KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
MODULAR TBUS-10xl
Table Connection Bus
P/N: 2900-300224 Rev 1
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Glossary 3
2.3 Recycling Kramer Products 3
3 Overview 4
4 Your TBUS-10xl Enclosure 5
4.1 TBUS-10xl Optional Inner Frames 6
4.2 TBUS-10xl Optional Inserts 7
4.3 Power Socket Options 8
4.4 Power Cord Options 11
5 Installing the TBUS-10xl 12
5.1 Assembling the Inner Frame 12
5.2 Installing the Inner Frame 18
5.3 Cutting an Opening in the Table 19
5.4 Inserting the TBUS-10xl through the Cut Out Opening 20
5.5 Connecting the Cables 21
5.6 Inserting Pass-through Cables 21
5.7 Adjusting the Height of the Inner frame 22
6 Using the TBUS-10xl 23
7 Technical Specifications of the Assembled TBUS-10xl 24
Figures
Figure 1: TBUS-10xl Enclosure Top View 5
Figure 2: TBUS-10xl Inner Frame (P/N: 80-000028) 13
Figure 3: Installing the MegaTOOL 14
Figure 4: T-RC8IR (P/N: 80-000599) 15
Figure 5: Removing the RC-8IR Faceplate 15
Figure 6: T-RC8IR Installation 16
Figure 7: Removing the Button Cover Plate Mounting Screws 17
Figure 8: T-RC-76/T-RC-78 Installation 17
Figure 9: Cut out Dimensions 19
Figure 10: Inserting TBUS-10xl into the Prepared Opening 20
Figure 11: TBUS-10xl Boardroom Installation 23
TBUS-10xl – Contents i
1
i
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Thank you for purchasing the Kramer TBUS-10xl enclosure, which is ideal for
boardrooms, conference and training rooms!
Note that the inner frame, power socket assembly, power cord and
other inserts for the TBUS-10xl enclosure are purchased
separately.
TBUS-10xl - Introduction 1
i
!
!
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, a complete list of Kramer wall plates and module
connectors, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack into tight coils
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your Kramer TBUS-10xl away from moisture, excessive sunlight
and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
There are no operator serviceable parts inside the unit.
2 TBUS-10xl - Getting Started
