Kontron CP381 User Manual

CP381

30 Channel CompactPCI

Digital Input Controller

Manual ID: 24107, Rev. Index 01

February 2002

The product described in this manual is
in compliance with all applied CE stan­dards.

Preface CP381

Revision History

Manual/Product Title: CP381

Manual ID Number: 24107

Rev.

Index

01 Initial Issue 00 Feb. 2002

Brief Description of Changes Board Index

Date of

Issue

Imprint

Copyright © 2002 PEP Modular Computers GmbH. All rights
reserved. This manual may not be copied, photocopied,
reproduced, translated or converted to any electronic or machine­readable form in whole or in part without prior written approval of
PEP Modular Computers GmbH.

DISCLAIMER:

PEP Modular Computers GmbH rejects any liability for the correctness
and completeness of this manual as well as its suitability for any partic­ular purpose.

This manual was realized by: TPD/Engineering, PEP Modular Computers GmbH.

Page ii © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

Table of Contents

Revision History ........................................................................................................ ii

Imprint ....................................................................................................................... ii

Table of Contents ..................................................................................................... iii

List of Figures ......................................................................................................... vii

List of Tables ............................................................................................................ ix

Proprietary Note ....................................................................................................... xi

Trademarks .............................................................................................................. xi

Environmental Protection Statement ....................................................................... xi

Explanation of Symbols .......................................................................................... xii

For Your Safety ...................................................................................................... xiii

High Voltage Safety Instructions ........................................................................ xiii

Special Handling and Unpacking Instructions ................................................... xiii

General Instructions on Usage .............................................................................. xiv

Two Year Warranty ................................................................................................. xv

Chapter

1. Introduction ................................................................................................. 1 - 3

1.1 System Overview .................................................................................. 1 - 3

1.2 Product Overview .................................................................................. 1 - 4

1.3 Board Overview ..................................................................................... 1 - 5

1.3.1 Board Introduction ........................................................................ 1 - 5

1.3.2 Board Specific Information ............................................................ 1 - 5

1.4 System Relevant Information ................................................................ 1 - 6

1.4.1 System Configuration ................................................................... 1 - 6

1.4.2 Driver Software ............................................................................. 1 - 6

1

1.5 Board Diagrams .................................................................................... 1 - 7

1.5.1 System Level Interfacing .............................................................. 1 - 7

1.5.2 Front Panel ................................................................................... 1 - 8

1.5.3 Board Layout ................................................................................ 1 - 8

1.6 Technical Specifications ...................................................................... 1 - 9

1.7 Applied Standards ............................................................................... 1 - 10

1.8 Related Publications ........................................................................... 1 - 10

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page iii

Preface CP381

Chapter

2. Functional Description ................................................................................ 2 - 3

2.1 General Information ............................................................................... 2 - 3

2.1.1 Signal Conditioning ....................................................................... 2 - 3

2.1.2 DI ProComm Controller ................................................................. 2 - 3

2.1.3 System Interfaces ......................................................................... 2 - 4

2.1.4 Monitor and Control ....................................................................... 2 - 4

2.1.5 Software ........................................................................................ 2 - 4

2.2 Board Level Interfacing Diagram ........................................................... 2 - 5

2.3 System Interfaces .................................................................................. 2 - 6

2.3.1 Digital Input Interface .................................................................... 2 - 6

2.3.2 CompactPCI Interface and Pinout ................................................. 2 - 8

2.3.3 Test and Program Development ................................................... 2 - 9

2.3.3.1 JTAG/ISP Interface and Pinout ................................................. 2 - 9

2.4 CapROM EEPROM ............................................................................... 2 - 9

2

2.5 Monitor and Control (M/C) ................................................................... 2 - 10

2.5.1 Pre-Operation M/C ...................................................................... 2 - 10

2.5.2 Operation M/C ............................................................................ 2 - 10

Chapter

3. Installation ................................................................................................... 3 - 3

3.1 Hardware Installation ............................................................................. 3 - 3

3.1.1 Safety Requirements ..................................................................... 3 - 3

3.1.2 Installation Procedures .................................................................. 3 - 4

3.1.3 Removal Procedures ..................................................................... 3 - 5

3.2 Software Installation .............................................................................. 3 - 5

3

Page iv © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

Chapter

4. Configuration .............................................................................................. 4 - 3

4.1 Jumper Settings .................................................................................... 4 - 3

4.2 Digital Input Signal Requirements. ........................................................ 4 - 3

4.2.1 Channels ....................................................................................... 4 - 3

4.2.2 Signal Characteristics ................................................................... 4 - 3

4.2.3 Channel Configuration .................................................................. 4 - 4

4.3 Programming Interface .......................................................................... 4 - 6

4.3.1 Access Control Logic (Address Decoder) ..................................... 4 - 6

4.3.2 Reading Input Data ....................................................................... 4 - 7

4.3.3 Debouncing Inputs ........................................................................ 4 - 8

4.3.4 Detecting Input Events .................................................................. 4 - 9

4.3.5 Latching on Input Events ............................................................ 4 - 10

4.3.6 Comparing Input Patterns ........................................................... 4 - 10

4.3.7 Hardware Debug/Test Registers ................................................ 4 - 11

4

4.3.8 Generating Interrupts .................................................................. 4 - 12

4.3.9 Programming the Board Capability ROM ................................... 4 - 13

Chapter

5. System Considerations ............................................................................... 5 - 3

5.1 Introduction ........................................................................................... 5 - 3

5.2 General ................................................................................................. 5 - 3

5.3 Shielding ............................................................................................... 5 - 3

5.4 Debouncing ........................................................................................... 5 - 4

5.5 Process-side Signal Conditioning ......................................................... 5 - 4

5.6 Cable Interfacing ................................................................................... 5 - 4

5

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page v

Preface CP381

This page was intentionally left blank.

Page vi © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

List of Figures

1-1 CP381 System Level Interfacing Diagram ............................................... 1 - 7

1-2 CP381 Front Panel .................................................................................. 1 - 8

1-3 CP381 Board (Front View) ....................................................................... 1 - 8

2-1 CP381 Board Level Interfacing ................................................................ 2 - 5

2-2 Pin Layout of the Digital Input Interface Connector CON2 ..................... 2 - 6

2-3 CPCI Connector CON1 (J1) ..................................................................... 2 - 8

2-4 JTAG Connector (CON3) ......................................................................... 2 - 9

4-1 Voltage Ranges ........................................................................................ 4 - 3

4-2 Input Configuration (Example for Channel 0) ........................................... 4 - 4

4-3 Configuration Diagram for All Channels ................................................... 4 - 4

4-4 Configuration Diagram for All Channels ................................................... 4 - 5

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page vii

Preface CP381

This page was intentionally left blank.

