Kramer Cobra RWM, Cobra TWM, Cobra TM-4, Cobra TMB User Manual

Kramer Electronics, Ltd.

USER MANUAL



Models:

Cobra RWM

Cobra TWM

Cobra TM-4

Cobra TMB

Contents

i

Contents

1

Introduction 1

2

Getting Started 1

3

Overview 1

4

Rack Mounting Solutions 2

4.1

Cobra RWM (for the Cobra R1300A, Cobra R1300S2) 2

4.2

Cobra TWM (for the Cobra R500A, R500-2 Series) 3

4.3

Cobra TM-4 (for the Cobra R500A, R500-2 Series) 4

Figures

Figure 1: Cobra RWM Receiver Mounting Bracket 2
Figure 2: Cobra TWM Built-in Mounting Tabs 3
Figure 3: Cobra TM-4 Rack Mounting Kit 4
Figure 4: Cobra Transmitter Rack Mounting Kit 4

Introduction

1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in eight groups1 that are clearly defined
by function. Congratulations on purchasing your Kramer rack mount solutions:
Cobra RWM and/or Cobra TWM and/or Cobra TM-4, and/or Cobra TMB.
The package includes the rack mount with the required screws and this user
manual2.

The Kramer Cobra series products are not compatible with Kramer non-Cobra

series products.

2 Getting Started

We recommend that you:
 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

3 Overview

Achieving the best performance means:

 Connecting only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)

 Avoiding interference from neighboring electrical appliances that may

adversely influence signal quality and positioning your product in a
location free from moisture and away from excessive sunlight and dust

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
