INSTRUCTION MANUAL
E
3
Thank you for purchasing the Minolta Vectis 300L. This camera is an easy
to operate lens shutter camera from Minolta’s line of Advanced Photo
System™ cameras, featured with Drop-in Loading and a 24 - 70mm zoom
lens. The sleek and compact design gives the Vectis 300La sophisticated
appearance suitable for any occasion. This manual is designed to help
you understand the operation of your camera and its functions. Please
familiarize yourself with the names of the controls and their locations on
the camera, then read this manual thoroughly.
* Advanced Photo System™ is a trademark of the five system developing companies.
Advantages of the Advanced Photo System
New print formats…
Classic C print, wider H print, and panorama P
print formats are available with Advanced Photo
System cameras.
New processing…
In addition to returning your prints in the format you
selected, certified photofinishers will return your
Advanced Photo System film in its original cassette
with an index print. To order reprints, simply choose
the images you want from the index print. No more
searching through negatives to find the right frame.
Easier to load…
Advanced Photo System cameras use the new IX240 type film. This new
film features Drop-in Loading to make loading your camera simple, the
first time, every time. Indicators on
the cassette tell you and your
camera if the film is unexposed,
partially exposed, exposed, or
processed.
Unexposed
Exposed
Processed
Partially
Exposed
2
4
FOR PROPER AND SAFE USE.........................................................................6
NAMES OF PARTS.............................................................................................8
QUICK OPERATION.........................................................................................12
BASIC OPERATION
Attaching the Strap..................................................................................15
Installing the Battery................................................................................16
Checking the Battery...............................................................................17
Loading Film............................................................................................19
Full-Auto Operation .................................................................................24
Focus Hold...............................................................................................28
For Closer Subjects.................................................................................30
Special Focusing Situations....................................................................33
Rewinding the Film..................................................................................34
Processing...............................................................................................36
USING THE BUILT-IN FLASH
Selecting the Flash Mode........................................................................38
Flash Range ............................................................................................39
Red-eye Reduction ..................................................................................40
Fill Flash ..................................................................................................41
Flash Cancel............................................................................................42
Night Portrait............................................................................................43
Landscape/Night View .............................................................................44
ADDITIONAL FEATURES
Date Imprinting ........................................................................................46
Title Imprinting.........................................................................................52
Self-timer..................................................................................................60
Remote Control (Sold Separately)..........................................................62
APPENDIX
Lab Services............................................................................................68
Caring For Your Camera .........................................................................70
Technical Details ......................................................................................76
5
TABLE OF CONTENTS
CAUTION
6 7
FOR PROPER AND SAFE USE
Read and understand all warnings and cautions before using this product.
WARNING
Batteries may become hot or explode due to improper use.
• Use only the batteries specified in this instruction manual.
• Do not install the batteries with the polarity (+/–) reversed.
• Do not subject batteries to fire or high temperatures.
• Do not attempt to recharge, short, or disassemble.
• Tape over lithium battery contacts to avoid short-circuit when disposing
of batteries, and follow local regulations for battery disposal.
Keep batteries or things that could be swallowed away from young
children. Contact a doctor immediately if an object is swallowed.
Immediately remove the batteries and discontinue use if...
• the product is dropped or subjected to an impact in which the interior is
exposed.
• the product emits a strange smell, heat, or smoke.
Do not disassemble. Electric shock may occur if a high voltage circuit
inside the product is touched. Take your camera to a Minolta Service
Facility when repairs are required.
The lens retracts when the camera is turned off or Auto Power Off is
activated. Touching the lens barrel while it is retracting may cause injury.
CAMERA BODY
8 9
NAMES OF PARTS
Flash-mode (38)/
Adjust button
Self-timer (60)/
Remote-control (62)/
Select button
Data panel (10)
Shutter-release
button (27)
Title button (53)
Zoom buttons (26)
Date button (46)
Format switch (24)
* Do not touch
Viewfinder window*
AF windows*
Meter window*
Remote-control receiver*
Flash* (38)
Self-timer/Remote-control/
Red-eye reduction lamp*
Lens*
Tripod socket
Film chamber (21)
Manual-rewind
button (35)
Strap eyelet (15)
Battery chamber
(16)
Ready lamp
(green) (11)
Viewfinder* (11)
For information on specific parts, refer to the page numbers shown in parenthesis.