Page viii © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

List of Tables

1-1 CP381 Product Overview ......................................................................... 1 - 4

1-2 System Relevant Information ................................................................... 1 - 6

1-3 CP381 Main Specifications ...................................................................... 1 - 9

1-5 Applied Standards .................................................................................. 1 - 10

1-6 Related Publications .............................................................................. 1 - 10

1-4 CP381 Analog Input Specifications ........................................................ 1 - 10

2-1 Pinout of the Digital Input Interface Connector CON2 ............................. 2 - 7

2-2 CompactPCI Connector CON1 (J1) ......................................................... 2 - 8

2-3 JTAG Connector (CON3) Pinout .............................................................. 2 - 9

2-4 System Status Indicators ....................................................................... 2 - 10

2-5 Function Modes of the CP381 ............................................................... 2 - 10

4-1 Backend Register Address Map .............................................................. 4 - 6

4-2 Input Data Register Bit Map ..................................................................... 4 - 7

4-3 Transparent Input Data Register Bit Map ................................................ 4 - 7

4-4 Input Control Register .............................................................................. 4 - 8

4-5 Programmable Input Sample Rates ......................................................... 4 - 8

4-6 Input Event Mask Register, Bit Map ......................................................... 4 - 9

4-7 Input Event Polarity Register, Bit Map ..................................................... 4 - 9

4-8 Input Status Register, Bit Map ................................................................. 4 - 9

4-9 Input Latch-on-Event Register, Bit Map ................................................. 4 - 10

4-10 Input Pattern Mask Register, Bit Map .................................................... 4 - 10

4-11 Input Pattern Compare Register, Bit Map .............................................. 4 - 10

4-12 Hardware Debug Register Bit Map ........................................................ 4 - 11

4-13 Hardware Status Register Bit Map ......................................................... 4 - 11

4-14 General Interrupt Enable Register, Bit Map ........................................... 4 - 12

4-15 General Interrupt Pending Register, Bit Map ......................................... 4 - 12

4-16 Input IRQ Enable Register, Bit Map ....................................................... 4 - 12

4-17 ROM Command Register Bit Map ......................................................... 4 - 13

4-18 ROM Control Register Bit Map .............................................................. 4 - 13

4-19 Opcodes and Commands ...................................................................... 4 - 14

4-20 ROM Status Register Bit Map ................................................................ 4 - 14

4-21 ROM Data Register Bit Map .................................................................. 4 - 14

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page ix

Preface CP381

This page was intentionally left blank.

Page x © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

Proprietary Note

This document contains information proprietary to PEP Modular Computers. It may not be cop­ied or transmitted by any means, disclosed to others, or stored in any retrieval system or media
without the prior written consent of PEP Modular Computers GmbH or one of its authorized
agents.

The information contained in this document is, to the best of our knowledge, entirely correct.
However, PEP Modular Computers cannot accept liability for any inaccuracies or the conse­quences thereof, or for any liability arising from the use or application of any circuit, product, or
example shown in this document.

PEP Modular Computers reserves the right to change, modify , or improve this document or the
product described herein, as seen fit by PEP Modular Computers without further notice.

Trademarks

PEP Modular Computers, the PEP logo and, if occurring in this manual, “CXM” are trade marks
owned by PEP Modular Computers GmbH, Kaufbeuren (Germany). In addition, this document
may include names, company logos, and trademarks which are registered trademarks and are,
therefore, proprietary to their respective owners.

Environmental Protection Statement

This product has been manufactured to satisfy environmental protection requirements where
possible. Many of the components used (structural parts, printed circuit boards, connectors,
batteries, etc.) are capable of being recycled.

Final disposition of this product after its service life must be accomplished in accordance with
applicable country, state, or local laws or regulations.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page xi

Preface CP381

Explanation of Symbols

CE Conformity

This symbol indicates that the product described in this manual is in
compliance with all applied CE standards. Please refer also to the
section “Applied Standards” in this manual.

Caution, Electric Shock!

This symbol and title warn of hazards due to electrical shocks (> 60V)
when touching products or parts of them. Failure to observe the pre­cautions indicated and/or prescribed by the law may endanger your
life/health and/or result in damage to your material.

Please refer also to the section “High Voltage Safety Instructions” on
the following page.

Warning, ESD Sensitive Device!

This symbol and title inform that electronic boards and their compo­nents are sensitive to static electricity. Therefore, care must be taken
during all handling operations and inspections of this product, in
order to ensure product integrity at all times.

Please read also the section “Special Handling and Unpacking
Instructions” on the following page.

Warning!

This symbol and title emphasize points which, if not fully understood
and taken into consideration by the reader, may endanger your health
and/or result in damage to your material.

Note...

This symbol and title emphasize aspects the reader should read
through carefully for his or her own advantage.

Page xii © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

For Your Safety

Your new PEP product was developed and tested carefully to provide all features necessary to
ensure its compliance with electrical safety requirement s. It wa s also de signed for a long fault­free life. However, the life expectancy of your product can be drastically reduced by improper
treatment during unpacking and installation. Therefore, in the interest of your own safety and
of the correct operation of your new PEP product, you are requested to conform with the fol­lowing guidelines.

High Voltage Safety Instructions

Warning!

All operations on this device must be carried out by sufficiently skilled
personnel only.

Caution, Electric Shock!

Before installing your new PEP product into a system always ensure
that your mains power is switched off. This applies also to the instal­lation of piggybacks.

Serious electrical shock hazards can exist during all installation,
repair and maintenance operations with this product. Therefore,
always unplug the power cable and any other cables which provide
external voltages before performing work.

Special Handling and Unpacking Instructions

ESD Sensitive Device!

Electronic boards and their components are sensitive to static electricity.
Therefore, care must be taken during all handling operations and inspections
of this product, in order to ensure product integrity at all times.

Do not handle this product out of its protective enclosure while it is not used for operational
purposes unless it is otherwise protected.

Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where
a safe work station is not guaranteed, it is important for the user to be electrically discharged
before touching the product with his/her hands or tools. This is most easily done by touching a
metal part of your system housing.

It is particularly important to observe standard anti-static precautions when changing piggy­backs, ROM devices, jumper settings etc. If the product contains batteries for RTC or memory
back-up, ensure that the board is not placed on conductive surfaces, including anti-st atic plas­tics or sponges. They can cause short circuits and damage the batteries or con ductive circuit s
on the board.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page xiii

Preface CP381

General Instructions on Usage

In order to maintain PEP’s product warranty, this product must not be altered or modified in an y
way . Changes or modifications to the device, which are not explicitly approved by PEP Modular
Computers and described in this manual or received from PEP Technical Suppo rt as a spe cial
handling instruction, will void your warranty.

This device should only be installed in or connected to systems that fulfill all necessary techni­cal and specific environmental requirements. This applies also to the operational temperature
range of the specific board version, which must not be exceeded. If batteries are present their
temperature restrictions must be taken into account.

In performing all necessary installation and application operations, please follow only the in­structions supplied by the present manual.

Keep all the original packaging material for future storage or warranty shipment s. If it is neces­sary to store or ship the board please re-pack it as nearly as possible in the manner in which it
was delivered.

Special care is necessary when handling or unp acking the product. Please, consult the special
handling and unpacking instruction on the previous page of this manual.

Page xiv © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Preface

Two Year Warranty

PEP Modular Computers grants the original purchaser of PEP products a TWO YEAR LIMITED

HARDWARE

granted or implied by anyone on behalf of PEP are valid unless the consumer has the express
written consent of PEP Modular Computers.

