Print Server Card

For Novell NetWare¨, AppleTalk, and TCP/IP Networks

Owner's Manual

Ethernet and Token Ring Models

Preface-1

Important

No title to or ownership of the software described in this document or any of its parts, including patents, copyrights and trade secrets, is transferred to customers. It is against the law to decipher, de-compile, or develop source code for the software described in this document, or knowingly allow others to do so.

There are no representations or warranties regarding the contents of this document. Information in this document is subject to change without notice and does not represent a commitment. This manual is protected by United States Copyright Law, and may not be copied, reproduced, transmitted or distributed, in whole or part, without the express prior written permission.

Trademarks

• AppleTalk is a trademark of Apple Computer, Inc.

• Ethernet is a registered trademark of Xerox Corporation.

• HP LaserJet III, HPLaserJet IIISi, HP LaserJet 4Si, are registered trademarks of Hewlett Packard Corporation. HP UNIX is a trademark of Hewlett Packard Corporation.

• DPO Card is a registered trademark of Osicom Technologies, Inc., DPI Print Server Division.

• Microsoft is a registered Trademark of Microsoft Corporation. Windows and Windows NT are trademarks of Microsoft Corporation.

• Novell, NetWare, and UNIX are registered trademarks of Novell, Inc.

• Token Ring is a registered trademark of International Business Machines Corporation. PC is a trademark of International Business Machines Corporation.

• PostScript is a registered trademark of Adobe Systems, Inc.

• SCO UNIX is a trademark of The Santa Cruz Operation, Inc.

• SUN and Solaris are trademarks of SUN Microsystems, Inc.

• ULTRIX is a trademark of Digital Equipment Corporation.

Part Number

8833158 Rev. C/March 1999

Preface-2

Warning

United States:

device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the owner's manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense.

Canada:

apparatus set out in the Radio Interference Regulations of the Canadian Department of Communication.

Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques (de la class A) prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

This equipment has been tested and found to comply with the limits for a Class A digital

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

Preface-3

Preface-4

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Introduction-1

1.1 What's in Your Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Introduction-2

1.2 Hardware/NOS Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Introduction-3

2 Installing the Print Server Card . . . . . . Hardware Installation-1

2.1 Preparing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hardware Installation-1

2.2 Token Ring Jumper Selection . . . . . . . . . . . . . . . . . . . . . . . . . Hardware Installation-2

2.3 Connect the Network to Print Server Card: Ethernet . . . . . . . . Hardware Installation-3

2.4 Connect the Network to Print Server Card: Token Ring . . . . . Hardware Installation-4

2.5 Powering Up the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hardware Installation-5

3 Using the Management Access Program or a Standard Web Browser . . Management Access Program or Web Browser-1

3.1 Where to Place the MAP Utility . . .Management Access Program or Web Browser-1

3.2 How to Install MAP in Windows . . .Management Access Program or Web Browser-2

3.3 Using the MAP Program . . . . . . . . .Management Access Program or Web Browser-2

3.4 Web IP Browser . . . . . . . . . . . . . . . .Management Access Program or Web Browser-2

4 NetWare Configuration . . . . . . . . . . . . NetWare Configuration-1

4.1 Configuring NetWare 2.15 and 3.x . . . . . . . . . . . . . . . . . . NetWare Configuration-1

4.1.1 Start PCONSOLE and Select File Server . . . . . . . . . . . . . NetWare Configuration-2

4.1.2 Create Print Queues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-2

4.1.3 Enter the Print Server Name . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-3

4.1.4 Configure the Print Server . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-3

4.1.5 Assign Print Queues to the Printer . . . . . . . . . . . . . . . . . . NetWare Configuration-4

4.1.6 Set Up Notify Options for the Printer (Optional) . . . . . . . NetWare Configuration-5

4.1.7 Installing the Print Server on Multiple File Servers . . . . . NetWare Configuration-5

4.1.8 Primary File Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-6

4.1.9 Preferred File Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-6

4.2 Configuring NetWare 4.0x Bindery Emulation . . . . . . . . . . NetWare Configuration-7

4.2.1 Confirm Bindery Context . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-7

4.2.2 Configure in Bindery Mode with PCONSOLE . . . . . . . . NetWare Configuration-8

4.3 Configuring the Print Server Card in NetWare Directory Services

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-10

4.3.1 Create Printer Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-11

4.3.2 Create Print Server Object . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-12

4.3.3 Create Print Queue Object . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-12

4.3.4 Assign Printer Object . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-14

TOC-1

4.3.5 Assign Print Server Object . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-16

4.3.6 Check Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-17

4.3.7 Set Up and Reset the Printer . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-18

4.4 Print Server Card Configuration . . . . . . . . . . . . . . . . . . . . NetWare Configuration-18

4.5 Using the Novell PCONSOLE Utility . . . . . . . . . . . . . . . . NetWare Configuration-20

4.5.1 Changing the File Server . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-20

4.5.2 Changing Print Queues . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-20

4.5.3 How to Set Up Notify . . . . . . . . . . . . . . . . . . . . . . . . . . . NetWare Configuration-21

5 Windows Peer-to-Peer Printing

. . . . . . . . . . . . . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-1

5.1 Windows IPX Peer-to-Peer Printing . . . . . . . . . . . . Windows Peer-to-Peer Printing-1

5.1.1 Introduction and Preparation . . . . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-1

5.1.2 Installation and Operation . . . . . . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-2

5.2 Windows IP Peer-to-Peer Printing . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-3

5.2.1 Introduction and Preparation . . . . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-3

5.2.2 Installation and Operation . . . . . . . . . . . . . . . . . . . Windows Peer-to-Peer Printing-4

6 AppleTalk Configuration . . . . . . . . . .AppleTalk Configuration-1

6.1 Choosing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-1

6.2 Loading the AppleTalk NIManage Utility Program . . . . . AppleTalk Configuration-3

6.3 Configuring the Print Server Card . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-4

6.3.1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-4

6.3.2 Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-5

6.3.3 Protocol Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-5

6.3.4 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AppleTalk Configuration-6

7 TCP/IP Configuration . . . . . . . . . . . . . . . TCP/IP Configuration-1

7.1 Installation in a Windows Environment . . . . . . . . . . . . . . . . .TCP/IP Configuration-1

7.1.1 Windows for Workgroups . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-1

7.1.1.1 Installing TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-2

7.1.1.2 Loading the lpr Spooler . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-2

7.1.1.3 Setting up the Print Server Card . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-2

7.1.1.4 Assigning IP Address with ARP . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-2

7.1.1.5 Assigning IP Address with BOOTPL16 . . . . . . . . . . . . . .TCP/IP Configuration-3

7.1.1.6 Setting up IP and lpr Parameters . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-4

7.1.1.7 Creating an lpr Queue on the Workstation . . . . . . . . . . . .TCP/IP Configuration-4

7.1.2 Microsoft Windows 95/98 . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-5

7.1.2.1 Loading the lpr Spooler . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-5

TOC-2

7.1.2.2 Setting up the Print Server Card . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-5

7.1.2.3 Assigning IP Address with ARP . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-6

7.1.2.4 Assigning IP Address with BOOTPL32 . . . . . . . . . . . . . .TCP/IP Configuration-6

7.1.2.5 Setting up IP and lpr Parameters . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-7

7.1.2.6 Setting up lpr on the Workstation . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-8

7.1.3 Windows NT Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-8

7.1.3.1 Setting Up the Print Server Card . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-9

7.1.3.2 Assigning IP Address with ARP . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-9

7.1.3.3 Assigning IP Address with BOOTPL32 . . . . . . . . . . . .TCP/IP Configuration-10

7.1.3.4 Setting up IP and lpr Parameters . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-10

7.1.3.5 Setting up lpr on the Workstation . . . . . . . . . . . . . . . . . .TCP/IP Configuration-11

7.2 Dynamic Host Configuration Protocol . . . . . . . . . . . . . . . . .TCP/IP Configuration-12

7.3 IP Discovery and Peer to Peer Printing . . . . . . . . . . . . . . . . .TCP/IP Configuration-13

7.3.1 How to Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-13

7.3.2 Configure IP Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-13

7.3.3 IP Unit Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-13

7.3.4 IP Peer-to-Peer Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-14

7.3.5 Add Printers for IP Peer To Peer Printing . . . . . . . . . . . . .TCP/IP Configuration-15

Step 1: Use IP-P2P to Add Printers . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-15

Step 2 Use the Add Printers option in Windows (Unset Settings/Printers).

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-15

7.4 FTP Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-16

7.4.1 FTP Printing Using Netscape . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-16

7.4.2 Drag and Drop Method using Netscape . . . . . . . . . . . . . . .TCP/IP Configuration-16

7.4.3 FTP Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-16

7.5 UNIX Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-17

7.5.1 Configuring the IP Address on the Print Server Card . . . .TCP/IP Configuration-18

7.5.1.1 Using BOOTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-19

7.5.1.2 Using rarp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-21

7.5.1.3 Using ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-22

7.5.2 lpd/lpr Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-23

7.5.2.1 Setting Up a BSD Remote Printer to Use lpd/lpr . . . . . .TCP/IP Configuration-23

7.5.2.2 Setting Up an AIX Version 2.5 Remote Printer to Use lpd/lpr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCP/IP Configuration-24

7.5.2.3 Setting Up an AIX 4.0 System. . . . . . . . . . . . . . . . . . . . TCP/IP Configuration-25

7.5.2.4 Setting Up an HP/UX Remote Printer to Use lpd . . . . .TCP/IP Configuration-26

7.5.2.5 Setting Up an AS/400 Systems to Use lpd/lpr . . . . . . . .TCP/IP Configuration-26

7.5.2.6 Setting Up a DEC ULTRIX 4.3 RISC or OSF1/ALPHA Remote Printer

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TCP/IP Configuration-27

TOC-3

7.5.2.7 Setting Up a SCO UNIX Remote Printer to Use lpd/lpr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-28

7.5.2.8 Setting Up System V Release 4 and Solaris 2.X to Use lpd/lpr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-29

7.5.3 Installing TCP/IP for Print Server Card If Not Running lpd/lpr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-30

7.5.3.1 Loading the Software . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-30

7.5.3.2 Script Selection of Filters . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-31

7.5.3.3 Manual Selection of Filters . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-31

7.5.3.4 Installing and Printing on Ver. 1 Solaris and OSF1 Systems

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-32

7.5.3.5 Installing & Printing on an DEC ULTRIX 4.3 System .TCP/IP Configuration-33

7.5.3.6 Installing and Printing on the HP/UX System . . . . . . . .TCP/IP Configuration-34

7.5.3.7 Installing and Printing on a System V (Solaris Ver. 2)/System V Rel. 4

386-based Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-35

7.5.3.8 Installing & Printing on a SCO UNIX System . . . . . . .TCP/IP Configuration-37

7.5.3.9 Installing and Printing on an AIX RISC System/6000 .TCP/IP Configuration-39

7.6 Running Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-41

7.6.1 Making Connection and Main Menu . . . . . . . . . . . . . . . . .TCP/IP Configuration-41

7.6.2 Configure IP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-42

7.6.3 Select Printer Languages . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-43

7.6.4 Enable/Disable Network Protocols . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-44

7.6.5 Restore Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-44

7.6.6 Change Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-45

7.6.7 Exit Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TCP/IP Configuration-45

8 Operation and Troubleshooting . . . . . . . . . . Troubleshooting-1

8.1 LED Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-1

8.2 Status Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-3

8.3 Resetting the Print Server to Factory Default . . . . . . . . . . . . . . . . . Troubleshooting-5

8.4 How to Diagnose Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-6

8.5 Troubleshooting Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-7

8.5.1 Troubleshooting Network Hardware Connections . . . . . . . . . . . . Troubleshooting-7

8.5.2 Troubleshooting NetWare Protocol . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-7

8.5.2.1 NetWare Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-7

8.5.2.2 File Server Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-8

8.5.2.3 Workstation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Troubleshooting-8

8.5.2.4 Print Server Card Configuration Checklist . . . . . . . . . . . . . . . . Troubleshooting-8

8.5.2.5 Printer Server/File Server/Printer Checklist . . . . . . . . . . . . . . Troubleshooting-9

TOC-4

8.5.2.6 Workstation to Print Server Card Connection Checklist . . . . . Troubleshooting-9

8.5.2.7 Print Server Card Loses Its File Server Connection . . . . . . . . . Troubleshooting-9

8.5.2.8 Unable to Print from a Different Context . . . . . . . . . . . . . . . Troubleshooting-10

8.5.3 Troubleshooting AppleTalk Protocol . . . . . . . . . . . . . . . . . . . . Troubleshooting-10

Appendix A Jumper Settings . . . . . . . . . . . . . . . Jumper Setting-1

Ethernet Print Server Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Jumper Setting-2

Token Ring Print Server Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Jumper Setting-3

A.2 Reset to Factory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Jumper Setting-3

A.3 BUS Handshake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Jumper Setting-3

A.4 Ethernet-Specific Jumpers (10BaseT/10Base2 only) . . . . . . . . . . . . Jumper Setting-4

A.5 Token Ring-Specific Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Jumper Setting-4

Appendix B Specifications . . . . . . . . . . . . . . . . . . Specifications-1

B.1Print Server Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications-1

B.210/100BaseT and Token Ring UTP Cables . . . . . . . . . . . . . . . . . . . . . Specifications-2

B.3Token Ring STP Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications-3

Appendix C NIC MIB Definition . . . . . . . . . . . NIC MIB Definition-1

TOC-5

TOC-6

Introduction

The Print Server Card is a Network Interface Controller that you install into compatible printers to provide Ethernet or Token Ring network connectivity. The Print Server Card has the following features:

• Automatic selection of 10Base2 (Thinnet), or, automatic selection of 100BaseT Fast Ethernet connection or 10BaseT Ethernet connection (for Ethernet cards with both type of connections).

• Token Ring interface connection - Unshielded Twisted Pair (UTP) and Shielded Twisted Pair (STP) (for Token Ring cards).

• Fully transparent AppleTalk printing support for the Macintosh, including support for binary PostScript printing.

• Peer-to-Peer (serverless) discovery and printing from Windows 95/98 or Windows NT (4.0 or higher) workstations, without a Novell ﬁle server present and without using IP.

• Novell NetWare PSERVER on both bindery based and Novell Directory Services (NDS).

• lpr/lpd over TCP/IP for UNIX platforms and Microsoft's Windows.

• Raw sockets support over selectable TCP/IP port with ﬁlters for selected UNIX environments.

• IP and IPX SNMP support of MIB-2 and DPI proprietary NIC MIB.

• SNMP support of standard MIB and proprietary printer MIBs on compatible printers.

• Integral HTTP Server to allow monitoring and management of your Print Server Card from a standard IP Web Browser program.

• Management Access Program (MAP) to allow Windows-based HTML viewing for monitoring and management of your Print Server Card.

• FTP printing to allow users to print directly from their IP browser or other FTP client.

• FTP download allow users in the TCP/IP environment the ability of ﬂash upgrading their Print Server Card.

• Flash memory to allow ﬁeld upgrades, with capability for either Novell IPX/SPX or TCP/IP (FTP) download of executable code.

Introduction-1

1.1 What's in Your Package

The Print Server contains the following:

• Print Server Card

• Quick Install Guide booklet for the Network Interface Card

• 1 CD-ROM that contains the following

• This Manual

• Quick Install Guide for the Network Interface Card

• Management Access Program (MAP)

• IPX Peer-to-Peer Windows Redirector

• IP Peer-to-Peer Windows Redirector

• AppleTalk NIManage Utility

• UNIX TCP/IP Utility

• BootP Lite Utility

The SNMP directory diskette also contains the ASN.1 coded SNMP MIB for the Network Interface Card (NIC). This MIB can be loaded into a standard SNMP console to provide SNMP access to all NIC parameters. The MIB is included in this manual as

Appendix C, NIC MIB Deﬁnition

Note

Introduction-2

The BootP directory contains the programs BOOTPL32 (for Windows 95/98) and BOOTPL16 (for W indo ws 3.x). These programs assist the administrator in entering IP parameters in a Windows environment.

Each directory may contain a README ﬁle containing the latest information about the installation and operation. Check for these ﬁles before going any further with installation.

Instructions and software to perform ﬂash downloads are provided with an y update or upgrade package and are not included in this manual.