Film-chamber
release (21, 34)
Main switch
10 11
NAMES OF PARTS
• Only the necessary indicators will appear in the data panel.
Flash-mode
indicators (38)
Self-timer indicator (60)
Remote-control
indicator (62)
Cassette mark
Frame counter
Battery-condition
indicator (17)
Title marks (54)
Date/Time/Title/ISO display
Ready lamp (green)
Close-framing guide (31)
Focus frame (26)
With the shutter-release button pressed partway down -
Glows: Camera is ready
Blinks quickly: Subject is too close (shutter is locked)
Blinks slowly: Camera shake warning
Off: Flash is charging (shutter is locked)
DATA PANEL VIEWFINDER
12 13
QUICK OPERATIONS
3. Select the print
format (p. 24).
4. Frame the subject
as desired (p. 26).
5. Center your
subject in the
focus frame
(p. 26).
6. Press the shutterrelease button allthe-way down to
take the picture
(p. 27).
1. Insert the battery
(p. 16) and press
the main switch (p.
20).
2. Insert the film
(p. 21).
T
W
14 15
ATTACHING THE STRAP
BASIC OPERATION
Attach the strap as shown.
Button keys are included on the strap. Use the
smaller key to push the manual-rewind button
(p. 35).
Button keys
16 17
INSTALLING THE BATTERY CHECKING THE BATTERY
Your camera uses one 3-volt CR-2 lithium
battery to supply power for all camera
operations.
1. Open the battery chamber as shown.
Each time the main switch is turned on, a symbol will appear in the data
panel to indicate the power status of the battery.
Briefly appears. Power is sufficient for all camera
operations.
Power is sufficient, but the battery must be
replaced soon.
Replace the battery. The shutter will lock until
the battery is replaced.
Continued on following page.
2. Insert the battery into the chamber as
indicated by the + and – marks.
3. Close the battery chamber.
• After installing a new battery, reset the date and
time (p. 48).
18 19
CHECKING THE BATTERY
LOADING FILM
Your camera uses IX240 type film designed for use in Advanced Photo
System cameras.
• Your camera’s automatic transport system loads the film, sets the film
speed, and advances the film after each exposure.
• Use film from ISO 25-3200. Your camera will automatically set the proper
ISO.
• After loading, the film chamber cannot be opened until rewind has been
initiated.
• DEP, Double Exposure Prevention, prevents the camera from accepting
exposed film.
• This camera will only load film with the mark current.
• If no display appears, replace the battery or check that it is inserted
correctly.
• Auto Power Off: The data panel will shut off and the lens will retract if the
camera is not operated for more than eight minutes. Press the main switch
to restore power.
• Do not obstruct the lens while it is retracting.
Continued on following page.
20 21
LOADING FILM
3. Insert the cassette into the film chamber
with the VEI on top.
• Do not use force when opening the film-chamber
door.
2. Turn the camera upside down, then slide
the film-chamber release to open the film
door.
Visual Exposure Indicators
• The current VEI has a white indicator behind it.
VEI MEANING
UNEXPOSED
PARTIALLY EXPOSED
EXPOSED
PROCESSED
1. Press the main switch to turn the camera
on.
Continued on following page.
22 23
LOADING FILM
If 0 blinks in the data panel, press the film-chamber
release, open the chamber, then remove the film.
- If the film’s current VEI is , insert a new roll of film.
- If a partially exposed roll of film was loaded into this
camera, the VEI has been changed from to .
- If a processed roll of film was loaded into this camera,
the VEI has been changed from to .
- If the film’s current VEI is , remove the film, remove
and reinsert the battery, then reload the film. If the film
will not load, contact the nearest authorized Minolta
Service Facility.
4. Press the film-chamber door closed until it clicks.
• The data panel will display the cassette mark
and the film’s ISO, then the number of frames
remaining on the roll.
• After the film is loaded, the film chamber cannot be opened until the film has
been rewound.
• Film can be loaded when the camera is on or off. If film is loaded with the
camera off, all indicators in the data panel will disappear after the number of
frames remaining is displayed.
24 25
FULL-AUTO OPERATION
Hold the camera steady, making sure your fingers do not cover the flash,
AF windows, or meter window. If you are taking a vertically framed
picture, turn the camera so the flash is on top.