PEP Modular Computers warrants their own product s, excluding software, to be free from man­ufacturing and material defects for a period of 24 consecutive months from the date of pur­chase. This warranty is not transferable nor extendible to cover any other users or long-term
storage of the product. It does not cover products which have been modified, altered or re­paired by any other party than PEP Modular Computers or their authorized agents. Further­more, any product which has been, or is suspected of being damaged as a result of neg ligence,
improper use, incorrect handling, servicing or maintenance, or which has been damaged as a
result of excessive current/voltage or temperature, or which has had its serial number(s), any
other markings or parts thereo f altered, defaced or removed will also be excluded from this war­ranty.

WARRANTY as described in the fo llowing. However, no other warranties that may be

If the customer’s eligibility for warranty has not been voided, in the event of any claim, he may
return the product at the earliest possible convenience to the original place of p urchase, togeth­er with a copy of the original document of purchase, a full description of the application the
product is used on and a description of the defect. Pack the product in such a way as to ensure
safe transportation (see our safety instructions).

PEP provides for repair or replacement of any part, assembly or sub-assemb ly at their own dis­cretion, or to refund the original cost of purchase, if appropriate. In the event of repair , refunding
or replacement of any part, the ownership of the removed or replaced parts reverts to PEP
Modular Computers, and the remaining part of the original guarantee, or any new guarantee to
cover the repaired or replaced items, will be transferred to cover the new or repaired items. Any
extensions to the original guarantee are considered gestures of goodwill, and will be defined in
the “Repair Report” issued by PEP with the repaired or replaced item.

PEP Modular Computers will not accept liability for any further claims resulting directly or indi­rectly from any warranty claim, other than the above specified rep air , replacement or refunding.
In particular, all claims for damage to any system or process in which the product was em­ployed, or any loss incurred as a result of the product not functioning at any given time, are
excluded. The extent of PEP Modular Computers liability to the customer shall not exceed the
original purchase price of the item for which the claim exists.

PEP Modular Computers issues no warranty or representation, either explicit or implicit, with
respect to its products’ reliability, fitness, quality, marketability or ability to fulfil any particular
application or purpose. As a result, the products are sold “as is,” and the responsibility to ensure
their suitability for any given task remains that of the purchaser. In no event will PEP be liable
for direct, indirect or consequential damages resulting from the use of our hardware or software
products, or documentation, even if PEP were advised of the possibility of such claims prior to
the purchase of the product or during any period since the date of its purchase.

Please remember that no PEP Modular Computers employee, dealer or agent is authorized to
make any modification or addition to the above specified terms, either verbally or in any other
form, written or electronically transmitted, without the company’s consent.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page xv

Preface CP381

This page was intentionally left blank.

Page xvi © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Introduction

Chapter

1

Introduction

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 1

Introduction CP381

This page was intentionally left blank.

Page 1 - 2 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Introduction

1. Introduction

1.1 System Overview

The CompactPCI board described in this manual operates with the PCI bus architecture to sup­port additional I/O and memory-mapped devices as required by various industrial applications.
For detailed information concerning the CompactPCI standard, please consult the complete
Peripheral Component Interconnect (PCI) and CompactPCI S pecifications. For further informa­tion regarding these standards and their use, visit the homepage of the PCI Industrial Computer

Manufacturers Group (PICMG).

Many system relevant CompactPCI features that are specific to PEP Modular Computers Com­pactPCI systems may be found described in the PEP Comp actPCI System Manual. Please re­fer to the section “Related Publications” at the end of this chapter for the relevant ordering
information.

The CompactPCI System Manual includes the following information:

• Common information that is applicable to all system components, such as safety infor­mation, warranty conditions, standard connector pinouts etc.

• All the information necessary to combine PEP’s racks, boards, backplanes, power supply
units and peripheral devices in a customized CompactPCI system, as well as configura­tion examples.

• Data on rack dimensions and configurations as well as information on mechanical and
electrical rack characteristics.

• Information on the distinctive features of PEP CompactPCI boards, such as functionality,
hot swap capability. In addition, an overview is given for all existing PEP CompactPCI
boards with links to the relating data sheets.

• Generic information on the PEP CompactPCI backplanes, such as the slot assignment,
PCB form factor , distinctive feature s, clocks, power supply connectors and signalling en­vironment, as well as an overview of the PEP CompactPCI standard backplane family.

• Generic information on the PEP CompactPCI power supply units, such as the input/out­put characteristics, redundant operation and distinctive features, as well as an overview
of the PEP CompactPCI standard power supply unit family.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 3

Introduction CP381

1.2 Product Overview

The CP381 Digital Input controller is part of a comprehensive concept whose goal is to provide
CompactPCI system integrators with a complete range of CompactPCI I/O products which in­clude the functions of analog input, analog output, digital input and digital output implemented
on separate individual boards. This concept ensures the maximum degree of system design
flexibility thus allowing for the efficient and effective usage of available resources.

The CP381 is a 3U/4HP CompactPCI board which provides 30 digital input channels and has
some useful optional features (such as debouncing, input event detection, input capture and­compare).

The basic functions of this board are to provide interfacing to the application (process), perform
D/D signal conversion, and to make the raw digitized data available for further processing.

The major components involved in these processes are the front end (process side) Signal
Conditioning and the Digital Input Process and Communications (DIProcomm) Con troller which
is realized within a Field-Programmable Gate Array ( FPGA). The DI ProComm controller is de­signed to provide effective and efficient control of digital input signal conditioning as well as in­terfacing with the CPCI system controller.

The following table provides a quick overview of the CP381 board.

Table 1-1: CP381 Product Overview

CP381 FEATURES DESCRIPTION

Digital Input Board CompactPCI: 3U, 4HP

33 MHz system clock
32-bit address and data bus
Designed for Plug&Play
Complies with the CPCI specification

Input Signals Voltage range: low: -3V to +5V

high: +11V to + 30 V (+24V standard)

Maximum current: 5 mA

Output Data A maximum of 30 measured digital values

Interrupt messages (optional)
Programmable registers (writeable compare, event and latch registers)

Debouncing Range of settings available: 33 MHz, 128 kHz, 32 kHz, 8 kHz, 2 kHz, 500 Hz, 125

Hz, 31 Hz (30ns default)

Monitor and Control Two green LED’s: RUN and HIT

DI ProComm controller
System Master driver software

Page 1 - 4 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Introduction

1.3 Board Overview

1.3.1 Board Introduction

The CP381 is a 30 channel digital input board. The source of the digital inputs must be a volt age
generator. The board accept s only single-ended volt ages up to a ma ximum of +30V. The input
current is limited to 5 mA over the specified input voltage range.

Input signal processing begins with the presentation of the signal to the front panel connector.
Signal conditioning prior to the signal reaching the DI ProComm controller includes: overvolt­age protection, ESD, low-pass filtering, inverse polarity protection, defined low and high rang­es, current limitation, optoisolation and buffering.

After signal conditioning, all parallel digital data is routed to the DI ProComm controller, where
the control and status registers are set.

The DI ProComm controller controls the interface with the CompactPCI bus and the dedicated
software.

