KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
81 0B
Black Burst/Audio Generator
P/N: 2900-000012 Rev 2
810B – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the 810B Black Burst/Audio Generator 4
4 Connecting and Adjusting the 810B 5
4.1 Adjusting the Audio Level 6
5 Technical Specifications 7
Figures
Figure 1: 810B Black Burst/Audio Generator 4
Figure 2: Connecting the 810B Black Burst/Audio Generator 5
Figure 3: Underside of the 810B Black Burst / Audio Generator 6
810B - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer 810B Black Burst/Audio Generator,
which is ideal for the following typical applications:
Testing and aligning of video equipment, including monitors, recorders and
projectors