1. Press the main switch to turn the camera
on.
• The camera is set for fully-automatic operation
and the flash will fire automatically when
necessary.
Continued on following page.
Correct Incorrect
2. Select the print format.
• The viewfinder will change to
match your selection.
26 27
FULL-AUTO OPERATION
5. When the green ready lamp glows,
press the shutter-release button allthe-way down to take the picture.
• Press the shutter-release button with a
slow steady squeeze - never a quick jab.
3. Looking through the viewfinder, frame
the subject as desired.
Press the W zoom button to zoom out.
Press the T zoom button to zoom in.
• Do not hold or obstruct the lens barrel.
4. Center your subject in the focus frame,
then press the shutter-release button
partway down.
• If the ready lamp does not glow, the flash is not charged. Wait until it glows,
then take the picture.
• If the ready lamp blinks quickly and the shutter is locked, your subject is too
close (p. 30).
• Zoom position may change a little when the shutter-release button is
pressed all-the-way down, but the picture will be taken with your first
framing.
• Press the main switch and turn the camera off after use.
2928
FOCUS HOLD
Subjects outside the focus frame may not
be in focus. Use focus hold to ensure
accurate focusing.
1. Center your subject in the focus
frame.
2. Press and hold the shutter-release
button partway down so the green
ready lamp glows.
3. Without lifting your finger,
recompose the picture and press the
shutter-release button all-the-way
down to take the picture.
• Lift your finger from the shutter-release
button to cancel focus hold.
• When the print format is P, the minimum focus distance changes with the
focal length; 50cm (1.6ft.) at W (24mm), 80cm (2.6ft.) at T (70mm), and
middle distance for middle focal length position.
• If the subject is very close, the ready lamp may glow or blink slowly and
shutter may be released, but the picture will not be in focus.
30 31
FOR CLOSER SUBJECTS
The green ready lamp will blink rapidly and the
shutter will lock when you are closer than the
minimum focus distance.
If your subject is closer than 1.3m (4.3ft.), parallax will occur and actual
image and image seen through the viewfinder do not match. In this case,
center your subject in the focus frame, press the shutter-release button
partway down, and without lifting your finger, move the camera slightly
upward and take the picture (page 28). The amount of parallax is the
maximum when the zoom position is tele end and focusing distance is the
minimum; in this case, top end is guided by the close-framing guide.
The minimum focus distance of this camera is 50cm (1.6ft.) when the print
format is C or H.
CLOSE-FRAMING GUIDE
Close-framing guide
Actual image area
Continued on following page.
33
SPECIAL FOCUSING SITUATIONS
32
FOR CLOSER SUBJECTS
Some scenes or subjects, like the examples below, are difficult for the
autofocus system to lock on to. In these shooting situations, focus hold (p.
28) on another object with the same brightness and the same distance
from you as your main subject, recompose, then press the shutter-release
button all-the-way down to take the picture.
• Bright light sources such as the sun or neon lights
• Highly reflective surfaces such as water, mirrors,
etc.
• Flame, fireworks, etc.
• Dark objects and surfaces with
low reflectance
Correct
Incorrect
Example:
Zoom position: 70mm
Focus distance: 50cm (1.6ft.)
• Objects behind glass, bars, or other such as partitions
Your camera automatically rewinds the film into the cassette after the last
exposure.
1. Wait for the film to completely rewind into the
cassette.
• The frame counter will count down during rewind.
• 0 will appear in the frame counter and will blink when
rewind is complete.
• The lens will retract after rewind.
34 35
REWINDING THE FILM
2. Turn the camera upside down, then slide the
film-chamber release to open the film door.
3. Open the film chamber and remove the film.
• The film’s VEI indicator will be .
1. Press the main switch to turn the camera
on.
• Rewind doesn’t start if the camera is off.
MANUAL REWIND
Use manual rewind to rewind the film before the roll is finished.
2. Gently press the manual-rewind button
using the smaller button key on the
strap.
3. Follow steps 1- 3 from automatic rewind.
36 37
PROCESSING
For best results, take your film to a Certified
Advanced Photo System photofinisher displaying
this symbol (p. 68).