Input signal types and ranges are as follows:

• Edge frequency:

• Maximum 10 kHz

• Voltage Ranges:

• High range: +11V to +30V (+24V nominal)

• Low range: -3V to +5V

• Signal is single-ended

Output data
The following outputs are routed from the DI ProComm controller to the CompactPCI bus:-

• Input data for all channels as a 32-bit value (each bit from 0 - 29 represents the status of

• Flag set information from the control and status registers

• Interrupts

:

the respective input channel)

1.3.2 Board Specific Information

Specific board components involved in the signal conditioning and data handling processes
are:

• One front panel connector (62-pin, female, D-sub type)

• 30 channels of input signal conditioning

• Optoisolation for each channel

• One FPGA (the DI ProComm controller)

• One CompactPCI bus connector (J1, board to backplane, 132-pin, female, six row)

• JTAG/ISP onboard programming connector (10-pin, male, dual row)

• One EEPROM (CapROM)

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 5

Introduction CP381

1.4 System Relevant Information

The following system relevant information is general in nature but should still be considered
when developing applications using the CP381.

Table 1-2: System Relevant Information

SUBJECT INFORMATION

System Configuration The CP381 operates with a system clock frequency of 33 MHz.

The number of CP381’s which can be installed in any one system depends
solely on the number of CPCI slots available.

Master/Slave Functionality The CP381 functions only as a slave. As such it requires a system master for

servicing.

System Controller The CP381 cannot function as a system controller.
Digital Inputs Digital inputs to the CP381 must be conform to the inputs specifications set

forth in this manual for the CP381. In most cases, some form of signal condi­tioning will be required on the process side prior to a signal being presented
to the CP381.

1.4.1 System Configuration

When implementing applications, precautions must be taken to ensure that the input signals
presented to the CP381 comply with the specifications set forth in this manual. For this reason
it will be necessary for most applications to provide signal conditioning prior to presenting the
digital inputs to the CP381. In addition, it is imperative that signal interference be kept to a min­imum. Please refer to chapters 4 and 5 for further information.

1.4.2 Driver Software

The CP381 is supplied with appropriate driver software which provides software interfacing
with the system master.

Page 1 - 6 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Introduction

1.5 Board Diagrams

The following diagrams illustrate board functionality and component layout.

1.5.1 System Level Interfacing

Figure 1-1: CP381 System Level Interfacing Diagram

CompactPCI Sy stem

System Master

Digital

Input

System

CP381

digital

input

30 max

CPCI - BUS

CP381

n

1

digital

input

30 max

1

digital

input

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 7

digital

input

1

Introduction CP381

1.5.2 Front Panel

Figure 1-2: CP381 Front Panel

LEGEND:

CP 381

RUN HIT

“RUN” and “HIT” are status LED’s. The different LED st atus combi­nations are illustrated and an explanation of their meaning given in
the Operation M/C section in chapter 2.5

1.5.3 Board Layout

Figure 1-3: CP381 Board (Front View)

LED1

C
O
N

Channels 0...29

Signal

Conditioning

2

O
P
T
O

O
P
T
O

O
P
T
O

O
P
T
O

O
P
T
O

O
P
T
O

O
P
T
O

OPTO

210

CON3

1

9

DI
ProComm
Controller

CapROM

25

C
O
N

1

1

Page 1 - 8 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Introduction

1.6 Technical Specifications

Table 1-3: CP381 Main Specifications

GROUP TYPE DESCRIPTION

DI ProComm

Controller and

Related

Peripheral

Memory

External

Interfaces

Internal Interfaces

Indicators Front Panel LED’s Two green LED’s to indicate operational status

General

FPGA Logic Device Provides CompactPCI interfacing and IO control logic

CapROM 4 kBit (512 byte) EEPROM

Digital Input One 62-pin, female, three row, D-sub connector

Supports up to thirty digital input channels

CompactPCI Bus One, 132-pin, female, six row connector (standard CPCI type

connector for J1)

JTAG/ISP JTAG/ISP 10-pin SMD connector for programming and testing

purposes

Mechanical Conforms with IEEE 1101.1
Power Requirements Voltage: 3.3V
Power Consumption 370 mW maximum
Temperature Range Operational: 0ºC to +70ºC Standard

-40ºC to +85ºC E2

Storage: -55ºC to +125ºC
Humidity 0% to 95% non-condensing
Dimensions 100 mm x 160 mm single height Eurocard
Board Weight 145 grams

Software Driver

Information

(See note below)

Note...

The Device ID and Vendor ID refer to the chip manufacturer. In the Class Code
value given, “11” relates to the data acquisition and signal processing control­lers and “0000” relates to the DPIO modules. Subsystem Device ID and Sub­system Vendor ID are defined by PEP.

PCI Header Device ID: 0x5555

Vendor ID: 0x1556
Class Code: 0x110000
Subsystem Device ID: 0x00E0
Subsystem Vendor ID: 0x1518

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 9

Introduction CP381

Table 1-4: CP381 Analog Input Specifications

TYPE DESCRIPTION

Input Voltage Range Low: -3V to +5V

High: +11V to +30V
Channels 30 channels
Channel Connections 2 pins per channel
Input Filter (edge frequency) 10 kHz
Input Protection 8 kV ESD
Isolation 2 kV process to system
Input Impedance Minimum: 1.5 k ohm

Maximum: 6 k ohm at 30V

1.7 Applied Standards

The PEP Modular Computers’ CompactPCI systems comply with the requirements of the fol­lowing standards:

Table 1-5: Applied Standards

TYPE STANDARD

Emission EN50081-1

CE

MECHANICAL Mechanical Dimensions IEEE 1101.1

ENVIRONMENTAL TESTS

Immunity, Industrial Environment EN50082-2
Immunity, IT Equipment EN55024
Electrical Safety EN60950

Vibration, Sinusoidal IEC68-2-6
Random Vibration, Broadband IEC68-2-64 (3U boards)
Permanent Shock IEC68-2-29
Single Shock IEC68-2-27

1.8 Related Publications

Table 1-6: Related Publications

ISSUED BY DOCUMENT

CompactPCI

Systems

Page 1 - 10 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

PICMG CompactPCI Specification, V. 2.0, Rev. 3.0
PEP Modular Computers CompactPCI Systems Manual (ID 19953)

CP381 Functional Description

Chapter

2

Functional Description

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 2 - 1

Functional Description CP381

This page was intentionally left blank.

Page 2 - 2 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Functional Description

2. Functional Description

The following sections present more detailed, board level information about the CP381 digital
input controller whereby the board components and their basic functionality are discussed in
general.

2.1 General Information

The CP381 is comprised basically of the following:

• Signal conditioning

• DI ProComm controller

• Controls digital data acquisition and provides interfacing to the CompactPCI bus

• System interfaces for:

• Digital inputs

• 30 channels

• One 62-pin, female, 3-pin row, D-sub connector (CON2)

• CompactPCI bus

• 132-pin, female, 6-pin row connector (CON1)

• CompactPCI specification

• Testing and program development (JTAG/ISP) connector (CON3)

• On board memory: Capability EEPROM (CapROM)

• Monitor and Control

• Two green LED’s

• Registers

• Software

2.1.1 Signal Conditioning

The digital input signal conditioning consists of the following:

• Overvoltage protection

• Low-pass signal filtering

• Current limitation

• Inverse polarity protection

• Input signal high-low determination

• Output signal stabilization buffering

• Optoisolation: galvanic isolation of process side from system side

2.1.2 DI ProComm Controller

The DI ProComm controller is responsible for supervising and controlling the digita l data acqui­sition process and maintaining communication with the CompactPCI system master. Applica­tions address the CP381 through its software driver interface within the system master whereby
the controller accepts requests from the driver and executes them accordingly . Digit al data from
the signal conditioning is processed through the DI ProComm controller and then made avail­able to the system master.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 2 - 3

Functional Description CP381

2.1.3 System Interfaces

The CP381 provides interfacing capability for the following system elements:

• Digital input

• CompactPCI bus

• Test and program development: JTAG/ISP

Digital input interfacing is achieved via the CON2 connector . Interfacing to the CompactPCI bus
is accomplished via the CON1 connector. Test and program development is supported by the
CON3 connector.