: Each print server has a unique serial number preﬁxed by three letters. The screen

examples in this manual show serial numbers with the preﬁx “OTS”, such as “OTS_991354”. The serial number preﬁx for your printer server may be different (for example: “NPS” or “PSI”).

1.2 Hardware/NOS Requirements

The Print Server Card hardware and software require the following:

Version of Protocol or NOS

Software Novell NetWare printing requires NetWare Capture, NPRINT and

Novell NetWare Version 2.15, 3.x, or 4.x. Macintosh System 7. UNIX, Windows, or LAN Server systems supporting lpr over

TCP/IP. DEC ULTRIX 4.3 or 4.4, DEC OSF/1 2.0 or 3.0, Solaris 1.1.3 or

2.3, (SUN OS 4.1.3 or 5.3), System V Release 4, HP-UX 9.01, IBM AIX 3.2.5, or SCO UNIX 2 for DPI TCP/IP port 10001.

PCONSOLE (later than 1.0) utilities. The IP Peer-to-Peer utility requires Windows NT 4.0 or later; Win-

dows 95/98. The IPX Peer-to-Peer utility requires Windows NT 4.0 or later;

Windows 95/98. The MAP utility requires Windows NT 4.0 or later; Windows 95/

98. MAP also requires a browser such as Microsoft Internet Explorer or Netscape.

AppleT alk printing requires printer PPD appropriate to the printer . AppleTalk MAP Utility is provided for setup and maintenance.

TCP/IP setup and maintenance may be done with Telnet. Monitoring and maintenance with HTTP requires a suitable internet Web Browser program supporting HTML.

Hardware Support for 10 megabit Ethernet networks: either 10Base2 (also

known as ThinWire or Thinnet) or 10BaseT (twisted pair) cables and hardware.

Support for 100 megabit Ethernet networks: 100BaseT (twisted pair) cables and hardware.

CD-ROM dri ve on the workstation to accept W indows, Macintosh, or UNIX utilities.

Introduction-3

Introduction-4

2.1 Preparing the Printer

If the printer can generate a test or status page, you should generate one before you begin. This will give you detailed information on the identiﬁcation and conﬁguration of your printer, as well as ensuring that the printer is properly set up and operating.

If you are installing an Ethernet Print Server Card, continue to step 1. If you're installing a Token Ring board, you must ﬁrst set the speed to the same setting as the Token Ring adapter cards on your network. Refer to

tion,

for details.

Warning: If you are installing a Token Ring card, you must set the network speed now.

Changes made after start-up or after you power up the Print Server Card will not be implemented and may cause problems. If you do not set the speed to match the speed of other Token Ring adapter cards on the network, all trafﬁc on the network will come to a halt.

1. Make sure that the printer is operating properly. Check to see that paper is in the paper tray and toner cartridge is full. If the printer handles multiple printer languages, make sure it is set up for automatic emulation sensing or PCL or ASCII mode.

2. Turn off the printer and remove the power cord.

3. Install the Print Server Card in the option port, according to the printer manufacturer instructions.

Installing the Print Server Card

Section 2.2 Token Ring Jumper Selec-

Note:

Handling Precautions for Static Sensitive Devices:

designed to protect sensitive components from damage due to electrostatic discharge (ESD) during normal operation. When performing installation procedures, however, take proper static control precautions to prevent damage to equipment.

The Print Server Card is

Hardware Installation-1

2.2 Token Ring Jumper Selection

This section is for Token Ring installations only. Go to Section 2.3 if you are installing the Ethernet Print Server card.

The Token Ring speed is selected by the position of jumper 12 (JP12) on the Print Server Card. The factory

16Mbps

thing. If you need to change the speed to 4Mbps, you must reposition the jumper across pins 1-2. Follow the instructions below:

1. Make sure you remove the power cord from the printer.

2. Locate Jumper JP12 on the Print Server Card.

3. Once you locate Jumper JP12, move the jumper to between pins 1-2. This changes

4. Install the Print Server Card in the option port, according to the printer manufac-

. If this is the speed that your network uses, then you do not need to do any-

the speed setting to 4Mbps.

turer instructions.

default position

for the jumper is across pins 2-3, selecting

Note:

Handling Precautions for Static Sensitive Devices:

The Print Server Card is

Hardware Installation-2

2.3 Connect the Network to Print Server Card: Ethernet

You can connect your

Using the 10BaseT or 100BaseT Ethernet interface

uses a 4-wire RJ cable to plug into the RJ45 network connector on the Print Server Card.

Note: The Print Server Card automatically determines which type of network connec-

tion you are making; 100BaseT, 10BaseT or 10Base2. However, some older 10BaseT hubs may not support auto-detection of 10BaseT versus 10Base2. If this occurs, you may be required to change a jumper from automatic to manual selection. See

Using a Thinnet Ethernet interface

connector for 10Base2 or Thinnet connection. The Thinnet Ethernet wire uses a BNC T-connector to plug into the BNC port on the Print Server Card (marked

Thinnet

RG-58/U) that uses the cylindrical BNC T-connector to attach to the BNC port.

Appendix A

on the bracket). This Ethernet cable is 1/4-inch coaxial cable (usually

Ethernet

for details.

network in one of two ways:

. This network connection

. Your Print Server Card may include a BNC

Once you make the connection, continue to

2.5 Powering Up the Printer,

Hardware Installation-3

2.4 Connect the Network to Print Server Card: Token Ring

You can connect your

Using the Token Ring Unshielded Twisted Pair/Type 3 (UTP) interface

UTP network connection uses a 4-wire twisted pair RJ cable to plug into the RJ45 network connector (marked continue to conﬁgure the Print Server Card and the network for the appropriate protocols.

Warning: It is recommended that you DO NOT use the medial ﬁlters when making your

connection with the UTP cable. When you are wired for UTP, use a straightthrough twisted pair standard UTP cable connecting it directly to the UTP plug on the Print Server Card.

Token Ring

UTP

network in one of two ways:

on the bracket). Once you make the connection,

. The

Once you make the connection, continue to

2.5 Powering Up the Printer,

Hardware Installation-4

2.5 Powering Up the Printer

1. Plug in the power cord.

2. Turn on the po wer and wait for the printer to w arm up. The printer may print out a status or start-up page (if this option is not disabled). The Print Server Card then provides a print job to the printer which contains the Print Server Card status information. Refer to

3. Check the Print Server Card status report. Record the serial number and the Network address or save the status report. You need this information when you conﬁgure the printer for your network.

Go to one or more of the appropriate chapters for instructions on conﬁguring the network for the Print Server Card.

8.2 Status Report,

for more information.

Hardware Installation-5

Hardware Installation-6

Using the Management Access Program or a

Standard Web Browser

MAP has the following requirements:

• The Microsoft TCP/IP protocol stack must be installed on this PC. It is not necessary for the network to support TCP/IP. However, the TCP/IP protocol must be installed on this PC even if the network does not support it.

• A web bro wser must be installed on this PC. Both Netscape Na vigator and Internet Explorer are supported.

• If the IPX search functions are to be used, then IPX must be installed on this PC. Both the Microsoft and the NetWare 32-bit stacks are supported.

The Management Access Program (MAP) uses a Windows-based HTML viewer program linked with a proprietary bi-directional IPX/IP channel program to allow access to the Print Server Card's HTML-based monitoring and maintenance capabilities. An IP Web Browser also provides access to this capability directly . Either program allows you to:

• Conﬁgure your network protocols for the Print Server Card.

• Reset the Print Server Card remotely to either clear an error condition, or return the print server to its factory default settings.

• Troubleshoot problems in the Print Server Card.

• Enable or disable the status sheet printout.

• Access a context-sensitive help menu that fully explains how to use each Management Access Program feature.

Note: To be able to change parameter values with the Management Access Program or

the Web Browser, you must know the Print Server Card management password. The factory default password is "

sysadm

3.1 Where to Place the MAP Utility

The utility can be installed on any workstation hard drive or network drive.

Using MAP or Web Browser-1

3.2 How to Install MAP in Windows

The Management Access Program must be installed from Windows95/98 or NT 4.0, it

CANNOT

lowing procedures to install:

1. Start Windows on your PC or workstation.

2. Insert the supplied CD ROM into the CD ROM drive.

be installed from DOS, Windows 3.1x or Windows NT 3.51. Use the fol-

3. Select

4. At RUN, type

5. Read the information on the MAP setup program screen.

6. Identify a path for the program. The path default is

When the installation is complete, remove the CD ROM from the CD drive.

RUN

from the

<CD_Drive>:\MAP\SETUP.EXE

Click

Cancel

Click

can change the path or use the default. The installation begins.

to quit setup and then close any programs you have running.

to continue with the setup program.

Start

3.3 Using the MAP Program

When you click on the MAP icon in the Windows Start menu to start the program, the program will prompt you with a list of IPX print servers listed by their SAP identiﬁcation and IP print servers by their IP address. Select the print server you want to access. The program will setup a link to the print server and obtain HTML code describing the home page.

3.4 Web IP Browser

Once you have assigned an IP address to your Print Server Card, you may use an IP browser, such as Netscape, to access the HTTP Server and the HTML code allowing Print Server Card monitoring and maintenance. To access the HTTP Server screens from your browser, do the following:

menu.

and click on the OK button.

C:\ProgramFiles\MAP

. You

1. Open up your browser by clicking on its icon.

2. For the URL, type in the IP address of the Print Server Card. The HTTP Server screens should appear. If you ha v e problems, check to mak e sure you are using the correct IP address.

Using MAP or Web Browser-2

NetWare Conﬁguration

Use this chapter if you will be printing from a Novell NetWare NOS. This chapter is divided into the following sections:

•

Conﬁguring NetWare 2.15 and 3.1x

Card for use with Versions 2.15 or 3.1x. Use PCONSOLE to set up the print server function.

•

Conﬁguring NetW are 4.0x in Bindery Emulation

Print Server Card for use with Version 4.x Bindery Services. Use PCONSOLE to set up the print server function.

•

Conﬁguring NetWare Directory Services

Server Card for use with Version 4.x Directory Services. Use NWADMIN to set up the print server function.

•

Print Server Card Setup Parameters

or an IP Browser used to conﬁgure the Print Server for NetWare.

•

Using NetWare Utilities

make changes to the conﬁguration of the Print Server function.

explains how to use standard Novell NetWare utilities to

describes how to conﬁgure the Print Server

describes how to conﬁgure the

describes how to conﬁgure the Print

describes the parameters accessible via MAP

4.1 Conﬁguring NetWare 2.15 and 3.x

Before conﬁguring NetWare, you must determine if the Print Server Card has its desired name. You may use MAP or an IP Browser.

The following steps are the general procedure for conﬁguring the Print Server Card. You must have supervisor privileges to do this conﬁguration. These steps are covered in detail in the following paragraphs:

1. Start PCONSOLE and select the ﬁle server you want to use.

2. Create the print queues.

3. Specify the <

4. Conﬁgure the print server and printer.

5. Assign the print queues.

6. Set up the NOTIFY options.

7. Repeat the procedure for other ﬁle servers.

print server

> card as a print server.

NetWare Conﬁguration-1

When you are ﬁnished, turn the printer off and on again. The printer creates a status report that indicates the ﬁle servers to which the unit is attached and the queues which it services.

Before you begin:

• Verify that you have supervisor privileges on the ﬁle servers on which the Print Server Card print server is to be entered.

• Verify that your version of PCONSOLE is later than 1.0.

4.1.1 Start PCONSOLE and Select File Server

Follow these steps to start PCONSOLE:

1. Log in to the network, type

2. Choose Change Current File Serv er from the Available Options menu. A list of

ﬁle servers is displayed.

3. Select the ﬁle server on which you want to install the print server and press the

return key. If the name of the ﬁle server you want is not displayed, press the h key to get a list of ﬁle servers.

4. Log in to the ﬁle server.

5. Press the UP key to return to the Available Options menu.

4.1.2 Create Print Queues

The print server must be assigned to at least one print queue on the ﬁle server.

• If the print queue that you want the <print server> card to service already exists, and you know the name of this queue, go to 4.1.3 Enter the Print Server Name.

• If you do not know the name of the queue, or it does not exist, use the following procedure:

1. Choose Print Queue Information from the Available Options menu, and press

the return key. A list of existing queues is displayed.

2. To create a new queue, press INSERT. Enter the name of the queue and press the

return key. You do not need to enter any more information at this time.

PCONSOLE

and press the return key.

3. Press the ESC key to return to the Available Options menu.

NetWare Conﬁguration-2

4.1.3 Enter the Print Server Name

A print server takes the print jobs from queues and sends them to the printer. Use this procedure to specify the name of the print server:

1. Choose Print Server Information from the Available Options menu, and press

the return key. A list of existing print servers is displayed.

2. Press the INSERT key. The New Print Server Name box is displayed.

Type the name of the print server into the entry box. The Novell print server name is printed under Novell NetWare information on the status sheet.

Note: If desired, this name can be changed using MAP or Web Browser utilities. The

screen example shows how to enter the print server name for a print server with a serial number of OTS_991354.

3. Press the RETURN key to add the print server name to the Print Servers list.

4.1.4 Conﬁgure the Print Server

Use the following procedures to conﬁgure the Print Server's function:

1. Choose the print server name from the Print Servers list and press the return key. The Print Server Information menu appears.

2. Choose Print Server Conﬁguration from the menu and press the return key.

3. Choose Printer Conﬁguration from the menu and press the return key. The Con- ﬁgured Printers menu appears. Since this is a new Print Server entry, all printers are labeled "Not Installed".

NetWare Conﬁguration-3

4. Choose the printer and press the return key. The Printer 0 Conﬁguration screen appears with a title of Printer 0.

5. If you choose to, change default in the Name ﬁeld on this form to something that helps you identify the printer, for example, LASER_PRINTER. The print server uses this name in its message back to the users on the Notify list. Select Name, enter a name, and then press the return key.

6. Select Type and press the return key. A list of printer types is displayed. Choose Remote Other/Unknown and press the return key. This creates default entries in the other ﬁelds. These defaults are usually optimal, so do not change them without speciﬁc knowledge of the effects.

7. Press the ESC key. At the prompt, choose to save your changes.

8. Press the ESC key to return to the Print Server Conﬁguration menu.

4.1.5 Assign Print Queues to the Printer

When you assign queues to the deﬁned printer, you authorize the print server to service these queues.

Note: Do not assign the same queue to two different print servers. If a queue is assigned

to multiple print servers, print jobs may not go to the intended printer.

1. Choose Queues Serviced By Printer from the Print Server Conﬁguration menu.

2. Select the printer name from the list of deﬁned printers.

3. Press the RETURN key to display the Available Queues list for the printer.

4. Select the queue you want and then assign a priority level from 1 to 10. It is recommended that you accept the default priority level. Press the RETURN k ey. The queue appears on the list for the printer. Press the RETURN key again to assign additional queues.

5. When you ﬁnish assigning queues, press the ESC key and then save your changes. Continue to press the ESC key to return to the Print Server Conﬁguration menu. If you want to set Notify options, go to Section. 4.1.6. If you are ﬁnished, continue to press the ESC key and then save your changes.

NetWare Conﬁguration-4

4.1.6 Set Up Notify Options for the Printer (Optional)

To enable the print server to notify users or user groups if a problem occurs with the printer, set up the Notify options. The print server supports the enhanced NOTIFY options for printers, including informing users when the printer:

• Is off-line, jammed, opened, or out of paper

• Requires a manual paper feed or a form change

• Has had an engine failure

1. Choose Notify List for Printer on the Print Server Conﬁguration menu.

2. Select the printer from the Deﬁned Printers list. The screen appears (which is blank for an initial installation). Press the RETURN key to view a list of Notify Candidates.

3. Select the user or group from the list.

4. Set the First and Next intervals in the Notify Intervals screen. It is recommended that you use the defaults. The First interval is the number of seconds the network waits before it notiﬁes candidates about a print job problem. The Next interval speciﬁes how often in seconds candidates are notiﬁed. Enter a number for each interval and press the RETURN key.

5. Press the ESC key and then choose Save Changes. Press the ESC key at each screen until you reach the Print Server Conﬁguration menu. If you have ﬁnished the conﬁguration, press the ESC key and then save the changes.

