KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
6505
1
:5 S/PDIF Distributor
P/N: 2900-000420 Rev 2
6505 – Contents i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
3 Overview 3
3.1 Defining the 6505 1:5 S/PDIF Distributor 3
4 Connecting the 6505 4
5 Technical Specifications 5
Figures
UFigure 1: 6505 1:5 S/PDIF DistributorU 3
UFigure 2: Connecting the 6505 1:5 S/PDIF DistributorU 4
6505 - Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer 6505 1:5 S/PDIF Distributor, which is
ideal for the foll owing typi c al applications:
• Video and audio production facilities
• Recording studios, for connecting a source to several acceptors
2 6505 - Getting Started
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance, high-resolution cables
Go to http://www.kramerelectronics.com t o check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables to avoid interference, deterioration
in signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Do not secure the cables in tight bundles or roll the slack into tight coils
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your Kramer 6505 away from moisture, excessive sunlight and dust
Caution: No operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
6505 - Overview 3
3 Overview
The 6505 is a high−performance distribution amplifier for S/PDIF digital audio
signals. The unit takes one S/PDIF input and distributes the signal to five identical
S/PDIF outputs.
The 6505 features:
• Compatibility with EIAJ CP1201, IEC-60958, AES3id and S/PDIF standards
• A sample frequency range of 32kHz to 96kHz
• Equalization and reclocking of incoming data for low jitter recovery of the
digital audio data stream
• 5V DC power and is housed in a DigiTOOLS® enclosure
3.1 Defining the 6505 1:5 S/PDIF Distributor
This section defines the 6505.
Figure 1: 6505 1:5 S/PDIF Distributor
# Feature Function
1 INPUT RCA Connector Connects to the S/PDIF digital audio source
2 OUT RCA Connectors Connect to the S/PDIF digital audio acceptor (from 1 to 5)
3 5VDC +5V DC connector for powering the unit
4 LINK LED Illuminates when receiving the appropriate input signal
5 ON LED Illuminates whe n recei ving power
4 6505 - Connecting the 6505
4 Connecting the 6505
Always switch off the power to each device before connecting it to your
6505. After connecting your 6505, connect its power and then switch
on the power to each device.
To connect the 6505 as illustrated in the example in
Figure 2:
1. Connect an S/PDIF source (for example, a DVD Player) to the S/PDIF RCA
input connector.
2. Connect up to five S/PDIF RCA output connectors to up to five S/PDIF
acceptors (for example, power amplifiers).
3. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in
Figure 2.
Figure 2: Connectin g the 6505 1:5 S/PDIF Distributor
i
6505 - Technical Specifications 5
5 Technical Specifications
INPUT: 1 S/PDIF digital audio input on an RCA connector
OUTPUTS: 5 S/PDIF digital au dio outputs on RCA connect ors
STANDARD COMPLIANCE: CP1201, IEC-60958, AES3id and S/PDIF
SAMPLE RATE: 32kHz to 96kHz
INPUT IMPEDANCE:
75Ω
OUTPUT IMPEDANCE:
75Ω
POWER SOURCE: 5V, 120mA
OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 12cm x 6.95c m x 2.44cm (4.72" x 2.74" x 0.96", W, D, H)
WEIGHT: 0.3kg (0.66lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-3T 19" rack adapter
Specifications are subject to change without notice at Uhttp://www.kramerelectronics.comU
6 6505 - Technical Specifications
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site:
E-mail:
www.kramerelectronics.com
info@kramerel.com
P/N:
2900-000420
Rev:
2
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
