USER MANUAL

MODEL:

Yard en 6 -C (SP K- C6 21 -K )

Closed-back Ceiling Speakers

P/N: 2900-300347 Rev 1

This page is intentionally left blank

Yarden 6-C – Contents

i

Contents

1 Introduction 1
2 Getting Started 2

2.1 Achieving the Best Performance 2

3 Overview 3
4 Your Yarden 6-C Closed-back Ceiling Speakers 4
5 Installing the Yarden 6-C Closed-back Ceiling Speakers 6

5.1 Choosing the Best Location 6

5.2 Cutting the Ceiling Tile 6

5.3 Mounting the Speakers 7

5.4 Setting up an Array Installation 10

5.5 Painting the Speaker 13

6 Technical Specifications 14

Figures

Figure 1: Yarden 6-C in a Boardroom Setup 3
Figure 2: Yarden 6-C Closed-back Ceiling Speaker 4
Figure 3: Yarden 6-C Schematic Diagram 5
Figure 4: Mounting the Yarden 6-C 8
Figure 5: Plugging and Securing the Cable 9
Figure 6: Tighten the Mounting Tabs 9
Figure 7: Adjust Tap Selector 10
Figure 8: Square Layout 11
Figure 9: Hexagonal Layout 11
Figure 10: Square Layout Parallel Wiring 12

Yarden 6-C - Introduction

1

1

Yarden 6-C speakers are designed for indoor dry locations and are
suitable for use in air handling spaces (plenum spaces).

i

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.

Congratulations on purchasing your Kramer Yarden 6-C Closed-back Ceiling
Speakers, which are ideal for the following typical applications:

 Hotel lobbies and conference rooms
 Boardrooms and meeting rooms
 Classrooms and lecture venues

2

Yarden 6-C - Getting Started

Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).

This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.

Do not open the housing of the speaker; doing so may reduce the
quality of the sound.

i

!

i

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

2.1 Achieving the Best Performance

To achieve the best performance:

 Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)

 Do not secure the cables in tight bundles or roll the slack into tight coils
 Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

 Position your Kramer Speakers away from moisture, excessive sunlight and

dust