4.1.7 Installing the Print Server on Multiple File Servers

To install the print server on more than one ﬁle server, perform the procedures described in Sections 4.1.1 through 4.1.6 for each ﬁle server. You must use the same name and password for the print server (or no password) on all ﬁle servers. You set the password for the Print Server Card using the MAP program (refer to 4.3 Conﬁguring the Print Server Card in NetWare Directory Services). If you use a password, specify it on each ﬁle server using the Change Password option on the Print Server Information menu of the PCONSOLE utility.

When the Print Server Card comes up, it automatically searches for and attaches to the ﬁle servers that are no more than four hops and have no more than eight ticks propagation delay. For extremely large or complex networks, this allows a bounded search time on start-up. If the print server must attach to ﬁle servers beyond this range, or, if you wish to accelerate start-up by eliminating the need to search all ﬁle servers in the four hops/eight ticks radius, the ﬁle servers with which the print server is to operate may be entered into the Print Server Conﬁguration of a primary ﬁle server. The pri-

NetWare Conﬁguration-5

mary ﬁle server can be any ﬁle server within the four hops/eight ticks propagation time limits, but ideally is as close as possible to the print server. Once the print server locates the primary ﬁle server and the list of ﬁle servers to be serviced, the automatic search is dropped and the print server will go directly to those ﬁle servers listed (and to no others).

4.1.8 Primary File Server

To use the primary ﬁle server option, use the following procedure on a ﬁle server close to the printer:

1. List the ﬁle servers to be serviced by the primary ﬁle server by selecting File Server To Be Serviced option from the Print Server Conﬁguration Menu.

2. Press the INSERT key to display the Available File Servers list.

3. Select the name of each ﬁle server to be serviced and press the return key to add it to the File Servers To Be Serviced list.

4. When the list is complete, press the ESC key to return to the menu.

5. Install the Print Server Card on each of the primary ﬁle servers.

4.1.9 Preferred File Servers

The MAP or Web Browser utilities allow you to identify a preferred ﬁle server, to be identiﬁed within the Print Server Card itself. If a preferred ﬁle server is listed, the Print Server Card will attach to this identiﬁed ﬁle server instead of initiating the automatic search. If the preferred ﬁle server is also a primary ﬁle server (for example, has ﬁle servers listed under ﬁle servers to be serviced), the Print Server Card will connect directly to these ﬁle servers.

Note: The Preferred File Server is only applicable to bindery-based queues. Entering it

has no affect on NDS queues.

NetWare Conﬁguration-6

4.2 Conﬁguring NetWare 4.0x Bindery Emulation

Novell's NetWare 4.0x can operate in two modes NetWare Directory Services (NDS) and Bindery Services Emulation. For NDS, see 4.3 Conﬁguring the Print Server Card in NetWare Dir ectory Services. These services run simultaneously and transparently to each other. The Print Server Card may be conﬁgured to operate with Bindery Services mode only (this section), or to operate under NDS (4.3 Conﬁguring the Print Server Card in NetWare Directory Services). When conﬁgured under NDS, the print Server Card will also service older ﬁle servers operating in bindery mode.

Note: If the Print Server Card is not properly set up for NDS and the Bindery Services

mode is not running, the Print Server Card can not ﬁnd its ﬁle servers, and the status page indicates the Novell NetWare protocol is not active.

4.2.1 Conﬁrm Bindery Context

Before installing the Print Server Card on a Novell NetWare 4.x server in Bindery Emulation mode, check that the server has a Bindery Context (name for the server under Bindery Services mode). If the server does not have Bindery Context, it may be preferable to install in NDS mode. If the Print Server Card must be installed in the Bindery Emulation mode, the server must have Bindery Context. Perform the following steps to conﬁrm the server has Bindery Context:

1. Go to the 4.x server and at the system console type: load install

2. Select Maintenance/Selective Install from the menu.

3. Select NCF Files Options from the menu.

4. Select Edit AUT OEXEC.NCF from the menu.

5. Search the ﬁle to see if you have a statement similar to the following included:

SET BINDERY CONTEXT=0U=ENG

Where =0U=ENG is an example of a name for the ﬁle server context. Use your own ﬁle server context in place of =0U=ENG.

6. At the console prompt, type the SET BINDERY CONTEXT statement that you entered in the AUTOEXEC.NCF ﬁle.

NetWare Conﬁguration-7

Note: The command at the console prompt takes effect immediately. The deﬁnition in

the ﬁle takes effect when the server is shut down and then restarted.

4.2.2 Conﬁgure in Bindery Mode with PCONSOLE

Once you conﬁrm the server has Bindery Context, use the following procedures to conﬁgure the Print Server Card.

1. Log into the network as ADMIN.

2. Type PCONSOLE and press the return key. The following screen appears.

Available Options

Print Queues Printers Print Drivers Quick Setup Change Context

3. When the Available Options menu appears, press the o key (for the Bindery Mode).

Note: If you receive a message asking you to login to a server with Bindery connections,

the server you are attached to does not have Bindery Mode enabled. Follow the procedures in 4.2.1 Conﬁrm Bindery Context or log onto a server with Bindery Services activated.

4. From the Available Options screen, select Quick Setup and press the return key. Use Quick Setup to connect your print server, print queue and printer correctly. You can modify these later if you need to.

5. Select Print server and press the n key to modify the entry.

6. Enter the name of the print server in the Print server ﬁeld and press the return key.

NetWare Conﬁguration-8

Note: The print server name is printed under the Novell Network Information on the

Status and Conﬁguration report. The factory default name consists of three letter identiﬁer, an Underscore, and the serial number of the unit.

7. Press the ESC key to move to the New printer ﬁeld. Enter a name and press the return key.

8. Press the ESC key to move to the New print queue ﬁeld. Enter a name and press the return key.

9. Press the ESC key to move to the Printer type ﬁeld and press the return key. From the list of printer types, select Other/Unknown and press the return key.

10. When you are ﬁnished, press the u key to save the conﬁguration. Repeat steps 5 through 10 for each ﬁle server that the printer server services.

11. To view, add, delete, or modify print servers or queues after the initial setup, select either the Print Queues or Print Servers option on the Available Options screen.

NetWare Conﬁguration-9

4.3 Conﬁguring the Print Server Card in NetWare Directory Services

NetWare Directory Services (NDS) offers a different, more advanced approach to network management than previous NetWare versions. Generally, it stores and tracks all network objects. As a rule, all 4.x servers must have NDS loaded in order to function. In this way, every NetWare 4.x server is a Directory server, because it services named Directory objects such as printers, print servers and print queues. With the appropriate privileges, you can create a print server object, which, once conﬁgured in its context (or location) on the network, eliminates the cumbersome setup of print servers on every network server. NDS provides true enterprise networking based on a shared net- work database rather than a individually deﬁned physical sites. The result is greatly improved print server setup and management.

The Directory Information Base (DIB) is used to store information about servers and services, users, printers, gateways, etc. It is a distributed database, allowing access to data anywhere on the network wherever it is stored. Pre-4.x NetWare versions provide the same data found in the DIB but the data is stored in the NetWare Bindery. The DIB was designed with more ﬂexible access, more speciﬁc security, and, since it is distributed, it was designed to be partitioned. The Directory uses an object-oriented structure rather than the ﬂat-ﬁle structure of the Bindery, and offers network-oriented access, rather than server-oriented access found in the Bindery.

The Directory is backward-compatible with the NetWare Bindery through Bindery emulation mode. Section 4.3 describes Print Server Operation with a 4.x NetWare system in bindery emulation mode. When Bindery emulation is enabled, Directory Services will accept Bindery requests and respond just as if a Bindery existed on the NetWare server being accessed. Be aware that information obtained from the Bindery query may not be stored in the server since the Directory is a partitioned and distributed database. Even though the NetWare 4.x server is not operating from a Bindery, the applications making Bindery requests will not know the difference.

You may use NW ADMIN to conﬁgure the printer in NDS. Prior to printing, NDS must be set up as follows and the Print Server Card must be set up with NDS Context and Tree. See Section 4.4. The steps below describe the use of NWADMIN conﬁguration to create printer, print server, and print queue objects. Then, you will assign, or associate, those objects with each other. If you wish to keep Bindery resources on any server, you can under NetWare 4.x if you declare a SET statement in your AUTOEXEC.NCF ﬁle.

NetWare Conﬁguration-10

For those who prefer, NetWare does offer PCONSOLE as an alternative to NWADMIN. PCONSOLE can be used to set up static information about print servers such as: which queues to service, and whom to notify in the event of a problem. See Novell NetWare documentation for more information about the use of PCONSOLE for NDS.

4.3.1 Create Printer Object

1. Click on the NWADMIN icon in the NetWare Tools group in Windows. The NetWare Administrator window will appear. To bring up your Directory Tree, open a Browser window by clicking on the T

2. Highlight the Organizational Unit or Organization where you want to create the print service in the Directory Tree, select the Object item from the main menu and choose Create.

Note: If you wish, you can create objects another way in NWADMIN by: selecting an

Organizational Unit, clicking on the right mouse button (which produces a pop-up menu), and clicking on Create... (use the left mouse button to bring up the New

Object window). From this point, the procedure continues as described.

ools menu item then the Browse item.

3. When the New Object window appears, scroll down the C icon list, select the Printer icon and click on the OK button.

lass of New Object

NetWare Conﬁguration-11

4. When the Create Printer window appears, type a v alue in the Printer Name ﬁeld and click on the C

reate button.

4.3.2 Create Print Server Object

1. Again, highlight the Organizational Unit, select the Object item from the menu and choose C

reate.

2. At the New Object window, scroll down the C the Print Server icon, and click on the OK button.

3. At the Create Print Server windo w, type a value in the Print Server N and click on the C

reate button.

4.3.3 Create Print Queue Object

1. Once again, highlight the Organizational Unit, select the Object item from the menu and choose C

2. At the New Object window, scroll down the C the Print Queue icon, and click on the OK button.

NetWare Conﬁguration-12

reate.

lass of New Object icon list, select

ame ﬁeld

lass of New Object icon list, select

3. At the Create Print Queue screen, click on the Directory Service Queue button, then type in values for Print Queue N the C

reate button. If you don't know the Print Queue Volume name (the hard

ame and Print Queue Volume and click on

drive you will be accessing), click on the icon to the right of the volume ﬁeld. The Select Object window will appear with the volume listed in O ume is not listed, scroll the D

irectory Context items until you ﬁnd the volume

bjects. If the vol-

where you want the queue to reside.

4. Click on the object (hard drive) of your choice and it will appear in the Selected

Object: ﬁeld. Click on the OK button. The full volume will now appear in the Print Queue V

olume ﬁeld. Finally, click on the Create button.

NetWare Conﬁguration-13

4.3.4 Assign Printer Object

1. Go to the Directory Tree. Double click on the printer object just created and bring up the Printer window. See below. Find the Assignments button on the right-side of the window and click on the A

2. When the Select Object window appears, ﬁnd the print queue object just created among the choices listed in the O

dd button.

bjects box and select it.

NetWare Conﬁguration-14

Click on the OK button and the print queue just created is added to the Print Queues: box in the Printer: window. Click on the OK button again.

NetWare Conﬁguration-15

4.3.5 Assign Print Server Object

1. At the Directory Tree, double click on the print server object you just created and bring up the Print Server window.

2. At the Print Server: window, click on the Assignments button and A bring up the Select Object window. Select the printer object just created from the

bjects: box and click on the OK button. Now the printer (with its context)

appears in the Printers: box of the Print Server window. Click on the OK button.

NetWare Conﬁguration-16

dd button to

4.3.6 Check Assignments

At the Directory Tree, double click on the Print Queue object you just created. At the Print Queue window, click on the Assignments button.

If you conﬁgured the print queue and printer correctly they will appear in the proper boxes on the Print Queue window. Press the Cancel button.

NetWare Conﬁguration-17

4.3.7 Set Up and Reset the Printer

NWADMIN conﬁguration is complete. Before you can begin printing, though, be sure to set up and reset (power cycle) the printer.

4.4 Print Server Card Conﬁguration

The MAP utility or an IP Web Browser must used to deﬁne the context and tree of the Print Server. It is also used to change the Print Server name, set a password, modify scan and frame search parameters, and sent in bindery-mode speciﬁc values.

Use the MAP utility or IP Web Browser (refer to Chapter 3) to access the Setup pages of the Print Server Card. Once you have accessed the Network Administration pages or the Main Menu, do the following:

1. Select Setup NetWare under Protocols.

2. Select Enable NetWare. If it is not selected, the NetWare protocols will not come up, the Print Server card will not appear as an advertised device, and the NIC will not be accessible using IPX SNMP.

3. The default name for the NetWare Print Server is XXX_123456, where XXX is a three character sequence identifying the manufacturer, and 123456 is the serial number of the Print Server Card. This is also the default name of the printer in peer-to-peer mode. If you want to change the default Print Server name, type this name in the Print Server Name space. Leave the space blank if the default name is to be used.

4. If you want the Print Server Card login with a password, this password may be entered in the Print Server Password ﬁeld, and again in the Password Retype ﬁeld. If a password is used, this password must be the same password for all bindery-based and NDS-based Print Server entries.

5. Enter the name of a preferred bindery-based ﬁle server in the Preferred File Server ﬁeld. The Preferred File Server entry is signiﬁcant only for bindery or bindery emulation based operations. Refer to 4.1.9 Preferred File Servers for the signiﬁcance of a Preferred File Server . The Print Server must be conﬁgured on the preferred ﬁle server. Incorrect setup of a Preferred File Server can interfere with NetWare printing.

NetWare Conﬁguration-18

6. If the Print Server is to be operated under Novell Directory Services, type in a

Context entry and P

referred NDS Tree entry in the appropriate ﬁelds. Be sure to

give the whole context, whether typed or typeless, and do not begin your context path with a trailing period (.). If you don't know your tree, type: whoami at the DOS command line. A typed context name example is:

ou=standard.ou=organization_1

7. In the default mode, the Print Server scans each queue which it is to service once per second. If you prefer a longer scan rate, you may enter the time between scans in seconds in the Print Queue Scan Rate ﬁeld.

8. The Print Server Card will normally monitor the network to determine which frame type is being used for Novell. When it recognizes a type, it will assume the same frame type. Once it selects a frame type, the Print Server Card will only operate over that Novell frame type. Monitoring normally starts looking for IEEE

802.3, then Ethernet II, then 802.3 SNAP, etc. If your network is using multiple frame types for Novell, you should bias the frame search to the desired type by setting the button next to the designation under Ethernet Frame Type.

9. You can Disable Bindery mode on the Print Server if are operating in NDS mode only . To do so, click on that box. If you disable Bindery, the Print Serv er Card will not support Print Servers on a Bindery ﬁle server.

10. Once you have selected all desired settings and entered the desired NetW are infor mation, you may cause this information to be entered in the Print Server Card NV RAM by clicking on Accept Settings. As with all value changes, if you have not entered the Print Server Card Management Password before, you must enter it in the appropriate space before clicking on Accept Settings.

11. Entered values do not take effect until the Print Server Card is reset or power cycled. You may reset from MAP or the Web Browser by returning to the Home or Network Administration page, and click on Reset under System. Now click on Reset Unit. Alternatively, you may power cycle the printer. The new NetWare values should now be in effect.

NetWare Conﬁguration-19

4.5 Using the Novell PCONSOLE Utility

This section explains how to use the PCONSOLE utility to perform the following tasks:

• Attach and select a ﬁle server

• Select or delete queues for the print server

• Set-up the Notify function See the NetWare Print Server Manual for detailed information on this utility.

Note: You must have Supervisor privileges to perform many PCONSOLE operations.

4.5.1 Changing the File Server

You can specify a ﬁle server as the current one. To change the ﬁle server, use the following procedures:

1. Log into the current ﬁle server and start the PCONSOLE utility.

2. Select Change Current File Server from the Available Options menu.

3. Press the Insert key to display the available ﬁle servers.

4. Select the ﬁle server you want as the current one and press the return key.

5. Enter your username and press the return key. If the username requires a pass-

word, the Password screen is displayed. Enter the password and press the return key.

6. Select Change Current File Server from the Available Options menu. A list of

the attached ﬁle servers is displayed.