2.1.4 Monitor and Control

Various monitor and control functions are available for the operation of the CP381. Two LED’s
are available for operator interaction. In addition, applications have access via the System Mas­ter driver software to board specific registers.

2.1.5 Software

Driver software is available for the System Master application software.

Page 2 - 4 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Functional Description

2.2 Board Level Interfacing Diagram

The following figure demonstrates the interfacing structure between the internal processing
modules of the CP381 and other major CP381 system components. Where CP381 system el­ements have common interfacing they are grouped into a block. Interfacing common to only
one element of a block is indicated with a direct connecting line. The interfacing lines are shown
in white where they are onboard and in black for board external interfacing.

Figure 2-1: CP381 Board Level Interfacing

CP381 Digital Input Controller

CPCI - Interface

DI ProComm Controller

Signal Conditioning

Channel 0 Channel 29

Digital Input Digital Input

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 2 - 5

Functional Description CP381

2.3 System Interfaces

2.3.1 Digital Input Interface

The digital input interface is routed through the CON2 connect or . The following figure and table
indicate the pin layout and pinout of this connector.

Figure 2-2: Pin Layout of the Digital Input Interface Connector CON2

0+

0-

CP 381

RUN HIT

1+

2-

4+

5-

7+

8-

10+

11-

13+

14-

16+

17-

19+

20-

22+

23-

25+

26-

28+

29-

1-

2+

3+

3-

4-

5+

6+

6-

7-

8+

9+

9-

10-

11+

12+

12-

13-

14+

15+

15-

16-

17+

18+

18-

19-

20+

21+

21-

22-

23+

24+

24-

25-

26+

27+

27-

28-

29+

NC

NC

Pin 43

Pin 1

Pin 22

Page 2 - 6 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Functional Description

Table 2-1: Pinout of the Digital Input Interface Connector CON2

PIN SIGNAL PIN SIGNAL PIN SIGNAL

1NC 22 NC 43 DIGIN 29-

2 DIGIN 28- 23 DIGIN 29+ 44 DIGIN 28+

3 DIGIN 27+ 24 DIGIN 27- 45 DIGIN 26-

4 DIGIN 25- 25 DIGIN 26+ 46 DIGIN 25+

5 DIGIN 24+ 26 DIGIN 24- 47 DIGIN 23-

6 DIGIN 22- 27 DIGIN 23+ 48 DIGIN 22+

7 DIGIN 21+ 28 DIGIN 21- 49 DIGIN 20-

8 DIGIN 19- 29 DIGIN 20+ 50 DIGIN 19+

9 DIGIN 18+ 30 DIGIN 18- 51 DIGIN 17-

10 DIGIN 16- 31 DIGIN 17+ 52 DIGIN 16+

11 DIGIN 15+ 32 DIGIN 15- 53 DIGIN 14-

12 DIGIN 13- 33 DIGIN 14+ 54 DIGIN 13+

13 DIGIN 12+ 34 DIGIN 12- 55 DIGIN 11-

14 DIGIN 10- 35 DIGIN 11+ 56 DIGIN 10+

15 DIGIN 9+ 36 DIGIN 9- 57 DIGIN 8-

16 DIGIN 7- 37 DIGIN 8+ 58 DIGIN 7+

17 DIGIN 6+ 38 DIGIN 6- 59 DIGIN 5-

18 DIGIN 4- 39 DIGIN 5+ 60 DIGIN 4+

19 DIGIN 3+ 40 DIGIN 3- 61 DIGIN 2-

20 DIGIN 1- 41 DIGIN 2+ 62 DIGIN 1+

21 DIGIN 0+ 42 DIGIN 0-

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 2 - 7

Functional Description CP381

2.3.2 CompactPCI Interface and Pinout

The CompactPCI interface is based on the specification PICMG 2.0 R 3.0, 10/1/99. The following
figure and table indicate the pin layout and pinout of the CompactPCI connector, CON1 (J1).

Figure 2-3: CPCI Connector

CON1 (J1)

F EDCBA

25

CON1

1

Table 2-2: CompactPCI Connector CON1 (J1)

PIN ROW

PIN

A B C D E F

1NCNCNCNCNCGND
2NCNCNCTDOTDIGND
3 INTA# NC NC NC NC GND
4 NC GND NC NC NC GND
5NC NC RST GND NC GND
6 NC GND 3,3V CLK AD[31] GND
7 AD[30] AD[29] AD[28] GND AD[27] GND
8 AD[26] GND NC AD[25] AD[24] GND

9 C/BE[3] IDSEL AD[23] GND AD[22] GND
10 AD[21] GND 3,3V AD[20] AD[19] GND
11 AD[18] AD[17] AD[16] GND C/BE[2] GND

12-14 Key Area
15 3,3V FRAME# IRDY GND TRDY GND
16 DEVSEL# GND NC STOP LOCK GND
17 3,3V NC NC GND PERR GND
18 SERR# GND 3,3V PAR C/BE[1] GND
19 3,3V AD[15] AD[14] GND AD[13] GND
20 AD[12] GND NC AD[11] AD[10] GND
21 3,3V AD[9] AD[8] M66EN C/BE[0] GND
22 AD[7] GND 3,3V AD[6] AD[5] GND
23 3,3V AD[4] AD[3] NC AD[2] GND
24AD[1]NCNCAD[0]NCGND
25 NC NC NC 3,3V NC GND

Page 2 - 8 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Functional Description

2.3.3 Test and Program Development

2.3.3.1 JTAG/ISP Interface and Pinout

A JT AG/ISP interface is provided on the CP381 for the manufacturer’s use (logic programming,
JTAG test).

Figure 2-4: JTAG Connector (CON3)

This is a SAMTEC 10-pin, male, dual row connector (0.050” pin pitch).

2

1

Table 2-3: JTAG Connector (CON3) Pinout

SIGNAL PIN PIN SIGNAL

TCK 12GND
TDO 343.3V
TMS 56NC
NC 78NC
TDI 9 10 GND

10

9

2.4 CapROM EEPROM

The CapROM is a 4 kBit (512 byte) EEPROM which provides the capability t o store board con­trol relevant information to allow software configuration of the CP381.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 2 - 9

Functional Description CP381

2.5 Monitor and Control (M/C)

Monitor and Control functions are divided essentially into Pre-operation and Operation. Pre-op­eration M/C deals with board configuration and system requirements. Operation M/C covers d i­rect operator interfaces.

2.5.1 Pre-Operation M/C

Pre-operation M/C is a direct function of the application and the system requirements. These
requirements dictate the digital input configuration as well as the overall system integration.
Digital input configuration is addressed in detail in chapters 4 and 5. These chapters provide
detailed information concerning input signal conditioning and environment al aspects which re­late to the operation and performance of the CP381. Overall system integration and compli­ance with its requirements is beyond the scope of this manual.