USING THE BUILT-IN FLASH
When you turn the camera on, the built-in flash
is set to Autoflash or Autoflash with red-eye
reduction. The flash will fire automatically when
necessary.
38 39
SETTING THE FLASH MODE FLASH RANGE
The range of the built-in flash depends on the film speed and the focal
length you are using. To ensure proper exposure, make sure your subject
is positioned within the flash range.
Press the flash-mode button until the
desired indicator appears in the data panel.
• Flash modes remain selected after the picture is
taken.
Autoflash mode , Autoflash with red-eye reduction , Fill-flash ,
Flash cancel , Night Portrait , or Landscape/Night View
can be selected.
ISO 100
0.5 - 3.3 m
1.6 - 10.8 ft.
0.5 - 1.7 m
1.6 - 5.6 ft.
ISO 200
0.5 - 4.7 m
1.6 - 15.4 ft.
0.5 - 2.4 m
1.6 - 7.9 ft.
ISO 400
0.5 - 6.6 m
1.6 - 21.6 ft.
0.5 - 3.4 m
1.6 - 11.1 ft.
Wide
24 mm
Tele
70 mm
Film speed
Focal length
40 41
RED-EYE REDUCTION FILL FLASH
Press the flash-mode button until
appears in the data panel.
• When you turn the camera off, the flash mode
will be reset to Autoflash or Autoflash with redeye reduction, whichever mode was used last.
The flash will fire when the shutter is released regardless of lighting. Use
fill flash to illuminate a backlit subject or to reduce harsh shadows on your
subject’s face.
Press the flash-mode button until
appears in the data panel.
• The flash mode will remain selected after you
turn the camera off.
Use the built-in flash’s red-eye reduction mode
to reduce the red-eye effect when photographing
people or animals at night or in low light
situations. The red-eye reduction lamp on the
front of the camera will blink to reduce the redeye effect.
42 43
FLASH CANCEL NIGHT PORTRAIT
Press the flash-mode button until
appears in the data panel.
• The shutter speed may be slow. Use of a tripod
is recommended.
• When you turn the camera off, the flash mode
will be reset to Autoflash or Autoflash with redeye reduction, whichever mode was used last.
In this mode, the camera balances the flash and existing light exposure so
you can take beautiful pictures of people at sunset or at night. The flash is
set to fill flash with red-eye reduction.
Press the flash-mode button until
appears in the data panel.
• Shutter speeds may be slow in this mode. Use
of a tripod is recommended.
• When you turn the camera off, the flash mode
will be reset to Autoflash or Autoflash with redeye reduction, whichever mode was used last.
The flash will not fire in this mode. Use flash cancel when you want to
photograph subjects that are beyond the flash range or to capture the
ambiance of existing light.
44 45
LANDSCAPE / NIGHT VIEW
Press the flash-mode button until
appears in the data panel.
• The shutter speed may be slow. Use of a tripod
is recommended.
• When you turn the camera off, the flash mode
will be reset to Autoflash or Autoflash with redeye reduction, whichever mode was used last.
The flash will not fire in this mode and the focus is set to infinity. It can be
used to photograph night scenes, ensure sharp focus for landscapes and
other distant subjects, and should be used when photographing through
glass.
ADDITIONAL FEATURES
The sequence is as follows:
46 47
DATE IMPRINTING
Your camera records date and time information on the film’s magnetic strip
that certified photofinishers can imprint in the front and back of your
photographs (Date/Time Imprinting).
• Some labs can not imprint date and/or time information on the front of
your photographs. See your photofinisher for a full description of
available services.
Before taking the picture:
Press the date button until the data panel
displays the format you want to see on the
print.
• When is displayed in the data panel, no data will be printed on the
front of the print, but the date and time of exposure will be imprinted on the
back of the print.
• If the date/time display is blinking, date/time information will not be
imprinted. The date/time information needs to be reset (p. 48).
Date Time No display
48 49
DATE IMPRINTING - Setting the date and time
1. Press the main switch to turn the camera
off.
This camera has a quartz clock and automatic
calendar through the year 2029.
6. Press the select button until all items
stop blinking to set the updated
information.
• The data panel shows the date display for five
seconds, then all the indicators will disappear.
4. Press the adjust button to change the
blinking item.
• Press and hold the adjust button to change the
value rapidly.
2. Press the date button.
• The date display will appear in the data panel.