7. Select the current ﬁle server from the File Server/Username screen.

4.5.2 Changing Print Queues

When you print a ﬁle, your system sends the ﬁle to a print queue. The print server assigned to that queue extracts the print job and sends it to the assigned printer. If a print server is servicing queues on multiple ﬁle servers, you must assign queues to the printer on each ﬁle server. To change the print queues, use the following procedures:

1. Start the PCONSOLE utility.

2. Select Print Server Information from the Available Options menu.

3. Select the print server from the list.

4. Select Print Server Conﬁguration from the menu.

NetWare Conﬁguration-20

5. Select Queues Serviced by Printer from the menu.

6. Select a printer from the Deﬁned Printers list.

7. Press h at the File Server/Queue/Priority screen. The Available Queues list

appears.

8. Select a queue from the list.

9. Press the return key at the Priority screen to leave the priority setting at 1.

The highest priority queue is 1; 10 is the lowest. To change the priority of a queue, press the return key at the File Server/Queue/Priority screen to display the Pri- ority setting screen. Press the back-arrow key to delete the current setting. Type a new number from 1 to 10 and press the return key. Repeat steps 7, 8, and 9 to assign additional queues to the printer.

10. Press the ESC key and save all changes.

4.5.3 How to Set Up Notify

You can specify users or groups of users that are notiﬁed if a problem occurs when a print job is sent to the printer. If the print server is servicing queues on multiple ﬁle servers, you must set up a NOTIFY list for each ﬁle server. To set up NOTIFY, use the following procedures:

1. Start the PCONSOLE utility.

2. Select Print Server Information from the Available Options menu.

3. Select the print server from the menu.

4. Select Print Server Conﬁguration from the menu.

5. Select Notify List for Printer from the menu.

6. Select the printer from the Deﬁned Printers menu.

7. Press the ESC key at the File Server/Notify Name/Notify Type/First/Next

screen. The Notify Candidates screen appears.

8. Select the user or user group from the Notify Candidates screen. The Notify

Intervals screen displays.

NetWare Conﬁguration-21

9. Set the First and Next intervals for notifying users about printer problems. The

First interval is the number of seconds the network waits before it notiﬁes users

about a print job problem. The Next interval speciﬁes how often in seconds users are notiﬁed. Enter a number for each interval and press the return key.

10. Press the ESC key and save all changes.

11. Press the ESC key until you see the prompt to exit PCONSOLE. Select Yes and

then press the return key.

NetWare Conﬁguration-22

Windows Peer-to-Peer Printing

5.1 Windows IPX Peer-to-Peer Printing

Windo ws Peer-to-Peer printing allo ws Windows 95/98 workstations and Windo ws NT

4.0 workstations and servers to print to Print Server Card printers without an intervening server and without using IP. The main features of the Windows IPX Peer-to-Peer printing are as follows:

• Runs on Windows-95/98 workstations and on Windows NT 4.0 workstations or

servers "out of the box".

• Runs on networks which do not have a NetWare ﬁle server, as well as those that do.

• Implements IPX peer-to-peer bi-directional printing between W indows w orkstations

and Print Server Card printers.

5.1.1 Introduction and Preparation

The Peer-to-Peer implementation uses the IPX/SPX stacks that are provided with Windo ws 95/98 or Windows NT 4.0. The redirector software provided will establish a connection with the printers supporting IPX Peer-to-Peer, without using an intermediate ﬁle server, whether or not your network uses Novell NetWare.

When conﬁguring the network capabilities for the Windows computer, you must include the "IPX/SPX Compatible Protocol". If you are not using NetWare, you do not need to activate any NetWare Client application.

This inclusion of IPX/SPX can also be done after initial Windows installation by going to the Network setup function under Control Panel. To do this, you will need the Windows CD.

Note: Because Peer-to-Peer uses the IPX/SPX Protocol, Novell operation must remain

enabled on the Print Server Card, even if traditional Novell printing facilities are not being used. The name of the Peer-to-Peer printer , as it appears in the Windows Port List, is the same as the Novell Print Server name, and may be changed by changing the Novell Print Server name using the Web-based management or MAP utilities.

Windows Peer-to-Peer Printing-1

On power up, the Print Server Card snif fs the network to see if there is No vell acti vity. If there is, it will use the same frame type and the local network number that it senses. If, in addition, the NIC can log on to a ﬁle server, it will assume that Novell is normally used and will store this frame type and new number in NV RAM so that, when it comes up again, it will not have to spend the time sensing (which can take some time). However, if the NIC cannot attach to a ﬁle server, it will use the sensed values, but will not store them.

If the NIC does not see any Novell activity, it will use 802.2 on 802.3 as a frame type and will assign itself a network number of 0. The frame type and network number being used is reported on the status and conﬁguration sheet.

If a NIC is being moved from a site that had active Novell to a site that does not, the unit should be reset to factory default to clear the frame type and network number information.

5.1.2 Installation and Operation

Install the Windows IPX Peer-to-Peer redirector as follows:

1. Put the CD ROM which came with your NIC into the CD ROM drive.

2. From the Windows main window, click on Start.

3. Click on Run.

4. From Run, type <CDROM drive>:\IPX-P2P\SETUP.EXE.

5. Click on OK.

6. At the IPX Peer-to-Peer Setup screen, click on Next.

Note: If setup detected a previous installation of the IPX Peer-to-Peer Redirector, it will

prompt you to have Setup delete the old driver and continue the installation procedure. Click on Yes or No.

Once the redirector is installed, each printer on the network that supports this peer-topeer capability will appear as a Port under Printer Properties.

To use the Peer-to-Peer connection, create a logical printer using the Add Printer Wizard according to the instructions for your printer. Set up the printer as a LOCAL printer. Use the driver that came with your printer.

When the Add Printer Wizard asks you to choose the Port, select the name of the Peer-to-Peer printer you wish to print to. When you complete the installation, select the Print Test Page option.

Windows Peer-to-Peer Printing-2

5.2 Windows IP Peer-to-Peer Printing

For more detailed information on TCP/IP setup and printing, see Chapter 7. Windows IP Peer-to-Peer printing allows Windows 95/98 workstations and Windows

NT 4.0 workstations and servers to print to Print Server Card printers without an intervening server and without using IPX. The main features of the Windows IP Peer-toPeer printing are as follows:

• Runs on Windows 95/98 workstations and on Windows NT 4.0 w orkstations or serv-

ers "out of the box".

• Implements IP peer-to-peer bi-directional printing between Windows workstations

and Print Server Card printers.

5.2.1 Introduction and Preparation

The Peer-to-Peer implementation uses the TCP/IP stacks that are provided with Windows 95/98 or Windows NT 4.0. The redirector software provided will establish a connection with the printers supporting Peer-to-Peer, using a direct IP connection o ver the network.

When conﬁguring the network capabilities for the Windows computer, you must include the "TCP/IP Protocol". You do not need to activate any TCI/IP Client application.

This inclusion of TCP/IP can also be done after initial Windows installation by going to the Network setup function under Control Panel. To do this, you will need the Windows CD.

Note: Because Peer-to-Peer uses the TCP/IP Protocol, TCP/IP operation must remain

enabled on the Print Server Card, and the Print Server Card must be assigned a valid IP address. The name of the Peer-to-Peer printer, as it appears in the Windows Port List, is the same as the IP Address assigned to the Print Server Card. The IP Address may be changed by changing the TCP/IP section using the Webbased management or MAP utilities.

If a NIC is being moved from a site that had active TCP/IP to a site that does not, the unit should be reset to factory default to clear the IP Address and other network information.

Windows Peer-to-Peer Printing-3

5.2.2 Installation and Operation

Install the Windows IP Peer-to-Peer redirector as follows:

1. Put the CD ROM that came with the NIC into your CD drive.

2. From the Windows main window, click on Start.

3. Click on Run.

4. From Run, type <CD ROM drive>:\IP-P2P\SETUP.EXE.

5. Click on OK.

6. At the IP Peer-to-Peer Setup screen, click on Next.

Note: If setup detected a previous installation of the IP Peer-to-Peer Redirector, it will

prompt you to have Setup delete the old driver and continue the installation procedure. Click on Yes or No.

Once the redirector is installed, each printer on the network that supports this peer-topeer capability will appear as a Port under Printer Properties.

When the Add Printer Wizard asks you to choose the Port, select the name of the Peerto-Peer printer you wish to print to. When you complete the installation, select the Print Test Page option.

Windows Peer-to-Peer Printing-4

Use this chapter if you will be printing from a Macintosh. This chapter explains how to conﬁgure the Print Server Card using AppleTalk and how to use the AppleTalk NIManage utility program.

6.1 Choosing the Printer

To choose the printer, use the following procedure:

1. Make sure you have loaded the print driver and ﬁle drivers appropriate to your

printer.

2. Select the AppleTalk link for AppleTalk by clicking on the Apple icon in the Mac-

intosh menu bar.

3. Select Control Panel.

4. Click on Networks.

5. Choose AppleTalk as the AppleTalk connection, as shown in the example.

AppleTalk Conﬁguration

6. Click on the Apple icon.

7. Select Chooser to display the Chooser screen.

AppleTalk Conﬁguration-1

Note: The screen shown above will not show AppleTalk zones if your network does not

have more than one zone.

8. Select the AppleTalk Zone containing the printer from the list at the lower left of

the screen. Select the device driver type corresponding to your printer from those indicated at the upper left of the screen. A list of printers will appear in the display panel at the right of the screen.

9. From the display panel at the right of the screen, choose the name of the printer

from the list of printers. The AppleTalk printer name for your printer is printed out on the Status and Conﬁguration report under AppleTalk Connection Information.

10. The options available at this point depend on your printer driver. With a typical

driver , you may select SETUP. Then select AUTO SETUP. There will be a series of messages as the Chooser communicates with the printer and locates the proper PPD. The setup screen will return, listing the PPD ﬁle selected. Select OK. Then exit from Chooser.

AppleTalk Conﬁguration-2

6.2 Loading the AppleTalk NIManage Utility Program

The AppleTalk NIManage utility program has the following functions:

• View and modify the names of the printer or printer zone.

• Enable or disable the Status/Conﬁguration report.

• View the error log.

• Enable or disable other protocols and view or modify the TCP/IP address, subnet

mask, and default gateway address.

Use the following procedure to get access to AppleTalk NIManage utility program:

1. Copy the ﬁles from the Macintosh AppleTalk NIManage utility program diskette

to a folder.

2. When the AppleTalk NIManage utility program icon displays on the desktop,

double-click on it. The Zone and Device screen is displayed.

3. For each zone, the Device display panel sho ws the av ailable Print Server Cards. If

your network has no zones, the screen shows only the Device display panel. Select the name of your network zone.

Note: If you have one zone, the above screen will not display.

4. From the Device display panel, select the Print Server Card. After you select the

device, a menu of options is added to the menu bar at the top of your screen.

AppleTalk Conﬁguration-3

6.3 Conﬁguring the Print Server Card

You use the options added to the menu bar to conﬁgure the print server. Depending on your printer, certain operations may not be available. These functions will be grayed out and cannot be selected.

6.3.1 Conﬁguration

Use the Conﬁguration function to change the names of the device and AppleTalk Zone. These changes are stored only in the print server and are not passed on to the PostScript interpreter. When you choose this function, the following screen is displayed:

1. To change the print server device name, click on the name displayed and then

enter the new name. Be careful when you do this. Many printers maintain the printer name in the printer controller where it can be changed using a Macintosh utility. If you change the name in the Print Server Card, you may make the network interface and the printer become "out of sync".

2. To change the AppleTalk Zone, click on the zone displayed. A menu displays all

available zones.

3. Select the new zone from the menu.

4. Click on OK when you have ﬁnished viewing this screen or when you are done

making changes.

5. Turn off the printer and then turn it on again to make the changes take effect. The

status sheet should identify the new printer name and the new zone preference.

AppleTalk Conﬁguration-4

6.3.2 Error Log

The Error Log function is used to view a log of events that the Print Server Card has registered. The log contains information as well as errors. Customer Support may need the information on this screen if your Print Server Card encounters problems.

When you choose this function, a screen containing the text of the log is displayed. You can print the error log contents by using the Print option under the File menu. To save the contents of the error log, do one of the following:

• Use the Save As option from the File menu to save the entire log ﬁle.

• Use the Edit option to cut, copy, and paste some or all of the log ﬁle.

Note: This does not enter data into the error log itself. The data is cleared each time the

printer is power cycled.

6.3.3 Protocol Setup

Use the Protocol Setup option to conﬁgure network protocols other than AppleTalk. When you select the Protocol Setup function, the following screen is displayed:

Note: The default values for the IP address and Subnet Mask are shown as zeros. How-

ever, this represents a "no IP address" condition, not an IP address.

1. Click the protocols to On if you want them to be active. Click those protocols that

you do not want to use to Off. The utility will not let you make active any protocol that the Print Server Card does not support or cannot handle because of active protocol limitations.

2. Enter the IP address and subnet mask if you have enabled TCP/IP. Enter the

default gateway address, if you have one.

AppleTalk Conﬁguration-5

3. Click on OK when you have ﬁnished using this screen.

4. You must power the printer off and on to make the changes take effect.

6.3.4 Options

Click on Status Sheets: Enable to send a status report to the printer each time you power it on, or click on Disable to disable this option. Click on OK. The change takes effect the next time you power on the printer.

AppleTalk Conﬁguration-6

TCP/IP Conﬁguration

This chapter explains how to conﬁgure the Print Server Card and your netw ork for use with TCP/IP communication in various environments. Independent setup and installation procedures are provided for Windows systems and for most popular UNIX systems. The Print Server Card TCP/IP capability will also operate with lpr spoolers on other systems, and with spooler/supervisor capabilities that communicate raw print jobs to the Print Server TCP/IP Port. The IP Peer-to-Peer redirector for Windows 95/ 98 and Windows NT systems, provided with the Print Server Card, uses this TCP/IP port. The default port number is 10001, but may be changed to any desired number using the Telnet utility, SNMP, or the HTML pages accessible via MAP or a Web Browser. Section 7.5 Running Telnet, describes the interactive setup capability acces- sible through the Telnet utility on any TCP/IP platform, and is equally applicable to Windo ws, UNIX, and other TCP/IP environments. The use of MAP or a W eb Bro wser to access HTML management pages in the Print Server Card is described in Chapter

7.1 Installation in a Windows Environment

The several versions and variations of Microsoft Windows may be used on a NetWare and/or TCP/IP networks, as well as in a nativ e Microsoft Windo ws netw ork. This ﬂexibility allows various options for setting up the network printing system even though this Print Server Card does not support NetBEUI. If the Windows workstations are connected to a NetW are network, conﬁgure the printer interf aces for NetWare, and use standard W indows/NetW are utilities to pro vide access to the printer. If NetWare is not to be used, the users may access the printer using TCP/IP. Windows 95/98 and Windows NT 4.0 users can also use the Print Server Card Peer-to-Peer capability as described in Chapter 5. The following sections describe installation using TCP/IP under Windo ws for W orkgroups, Windows 95/98, and Windo ws NT.

7.1.1 Windows for Workgroups

Printing with TCP/IP requires that the workstation have TCP/IP capability and the corresponding spooler, lpr; or that the workstation can share an lpr queue on a Windows NT server (for example) that has one. In general, if printers are not shared, an lpr queue must be created on each workstation from which printing is initiated. See the Windows documentation about sharing printers.

Windows for Workgroups does not normally come with TCP/IP. However, various TCP/IP facilities are available for Windows for Workgroups workstations, including a

TCP/IP Conﬁguration-1

free TCP/ IP provided by Microsoft. There are third party lpr spoolers available. The following instructions are based on the Microsoft TCP/IP and a share w are lpr application that is available from various sources, including the Print Server Card manufacturer. You will need the ﬁles WFWTCP32.zip and WFWTCP32.txt for the TCP/IP, and wlprs41.zip and wlprspl.txt for the lpr.

You will need the BOOTPL16 program if you wish to use the BOOTP Lite program to set up IP parameters. The BOO TPL16 program is provided with the Print Serv er Card.

7.1.1.1 Installing TCP/IP

Follow the instructions in the text ﬁle for the TCP/IP stack to set up TCP/IP on the workstations.