2.5.2 Operation M/C

The front panel of the board is equipped with two green LED’ s whose st atus combinations pro­vide information for the operator on the operational status of the boards. The following tables
describe the LED status combinations and the meanings of the modes

Table 2-4: System Status Indicators

LED State Description

ON

Run

OFF

ON

Hit

OFF

The different LED status combinations have the following meanings:
Run Hit Description
Off Off Board is disabled
On Off Board is enabled and the modes (“Event-

hit”, “Compare-hit” and “Latch-hit”) are dis­abled or no hit has occurred.

Off On Board is enabled and “Latch-hit” mode is en-

abled; a defined event has occurred and the
input will be captured.

On On Board is enabled and an “Event-hit” or

“Compare-hit” is detected, but not a “Latch­hit”.

Table 2-5: Function Modes of the CP381

Mode Description

Event hit The CP381 monitors the input ports and detects any change in their state:

- Whenever individual input channels are enabled they are monitored.

- The direction of the change-of-state may be set.

- A status register reports the detected events.

Latch hit In addition to standard event detection (i.e. event-hit) there is a latch mode extension.

This mode is used in the event that it is necessary to capture the inputs when a defined
event has occurred.

Compare hit It is possible to detect a complete input pattern automatically. The input vector is con-

tinuously compared with the content of the mask register. Single inputs may also be
individually masked out.

Page 2 - 10 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Installation

Chapter

3

Installation

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3 - 1

Installation CP381

This page was intentionally left blank.

Page 3 - 2 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Installation

3. Installation

The CP381 has been designed for easy installation. However, the following standard precau­tions, installation procedures and general information must be observed to ensure proper in­stallation and to preclude damage to the board or injury to personnel.

3.1 Hardware Installation

The product described in this manual can be installed in any available 3U slot of a CompactPCI
system except for the system master slot.

3.1.1 Safety Requirements

The board must be securely fastened to the chassis using the two front panel retaining screws
located at the top and bottom of the board to ensure proper grounding and to avoid loosening
caused by vibration or shock.

In addition the following electrical hazard precautions must be observed.

Caution, Electric Shock Hazard!

Ensure that the system main power is removed prior to installing or removing
this board. Ensure that there are no other external voltages or signals being
applied to this board or other boards within the system. Failure to comply with
the above could endanger your life or health and may cause damage to this
board or other system components including process-side signal conditio ning
equipment.

ESD Equipment!

This PEP board contains electrostatically sensitive devices. Please observe
the following precautions to avoid damage to your board:

Discharge your clothing before touching the assembly. Tools must be
discharged before use.

Do not touch any on board components, connector pins, or board conductive
circuits.

If working at an anti-static workbench with professional discharging
equipment, ensure compliance with its usage when handling this product.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3 - 3

Installation CP381

3.1.2 Installation Procedures

To install the board proceed as follows:

1. Ensure that the safety requirements indicated above are observed.

Warning!

Failure to comply with the instruction below may cause damage to the board or
result in improper system operation. Please refer to chapters 4 and 5 for config­uration information.

2. Ensure that the board is properly configured for operation before installing.

Note...

Care must be taken when applying the procedures below to ensure that when
the board is inserted it is not damaged through contact with other boards in the
system.

3. To install the board perform the following:

1. Prior to installation of the board disengage the insertion/extraction handle by first un­locking the handle and pressing it down.

2. Insert the board into an appropriate slot, and, using the insertion/extraction handle, en­sure that it is properly seated in the backplane. (Front panel is flush with the rack front;
the insertion/extraction handle is locked.)

4. Fasten the front panel retaining screws.

Warning!

Proper and safe operation of the CP381 Digital Input Controller depends on the
correct configuration of input signals and signal conditioning. System
integrators must ensure that all signals presented to the CP381 comply with the
specifications set forth in this manual.

Failure to comply with the above may cause damage to the board or result in
improper system operation. Please refer to chapters 4 and 5 for configuration
information.

5. Connect external interfacing cables to the board as required.

6. Ensure that the interfacing cables are properly secured.

Page 3 - 4 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Installation

3.1.3 Removal Procedures

To remove the board proceed as follows:

1. Ensure that the safety requirements indicated above are observed.

Warning!

Care must be taken when applying the procedures below to ensure that when
the board is removed it is not damaged through contact wit h othe r board s in the
system.

2. Disconnect any interfacing cables that may be connected to the board.

3. Loosen both of the front panel retaining screws.

4. To remove the board from the backplane perform the following:

1. Unlock the insertion/extraction handle by pressing down on the grey locking mecha­nism in the middle of the handle. (This should be achievable with a minimum of f orce.
If necessary lift the handle up slightly while pressing down on the grey locking mech­anism.)

2. Disengage the board from the backplane by pressing down on the insertion/extraction
handle and pull the board out of the slot ensuring that the board does not make cont act
with adjacent boards. (If the handle does not move, it is not unlocked. Repeat the un­locking procedure above and try again. Do not use force!)

3.2 Software Installation

Installation of the CP381 driver software is a function of the application operating system. For
further information refer to the appropriate software documentation.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3 - 5

Installation CP381

This page was intentionally left blank.

Page 3 - 6 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

Chapter

4

Configuration

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 1

Configuration CP381

This page was intentionally left blank.

Page 4 - 2 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

4. Configuration

This chapter provides information for configuring the CP381 board for operation.

4.1 Jumper Settings

The CP381 does not have any jumpers which require configuring.

4.2 Digital Input Signal Requirements.

In addition to the input signal type and its range, which have been specified in chapter 1, para­graph 1.3.1, system integrators must be aware of certain input configuration requirements for
the CP381. The following paragraphs provide some information regarding individual connec­tion configuration requirements.

4.2.1 Channels

The CON2 connector of the CP381 is designed so that there are two input pins per channel.
This allows each channel to be configured separately as required. This is illustrated in Figure
2-2, which shows the front panel connector pinout, with the 30 channels shown starting at the
top of the connector with channel 0.

The following sections address the basic requirements.

4.2.2 Signal Characteristics

The signals are single-ended and the specified voltage ranges illustrated in the following table
should be observed.

Figure 4-1: Voltage Ranges

+30V Maximum

+24V
standard

HIGH

HIGH

+11V

INDETERMINATE ZONE

+5V

is > +11V

LOW

-3V

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 3

LOW is < +5V

Configuration CP381

4.2.3 Channel Configuration

Signals require to be connected: plus to plus, minus to ground as shown in figure 4-2 below

Figure 4-2: Input Configuration (Example for Channel 0)

CP381

+

Voltage
Source

Figure 4-3: Configuration Diagram for All Channels

V

Digital Sensors

+

DIGIN0+
Pin21

DIGIN0­Pin42

CON2

CON2

Ch 0

V

Ch n

Ch 29

CP381

Page 4 - 4 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

Figure 4-4: Configuration Diagram for All Channels

CON2

V

+

Digital Sensors

Ch 0

Ch n

Ch 29

CP381

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 5

Configuration CP381

4.3 Programming Interface

4.3.1 Access Control Logic (Address Decoder)

All the resources of the CP381 are mapped within the 64 kB PCI memory address space which
itself is set in the PCI configuration register BAR0. The port size of all local or backend registers
is 32-bit by default. The address map of the registers is as follows.