3. Press the select button until the item you
want to adjust blinks.
• Each press of the select button causes the next
item to blink. The seuqence is:
Year - Month - Day - Hour - Minute
5. Repeat steps 2 and 3 until all items in
the date and time display are correct.
50 51
DATE IMPRINTING - Changing the format
4. Press the adjust button to change the
display format.
• The format sequences as follows:
5. Press the select button to set the
updated information.
• The data panel shows the date display for five
seconds, then all the indicators will disappear.
• The format will remain after replacing the battery.
1. Press the main switch to turn the camera
off.
The order of year/month/day can be changed.
2. Press the date button.
• The date display will appear in the data panel.
3. Press and hold the select button for
three seconds.
• All the items start blinking.
Y/M/D M/D/Y D/M/Y
52 53
TITLE IMPRINTING TITLE IMPRINTING - Preselecting titles
Three title codes have been set into memory. You can change one or all
three title codes at any time.
1. Press the main switch to turn the camera off.
2. Select the code for the title you want from the title list.
Three titles from the title list can be preset for use while taking pictures.
Any one of the three preselected titles can be selected before the picture
is taken (User Select Title Imprinting). When selected, the title will be
recorded on the film’s magnetic data strip. At certified Advanced Photo
System labs, the selected title will be printed on the back of the print.
See your photofinisher for details. Some labs may not be able to print the
titles in all of the available languages.
Titles are displayed in the data panel as a title code.
Please refer to the Title List sheet for the titles
available with this camera.
When appears in the data panel, the title will be
recorded on the print.
Continued on following page.
3. Press the title button to display the title
code you want to change.
54 55
TITLE IMPRINTING - Preselecting titles
Continued on following page.
4. Press the select button, the last digit of
the title code number will blink.
5. Press the adjust button to change its
value.
• Press and hold the adjust button to change the
value rapidly.
6. Press the select button to make the next
digit blink, change its value using the
adjust button.
5756
TITLE IMPRINTING - Preselecting titles
7. Press the select button to make the
language code blink.
8. Press the adjust button to change the
language code.
9. Press the select button until all items
stop blinking to set the updated
information.
• The data panel shows the updated title for eight
minutes, then all the indicators will disappear.
• If you press the title button instead of select
button, next title can be changed.
1. Turn the camera on and press the title
button to display the code for the title
you want.
• Each press of the title button changes the title
code to the next selection.
58 59
TITLE IMPRINTING - Imprinting titles
• Pressing any other button replaces the title code with
date/time display.
2. Take the picture. The magnetic data is
written and the selection is cancelled
for the next frame.
Date/time
Select the title for each frame before taking the picture.
60 61
SELF-TIMER
1. Place the camera on a tripod, then press
the self-timer button until appears in
the data panel.
The self-timer delays release of the shutter for approximately 10 seconds
after you press the shutter-release button.
3. Press the shutter-release button all-theway down.
• will blink in the data panel during countdown.
• The self-timer lamp will blink slowly. Just before
the shutter is released, the self-timer lamp will
blink rapidly, then glow.
• To cancel the self-timer, press the self-timer
button or turn the camera off.
• The self-timer is automatically cancelled after the
shutter releases.
• Do not press the shutter-release button while
standing in front of the camera.
2. Center your subject in the focus frame.
• Use Focus Hold for off-center subjects (p. 28).
62 63
REMOTE CONTROL (Sold Separately)
3. Point the remote control with its emitter
window toward the front of the camera
and press • or 2s button.
• Release (•): the remote-control lamp will blink
once, and the picture is taken immediately.
Delay (2s): the remote-control lamp will blink for
two seconds before the picture is taken.
• Remote control mode will remain selected after
the picture is taken.
• To save power, the data panel will shut off and
the lens will retract if the remote control is not
operated for more than eight minutes.
The IR Remote Control RC-3 (not included)
allows remote camera operation from up to 5m
(16 ft.) away.
• The distance may be shorter or the remote
control may not operate with backlit subjects,
under fluorescent light, or in extremely bright
lighting conditions.
1. Place the camera on a tripod, then press
the remote-control button until
appears in the data panel.
2. Compose your picture.
Emitter window
Delay button
Release button
Continued on following page.
