Configuration Guide

KISS 4U V2 KTC 5520

Configuration Options for KISS 4U V2 KTC 5520

Categories Select one option of each category

Processor Board

Processor 1

Processor 2

st

Processor

Memory 1

Memory 2nd Processor

Drive Bay 1, 2 12 Front accessible 5.25" No

Drive Bay 3 3 Slim Line No

Drive Bays 4 4

3.5" Internal No

Power Supply

Graphic Adapter

Network Adapter

RAID Controler No

Options

Preinstalled OS

Mounting

Protection Class

KTC 5520

Intel Xeon E5504 (2GHz) Intel Xeon E5540 (2.53GHz)

4GB DIMM-DDR3 1066MHz ECC 6GB DIMM-DDR3 1066MHz ECC 12GB DIMM-DDR3 1066MHz ECC 24GB DIMM-DDR3 1066MHz ECC

KISS DA135 500GB KISS DA135 1TB KISS DA135 2TB DVD-R/RW SATA KISS Stor 1 (Blocks two 5.25" bays) no RAID controller required (2* 500 GB SATA WD) KISS Stor 1 (Blocks two 5.25" bays) no RAID controller required (2* 1TB SATA WD) KISS Stor 1 (Blocks two 5.25" bays) no RAID controller requiered (2* 2TB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3* 500 GB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3*1TB GB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3*2TB SATA WD) KISS DA335 (3* 500GB) blocks two 5.25" bays KISS DA335 (3* 1TB) blocks two 5.25" bays KISS DA335 (3* 2TB) blocks two 5.25" bays DA 425 (4* 2.5" HDD 250 GB) blocks one 5.25" bay DA 425 (4* 2.5" HDD 500 GB) blocks one 5.25" bay other drive combinations on request

Slim-line RW DVD (front accessible)

SATA 500 GB SATA 1 TB SATA 2 TB 1* 2.5" HDD 250 GB 1* 2.5" HDD 500 GB SSD 64 GB SLC SSD 128 GB MLC

AC 650 W 80+ AC Redundant (2* 500W) DC: +24V (400W) DC: -48V (400W)

No PCIe *16 NVS 295, 2* Display port incl. 2* Adapter to DVI, passive cooled

No PCIe *1 NET SK-9E21D Gigabit LAN

RAID Controller PCIe *4 (RAID 0, 1, 5, 10, JBOD)

No Custom Color others on request

No Linux Suse WIN 2008 Server Others on request

Tower Desktop 19" Rack Mount

Front: IP20 Front: IP52

Page 1 from 2 Updated: 21.06.2012

Configuration Guide

KISS 4U V2 X9DR3

Configuration Options for KISS 4U V2 X9DR3

Categories Select one option of each category

Processor Board

Processor 1

Processor 2

st

Processor

Memory 1

Memory 2nd Processor

Drive Bay 1, 2 12 Front accessible 5.25" No

Drive Bay 3 3 Slim Line No

Drive Bays 4 4

3.5" Internal No

Power Supply

Graphic Adapter

Network Adapter

RAID Controler No

Options

Preinstalled OS

Mounting

Protection Class

X9DR3-F

Intel Xeon E5-2620 Intel Xeon E5-2658

8GB DIMM-DDR3 1600MHz ECC 16GB DIMM-DDR3 1600MHz ECC other on request

KISS DA135 500GB KISS DA135 1TB KISS DA135 2TB DVD-R/RW SATA KISS Stor 1 (Blocks two 5.25" bays) no RAID controller required (2* 500 GB SATA WD) KISS Stor 1 (Blocks two 5.25" bays) no RAID controller required (2* 1TB SATA WD) KISS Stor 1 (Blocks two 5.25" bays) no RAID controller requiered (2* 2TB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3* 500 GB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3*1TB GB SATA WD) KISS Stor 0/5 (Blocks two 5.25" bays) no RAID controller requiered (3*2TB SATA WD) KISS DA335 (3* 500GB) blocks two 5.25" bays KISS DA335 (3* 1TB) blocks two 5.25" bays KISS DA335 (3* 2TB) blocks two 5.25" bays DA 425 (4* 2.5" HDD 250 GB) blocks one 5.25" bay DA 425 (4* 2.5" HDD 500 GB) blocks one 5.25" bay other drive combinations on request

Slim-line RW DVD (front accessible)

SATA 500 GB SATA 1 TB SATA 2 TB 1* 2.5" HDD 250 GB 1* 2.5" HDD 500 GB SSD 40 GB MLC SSD 80 GB MLC SSD 120 GB MLC SSD 160 GB MLC

AC 650 W 80+ AC Redundant (2* 500W) DC: +24V (400W) DC: -48V (400W)

No PCIe *16 NVS 300, 2* Display port incl. 2* Adapter to DVI, passive cooled

No PCIe *1 NET SK-9E21D Gigabit LAN

RAID Controller PCIe *4 (RAID 0, 1, 5, 10, JBOD)

No Custom Color others on request

No Linux Suse WIN 2008 Server Others on request

Tower Desktop 19" Rack Mount

Front: IP20 Front: IP52

Page 2 from 2 Updated: 21.06.2012