Table 4-1: Backend Register Address Map

Base Address Size Function

bar0 + 0x0000 4 K Common Board Registers

0x0400 32 bit g_irq General Interrupt Enable Register
0x0800 32 bit hsr Hardware Status Register
0x0804 32 bit i_pen General Interrupt Pending Register
0x0c00 32 bit hdr Hardware Debug Register

bar0 + 0x1000 4 K Capability ROM, serial EEPROM

0x1000 32 bit r_cmd Command Register
0x1400 32 bit r_ctl Control Register
0x1800 32 bit r_sta Status Register
0x1c00 32 bit r_dat Data Register

bar0 + 0x2000 2 K Input Control

0x2400 32 bit i_ctl Input Control Register
0x2408 32 bit i_irqen Input Irq Enable Register
0x240c 32 bit e_pol Input Event Polarity Register
0x2410 32 bit e_msk Input Event Mask Register
0x2414 32 bit e_len Input Latch-on-Event Register
0x2418 32 bit c_cmp Input Pattern Compare Register
0x241c 32 bit c_msk Input Pattern Mask Register

bar0 + 0x2800 1 K Input Status

0x2800 32 bit i_event, Input Status Register

bar0 + 0x2c00 1 K Input Data

0x2c00 32 bit d_in, Input Data Register
0x2c04 32 bit input, Transparent Input Data

bar0 + 0x3000 – 0xffff 52 K Reserved

Page 4 - 6 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

4.3.2 Reading Input Data

The input ports are made visible via the Input Data Register. This register reflects the inputs
after them having passed the digital programmable debouncer. An active input appears there
as a logical "1" whereas an open or inactive input port appears as a logical "0". The bit ordering
naturally corresponds with the numbering of the input ports at the connector.

Table 4-2: Input Data Register Bit Map

Bits Type Default Function

31-30 r 0 Reserved
29-0 r - Input (debounced)

Note...

Where the enhanced features such as interrupts, pattern or event detection are
not required, only the input data register is relevant.

Table 4-3: Transparent Input Data Register Bit Map

Bits Type Default Function

31-30 r 0 Reserved
29-0 r - Input (transparent)

Note...

In addition to the Input Data Register, there is a second non-latched input regis­ter (debouncer bypassed).

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 7

Configuration CP381

4.3.3 Debouncing Inputs

By default, all inputs are filtered through a passive analog low-pass filter placed immediately
behind the input connector . Additionally, the CP381 provides a programmable digita l debounc­er which is common for all inputs. It functions as follows; the input ports are sampled at a pro­grammable sample rate which is derived from PCI bus clock. Two consecutive samples must
be equal before being stored in the input data reg ister. By this means, bouncing and spikes on
inputs can be filtered out. For example, with a selected input sample rate of 500 Hz, input puls­es which are shorter than 2 ms are filtered out.

Table 4-4: Input Control Register

Bits Type Default Function

31-8 r/w 0 Reserved
7 r/w 0 Input enable
6 r/w 0 Event detect enable
5 r/w 0 Latch mode enable
4 r/w 0 Pattern detect enable
2-0 r/w 000 Debounce control deb[2..0]

Note...

The Inputs are sampled through the debouncer after the Input Enable bit is set.
Additional features such as event and pattern detection and latch mode are also
enabled in the input control register, after being configured within the corre­sponding mode registers.

Table 4-5: Programmable Input Sample Rates

deb[2..0]

000 1 33 MHz 30 ns
001 2^8 128 KHz 8 us
010 2^10 32 KHz 32 us
011 2^12 8 KHz 128 us
100 2^14 2 KHz 0.5 ms
101 2^16 0.5 KHz 2 ms
110 2^18 125 Hz 8 ms
111 2^20 31 Hz 32 ms

Clock

Divider

Input Sample clock

@ 33MHz PCI

Input Sample period @ 33MHz PCI

*Note...

The clock divider default value is 1. In addition to the choice of debouncing fil­ters, there is an analog filter implemented on board with an edge frequency at
10 kHz.

Page 4 - 8 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

4.3.4 Detecting Input Events

Detecting events on input means that the CP381 hardware can supervise the input ports upon
their changing state and without being continuously polled. This mode is controlled by three
control registers. In the Input Event Mask Register, individual input events can be enabled
which should be monitored. In the Input Polarity Register the direction of the change-of-state
is set. Detected events are reported in the corresponding Input Event Status Register.

Table 4-6: Input Event Mask Register, Bit Map

Bits Type Default Function

31-30 r/w 0 Not used
29 - 0 r/w 1 Input event mask bits

Note...

A set bit means that event detection is disabled for the corresponding input port.

Table 4-7: Input Event Polarity Register, Bit Map

Bits Type Default Function

31-30 r/w 0 Not used
29 - 0 r/w 0 Input event polarity bits

Note...

A bit setting of 0 bit means that an event is detected when the input port
changes from 0 to 1 whereas a setting of 1 means that an event is detected
when the input changes from 1 to 0.

Table 4-8: Input Status Register, Bit Map

Bits Type Default Function

31 r/w 0 Input latch-on-event status flag
30 r/w 0 Input compare status flag
29 - 0 r/w 0 Input event status flags

Note...

A set bit means that an event was detected on the corresponding input port.
Events must be cleared by writing a "1" to the corresponding input event flag.
Otherwise, consecutive events on the same input would no longer be detected.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 9

Configuration CP381

4.3.5 Latching on Input Events

In addition to the standard event detection described above, there is a latch mode extension.
This mode is used in cases where it is necessary to capture the inputs when one of the defined
events occurs.

Table 4-9: Input Latch-on-Event Register, Bit Map

Bits Type Default Function

31-30 r 0 Not used
29 – 0 r 0 Latch on event, enable bits to activate

Note...

A set bit means that a detected event on the corresponding input is latched. If
all bits are enabled all inputs are latched immediately. To switch back from latch
mode into active mode all detected events and the input latch-on-event status
flag have to be reset by writing "1" to the corrresponding bits in the Input Status
Register.

4.3.6 Comparing Input Patterns

In addition to the Event Detection Mode it is also possible to detect a complete input pattern
automatically. In this mode the input vector is continuously compared with the content of the
Input Pattern Compare Register . In the case of a match a flag is set within the Input S t atus Reg­ister. Single inputs can also be masked out individually in the Input Pattern Mask Register.

Table 4-10: Input Pattern Mask Register, Bit Map

Bits Type Default Function

31-30 r/w 0 Not used
29 - 0 r/w 1 Input event mask bits

Note...

A set bit means that the corresponding input is masked out for pattern recogni­tion. There is no special enable for pattern recognition since it is switched off by
default as long as all mask bits are set.

Table 4-11: Input Pattern Compare Register, Bit Map

Bits Type Default Function

31-30 r/w 0 Not used
29 - 0 r/w 1 Input pattern compare bits

Note...

This register stores the input compare dat a. A comp are match is reported within
the Input S t atus Register (Bit 31). To reset a compare match, the st atus flag ha s
to be reset by writing "1" to it and also the match condition must cease.

Page 4 - 10 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

4.3.7 Hardware Debug/Test Registers

These registers are for internal test and debug only. The Common Status Register contains
Logic-Version and PCB -Version. The Common Control Register is a read/write register with­out any further functionality. Neither of these registers should be used by standard sof tware.