7.1.1.2 Loading the

lpr

Spooler

The Windo ws lpr Spooler Version 4.1 - User's Guide (wlprspl.txt), provides detailed instructions for decompressing and installing the shareware lpr spooler.

7.1.1.3 Setting up the Print Server Card

The Print Server Card must be given IP address and routing information to be used with TCP/IP. This can be done with Management Access Program (MAP) if you have a NetWare connection on your network, or with AppleTalk NIManage for Macintosh utility program if there is an Apple Macintosh on the netw ork. F ollow the instructions for these programs which are documented elsewhere in this manual. If you cannot use these programs, you can use either the ARP procedure or the BOOTP Lite program.

Prior to running these programs, install the Print Server Card in your printer. Power-up the printer. Keep the status sheet handy for the Ethernet or Token Ring

(MAC) address. It should sho w that TCP/IP is enabled, b ut that the Protocol address is not conﬁgured. If the unit already has an IP address, these procedures will not work. However, you can Telnet to the unit or use the HTML pages accessed by MAP or a Web Browser to change the IP parameters.

7.1.1.4 Assigning IP Address with ARP

The Print Server Card must be on the same network segment as the workstation that you are using to conﬁgure it. The TCP/IP stack must be installed and operating.

Use the procedures in 7.1.1.5 Assigning IP Address with BOOTP Lite, if you prefer to use BOOTP Lite to conﬁgure the IP address instead of ARP.

1. From Windows, enter the MS/DOS box.

2. At the command prompt enter:

TCP/IP Conﬁguration-2

ping [any valid IP address on your network - not the print server]; the identified unit should reply.

After the response, enter: arp -s [IP address of Print Server Card] [MAC Address

of Print Server Card]; the entry should be accepted. ping [IP address of Print Server Card]; request

should time out.

3. Recycle the power on the printer, or let the Print Server Card reset itself. The

Print Server Card will produce a status page that should include the entered IP address.

4. When the Print Server Card is up again, type the following at the command

prompt:

ping [IP address of Print Server Card] (continue until you get a reply)

Note: This only enters the IP address; you must use the Telnet facility or the HTML

pages accessed by MAP or a Web Browser to complete the IP setup for networks where subnets are used. See 7.5 Running Telnet, for instructions on how to enter the other IP parameters.

7.1.1.5 Assigning IP Address with BOOTPL16

This program uses the BOOTP protocol. The Print Server Card must be on the same network segment as the workstation that you are using to conﬁgure it. The TCP/IP stack must be installed and operating. The BOOTPL16 program will not work in a Windows PC Operating as a DHCP Server.

The BOOTPL16 program will work with a 16 Bit TCP/IP Stack (FTP, NetManage, B&W, or WFWG).

1. Copy the BOOTPL16.exe ﬁle to the Windows directory of your workstation.

2. Reset the printer.

Note: The Print Server Card issues the BOOTP request for a ﬁnite period of time. The

print server must be freshly reset for this program to work.

3. From Program Manager under File, select Run \windows\ BOOTPL16.exe.

4. Pull down the Admin menu to Conﬁgure option.

TCP/IP Conﬁguration-3

5. Enter the IP address that you want to assign to the Print Server Card, its Subnet

Mask (make sure it matches what you are using on your subnet), the Default Gateway (your router's IP address), and the MAC address of the Print Server Card (Hardware Address, listed on the Status sheet as Ethernet Address). Use colons as delimiters as shown on the status sheet rather than the dashes that Windows uses.

6. Click on Go. You will get a message that the program is Verifying, and then it will

tell you whether the unit is active or not.

7. Wait for about ﬁve minutes for the Print Server Card to reset. The Status sheet

should report the newly entered IP information.

8. Enter the MS/DOS box. At the command prompt enter:

ping [IP address of Print Server Card] (continue until you get a reply)

If it does not respond, verify that TCP/IP is enabled on the status sheet. If the status sheet does not show the IP information, then repeat the above procedures.

7.1.1.6 Setting up IP and

lpr

Parameters

The Print Server Card provides for a setup connection via the standard Telnet port. To be able to make changes to a unit with factory default settings, you must logon as "sysadm". The default password is also "sysadm" (This password can be changed from the Telnet utility). Section 7.5 Running T elnet, describes the use of the Telnet util- ity .

1. Telnet to the Print Server Card (the login and password are both "sysadm").

2. Turn off the protocols that you are not utilizing (option 3).

3. Setup the subnet mask and default gateway for the Print Server Card if applicable

(menu option 1). (If you used BOOTP, this will already have been done).

4. Exit, Save and Reset the Print Server Card. You can also use the HTML pages accessible via MAP or a W eb Bro wser to setup lpr.

The password to change parameters with the HTML pages is the same as the Telnet password.

lpr

7.1.1.7 Creating an

Queue on the Workstation

Once you install the spooler onto the workstation, the setup program will create a group and icon.

1. Double click on the spooler icon.

2. Click on setup, and deﬁne a new queue.

TCP/IP Conﬁguration-4

3. At the Remote Host Name prompt enter the Print Server Card IP Address. Enter

PORT1 for the Remote Printer Name.

4. Go to Control Panel, Printers, and choose Connect.

5. Select your driver and click on Next. At this point, you should see an entry for your Windows lpr Spooler's printer in the

"Available ports" listing. For example, C:\SPOOL\PRINTER_NAME.

7.1.2 Microsoft Windows 95/98

Windows 95/98 comes with a TCP/IP stack. To print with this protocol, a client also requires an lpr utility. This program is available from various sources. The lpr queue can be created on each workstation or the lpr queue can be created on one workstation and shared on the network. Windows 95/98 workstations can also share a lpr printer installed on an Windows NT server on the network.

The following instructions are based on the a shareware lpr application that is avail- able from various sources, including the Print Server Card manufacturer. You will need the wlprs41.zip and wlprspl.txt for the lpr.

If you wish to use the Bootp Lite program, you will also need the BOOTPL32.EXE and ﬁle provided with this Print Server Card in the BOOTP directory of the CD ROM.

7.1.2.1 Loading the

The Windo ws lpr Spooler Version 4.1 - User's Guide (wlprspl.txt) provides detailed instructions for decompressing and installing the shareware lpr spooler.

7.1.2.2 Setting up the Print Server Card

The Print Server Card must be given IP address and routing information to be used with TCP/IP. This can be done with MAP if you have a IPX connection on your network, or with AppleTalk NIManage utility program if there is an Apple Macintosh on the network. Follow the instructions for these programs which are documented elsewhere. If you cannot use these programs, you can use either the ARP procedure, or the BOOTPL32 program.

1. Install the Print Server Card in your printer.

2. Power-up the printer. Keep the status sheet handy for the Ethernet (MAC) address. It should show that

TCP/IP is enabled but that the Protocol address is not conﬁgured. If the unit already has an IP address, these procedures will not work. However, you

can Telnet or use the HTML pages accessed by MAP or Web Browser to change the IP parameters.

TCP/IP Conﬁguration-5

lpr

Spooler

7.1.2.3 Assigning IP Address with ARP

The Print Server Card must be on the same network segment as the workstation that you are using to conﬁgure it. The TCP/IP stack must be installed and operating.

You can use BOOTPL32 to conﬁgure the IP address instead of ARP.

1. From Windows, enter the MS/DOS box. At the command prompt enter:

ping [any valid IP address on your network - not the print server]. The identified unit should reply. After the response, enter:

arp -s [IP address of the Print Server Card] [MAC Address of the Print Server Card]. The entry should be accepted.

ping [IP address of the Print Server Card]. Request should time out.

2. Recycle the power on the printer, or let the Print Server Card reset itself. The

Print Server Card will produce a status page that should include the entered IP address.

3. When the Print Server Card is up again, at the command prompt, enter:

ping [IP address of Print Server Card] (continue until you get a reply).

Note: This only enters the IP address. You must use the Telnet facility, (Section 7.5 Run-

ning Telnet,) to enter the other IP parameters.

7.1.2.4 Assigning IP Address with BOOTPL32

You may provide the IP address and other IP parameters to the printer Print Server Card on 32 Bit TCP/IP Stack (Windows NT & Windows 95/98) using the BOOTPL32.exe program. You will have to store the BOOTPL32.exe ﬁle in the Windows directory. The BOOTPL32.exe program will not work if the Windows PC is an active DHCP Server.

TCP/IP Conﬁguration-6

1. Reset the printer.

Note: The Print Server Card issues the BOOTP request for a ﬁnite period of time. The

print server must be freshly reset for this program to work.

2. From Program Manager under File, select Run BOOTPL32.exe.

3. Pull down the Admin menu to Conﬁgure option.

4. Enter the IP address that you want to assign to the Print Server Card, its Subnet

Mask (make sure it matches what you are using on your subnet), Default Gateway (your router's IP address), and the MAC address of the Print Server Card (Hardware Address, listed on the Status sheet as Ethernet Address). Use colons as delimiters as shown on the status sheet rather than the dashes Windows uses.

5. Click on Go.

6. Wait about ﬁve minutes. The Print Server Card should recycle and produce a sta-

tus sheet showing the IP parameters you have just entered.

7. Pull down Admin menu to Verify. You should get a message back stating that the

Unit is Acti v e. If you do not get this message, v erify that TCP/IP is enabled on the status sheet.

8. When you get a response that your unit is active, you should be able to ping and

Telnet to the Print Server Card.

7.1.2.5 Setting up IP and

The Print Server Card provides for a setup connection via the standard Telnet port. To be able to make changes to a unit at factory default settings, you must logon as sysadm. The default password is also "sysadm". (This password can be changed from the T elnet utility.) See 7.5 Running Telnet, for instructions on using Telnet.

1. Telnet to the Print Server Card (the login and password are both "sysadm").

2. Turn off the protocols that you are not utilizing (option 3).

3. Setup the subnet mask and default gateway for the Print Server Card if applicable

(option 1).

4. Exit, Save, and Reset the Print Server Card.

TCP/IP Conﬁguration-7

lpr

Parameters

You can also use the HTML pages accessible via MAP or a W eb Bro wser to set up lpr. The password to change parameters with the HTML pages is the same as the Telnet password.

7.1.2.6 Setting up

lpr

on the Workstation

Once you install the spooler onto the workstation; the setup program will create a group and icon.

1. Double click on the spooler icon.

2. Click on setup, deﬁne new queue.

3. At the Remote Host Name prompt enter the Print Server Card's IP Address, and

for the Remote Printer Name enter PORT1.

4. Go to Settings.

5. Select Printers.

6. Choose Add Printer.

7. Click on Next.

8. Select your driver and click on Next. At this point, you should see an entry for your Windows lpr Spooler's printer in the

"Available Ports" listing. For example, C:\SPOOL\PRINTER_NAME.

7.1.3 Windows NT Instructions

Windows NT (version 3.5 or higher) does come with TCP/IP and lpr capabilities, although these must be installed when the unit is conﬁgured. You must install the TCP/IP Protocol, Simple TCP/IP Services, and Microsoft TCP/IP Printing prior to entering the network printer on the workstation.

Note: Once you have lpr installed on an Windows NT Server workstation and have

allowed printer sharing, other workstations may use the printer through the Microsoft Windo ws Network without having to have separate lpr queues installed on each workstation.

Note: If you wish to use BOO TPL, you will need the BOOTPL32.EXE ﬁle. This ﬁle is

in the BOOTP directory on the CD ROM which comes with the Print Server Card.

TCP/IP Conﬁguration-8

7.1.3.1 Setting Up the Print Server Card

The Print Server Card must be given an IP address and routing information to be used with TCP/IP. This can be done with MAP if you have a NetWare connection on your network, or with AppleTalk NIManage utility program if there is an Apple Macintosh on the network. Follow the instructions for these programs which are documented elsewhere. If you cannot use these programs, you can use either the ARP procedure or the BOOTPL32 program.

1. Install the Print Server Card in your printer.

2. Power-up the printer. Keep the status sheet handy for the Ethernet (MAC) address. It should show that

TCP/IP is enabled but that the Protocol address is not conﬁgured. If the unit already has an IP address, these procedures will not work. However, you

can TELNET to the unit to change the IP parameters.

7.1.3.2 Assigning IP Address with ARP

The Print Server Card must be on the same network segment as the workstation that you are using to conﬁgure it. The TCP/IP stack must be installed and operating.

You can use BOOTPL32 to conﬁgure the IP address instead of ARP.

1. From Windows, enter the MS/DOS box. At the command prompt enter:

2. Recycle the power on the printer or let the Print Server Card reset itself. The Print

Server Card will produce a status page that should include the entered IP address.

3. When the Print Server Card is up again, at the command prompt, enter:

Note: This only enters the IP address; you must use the Telnet facility or the HTML

pages accessed by MAP or Web Browser facility to enter the other IP parameters.

TCP/IP Conﬁguration-9

ping [any valid IP address on your network - not the print server]. The identified unit should reply.

After the response, enter: arp -s [IP address of the Print Server Card] [MAC

Address of the Print Server Card]. The entry should be accepted.

ping [IP address of the Print Server Card]. The request should time out.

ping [IP address of Print Server Card] (continue until you get a reply).

7.1.3.3 Assigning IP Address with BOOTPL32

You may provide the IP address and other IP parameters to the printer Print Server Card on 32 Bit TCP/IP Stack (Windows NT & Windows 95/98) using the BOOTPL32.exe program.

The NT cannot be operating as an active DHCP Server.

1. Reset the Print Server Card.

Note: The Print Server Card issues the BOOTP request for a ﬁnite period of time. The

print server must be freshly reset for this program to work.

2. From Windows Program Manager under File, select Run BOOTPL32.exe.

3. Pull down the Admin menu to Conﬁgure option.

4. Enter the IP address that you want to assign to the Print Server Card, its Subnet

5. Click on Go.

6. Wait about ﬁve minutes. The Print Server Card should recycle and produce a sta-

tus sheet showing the IP parameters you have just entered.

7. Pull down Admin menu to Verify. You should get a message back stating that the

Unit is Active. If you do not get this message, check that TCP/IP is enabled on the status sheet

8. When you get a response that your unit is active, you should be able to ping and

Telnet to the Print Server Card.

7.1.3.4 Setting up IP and

The Print Server Card provides for a setup connection via the standard Telnet port. To be able to make changes to a unit at factory default settings, you must logon as sysadm. The default password is also "sysadm" (this password can be changed from the Telnet utility). The use of the Telnet utility is described elsewhere.

TCP/IP Conﬁguration-10

lpr

Parameters

1. Telnet to the Print Server Card (the login and password are both "sysadm").

2. Turn off the protocols that you are not utilizing (option 3).

3. Setup the subnet mask and default gateway for the Print Server Card if applicable

(option 1).

4. Exit, Save, and Reset the Print Server Card You can also use the HTML pages accessible via MAP or a W eb Bro wser to set up lpr.

The password to change parameters with the HTML pages is the same as the Telnet password.

lpr

7.1.3.5 Setting up

on the Workstation

The following procedure is used to set up the lpr spooler on the Windows NT server.

1. Open Control Panel.

2. Go to Printers.

3. Choose Printer Menu.

4. Choose Create Printer.

5. Enter a printer name (For example, lprprinter).

6. Select the proper printer driver.

7. Enter a description. This is optional.

8. In the Print To dialog, choose Other.

9. In Print Destinations window, select lpr port. This leaves you with add lpr

compatible printer window.

Line 1: Address of host providing enter IP address.

Line 2: Name of printer on that machine - enter PORT1 (the word PORT

10. Choose OK to exit. Your Print Server Card is now conﬁgured to operate W indows NT. You may print from

any application by the following the normal print instructions for that application.

TCP/IP Conﬁguration-11

MUST

be in uppercase).

lpd

(Print server);

7.2 Dynamic Host Conﬁguration Protocol

DHCP is a service much like BootP that provides a method for assignment and maintenance of IP addresses. The Print Server Card is able to obtain IP information from this service.

There are two user settable variables related to the DHCP function. These are accessible in the TCP section of Network Administration, in the HTML pages.

