Installation Instructions
MODELS:
CLS-AOCH/xl (Low Smoke Version)
CP-AOCH/xl (Plenum Version)
Fiber Optic High Speed Pluggable HDMI Cable
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to this user manual may be found.
We welcome your questions, comments, and feedback.
www.kramerAV.com
info@kramerel.com
CLS-AOCH/xl / CP-AOCH/xl Fiber Optic High Speed Pluggable HDMI Cable
Congratulations on purchasing your Kramer CLS-AOCH/xl / CP-AOCH/xl Plug and Play active Fiber
Optic High Speed Pluggable HDMI Cable which is suited for critical and versatile installations.
The CLS-AOCH/xl / CP-AOCH/xl provides an extremely
high quality signal over a wide range of resolutions, up to
4K@60Hz (4:2:0) / 4K@ 30Hz (4:4:4). This cable is
available in different lengths from 33ft (10m) to 328ft (100m).
The CLS-AOCH/xl / CP-AOCH/xl has a slim design to let
you pull the cables easily (together with the supplied pulling
tool) through small-sized conduits.
The CLS-AOCH/xl / CP-AOCH/xl is ideal for long distance transmission in professional AV systems,
indoor and outdoor digital signage and kiosks, home theater systems, surgical theaters, facility
automation systems and whenever high resolution video and audio are required.
Figure 1: HDMI Connector plugs
(Source and Display)
Features
The CLS-AOCH/xl / CP-AOCH/xl:
• Supports a wide range of resolutions up to 4K@60Hz (col or space 4:2:0) and 4K@30Hz (color
space 4:4:4) Full HD, 3D, Deep Color
• Supports Multi-channel audio, Dolby True HD, DTS-HD Master Audio
• Is HDMI compliant: EDID, CEC, HDCP
• Features K-Lock Pull-Resistant Connectors that provide 15lbs of restraining force for a non-slip
connection
• Reduced EMI and RFI
• Has built-in powering with low power consumption
• Includes a micro USB port to connect to an external 5V power supply (mostly on the display
side)
• Has high pulling strength and compression load
• Has Source / Display clearly printed on the connector as well as tagged on the cable for easy
identification
Cable Dimensions
The CLS-AOCH/xl / CP-AOCH/xl includes four optical fibers and six AWG 28 wires with compact size
HDMI connectors. On the source side, the micro HDMI connector enables smooth pulling of the cable.
The SOURCE end connects to the source (for example, a DVD, Blu-ray or game console box) and the
DISPLAY end to the acceptor (for example, a projector, an LCD display or a tablet device),
see Figure 2
(note that SOURCE appears here as an example).
Do not disassemble or modify the products, especially the HDMI connector head parts.
(tagged Source if pulling the source side or Display if pulling the display side).
Figure 2: HDMI Connectors – SOURCE and DISPLAY (with Dimensions in mm)
CLS-AOCH/xl / CP-AOCH/xl Plug and Play Installation
Before installing the cable, make sure that you have an HDMI graphic card or devices with an HDMI
port (for example, a PC, laptop, DVD/Blue-ray player or any other video/audio signal source device).
Optical fiber cable is not robust physically compared to conventional copper cable
materials. Even though this cable is designed to be resistant to artificial strengths on
the cable, CLS-AOCH/xl / CP-AOCH/xl can be damaged if it is excessively pinc hed,
twisted or kinked when being installed and after being installed. Take care not to bend
or twist the cable tightly.
When CLS-AOCH/xl / CP-AOCH/xl is installed into the conduit, the fiber pulling
strength and the bending radius are the key conditions to safe installation of the cable.
To install the CLS-AOCH/xl / CP-AOCH/xl:
1. Unpack the cable from the package with care and remove the cable tie.
2. Place the micro-HDMI (Type D) connector inside the Pulling Tool and cl ose its cover.
Note that you can pull the cable either from the display side or the source side (as
shown in Figure 3
3. Attach the pulling cable to the Pulling Tool.
Figure 3: Attaching the Pulling Tool
4. Carefully install the cable (for exam ple, in the wall or conduit or under the floor).
), but you have to make sure that the cable polarity is correct
VIDEO RESOLUTION:
4K@60Hz (4:2:0), 4K@30Hz (4:4:4), 1080p Full HD Deep Color 48 bit, 3D
EMBEDDED AUDIO SUPPORT:
PCM 8ch, Dolby Digital True HD, DTS-HD Master Audio
Cable Assembly
HDMI CONNECTOR:
Male HDMI Type A Connector
DIMENSIONS:
Micro HDMI port: 1.23cm x 4.9cm x 0.8cm (0.484" x 1.93" x 0.31") W, D, H
Assembly: 2.22cm x 7.1cm x 0.99cm (0.874" x 2.79" x 0.39") W, D, H
STRENGTH:
CABLE PULLING STRENGTH:
500N (50kg, 110lbs)
MICRO USB CABLE
External 5V power supply cable (for optional use)
Power
from an external USB connector on the display side.
POWER CONSUMPTION:
0.25W max.
General
(60m), 230ft (70m), 262ft (80m), 295ft (90m) and 328ft (100m)
5. Once the cable installation is complete, plug the SOURCE connector head of the cable into the
source devices.
Do not plug the SOURCE connector to the display device.
6. Plug the DISPLAY connector head of the cable into the display devices.
Do not plug the DISPLAY connector to the source device.
7. Switch on the power of the source and display devices.
8. If required, connect an external power source via the micro USB connector on the Display side.
Troubleshooting
If you have encountered a problem, check that:
• The source and display devices are both switched on
• Both HDMI connector heads are fully plugged into the devices
• The cable or its jacket is not physically damaged
• The cable is not bent or kinked
Note that it is important to connect the cable correctly as marked on the end of each
connector: SOURCE to the source s i de and DISPLAY to the acceptor side.
Specifications
Audio and Power
HDMI COMPLIANCE: HDCP 2.2, EDID, CEC
Type A HDMI port: 3.1cm x 4cm x 0.95cm (1.22" x 1.57" x 0.37") W, D, H
CABLE STRUCTURE: Hybrid Optical Fiber Cable
CABLE JACKET MATERIAL: UL Plenum (CMP-OF) and LSHF (Low Smoke Halogen Free)
CABLE JACKET COLOR: UL Plenum: gray; LSHF: blue
CABLE DIAMETER: 3.4mm
CABLE BENDING RADIUS: 6mm
CONNECTOR MAX. PULLING
POWER SUPPLY HDMI: Draws current from the source. If required, power can be also supplied
OPERATING TEMPERATURE: 0° to +50°C (32° to 122°F)
STORAGE TEMPERATURE: -30° to +70°C (-22° to 158°F)
OPERATING HUMIDITY: 5% to 85%, RHL non-condensing
AVAILABLE SIZE: 33ft (10m), 50ft (15m), 66ft (20m), 98 ft (3 0m) , 131 ft (4 0m) , 164ft (50m), 197ft
100N (10kg, 22lbs)