Table 4-12: Hardware Debug Register Bit Map

Bits Type Default Function

31-0 r/w 0 Used for test purposes

Table 4-13: Hardware Status Register Bit Map

Bits Type Default* Function

31-16 r 0 Reserved
15-8 r 00 HW Version (PCB Index)
7-0 r 01 Logic Version

Note...

The HW version starts with 0, the Logic version starts with 1. At each further
release it will be incremented by 1.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 11

Configuration CP381

4.3.8 Generating Interrupts

Any detected event or, more clearly, any event flag set in the Input Status Register can trigger
an interrupt. Thus, any input can be enabled individually for interrupt generation.

Regardless of the cause of the interrupt, a board interrupt is always handled on the hardware
level in the same way, as follows; after having set the input control registers where compare
data and events are defined, interrupts can be enabled individually within the Input IRQ Enable
Register . The final step is to enable the board interrupt in the General Interrupt Enable Register .
Within the interrupt service routine interrupts should be handled as follows.

1. Check if the board is the cause of the interrupt (General Interrupt Pending is set)

2. If yes, check the reason for the interrupt by reading the input status register

3. Reset the corresponding Input Event Flag by writing a 1 to a set status bit.

4. Reset the boards’ IRQ by resetting the General Interrupt Pending Bit by writing a 1 to that
status bit

5. Return from Interrupt

Table 4-14: General Interrupt Enable Register, Bit Map

Bits Type Default Function

31 r/w 0 Board Interrupt Enable
30 - 0 r/w 0 Reserved

Note...

The board will continue issuing an interrupt until all interrupt sources are com­pletely dealt with and no interrupt condition remains.

A set bit means that the boards’ interrupt is enabled.

Table 4-15: General Interrupt Pending Register, Bit Map

Bits Type Default Function

31 r/w 0 Board Interrupt Pending
30 - 0 r/w 0 Reserved

Note...

A set bit means that the boards’ interrupt is pending. A board interrupt must be
cleared by writing a "1" to the corresponding input event flag.

Table 4-16: Input IRQ Enable Register, Bit Map

Bits Type Default Function

31 r/w 0 Not used
30 r/w 0 Input compare interrupt enable
29 - 0 r/w 0 Input event interrupt enable

Page 4 - 12 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 Configuration

4.3.9 Programming the Board Capability ROM

The Board Capability ROM contains all the board data necessary to identify b oard, version, op­tional features, etc., and to setup the basic software. The BCR is implemented using a 4 KBit
serial EEPROM of the type Microchip 93LC66.

(The contents list of the BCR is not described here.)

The serial interface of the device has been realized in hardware resulting in a very simple reg­ister based programming interface with command, control, status and dat a registers. All proto­col and serial timing specifications are resolved by hardware.

Programming of the BCR is undertaken as follows: The control word is written into the ROM
Control Register including command opcode and internal address. Then optional dat a (in case
of Write action) is written into the ROM Dat a Register . Command execution is started by se tting
the St artbit in the ROM Command Register. Then Ready/Busy must be polled in the ROM Sta­tus Register. After reaching Ready status, the next command can be set up and data (in case
of Read action) can be fetched from the ROM Data Register.

Table 4-17: ROM Command Register Bit Map

Bits Type Default Function

31 r/w 0 Startbit
30-0 r/w 00 Reserved

Note...

The Startbit will be automatically reset as soon as an action is completed.

Table 4-18: ROM Control Register Bit Map

Bits Type Default Function

31-18 r/w 0 Reserved
17-16 r/w 00 Opcode
15-9 r/w 00 Reserved
8-0 r/w 00 Internal address (A8..A0)

Note...

The commands READ, EWEN (Write Enable) and WRITE are sufficient for all
purposes.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 13

Configuration CP381

Table 4-19: Opcodes and Commands

Opcode A8..A0 Command

00 11xxxxxxx EWEN
10 xxxxxxxxx READ
01 xxxxxxxxx WRITE

Note...

The EWEN (Erase and Write Enable) command must be executed once before
the first write.

Table 4-20: ROM Status Register Bit Map

Bits Type Default Function

31 r/w 0 Busy/Ready
30-0 r/w 00 Reserved

Note...

As soon as the Startbit is set the Busy/Ready bit becomes active (Busy=1). It
remains set as long as the command is executed and is reset when command
execution is complete.

Table 4-21: ROM Data Register Bit Map

Bits Type Default Function

31-8 r/w 0 Reserved
7-0 r/w 0 Data (for data read and write commands)

Page 4 - 14 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 System Considerations

Chapter

5

System Considerations

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 5 - 1

System Considerations CP381

This page was intentionally left blank.

Page 5 - 2 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01

CP381 System Considerations

5. System Considerations

5.1 Introduction

In addition to the basic specification requirements for signals being presented to the CP381
which have been addressed in chapter 4, system integrators need to be aware of the overall
system environment and the application needs when designing the interfacing to the CP381.
The following chapters address a number of more apparent considerations which should be ad­dressed but certainly not all of the possible situations which may be encounte red. Many of the
considerations presented here are recommendations, but some are definite requirements if the
CP381 is to successfully achieve its purpose.

5.2 General

Considerations:

1. Care must be taken to ensure that proper grounding concepts a re followed, and that the
integrity of the grounding system within the application be maintained.

2. Input wire routing should avoid proximity to high voltage or current sources.

3. Where possible input wiring length should be kept as short as possible.

5.3 Shielding

Considerations:

1. Input cable shielding in general is recommended.

2. The requirements for shielding can be seen primarily as a function of the system design
and environment, but empirical results must also be considered.

3. The CON2 connector has a metal housing which is connected to the CP381 shield and
is isolated from the system ground.

4. Ensure that if shielding is used that it is not in anyway connected to the system ground.

ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 5 - 3

System Considerations CP381

5.4 Debouncing

On the CP381 it is possible to select from a number of debouncing times, dependant on the
type of switches/sensors in use. For example, when using mechanical switches or relays to
switch the input, bouncing will always occur and therefore debouncing is necessary. A de­bounce period may be selected from a range of values available, accessible via software in the
register depending on the settle time. Where it is known that an application does not generate
bouncing problems, the debounce period may be set to the default value.

Table 5-1: Debouncing Periods

Clock Divider

1 (default value - see note below) 33 MHz 30 ns
2^8 128 kHz 8 us
2^10 32 kHz 32 us
2^12 8 kHz 128 us
2^14 2 kHz 0.5 ms
2^16 0.5 kHz 2 ms
2^18 125 Hz 8 ms
2^20 31 Hz 32 ms

*Note...

The clock divider default value is 1. In addition to the choice of debouncing fil­ters, there is an analog filter implemented on board with an edge frequency at
10 kHz.

Input Sample Clock

@ 33 MHz PCI CLK

Input Sample Period

@ 33 MHz PCI CLK

5.5 Process-side Signal Conditioning

Considerations:

1. Input signals presented to the CP381 must be within the ranges specified for signals in
chapter 1.3.1 or erroneous results will occur as well as possible damage to the CP381.

5.6 Cable Interfacing

Considerations:

1. No modification to the CP381 itself is permitted.

2. If necessary , cabling to the CP381 CON2 connector should be physically fixed to prevent
strain on the CON2 connector.

Page 5 - 4 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01