• DHCP enable

• Use IP info in NVRAM a. If DHCP is not enabled, the Print Server Card will make no DHCP requests under

any circumstances. If the Print Server Card does not have an IP address stored, or if "Use IP info in NVRAM" is OFF, the Print Server Card will issue BOOTP requests, etc.

b. If DHCP is enabled, the Print Server Card will make DHCP requests when the Print Server Card is reset or on power up, provided that the Print Serv er Card does not ha ve an IP address stored, or that "Use IP info in NVRAM" is OFF. These DHCP requests will be in addition to BOOTP requests.

c. If DHCP is enabled, and the Print Server Card had an IP address in NVRAM, and "Use IP info in NVRAM" is ON, then the Print Server Card will use the IP information from NVRAM and there will be no DHCP activity on the part of the Print Server Card.

The factory default is with both DHCP enable ON and Use IP info in NVRAM ON. In this case, the Print Server Card will issue DHCP requests if it does not already have IP identiﬁcation information stored in its NVRAM.

If DHCP is enabled and the Print Server Card is in the default mode, you must establish a

permanent lease or reservation for the Print Server Card in the DHCP server. Failure to do this may cause the same address to be given out to another host.

TCP/IP Conﬁguration-12

7.3 IP Discovery and Peer to Peer Printing

This section explains how to setup and use the following two IP functions:

• IP Printer Discovery, which allows you to ﬁnd print servers on your network.

• IP Peer-to-Peer Printing, which allows you to set up your print server ports for peer

to peer printing for IP on Windows NT 4.0 and Windows 95/98.

Note: All features of IP Discovery are now included as part of MAP versions 3.02 and

higher.

7.3.1 How to Install

Place the CD ROM into the CD ROM drive.

• In Windows 95/98 or Windows NT 4.0, go to START and then RUN. Type <CD

ROM drive>:\IP-DISC\SETUP.EXE. Click on OK when done. Follow the program prompts.

7.3.2 Conﬁgure IP Discovery

Once you install the program, you can Conﬁgure IP Unit Discovery with the hop count. The default hop count is 2.

The hop count number determines how many subnetworks the program will search to ﬁnd units. An entry of 0 on the screen searches only the current subnet. An entry of 2 would search the wire directly connected to the workstation, and, all networks accessible through two routers. Entries of 15 or higher will automatically search every connected network (this number is not recommended due to the amount of trafﬁc it will generate).

Once a hop count is entered, click on OK.

7.3.3 IP Unit Discovery

Select IP Unit Discovery to search your network for all compatible print servers available.

The response is provided through the default Web Browser on your workstation. Once a list of units appears, you can select the print server unit you want to conﬁgure or reconﬁgure by clicking on the URL of the unit (which is http:// followed by the IP address).

TCP/IP Conﬁguration-13

Once you click on the URL of the unit you want to conﬁgure, the program automatically enters Microsoft Internet Explorer, Netscape Navigator, or your default browser to access the unit’s HTTP Serv er. Once the HTTP Server home page appears, you can conﬁgure or reconﬁgure your unit.

7.3.4 IP Peer-to-Peer Setup

IP Peer-to-Peer printing allows you to print to a network printer for networks without a ﬁle server or for networks where you do not want to use the server for printing. Use peer-to-peer printing on Windows NT (4.0), and Windows 95/98 systems. Click on the IP-P2P menu item in Windows to bring up the peer-to-peer printing setup screen. An explanation for each ﬁeld on the screen is described below.

• Max Hops for Search. Once you install the program, you can setup IP Peer-To-Peer

with the hop count. The default hop count is 2. The hop count number determines how many networks the program will search to ﬁnd units. An entry of 0 on the screen searches only the network wire directly connected to the workstation. An entry of 2 would search the wire directly connected to the workstation, and, all networks accessible through two routers. Entries of 15 or higher will automatically search every connected network (this number is not recommended due to the network trafﬁc it would generate).

• IP Port Base: The starting port number for the printserver. The default is 10000

(corresponding to a TCP/IP port of 10001) but you can change it if you need to.

• Printer Names: Lets you select how you can view the printer names in the Win-

dows port list.

• Based on Serial Number: Uses the printer server serial number to identify the

printer names. For example, if SN991354 is the serial number of the unit, SN991354 would be the printer port.

• Based on IP Address: Use the IP address to identify the printer names For exam-

ple, if 199.99.92.99 is the IP address for the unit, 199.99.92.99 would be the printer port.

• Based on DNS (Domain Name Server: Uses the DNS name to identify the printer

name. For example, <PTR-MKTG.DOMAIN.COM>.

• Based on Unit Name: Uses the NIC Peer-to-Peer name set in the Novell section of

the print server setup. This is the name used to identify the printer. This defaults to xxx123456 where the xxx stands for the three letter identiﬁer of the manufacturer and the digits represent the serial number of the NIC.

TCP/IP Conﬁguration-14

7.3.5 Add Printers for IP Peer To Peer Printing

You can add printers manually whenever you cannot ﬁnd printers automatically because of router setup or hop count setting. In general, this should not be necessary.

Step 1: Use IP-P2P to Add Printers

1. Click on the IP-P2P menu item in Windows. The IP Peer-to-Peer Setup screen

appears.

2. Press the Printers... button; a new form screen appears.

3. Enter information for the printer in all the ﬁelds described below.

IP Address: Enter the IP address of the printer you want to add. Name: Assign a name to the printer. You can enter any name which you

feel identiﬁes the printer.

Port Number: The port number of the printer. The default is 10001. Description: Use this ﬁeld to describe the printer location or the users who will

access the printer.

4. When you have entered all the information, click on the Add button. The printer is

listed in the Available Printers ﬁeld at the bottom of the screen.

5. Click OK when you have ﬁnished adding all the printers you want to add.

Step 2 Use the Add Printers option in Windows (Unset Settings/Printers).

1. Click on the Add Printer button.

2. Select Local Printer from the menu.

3. Select the make and model of the printer you want to use. A list of printer ports

appears. IP peer-to-peer printers will appear in this list.

4. Select the IP printer you want to use.

5. Complete the remainder of the printer setup procedure as you would normally.

Note: You may change the printer at a later time by doing the following:

1. Right click on the printer icon and selct properties.

2. Select the Details tab (it may take up to 15 seconds to access).

3. Click on the arrow in the box labeled Print to the Following Port.

4. Select the printer address you wish to use.(In NT, you must unselect the previous

printer port ﬁrst.)

5. Click OK.

TCP/IP Conﬁguration-15

7.4 FTP Printing

7.4.1 FTP Printing Using Netscape

Connect to the port you wish to send the print job to on your print server . For e xample, to print your print server from Netscape (must be Netscape 2.0 or greater), do the following:

1. Type: ftp://port1@<destination server IP address>

2. Select File.

3. Select Upload File.

Note: FTP printing does not support selecting multiple ﬁle names.

The selected ﬁle is now sent to the printer.

7.4.2 Drag and Drop Method using Netscape

You can also use the "drag and drop" method of printing ﬁles from Netscape. For example, to print a ﬁle on your print server from Netscape (must be Netscape 2.0 or greater), do the following:

1. Type: ftp://port1@<destination server IP address>

2. Click and hold on the ﬁle that is on your system and drag it to your IP browsers

window.

3. Click on OK to upload ﬁle. The selected ﬁle is now sent to the printer.

Note: FTP printing does not support selecting multiple ﬁle names. Only one person can

be logged on to a port at any particular time.

7.4.3 FTP Client

To print from a FTP Client, do the following:

1. Type: ftp <destination server ID>

2. Type: port1 as the login.

3. Type: put <ﬁlename> The selected ﬁle is now sent to the printer.

TCP/IP Conﬁguration-16

7.5 UNIX Printing

The Print Server Card can support UNIX TCP/IP printing in two modes:

• Host-based lpd where a supplied line printer daemon is run on one or more worksta-

tions and print data is communicated to the Print Server Card via a TCP/IP port, or,

• Printer-based lpd where the printer appears as a host running a line printer daemon. In general, printer-based lpd is easiest to use on BSD UNIX systems, requiring an

entry in the printcap ﬁle once the Print Server Card has its IP information. Some UNIX System V systems have restrictions on support of remote lpr/lpd printers, requiring that the host-based lpr/lpd approach be used. For many operating systems, you have the option of using host-resident printing or print server-resident printing. Each mode has certain advantages.

• The host-resident method can print the username and ﬁlename on its banner page;

the print server-resident method prints a banner page with the host's name.

• The print server-resident method requires you to conﬁgure the printer only one

time, when you install the print server. The host-resident method requires that a printing daemon be installed on every host that you want to be able to print jobs.

Note: The Print Server Card will also operate with other host-resident print supervisor/

spooler programs that present a print image to the printer over a TCP/IP port. The base TCP/IP port number can be changed via Telnet, or the Print Server Card HTML setup pages accessed by MAP or a Web Browser. Remember, the actual port is always one higher than the base port number. The Status and Conﬁguration page indicates the actual port number.

TCP/IP Conﬁguration-17

Between the host-based and printer-based TCP/IP printing capabilities, the Print Server Card works with:

• All UNIX systems that support lpd/lpr

• System V Rel. 4 (on 386 platforms)

• DEC ULTRIX RISC Versions 4.3 and 4.4

• DEC OSF/1 Versions 2.0 and 3.0

• Solaris:

Version 1.1.3 (SunOS 4.1.3), Version 2.3 (SunOS 5.3), Version 2.4, and Version 2.5

• HP-UX Series 700 and 800 Version 9.01 and Version 10.0

• IBM AIX Version 3.2.5

• SCO UNIX Version 3.2

• AS400 The TCP/IP diskette also includes source code that you can recompile into host-based

code for conﬁguring on other System V platforms.

7.5.1 Conﬁguring the IP Address on the Print Server Card

Regardless of the printing mode selected, the Print Server Card must be given IP address and routing parameters. You can conﬁgure the IP address for the Print Server Card in one of the following ways:

• Use MAP, as described in Chapter 3.

• Use AppleTalk NIManage utility program, as described in Chapter 6.

• Use the Internet Boot Protocol (BOOTP).

• Use the reverse ARP (rarp) capability (Ethernet II frame type only).

• Use arp and ping capability. For each method, you will need to provide the Ethernet address of the Print Server

Card. The Ethernet address is the 12-character code that is printed under Network Address on the conﬁguration status report each time the printer is turned on.

TCP/IP Conﬁguration-18

You can use the BOOTP, rarp, or ping procedures only when the Print Server is in its factory default state (no IP information entered.) After the Print Server has an IP address, you must use the Telnet utility, the AppleTalk NIManage utility for the Mac- intosh, or the Print Server Card HTML management pages accessed through the MAP utility or a Web Browser to change an IP address, Subnet Mask and Default Gateway.

7.5.1.1 Using BOOTP

The BOOTP daemon is a native TCP/IP option for conﬁguring the IP address of a diskless network device. To communicate the IP address, use the following procedure:

1. Turn off the printer.

2. Log in as superuser on a host on the same subnet as the print server. However, if

the server resides on another subnet, complete this procedure to store the IP address in the print server. Reconnect the print server anywhere on the network, and then use Telnet or the HTML pages accessed by MAP or a Web Browser util- ity to change the IP address. See 7.6 Running Telnet, for instructions on using Tel- net.

3. Find the Ethernet address of the Print Server Card. The address is printed on the

conﬁguration status report each time you turn the printer on.

4. Edit the hosts ﬁle (usually /etc/hosts) or use NIS or DIS to add the IP address and

Print Server Card's node name. See the network administrator for the IP address. For example, a Print Server Card named printfast with an IP address of

192.9.200.200 has the following entry:

192.9.200.200 printfast

5. Stop the BOOTP daemon if it is running.

6. Edit the /etc/BOOTP tab ﬁle and add the following information:

nic_host:\ :ht = hardware type:\ :ha = ethernet address:\ :ip = IP address:\ :sm = subnet mask:\ :gw = gateway address:

TCP/IP Conﬁguration-19

For example, for an RFC 1048 system:

printfast:\ :ht = ether:\ :ha = 0040AF03AF6E:\ :ip = 192.9.200.200:\ :sm = 255.0.0.0:\ :gw = 192.9.200.10:\

If running with a more recent BOOTP implementation, such as with SCO UNIX, add:

:vm = rfc1048:

Note: The :ht = ether command should be used ev en if working with a Token Ring NIC

card.

The same information uses the following format on an RFC 951 system:

host htype haddr iaddr bootﬁle

printfast 1 00:40:af:03:af:6e 192.9.200.200 defaultboot

7. Start the BOOTP daemon by typing:

bootpd -s

8. Check the printer to verify that the Print Server Card is connected to the network.

Turn on the printer.

9. Wait until the printer powers up and ﬁnishes initializing to allow enough time for

the IP address to become known and to be saved in non-volatile memory. The Print Server Card should reinitialize itself.

10. After the Print Server Card has reinitialized, send a ping command to verify that

the print server obtained its IP address. For example:

ping 192.9.200.200

If the print server has the address, the result is a confirmation message:

192.9.200.200 is alive

11. Remove, or comment out, your changes to the /etc/BOOTP tab ﬁle.

12. Stop the BOOTP daemon and, if you want it to run, restart it.

TCP/IP Conﬁguration-20

7.5.1.2 Using rarp

The Reverse Address Resolution Protocol (rarp) allows network devices to query a server for their IP addresses on start-up. For this procedure, there needs to be a workstation with a rarp server. To store the IP address, use the following procedure:

1. Turn off the printer.

2. Log in as superuser on the rarp server. However, if the server resides on another

subnet, complete this procedure to store the IP address in the print server. Reconnect the print server anywhere on the network, and then use the Telnet or the HTML pages accessed by MAP or a Web Browser to adjust the IP parameters for the subnet on which the Print Server Card is to operate.

3. Find the Ethernet address of the Print Server Card. The address is printed on the

conﬁguration status report when you power on the printer.

4. Edit the hosts ﬁle (usually /etc/hosts) or use NIS or DIS to add the IP Address and

Print Server Card's node name. See the network administrator for the IP address. For example, a print server with the name of printfast has the following entry:

192.9.200.200 printfast

5. Edit the /etc/ethers ﬁle or use NIS or DIS to add the Ethernet address. To continue

the example, for the printfast card with an Ethernet address of 00:40:c8:00:00:ff, make the following entry:

0:40:c8:0:0:ff printfast

6. If the rarp daemon is running, stop it and restart it. Verify that the daemon is run-

ning.

7. Check the printer to see that the print server is connected to the network. Turn on

the printer.

8. Wait until the printer powers up and ﬁnishes initializing to allow enough time for

the IP address to become known and to be saved in non-volatile memory. The Print Server Card should then reset itself.

9. After the Print Server Card has reset, send a ping command to verify that the print

server obtained its IP address. For example:

If the print server has the address, the result is a conﬁrmation message:

TCP/IP Conﬁguration-21

ping 192.9.200.200

192.9.200.200 is alive

10. Remove, or comment out, your changes to the /etc/ethers ﬁle.

11. Stop the rarp daemon and, if you want it to run, restart it.

7.5.1.3 Using ping

Use the following procedure to enter the IP Address:

1. Turn off the printer.

2. Log in as superuser on a host on the same subnet as the print server. However, if

3. Find the Ethernet address of the Print Server Card. The address is printed on the

conﬁguration status report each time you turn the printer on.

4. Edit the hosts ﬁle (usually /etc/hosts) or use NIS or DIS to add the IP address and

print server's node name. See the network administrator for the IP address. For example, a print server with a name of printfast and an IP address of

192.9.200.200 has the following entry:

192.9.200.200 printfast

5. Add an entry to the arp cache for the Print Server's IP address and Ethernet

address. For example:

6. Check the printer to see that the Print Server is connected to the network. Turn on

the printer.

7. Send a ping command to the Print Server Card to verify it is running on the net-

work. For example:

The Print Server Card will not respond to this ping command but it will read its IP address from the packets.

8. Turn the printer off and back on again and then send the ping command again to

verify that the print server obtained its IP address. If the Print Server has the address, the result is a conﬁrmation message:

TCP/IP Conﬁguration-22

arp -s 192.9.200.200 0:40:c8:0:0:ff

ping 192.9.200.200 or ping printfast

192.9.200.200 is alive

9. Remove the entry from the arp cache using the following command. Specify the

Print Server either by its IP address or by its name. For example:

arp -d printfast

7.5.2

lpd/lpr

lpd/lpr is an implementation of the standard UNIX line printer daemon which lets you print across a TCP/IP network without the need to install software on your workstation with all ﬁltering and banners done by Print Server Card. Remote printing uses the same commands (lpr, lpq, lpc) as local printing.