64 65
REMOTE CONTROL (Sold Separately)
3. Lift your finger from the shutterrelease button, then recompose the
picture.
4. Point the remote toward the front of the camera and press • or
2s.
• The green ready lamp keeps glowing and the focus will remain locked after
taking a picture.
• Reset the remote-control mode or press the zoom button to cancel focus
hold.
2. Center your subject in the focus
frame, then press the shutter-release
button partway down so the green
ready lamp glows.
• Focus is locked.
• Focus will be reset if you press the shutterrelease button partway down again.
1. Set the camera to remote control mode.
FOCUS HOLD IN REMOTE CONTROL MODE
Continued on following page.
APPENDIX
66 67
REMOTE CONTROL (Sold Separately)
1. Pull out the battery chamber and remove
the old battery.
The remote control uses a 3V lithium battery (CR2032). When pressing
the remote-control buttons does not release the shutter, the battery must
be replaced. Anew battery should be sufficient for approximately ten years
of operation.
CHANGING THE BATTERY
2. Insert a new battery into the battery
chamber with its plus side up.
3. Slide the battery chamber back into the
remote control.
68 69
LAB SERVICES
To receive the best possible prints, take your film to a
photolab displaying the Certified Advanced Photo System
logo. Photofinishers displaying this logo have been
certified according to Advanced Photo System guidelines.
Certified photolabs will be able to provide the following five services.
1. CHP - Print Format
Your film will be printed according to the format set when the picture was
taken.
2. Date and Title Imprinting
The date, time, and selected title are printed on the back of the picture in
the chosen format.
3. PQI - Print Quality Improvement
The lab will compensate (or not compensate) printing according to the data
recorded on the magnetic data strips.
4. Film is returned in the cassette.
To keep the film dust free and aid in organization, film is returned in its
original film cassette. The VEI will be set to to prevent accidental loading.
5. Index Print
An index print showing a numbered image of each frame is included with
your returned order.
Reprints
Images are always captured in the H format (High-Vision). You can select
any of the three formats when ordering reprints.
70 71
CARING FOR YOUR CAMERA
OPERATING TEMPERATURE AND CONDITIONS
• This camera is designed for use from –10 to 40 °C (14 to 104 °F).
• Never leave your camera where it may be
subjected to extreme temperatures such as in
the glove compartment of a car.
• At colder temperatures, the data panel
response time will be slow. At higher
temperatures, the display will temporarily
darken, but will restore when the temperature
normalizes.
• Never subject the camera to extreme humidity.
• To prevent condensation from forming, place the camera in a sealed
plastic bag when bringing it from the cold environment into a warm
environment. Allow it to come to room temperature before removing it
from the bag.
• When photographing in cold weather, it is recommend that you keep the
camera and spare batteries inside your coat to keep them warm when
you are not shooting. Cold batteries will regain some of their charge
when they warm up.
• This camera is not water proof, dust-proof, or sand-proof; take care
when using it at the beach or near water. Costly or irreparable damage
may occur.
Continued on following page.
72 73
CARING FOR YOUR CAMERA
Continued on following page.
CLEANING
• Keep the AF and Meter windows clean or the
focus and/or exposure may not be accurate.
• If the camera body is dirty, gently wipe it clean
with a soft, clean, dry cloth.
• To clean the lens surface, first brush away any
dust or sand then, if necessary, moisten a lens
tissue with lens cleaning fluid and gently wipe the
lens in a circular motion, starting from the center.
• Never place lens fluid directly on the lens.
• Never touch the lens surface with your fingers.
• Never use alcohol or solvents to clean the
camera.
STORAGE
When storing the camera for extended periods, please follow these
guidelines:
• Store the camera in a cool, dry, well-ventilated area away from dust and
chemicals. For very long periods, place the camera in an airtight
container with a silica gel drying agent.
• Before using after prolonged storage, always check the camera’s
operation to make sure it is functioning properly.
74 75
CARING FOR YOUR CAMERA
QUESTIONS AND SERVICE
• If you have questions about your camera, contact your local camera
dealer or write to the Minolta distributor in your area.
• If the camera is damaged or the rewind motor does not operate, do not
open the film chamber or forcefully remove the cassette. Contact an
authorized Minolta Service Facility.
• Before shipping your camera for repair, please contact an authorized
Minolta Service Facility for details.
