Kramer 401C User manual
Kramer Electronics, Ltd.
USER MANUAL
Models:
401C,
401DN,
Y/C to Composite Converter / DA
Composite to Y/C Decoder
Contents
Contents
1
2
2.1 Quick Start 1
3
4
4.1 Your 401C 4
4.2 Your 401DN 5
5
5.1 Connecting the 401C 6
5.2 Connecting the 401DN 7
6
Figures
Figure 1: 401C Y/C to Composite Converter / DA 4
Figure 2: 401DN Composite to Y/C Decoder 5
Figure 3: Connecting the 401C 6
Figure 4: Connecting the 401DN 7
Introduction 1
Getting Started 1
Overview 3
Your 401C and 401DN 4
Connecting the 401C and the 401DN 5
Technical Specifications 8
Tables
Table 1: 401C Y/C to Composite Converter / DA Features 4
Table 2: 401DN Composite to Y/C Decoder Features 5
Table 3: Technical Specifications of the 401C 8
Table 4: Technical Specifications of the 401DN 8
i
Introduction
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1 that are clearly defined
by function.
Congratulations on purchasing your Kramer 401C Y/C to Composite
Converter / DA or the 401DN Composite to Y/C Decoder. These products are
ideal for:
Professional presentation and display systems
Video duplication studios, delivering high quality s-Video duplications2
Teleconference systems
Conversion from s-Video to composite video (using the 401C) or for
conversion from composite video to s-Video (using the 401DN)
The package includes the following items:
401C or 401DN
Power adapter (12V DC Input) and this user manual3
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables4
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps for the
401C and 401DN.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers a nd Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 The 401C also provides composite video outputs for simple monitoring
3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
1
Getting Started
2