The process begins when the lpr call ﬁnds a printer on a remote system by looking at the remote (rm) entry in the /etc/printcap ﬁle for that printer. lpr handles a print job for a remote printer by opening a connection with the lpd/lpr process on the remote system and sending the data ﬁle (followed by the control ﬁle containing control information for this job) to the remote system. The printer-based lpd then ﬁlters the data and prints the job according to information contained in the control ﬁle and its own printcap ﬁle.

Print Server Card lpd recognizes the format of a certain printer emulations and ﬁlters the data, if possible, so it can be printed on the printer type you specify. You can indicate to the Print Server Card lpd what type of printer is attached to by either:

1. Accepting the default port setting (PCL, PostScript and other), or

2. Changing the listed emulations via the Telnet or the HTML pages accessed by

The following sections give speciﬁc lpd/lpr setup instructions for various systems.

Printing

MAP or a Web Browser utility.

7.5.2.1 Setting Up a BSD Remote Printer to Use

T o set up a remote printer on the host that sends jobs to Print Serv er Card using printer resident lpd, add an entry to the /etc/printcap ﬁle on your host for each printer you use. The steps are described on the next page.

TCP/IP Conﬁguration-23

lpd/lpr

1. Open the /etc/printcap ﬁle. Make an entry naming the Print Server Card as the

remote host and PORT1 as the remote printer name. A typical printcap entry is shown below:

<printer_name>\

(for example, lprprinter)

:lp=:\ :rm=<remote_host>:\

(for example, name as entered in /etc/hosts)

:rp=PORT1:\ :sd=/usr/spool/lpd/<printer_name>:

(for example, spool directory on system used to spool data and control ﬁles)

This entry will send jobs spooled at /usr/spool/lpd/<printer_name> to the printer designated <printer_name> to be printed at port 1 (the internal connection to the printer) of the Print Server Card designated as <remote_host>.

2. Create the spooling directory. For example, type:

mkdir /usr/spool/lpd/<printer_name>

3. To print via the spooler, use the lpr command. Type:

lpr-P <printer_name>< file_name>

Installation and testing is done. You are now ready to print.

7.5.2.2 Setting Up an AIX Version 2.5 Remote Printer to Use

Set up a remote printer on the host that sends jobs to the Print Server Card using the Print Server Card's lpd. Use the following procedures to do this:

1. At the prompt, type:

2. When a window appears, select Manage Remote Printers.

3. When a menu appears, select Client Services.

4. Another menu appears, select Remote Printer Queues.

5. Another menu appears, select Add a Remote Queue.

TCP/IP Conﬁguration-24

lpd/lpr

#smit spooler <cr>

6. When a window appears, change the values shown to conﬁgure the Print Server

Card. The values displayed are default v alues. You must replace the short and long form ﬁlter values with the values shown below.

Requested Information Inputted Data Example Description of Inputted Data

Name of queue to add print1 Name of local printer queue Destination Host printfast Print Server Card IP hostname Short Form Filter /usr/lpd/bsdshort Required value Long Form Filter /usr/lpd/bsdlong Required value Name of remote printer

PORT1 Print Server Card

queue Name of device to add

7. After you have supplied all values, press Enter.

You can now print.

7.5.2.3 Setting Up an AIX 4.0 System

Use the following procedures to install a Print Server Card in an AIX 4.0 system:

1. Run SMIT Printer.

print1 Name of local queue

2. Select Print Spooling.

3. Select Add a Print Queue.

4. Select Remote.

5. Use Standard Processing.

6. Assign a queue name.

7. Use the host address of the Print Server Card for the Remote System.

8. Use PORT1 for the queue on the remote system.

9. Add a description (optional).

10. Press [Enter] to generate.

Installation is complete. Test your printer by executing the following command:

TCP/IP Conﬁguration-25

lp -d<queue_name> <file_name>

7.5.2.4 Setting Up an HP/UX Remote Printer to Use

Set up a remote printer on the host that sends jobs to a Print Server Card using the Print Server Card lpd. To do this:

1. At the prompt, type: sam

2. When a window appears, select Printer/Plotter Manager.

3. When the menu appears, select List printer and plotters.

4. When a list appears, select Actions in the title bar.

5. From the pull-down menu, select Add Remote Printer.

6. When a window appears, add values to conﬁgure Print Server Card. See the fol-

lowing example.

lpd

Input Requested Example Description of Inputted Data

Printer Name myprinter name to be used in lp command Remote System

Name Remote printer

fastprint Print Server Card hostname as in /etc/

hosts

PORT1 lpd queue name

Name

7. At the bottom of the screen, select Remote Printer is on BSD system from the

three choices available.

8. Click on the OK button.

9. Ping the unit to test communications. Type:

10. Ping should conﬁrm your IP address with the message:

<Print Server Card IP address> is alive

11. If the connection is conﬁrmed, you can now print.

7.5.2.5 Setting Up an AS/400 Systems to Use

When working with the output queue description (WORKOUTQD), there are several ﬁelds that must be deﬁned for the Print Server Card to function properly as a remote printer device. Use the following procedures to do this:

1. When prompted for the remote system, type INTNETADR so the AS/400 recog-

nizes the device as an IP device.

2. Type PORT1.

3. Connection type must be IP.

4. Internet address must be the IP address of the Print Server Card device.

TCP/IP Conﬁguration-26

ping <Print Server Card IP address>

lpd/lpr

5. Destination type must be OTHER.

6. When prompted for transforming SCS to ASCII, type YES to allow the AS/400

do the character translation.

7. Manufacturer type and model must be the print driver that goes with your printer.

7.5.2.6 Setting Up a DEC ULTRIX 4.3 RISC or OSF1/ALPHA Remote Printer

Set up a remote printer on the host that sends jobs to a Print Server Card.

1. At the prompt, type:

lprsetup

2. Select add.

3. Enter a name for your printer and press [Enter].

4. “Do you want more information on speciﬁc printer types?" Press [Enter].

5. A list of ULTRIX-supported printers is listed. Type remote and press [Enter].

6. Enter a printer synonym (alias) and press [Enter].

7. Designate a spooler directory and press [Enter], or accept the default spooler

directory displayed and press [Enter].

8. Designate a remote system name and press [Enter].

9. Designate PORT1 as the remote system printer name and press [Enter].

10. You are asked to enter the name of a printcap symbol from a displayed list. Type

Q and press [Enter].

11. Your conﬁguration is displayed. You are asked whether these values are ﬁnal.

Type Y or N and press [Enter]. An example is shown below.

Printer #7 Symbol Type Representative Value

lp (line printer) STR rm (remote host) STR Printer Server Card_host rp (remote printer) STR PORT1 sd (spooler directory) STR /usr/spool/lpd7

TCP/IP Conﬁguration-27

12. Add comments to the printcap ﬁle. For example, you can type:

Dick's printer down the hall [Enter]

13. Select exit to save your conﬁguration and press [Enter].

You are now prepared to print.

7.5.2.7 Setting Up a SCO UNIX Remote Printer to Use

lpd/lpr

Set up a remote printer on the host that sends jobs to a Print Server Card using lpd. Use the following procedures to do this:

1. At the prompt, type: mkdev rlp

Note: You cannot run mkdev rlp twice. If you have additional printers to be conﬁgured,

use the rlpconf command.

2. You will now be asked a series of questions. Respond as follows. Do you want to

install or remove a remote printer? Type: I

3. Do you want to change printer description ﬁle /etc/printcap? Type: Y

4. Write a printer name. For example, type: lprprinter1

5. Is lprprinter1 a remote printer or a local printer? Type: R

6. Enter remote host name: type host name entered in printcap for Print Server Card.

For example, type: lprprinter

7. Conﬁrm the information you have entered. Type: Y

8. Conﬁrm the preceding connection as your system default. Type: Y

9. Enter another printer name or quit setup. Type: Q

10. Do you want to start the remote daemon now? Type: Y

TCP/IP Conﬁguration-28

11. Using a line editor of your choice, edit the /etc/printcap ﬁle by changing the :rp=

entry to PORT1. For example,

printer1:\ :lp=:\ (used to specify the device name for a local

printer; this field must be empty) :rm=lprprinter:\ (remote machine name or network

name of the print server) :rp=PORT1:\ (remote printer name or the name of the

print server) :sd=/usr/spool/lpd/printer1: (name of the spool

directory on the client)

7.5.2.8 Setting Up System V Release 4 and Solaris 2.X to Use

lpd/lpr

If your system recognizes the LPSYSTEM command, you can use lpd/lpr. Another option is the admintool if your system supports it.

LPSYSTEM Installation

Use the following procedures to install LPSYSTEM:

Note: The following must be executed from the Bourne Shell. Type: SH e to enter the

Bourne Shell program.

1. lpsystem -t bsd <IP_address_of_Print Server Card>

Enter Print Server Card host name in

/etc/hosts

file. Your system may want its IP address instead of the remote host name.

2. lpadmin -p <local printername> -s <remote host name or IP address>!PORT1

Note:There is no space after the remote host name.

3. Enable <local printername>

4. Accept <local printername>

TCP/IP Conﬁguration-29

7.5.3 Installing TCP/IP for Print Server Card If Not Running

The TCP/IP diskette provided with the Print Server Card includes install scripts for various UNIX systems. This section describes how to install TCP/IP printing to the Print Server Card on any of the following operating systems:

• DEC ULTRIX 4.3 RISC

• System V Rel. 4

• Solaris (Ver. 1.x, 2.x)

• SCO UNIX

• OSF1/ALPHA

• IBM AIX

• HP/UX Once the Print Server Card has its IP information loaded, the following steps are nec-

essary for Host-Side TCP/IP printing:

1. Load the print server software on your workstation. It is presented as a tar ﬁle on

the TCP/IP diskette.

2. Run the appropriate installation script, if available.

3. Complete the conﬁguration for your operating system.

lpd/lpr

7.5.3.1 Loading the Software

The following procedures are only necessary when using the supplied host-based lpr capability. Loading the software is not necessary if printer-based lpr is used.

1. Log in as superuser to the system that spools directly to the print server.

2. Insert the print server's TCP/IP diskette in the host drive.

3. Go to or create the directory in which you want to install the software. For

example:

Note: If you already have a Print Serv er Card printer at your site and you are no w install-

ing another one, delete the ﬁles in the installation directory (not /usr/nic). If these ﬁles remain, they can prevent the installation of a subsequent print server.

4. Use the tar command to load the software from the diskette. Choose your UNIX

version from the example from the following table, or if not shown, consult the man page for your system:

TCP/IP Conﬁguration-30

mkdir /usr/PSC_install

UNIX V ersion Example

BSD/UL TRIX/AIX/

tar -xvf/dev/rfd0

SCO System V tar -xvf/dev/rdsk/f13ht System V/Solaris 2.3 tar -xvf/dev/rdiskette

Note: The device name varies depending on the computer and its peripheral designa-

tions. The ﬁrst BSD ﬂoppy device is often called rfd0.

5. After performing the tar, the system will display a list of Print Server Card ﬁles

copied by the tar. At this point, go to the speciﬁc section for your system for instructions on running the installation script.

7.5.3.2 Script Selection of Filters

There will be certain options in executing the script for various systems. One of the questions posed by the install script is whether the printer is a PostScript

printer. If you answered no to this question, the install script uses an input ﬁlter (inﬁlter) that supplies CR/LF translation to print ASCII ﬁles on a PCL printer. If you answered yes to this question, your printcap ﬁle will reference psﬁlter which offers easy ASCII-to-PostScript conversion. Normal PostScript format ﬁles are not affected. Proprietary and public domain ﬁlters are available for broader ﬁltering capabilities.

7.5.3.3 Manual Selection of Filters

The Print Server Card ships with an input ﬁlter called psﬁlter and an output ﬁlter called psbanner to print PostScript banners.

You may wish to change inﬁlter or outﬁlter entries in the /etc/printcap ﬁle. The following is a sample printcap entry using these ﬁlters:

<print_name> | Print Server Card printer:\ :lp=/dev/nic/<printer_name>:\ :if=/usr/nic/psfilter:\ :of=/usr/nic/psbanner:\ :sd=/usr/spool/<printer_name>:

TCP/IP Conﬁguration-31

7.5.3.4 Installing and Printing on Ver. 1 Solaris and OSF1 Systems

1. Run the Installation script by typing: nicinst.

The script automatically downloads the correct Print Server Card utilities for your particular system and prompts you for information as needed.

2. What is the node name of the Print Server unit?

Type the node name entered in /etc/hosts. For example: printfast and press [Enter].

3. What is the printer name?

Type the desired printer name and press [Enter].

4. Your screen will now display the information you provided to the install script.

For example:

Node name of the Print Server Card: printfast Printer name to be used: <printer_name> The printer is attached on: PORT 1

You are asked to OK this conﬁguration. Type yes or no and press [Enter].

5. Is this printer PostScript?

Type yes or no and press [Enter].

6. The script creates a printcap entry for the printer just conﬁgured. The screen dis-

plays the entry and asks if you want the script to append it to your /etc/printcap ﬁle. See below for a sample printcap ﬁle. Type yes or no and press Enter. If you type no, you may perform manual edits.

In your /etc/printcap ﬁle, be sure not to change the name of the device giv en Print Server Card in Step 2. You must reference the same :lp entry you wrote on the lp command line of the printcap ﬁle. For example:

<printer_name> | Print Server Card printer:\ :lp=/dev/<printer_name>:\ :if=/usr/nic/infilter:\ :sd=/usr/spool/<printer_name>:

All printcap entries must be prefaced with a tab except for the entry on the first line.

TCP/IP Conﬁguration-32

7. The script creates a spool directory in /usr/spool and starts the daemon for the

newly conﬁgured printer. It also displays the path used if you ever need to restart the daemon. For example:

/usr/nic/lpr_print /dev/nic/<printer_name> printfast 10001 &

8. Run the ps command so that you can view all your lpd/lpr processes.

Type: ps -ax | grep lpd

9. Kill all of your lpd/lpr processes. Type: kill -9 <Process ID> (this will stop ALL

printing).

10. Restart the daemon.

Type: /usr/lib/lpd

11. Installation for the system is done. You are prompted to conﬁgure any more print-

ers.

Type yes or no and press [Enter]. We also suggest you ping the Print Server Card to test communications.

7.5.3.5 Installing & Printing on an DEC ULTRIX 4.3 System

1. Run the Installation script by typing: nicinst.

The script automatically downloads the correct Print Server Card utilities for your particular system and prompts you for information as needed.

2. What is the node name of the Print Server unit?

Type the node name entered in /etc/hosts. For example, printfast and press [Enter].

3. What is the printer name?

Type the desired printer name and press Enter.

4. Your screen will now display the information you provided to the install script.

For example:

Node name of the Print Server Card: printfast Printer name to be used: <printer_name> The printer is attached on: PORT 1 You are asked to OK this configuration. Type yes or no and press [Enter].

5. Is this printer PostScript?

Type yes or no and press [Enter].

TCP/IP Conﬁguration-33

6. The script creates a printcap entry for the printer just conﬁgured. The screen dis-

plays the entry and asks if you want the script to append it to your /etc/printcap ﬁle. See below for a sample printcap ﬁle. Type yes or no and press [Enter]. If you type no, you may perform manual edits.

<printer_name> | Print Server Card printer:\ :lp=/dev/<printer_name>:\ :if=/usr/nic/infilter:\ :sd=/usr/spool/<printer_name>:

7. Installation for the system is done. The program prompts you to conﬁgure any

more printers. Type yes or no and press [Enter]. We suggest pinging the Print Server Card to test communications.

Like all BSD systems, ULTRIX uses the /etc/printcap ﬁle to conﬁgure a printer. The interface to the installation script is the same for all BSD systems, however, the printcap entry is different.

If you use the printcap entry generated automatically by the installation script, this will be transparent to you.

7.5.3.6 Installing and Printing on the HP/UX System

1. Run the Installation script by typing: nicinst.

The script automatically downloads the correct Print Server Card utilities for your particular system and prompts you for information as needed.

