W, D, H)

Power Source: 12 VDC, 2.5A
Weight: .3 kg (0.66lbs.) approx.

Accessories: Power supply, mounting bracket

1 Specifications are subject to change without notice
