Kramer RC-54DL User Manual

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

RC-54DL

KNET™ Auxiliary Control Panel

P/N: 2900-300130 Rev 1

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

RC-54DL – Contents i

Contents

1 Introduction 1
2 Getting Started 2

2.1 Achieving the Best Performance 2

3 Overview 3

3.1 The RC-54DL KNET™ Auxiliary Control Panel Front Side 4

3.2 The RC-54DL KNET™ Auxiliary Control Panel Rear Side 5

4 Connecting the RC-54DL KNET™ Auxiliary Control Panel 6
5 Grounding the RC-54DL 7
6 Operating the RC-54DL 8
7 Front Panel Button Caps and Labels 9

7.1 Installing the Front Panel Button Caps, Labels 12

8 Technical Specifications 14

Figures

Figure 1: RC-54DL Front Panel 4
Figure 2: RC-54DL Rear Panel 5
Figure 3: Connecting the RC-54DL 6
Figure 4: Grounding Connection Components 7
Figure 5: RC-54DL to RC-74DL Pinout Connection 8
Figure 6: Sample Button Label Sheet 11
Figure 7: Button Cap Orientation 12
Figure 8: Button Cap Orientation with Label 12
Figure 9: Placing the Button Cap 12

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

RC-54DL – Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer RC-54DL KNET™ Auxiliary Control

Panel, which is designed to let you remotely control an A/V system with ease, in a

multimedia classroom or conference room.

Each package includes the following items:

• The RC-54DL KNET™ Auxiliary Control Panel

• 3 Gang US Installation mud ring

• Power supply

• This user manual

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

2 RC-54DL - Getting Started

2 Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

• Review the contents of this user manual

• Use Kramer high performance high resolution cables

Go to http://www.kramerelectronics.com to check for up-to-date user
manuals, application programs, and to check if firmware upgrades are
available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

• Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

• Do not secure the cables in tight bundles or roll the slack into tight coils

• Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

• Position your Kramer RC-54DL away from moisture, excessive sunlight and

dust

Caution: No operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall
adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall
before installing

K-NET™ is a proprietary Kramer protocol for interconnecting Kramer
units

i

!

i

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

RC-54DL – Overview 3

3 Overview

The RC-54DL is a 3 gang US, auxiliary room controller that acts as an all-in-one

extended remote control panel for remotely controlling room controllers (for

example, the Kramer RC-74DL) in classrooms, boardrooms or auditoriums.

The RC-54DL features:

• 12 configurable, RGB backlit, front panel buttons in three groups

• 1 configurable rotary up/down controller with direction indicator LEDs

• Two K-NET™ control channels that connect compatible user interfaces and

supply power and control data over a single cable

• Flexible control via K-NET

k-Config is available from Kramer Electronics on our Web site at

http://www.kramerelectronics.com/support/?soft=k-config

i

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

4 RC-54DL - Overview

3.1 The RC-54DL KNET™ Auxiliary Control Panel Front Side

This section defines the RC-54DL:

Figure 1: RC-54DL Front Panel

#

Feature

Function

1 6 Configurable Button

Switches

Function is programmed by the K-Config Configuration
software

2 LCD Label Displays up to 8 characters at once (set by the K-Config

configuration software)

3 4 Configurable Button

Switches

Function is programmed by the K-Config Configuration
software

4 LCD Label Displays up to 8 characters at once (set by the K-Config

configuration software)

5 2 Configurable Button

Switches

Function is programmed by the K-Config Configuration
software

6 LCD Label Displays up to 8 characters at once (set by the K-Config

configuration software)

7 Rotary Dial up/down LED

indicator

Indicates the level set by the rotary dial

VOLUME Rotary Dial Function is programmed by the K-Config Configuration

software
