C-HM/HM/PRO
High-Speed HDMI™ Cable
with Ethernet
Kramer C-HM/HM/PRO series HDMI cables deliver highspeed, high-performance digital video and audio with
impeccable impedance stability, low skew, high signal
integrity, and noise immunity for up to 4K60 4:4:4.
With pro-grade heavy-duty construction, triple-shielded
bonded pairs and K-lock connectors, PRO series cables are
robust and reliable for the most demanding applications.
AV BEYOND
THE BOX
Non-slip connection with
15lbs of restraining force
Features
High-speed HDMI™ cable with Ethernet
•
Up to 4K60 4:4:4
•
High data transfer rate: up to 18 Gbps
•
Deep Color and x.v.Color™, 5.1/7.1 lossless Dolby TrueHD and
•
DTS-HD surround sound
CEC and HDCP 2.2 compliant
•
Uncompressed HDMI audio channels
•
1080p60, 3D, ARC, and Ethernet for all lengths
•
High-quality connectors: 24K gold-plated, corrosion-resistant
•
and best possible connectivity
Pull-resistant: K-Lock connectors with 15 lbs of restraining force
•
Triple overall shield against EMI/RFI interference
•
CL3/FT4 rating
•
RoHS 2011/65/EU compliant
•
with Ethernet
HIGH
SPEED
DEEP
COLOR
3D
2.2
ARC
4K
1080p
DOLBY
TRUE HD
DTS – HD
KramerAV.com
1
A
B
CABLE SPECIFICATIONS
AUDIO & VIDEO SPECIFICATIONS
Video Resolution
Data Rate (max) 3-20ft: Up to 18 Gbps. 25-50ft: Up to 10.2 Gbps. 65ft: Up to 4.95Gbps
Supported Color Spaces RGB, YCbCr, xvYCC, Adobe sRGB, sYCC601, BT.2020
Supported Audio Formats Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio™, DVD Audio, SA-CD
3-20ft: Up to 4K UHD and 4K60 4:4:4, 8-bit, full-HD, 3D. 25-50ft: Up to 4K30 4:4:4,
8-bit, full-HD, 3D. 65ft: Up to 1080p60, 8-bit, 3D
HDMI Compliance HDCP 2.2, EDID and CEC
PHYSICAL SPECIFICATIONS
Connector-1 (source end) Male HDMI Type A, 24K gold-plated K-Lock connector
Connector-2 (display end) Male HDMI Type A, 24K gold-plated K-Lock connector
Conductors
Shielding
Outer Sheath Material PVC
Outer Sheath Color Black
Outer Sheath Diameter 3-35ft: 8 ± 0.19mm; 50-65ft:9.5 ± 0.25mm
Cable Bending Radius 3-35ft: 80mm; 50-65ft: 95mm
A
B
3-35ft: 26AWG (7/34); 50-65ft: 24AWG (7/32)
TMDS pairs: aluminum/mylar
Overall: aluminum/mylar + aluminum braid w/ 85% minimum coverage
ELECTRICAL SPECIFICATIONS
Temperature Rating 80°C
Voltage Rating 30V
Conductor Resistance 26AWG: 148Ω/km, 24AWG:93.2Ω/km MAX. at 20Ω
COMPLIANCE
Rating (NEC/UL/CSA) CL3/FT4
RoHS 2011/65/ EU
KramerAV.com
2
OUTLINE DIMENSIONS
3-35ft 50-65ft
52.4mm
(2.063")
40mm
(1.592")
AV BEYOND
THE BOX
63.0mm
(2.480")
40mm
(1.556")
8.9mm
(.350")
18.6mm
(.732")
43.5mm
(1.713")
Bend radius
80mm/3.15”
Ø 8.0mm
Ø 12mm
(.472”)
9.0mm
(.354")
20.2mm
(.795")
54.0mm
(2.126")
Bend radius
95mm/3.74”
Ø 9.5mm
16mm
(.626")
KramerAV.com
3
AV BEYOND
THE BOX
ORDERING INFORMATION
MODEL DESCRIPTION LENGTH GROSS WEIGHT
C-HM/HM/PRO-3
High Speed HDMI™ Cable with Ethernet 3ft/0.9m 0.24lbs/0.11kg
C-HM/HM/PRO-6
C-HM/HM/PRO-10
C-HM/HM/PRO-15
C-HM/HM/PRO-20
C-HM/HM/PRO-25
C-HM/HM/PRO-35
C-HM/HM/PRO-50
C-HM/HM/PRO-65
High Speed HDMI™ Cable with Ethernet 6ft/1.8m 0.42lbs/0.19kg
High Speed HDMI™ Cable with Ethernet 10ft/3.0m 0.64lbs/0.29kg
High Speed HDMI™ Cable with Ethernet 15ft/4.6m 0.93lbs/0.42kg
High Speed HDMI™ Cable with Ethernet 20ft/6.1m 1.30lbs/0.57kg
High Speed HDMI™ Cable with Ethernet 25ft/7.6m 1.60lbs/0.73kg
High Speed HDMI™ Cable with Ethernet 35ft/10.7m 2.10lbs/0.95kg
High Speed HDMI™ Cable with Ethernet 50ft/15.2m 2.40lbs/1.10kg
High Speed HDMI™ Cable with Ethernet 65ft/19.5m 2.90lbs/1.30kg
www.KramerAV.com
© 2017 KRAMER ELEC TRONICS, Ltd. All rights reserved.
Reproduction in whole or in part without written permission is prohibited. Specications are subject to change without notice.
REV 1.0