2. What is the node name of the Print Server unit?

Type the node name entered in /etc/hosts. For example,

printfast and press [Enter].

3. What is the printer name?

Type the desired printer name and press [Enter]. Your screen will now display the information you provided to the install script. For example:

Node name of the Print Server Card: printfast Printer name to be used: <printer_name> The printer is attached on: PORT 1

You are asked to OK this conﬁguration. Type yes or no and press [Enter].

4. The script starts the daemon for the newly conﬁgured printer automatically . It also

displays the path used should you ever need to restart the daemon. In the following example, the path would be:

TCP/IP Conﬁguration-34

/usr/nic/lpr_print /dev/nic/printer_name printfast 10001 &

This example reﬂects names supplied to the script earlier. When the installation script is complete, you must conﬁgure the printer and make it

known to the lp system. The HP/UX lp system uses the lpadmin maintenance command to conﬁgure a printer (there is not a /etc/printcap ﬁle). The speciﬁc commands to do this are:

lpadmin -p printer_name -v /dev/nic/printer_name enable printer_name accept printer_name

You can also use other options for the lpadmin command. See your system documentation for details.

Note: The printer name must be the same as the one you entered during the Print Server

Card installation. HP supplies the sam program as an alternative to conﬁgure the printer.

When using sam, specify everything as if the printer were directly connected to /dev/ lprprinter/printer_name.

The software installed with your HP system can satisfy most of your printing needs. HP supplies ASCII-to-PostScript ﬁlters and the system will in v oke them automatically if you deﬁne the content type of the printer as PostScript. The HP/UX lp system also supplies interface scripts that produce PostScript banners. Use the lpﬁlter command to deﬁne new ﬁlters and content types if necessary. The full power and ﬂexibility of the lp print service is now available to you. The fact that you are printing across the network is completely transparent.

7.5.3.7 Installing and Printing on a System V (Solaris Ver. 2)/System V Rel. 4 386-based Machine

Installation and setup is exactly the same for System V Solaris and SVR4 i386-based machines. Solution uses a network direct ﬁlter called nicﬁlter. The system invokes nicﬁlter directly from the printer interface ﬁle. To load the software, create a /usr/nic directory and tar the TCP/IP diskette to it.

1. Go to the /usr/nic directory by entering the following:

2. Run the Installation script by typing: nicinst.

TCP/IP Conﬁguration-35

cd /usr/nic

Once the operating system has been identiﬁed, the script downloads the ﬁles for your particular system, to the /usr/nic directory, and prompts you for information as needed.

3. Type cd /usr/spool/lp/model/standard/usr/nic/port1_interface

Note: Use of this default interface in most cases will sufﬁce for generic or routine print-

ing of most PostScript, PCL, and ASCII ﬁles. In order to utilize a printer speciﬁc inter face other than the default interface script (named standard), you must have a copy of that printer interface edited and installed in the /usr/nic directory.

Next, you will need to edit the printer interface program you created in step 3.

4. Type: cd /usr/nic and using a text editor, open and edit the port1_interface ﬁle.

5. Search on FILTER=0 and insert the following line above or below the # FILTER=0${LPCAT} section of the ﬁle. Remark out (using the # sign) any other FILTER entries present in this section of the ﬁle.

FILTER="/usr/nic/infilter| /usr/nic/nicfilter printer server name 10001"

Note: The <print server name> must be the same as the one present in the /etc/hosts ﬁle.

Optional arguments to be inserted after the 10001 entry and before the trailing 0 are ${banner}, ${user_name}, ${request_ID}, and ${ﬁles}. For further explanation of these and the statement above, refer to the System 5 Release 4 System Administration

Manual.

6. Save the ﬁle and close the editor.

You need to configure the host-side printer using lpadmin.

7. Type the following:

lpadmin -p <printer name> -v /dev/null -i /usr/nic/ port1_interface

Note: lpadmin conﬁgures the printer name and associates it with a given device and

printer interface program. There is no /etc/printcap ﬁle involved with this method of conﬁguration.

Next, you need to initialize the printer

TCP/IP Conﬁguration-36

8. Type the following commands:

accept <printer name> and press [Enter]. enable <printer name> and press [Enter].

Note: After each entry, lpadmin should provide an acknowledgment of the command

invoked.

9. Type the command:

lp -d <printer name> /etc/hosts, and press [Enter].

10. Check for output, or type the following:

lpstat <printer name> or -t.

7.5.3.8 Installing & Printing on a SCO UNIX System

Installation and setup is similar for HP/UX and SCO UNIX systems. The Print Server Card solution uses a network direct ﬁlter called nicﬁlter . The system invokes nicﬁlter directly from the printer interface ﬁle.

After completing software download in Section 7.4.3.1 Loading the Software, you must conﬁgure the printer and make it known to the lp system. Follo w the steps belo w:

1. Run the Installation script by typing: nicinst.

The script automatically downloads the correct Print Server Card utilities for your particular system and prompts you for information as needed.

2. Select your system. Choose one from these options:

1) AT&T/SVR4; 386

2) SCO UNIX System V

3) None of the above Type 1, 2, or 3 and press [Enter].

3. What is the node name of the Print Server Card? Type the name assigned in the /etc/hosts ﬁle and press [Enter]. For example, printfast

4. What is the printer name for this Print Server Card-linked printer?

Type a printer name and press [Enter].

TCP/IP Conﬁguration-37

5. Your screen will now display the information you provided the install script. For example:

Node name of the Print Server Card: printfast Printer name to be used: <printer_name> The printer is attached on: PORT 1 Do you want to accept this configuration? Type yes or no and press [Enter].

6. Is this printer PostScript?

Type yes or no and press [Enter].

7. The script automatically starts the daemon for the newly conﬁgured printer . It also displays the path used should you ever need to restart the daemon. In the preceding example, the path would be:

/usr/nic/lpr_print /dev/nic/printer_name printfast 10001 &

This example reﬂects names supplied in the script earlier. When the installation script is complete, you must still conﬁgure the printer and make

it known to the lp system. The SCO UNIX lp system uses the lpadmin maintenance command to conﬁgure a

printer (there is no /etc/printcap ﬁle). The speciﬁc commands to do this are:

lpadmin -p printer_name -v /dev/nic/printer_name

Note: Your host may require you to specify the model by using the -i command.

enable printer_name accept printer_name

You can also use other options for the lpadmin command. See your system documentation for details. Note that the printer name must be the same as the one you entered during Print Server Card installation. SCO supplies the sam program as an alternative to conﬁgure the printer.

When using sam, specify everything as if the printer were directly connected to /dev/ nic/printer_name.

The software installed with your SCO system can satisfy most of your printing needs. SCO supplies ASCII-to-PostScript ﬁlters and the system will invoke them automatically if you deﬁne the content type of the printer as PostScript. The SCO UNIX lp system also supplies interface scripts that produce PostScript banners. Use the lpﬁlter

TCP/IP Conﬁguration-38

command to deﬁne new ﬁlters and content types if necessary. The full power and ﬂexibility of the lp print service is now apparent. Your printing across the network is completely transparent.

7.5.3.9 Installing and Printing on an AIX RISC System/6000

The AIX printing subsystem is driven by the qdaemon program. The qdaemon uses conﬁguration information stored in the /usr/lpd/qconﬁg ﬁle to manage queues and route jobs to the proper devices. This information includes entries for each virtual printer and physical device known to the system.

An AIX virtual printer is simply a high level software view of a data stream, queue, and device that controls how a given job will be processed. A different virtual printer should be deﬁned for each data stream that a real printer supports. For example, you would use different virtual printers for PostScript and PCL jobs even though they are destined for the same physical printer.

Conﬁguring a Print Server Card printer on an AIX system approximates conﬁguration of a local printer as closely as possible. The only difference is that the physical de vice associated with your Print Server Card printer must be a named pipe used by the print daemon to route data to Print Server Card. The most straightforward way to add a printer to your system is:

1. Run the Install script by typing: nicinst.

The script automatically downloads the correct Print Server Card utilities for your particular system and prompts you for information as needed.

2. What is the node name of the Print Server unit?

Type the node name entered in /etc/hosts, for example: printfast and press [Enter].

3. What is the printer name?

Type the desired printer name and press [Enter].

4. Your screen will now display the information you provided to the install script. For example:

Node name of the Print Server Card: printfast Printer name to be used: <printer_name> The printer is attached on: PORT 1 You are asked to OK this configuration. Type yes or no and press [Enter].

TCP/IP Conﬁguration-39

5. Conﬁgure a virtual printer using printer_name as the physical device, where printer_name is the same printer name chosen during install.

6. Shut down the qdaemon using the command

stopsrc -s qdaemon

7. Edit /usr/lpd/qconﬁg to change the special ﬁle for device printer_name from /dev/ printer_name to /dev/nic/printer_name.

8. Restart the daemon with:

startsrc -s daemon

The installation script then will create the named pipe and start the supplied print daemon using the printer name and Print Server Card information you supplied. Since the AIX System Management Interface Tool (SMIT) will not accept a named pipe as a printer device, the installation script also creates a null character device in /dev/ printer_name.

7.5.3.9.1 Virtual Printer Commands

Virtual printers can be added either through SMIT or through the mkvirprt command, entering the device name printer_name for conﬁguration purposes. During this process you also select a particular printer type for the new printer, which inherits the set of predeﬁned attributes for that printer type. In most cases, this set of attributes will be sufﬁcient, but it can be changed either through SMIT or by using the chvirprt command. If you need more extensive changes on your printer, see the AIX RISC System/ 6000 documentation for assistance. After the virtual printer has been added, there will be a stanza in /usr/lpd/qconﬁg for device printer_name that looks like the following:

printer_name: file=/dev/printer_name backend=/usr/lpd/piobe

Edit /usr/qconﬁg and change ﬁle=/dev/printer_name to ﬁle=/dev/nic/printer_name. Output spooled on the virtual printer as deﬁned above, will now be sent to the named

pipe and routed to Print Server Card. Before you edit the ﬁles above, be sure that the following daemon is running:

/usr/nic/lpr_print /dev/nic/printer_name printfast 10001 &

TCP/IP Conﬁguration-40

7.5.3.9.2 AIX Print Commands

The AIX lp command works slightly differently than the lp command for other System V Release 4 systems. The following lp commands can be used to print ﬁles:

lp -d <queue_name> <filename> or lp -d <queue_name>:<device_name> <file_name>

7.6 Running Telnet

The Telnet utility uses the standard remote terminal protocol to conﬁgure the IP address, lpd/lpr printers, and other parameters on your system. Use the following guidelines to run Telnet. You have the same functionality with the HTML pages accessed by MAP or a Web Browser, as described in Chapter 3.

• Most often, you make selections from menus by toggling between one choice or another, by selecting/deselecting or enabling/disabling an item.

• Press Enter, when not selecting an item. This will return you to a previous menu.

• If you do not make a menu selection for 2 minutes, you get a "Two Minute Warn- ing" that within 2 more minutes your Telnet session will end. This ensures that one user does not leave a session idle for too long.

7.6.1 Making Connection and Main Menu

1. At the prompt, type:

telnet <network interface card IP address>

2. When login: appears, type guest if you are only interested in browsing the menus or sysadm if you want to change the conﬁguration. Press Enter . When passwor d: appears, again type guest or sysadm and press Enter.

TCP/IP Conﬁguration-41

3. The main menu is displayed. This utility lets you change the IP Parameters, lpd/ lpr printers, protocols, restore to factory defaults, and change password. Press the

number for the parameter you wish to check or change and press Enter.

The Conﬁguration Utility Unit Serial no. 221963 V4.10

Main Menu

1. IP Parameters

2. LPD Printers

3. Protocols

4. Restore Factory Defaults

5. Change Password E. Exit

4. To end your Telnet session, type E at the Main Menu. If you have made any changes you are prompted to either Save Changes and Exit or Exit W ithout Saving Changes. Choose your option and press Enter.

Note: Press ? to access the Telnet help utility.

7.6.2 Conﬁgure IP Parameters

Although the Print Server Card must have an IP address before a Telnet Connection can be made, you can use the utility to change the address or the other IP parameters. The Print Server Card will automatically initiate a soft reset when the IP address change is sensed.

Note: This will cause the Telnet connection to be broken. It is advisable to make all other

desired changes before changing the IP address.

1. At the Main Menu, type 1 and press Enter to bring up the IP Parameters menu (shown on the next page).

TCP/IP Conﬁguration-42

2. Type 1 again and press [Enter]. The IP Address submenu will appear:

The Conﬁguration Utility Unit Serial no. 221963

1. IP Address 199.92.187.37

2. Subnet Mask 255.255.255.0

3. Default Gateway 199.92.187.254

4. Base Port Number 10000

3. Enter a new IP Address and press Enter. Repeat the previous steps to change Subnet Mask and Default Gateways.

4. Enter 4 to change the base port number.

Note: The base port number is one less than the actual TCP/IP port number used by the

printer. For example, to set the port number to 9100, enter 9099.

7.6.3 Select Printer Languages

Selection 2 in the Main Menu allows you to designate which emulations (printer interpreter languages) the printer supports. This is to allow the resident lpd/lpr to modify ﬁles intended for other emulations so that they may be printed. The menu also allows you to enable or disable banners attached to lpd/lpr handled jobs.

The emulation choices are Printer Control Language (PCL), PostScript (PS), ASCII (simple text) and Other (any print job not recognized as PCL, PS, or ASCII). The ﬁle modiﬁcations and conditions are:

Print Server Setup Job Detected to be Action

PCL, (PostScript) ASCII <CR> changed to <CR><LF> PostScript PCL, Other PostScript header added not PostScript PostScript Job discarded PostScript ASCII PostScript header added, <CR>

PCL, PS, ASCII any no action

TCP/IP Conﬁguration-43

changed to <CR><LF>

1. To access the LPD Printers menu, type 2 and press Enter. For a unit at factory default, the menu shown below will appear.

LPD Printers

1. Printer 1 PCL PS OTHER

2. Banners DISABLED

2. T o change the set of emulations, type 1 and press Enter. The options shown below will appear.

Printer 1 PCL PS OTHER

1. PCL

2. PS

3. ASCII

4. OTHER

3. To delete an emulation, select the number opposite the language listed. For example, type 1 and press Enter to delete PCL. Typing 1 again will again select PCL.

4. From the LPD Printers menu, press 2 to toggle Banners between Enabled/Disabled.

7.6.4 Enable/Disable Network Protocols

To enable network protocols, at the Main menu type 3 and press Enter. You are given the choice of disabling either NetW are or AppleTalk since both network

OSs are enabled by default. For example, to disable Appletalk, type 2 and press Enter.

7.6.5 Restore Factory Defaults

When it is necessary to restore factory defaults on your print server, choose 4 on the Main Menu and press Enter. All NVRAM stored parameters will be returned to their factory default values. The factory default values will not take effect until the Telnet program is exited, or, the unit is powered cycled.

TCP/IP Conﬁguration-44

7.6.6 Change Password

When you want to establish a new password, enter 5 from the Main menu. Type up to eight characters after the New Password query and press Enter. Retype the same char- acters at the Retype New Password query and press Enter. Use the Save Changes and Exit option. Once you have established your password using Change Password, the password sysadm will be rejected.

Note: There is a single maintenance access password to the Print Server Card. This pass-

word is used for both Telnet and HTML maintenance programs. This password may be changed from Telnet or from HTML (accessed either via MAP or Web Browser utility).

7.6.7 Exit Telnet

Use the following procedures to exit Telnet:

1. To end your Telnet session, type E at the main menu. If you have made any changes, the following menu will appear:

The Conﬁguration Utility Unit Serial no. 221963

Exit

2. Choose your option and press Enter. For example, type 2 and press Enter. The program will save your changes and reset the print server so that the changes will take effect.

TCP/IP Conﬁguration-45

1. Save Changes and Exit

2. Save Changes and Reset

3. Exit Without Saving Changes

TCP/IP Conﬁguration-46

Konica Minolta 2560 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

1.1 What's in Your Package

1.2 Hardware/NOS Requirements

2.1 Preparing the Printer

Installing the Print Server Card

2.2 Token Ring Jumper Selection

2.3 Connect the Network to Print Server Card: Ethernet

2.4 Connect the Network to Print Server Card: Token Ring

2.5 Powering Up the Printer
