Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
6241N
4x1 SDI Switcher
Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 3
4 Your 6241N 4x1 SDI Switcher 4
5 Connecting the 6241N 4x1 SDI Switcher 5
6 Technical Specifications 6
Figures
Figure 1: 6241N 4x1 SDI Switcher Functions 4
Figure 2: Connecting the 6241N 4x1 SDI Switcher 5
Tables
Table 1: 6241N 4x1 SDI Switcher Functions 4
Table 2: 6241N Technical Specifications 6
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, ma king the best even b etter! Our
1,000-plus different models now appear in 11 groups
1
Thank you for pur chasing the Kramer DigiTOOLS® 6241N 4x1 SDI
Switcher, which is ideal for :
that are clearly
defined by function.
• Video broadcast studios for signal routing
• Non-linear editing suites
• Video production studios
Each package includes the following items:
• 6241N 4x1 SDI Switcher
• Power adapter (5V DC Input)
• This user manual
2
2 Getting Started
We recommend that you:
• Unpack t he equip ment carefully and s ave the original box and
packaging mat erials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance high-resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GR OUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