BEFORE IMOPRTANT EVENTS
• Check camera operation carefully or take test photographs.
• Minolta is not responsible for any loss which may occur due to an
equipment malfunction.
FILM CASSETTE WARNING
The film used in Advanced Photo System cameras stores some data
magnetically. Do not place the cassette on or near anything that creates a
magnetic field, such as a television or stereo speakers.
CAMERA ERROR
If all the indicators in the data panel blink or the data panel is blank and
the camera will not function with a fresh battery, remove and reinsert the
battery. If normal operation does not resume or the camera malfunctions
repeatedly, contact an authorized Minolta Service Facility.
76 77
TECHNICAL DETAILS
Battery: One CR-2 3V lithium battery
Battery performance: Approx. 12 rolls (Based on Minolta's
standard test method using 25 exposure rolls with the flash for
50% of the exposures)
Dimensions: 99 x 59.5 x 29.5 mm (3.9 x 2.3 x 1.2 in.)
Weight: 145 g (5.1 oz.) without battery
Specifications are based on the latest information available at the time of printing
and are subject to change without notice.
Camera Type: IX240 Lens Shutter Camera
Lens: 24 - 70mm f/5.7 - 11.2 lens
(approx. equivalent to 30 - 88mm in 35mm format)
Metering: Center-weighted metering
Range (ISO 200): 24mm: EV 4 - 16, 70mm: EV 4 - 18
Shutter Speed: 7.8 - 1/380 sec.
Film Speed: Setting: Automatic for DX-coded film
Non-DX coded film set to ISO 100
Range: ISO 25 - 3200
Viewfinder: Magnification: 0.32X - 0.87X
Diopter: -1 diopter
Field of View (H format): 85% (for subject at 3m)
Flash: Recycling time: approx. 5.0 sec.
78 79
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. Changes or modifications not approved by the
party responsible for compliance could void the user's authority to operate the
equipment. This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
This mark on the bottom of your camera is there to inform you that
this camera meets the requirements of the EU (European Union)
concerning interference causing equipment regulations. CE stands
for Conformité Européenne (European Conformity).
©2000 Minolta Co., Ltd. under the Berne Convention and
Universal Copyright Convention
9222-2223-31 MM-A003
Minolta Co., Ltd. 3-13, 2-Chome, Azuchi-Machi, Chuo-Ku, Osaka 541-8556, Japan
Minolta Europe GmbH Kurt-Fischer-Strasse 50, D-22923 Ahrensburg, Germany
Minolta France S.A. 365 Route de Saint-Germain, F-78420 Carrieres-Sur-Seine, France
Minolta (UK) Limited 7 Tanners Drive, Blakelands, Milton Keynes, MK14 5BU, England
Minolta Austria Ges. m.b.H. Amalienstrasse 59-61, A-1131 Wien, Austria
Minolta Camera Benelux B.V. Zonnebaan 39, P.O. Box 6000, NL-3600 HA Maarssen, The Netherlands
Belgium Branch Prins Boudewijnlaan 1, B-2550 Kontich, Belgium
Minolta (Schweiz) AG Riedstrasse 6, CH-8953 Dietikon, Switzerland
Minolta Svenska AB Albygatan 114, S-171 54 Solna, Sweden
Finland Branch Niittykatu 6 PL37, SF-02201 Espoo, Finland
Minolta Portugal Limitada Av. do Brasil 33-A, P-1700 Lisboa, Portugal
Minolta Corporation
Head Office 101 Williams Drive, Ramsey, New Jersey 07446, U.S.A.
Los Angeles Branch 11150 Hope Street Cypress, CA90630, U.S.A.
Minolta Canada Inc.
Head Office 369 Britannia Road East, Mississauga, Ontario L4Z 2H5, Canada
Vancouver Branch 230-3771 Jacombs Road, Richmond, B.C. V6V 2L9, Canada
Minolta Hong Kong Limited Room 208, 2/F, Eastern Center, 1065 King’s Road, Quarry Bay, Hong Kong
Minolta Singapore (Pte) Ltd. 10, Teban Gardens Crescent, Singapore 608923
Shanghai Minolta Optical
Products Co., Ltd. 368 Minolta Road, Songjiang, Shanghai, China
Printed in Malaysia
Loading...
