magicolor plus
PRINT BOARD SOLUTIONS
GET THE MOST OUT OF YOUR MEETINGS.
Print and organize the results of your meetings and presentations with
magicolor
®
plus Print Board Solutions. Connect the magicolor 1600W, magicolor 1680MF
or magicolor 1690MF to a PLUS M-12 Copyboard or C-12 CaptureBoard
®
via a standard
USB cable and press the Print button on the board. You’ll get full-color prints of your notes
and drawings ready for distribution. And since the printers use Simitri
®
HD toner, your
prints will look vibrant and stand the test of time.
CONNECT_
COMMUNICATE_ CONTROL_
_MEET
_PRINT
_DISTRIBUTE
CAPTURE THE DETAILS
Make your meetings more productive with magicolor plus Print Board
Solutions. Innovative and practical, magicolor plus lets you organize
and distribute the results of your presentation activities efficiently so you
can focus on your meeting goals.
The magicolor plus Print Board Solution is a combination of the
magicolor 1600W, magicolor 1680MF or magicolor 1690MF, along
with PLUS Copyboards or CaptureBoards. Your meeting discussions,
brainstorming sessions and final decisions—anything you write or
project on your print board—can be printed in full color to further
analyze, distribute or file. Or choose to save your print board information
electronically. That’s another plus that magicolor plus brings to the
conference room table!
CAPTURE YOUR IDEAS WITH
THE PUSH OF A BUTTON WITH
MAGICOLOR PLUS PRINT
BOARD SOLUTIONS.
Printer shown with optional stand
MAGICOLOR PLUS PRINT BOARD SOLUTIONS
Immediate prints for discussion or distribution
Eliminate note taking altogether
Full-color output captures details and highlights
Quick connect via USB 2.0 interface
One-button action to print or save files
MAGICOLOR AT YOUR SERVICE
Konica Minolta magicolor laser printers are perfect in the conference
room, delivering pages from your print board on the spot. And they can
serve as a stand-alone machine on your desktop or a multifunction
printer on your network, giving you even more for your money.
LONG LASTING PRINTS.
MAGICOLOR PRINTS LOOK
VIBRANT AND LAST FOR YEARS,
A RESULT OF KONICA MINOLTA'S
OWN SIMITRI HD TONER.
CHOOSE THE SOLUTION TO FIT
YOUR MEETING STYLE
To get the most from your meetings, select the magicolor plus Print
Board Solution that works with the way you do business. Build the
solution for your meeting space and style in two easy steps.
Pick a printer that delivers quick, quiet color prints
or one that offers print, copy, scan and fax
capabilities for added convenience.
Choose a Copyboard which conveniently prints
and/or saves what you write, or a CaptureBoard
which captures your notes and
projected images.
SELECT_YOUR_SOLUTION
1
2
EXTRA-SMALL 15.6" X 15" FOOTPRINT
QUICK 20 PPM B&W, 5 PPM COLOR PRINTING
1200 X 600 DPI FOR RICH COLOR
200-SHEET FOLD-UP INPUT TRAY,
100-SHEET OUTPUT TRAY
SUPPORTS UP TO 8.5" X 14" MEDIA; PLAIN,
THICK, LABELS, ENVELOPES
REMOTE PANEL UTILITY CLEARLY COMMUNICATES
PRINTER AND JOB STATUS
PRODUCTIVE, RELIABLE 35,000 PRINT MAXIMUM
MONTHLY DUTY CYCLE
PLUS M-12 Series
Copyboards
PUSH A BUTTON TO PRINT
OR SAVE YOUR NOTES
Setting the standard in the copyboard market, the new M-12
Series Copyboards give you the option of printing out your notes
and drawings in full color or saving them to either a USB memory
stick or to a PC. A newly adopted LED lighting system reduces
energy usage as well as costs. Added security features, including
the Erase Reminder function, make the M-12 ideal for those
working in information sensitive environments.
COMPACT, QUIET AND STYLISH
The compact size, high performance and low
color printing costs of the magicolor 1600W
make it a perfect match for your PLUS M-12
Copyboard or C-12 CaptureBoard. Its chic design
will compliment your conference room and its
quiet operation keeps it from becoming a
distraction during meetings and presentations.
SELECT_YOUR_PRINT_BOARD
SELECT_YOUR_LASER_PRINTER
M-12S
Standard Model
M-12W
Wide Model
Main Features
• 2 Writing Surfaces (M-12S/W)
• Print in Color or Black &
White*
1
• Save to a USB Memory Stick
• Save to a PC
• Save as PDF, JPG or PNG
• Standard & Wide Models
• Floor Standing or Wall Mountable*
2
*1. Printer sold separately.
*2. Copyboards come with a wall mount kit. The floor stand is optional.
BRILLIANT 1200 X 600 DPI PRINT QUALITY
DESKTOP FRIENDLY SIZE
20 PPM B&W, 5 PPM COLOR PRINTS AND COPIES
VERSATILE SCAN-TO-FILE FORMATS INCLUDING PDF,
TIFF & JPEG
QUIET ACOUSTIC OPERATING NOISE LEVEL
CONVENIENT FRONT ACCESS PANEL FOR QUICK
SUPPLY REPLACEMENT
SIMPLE CONTROL PANEL LAYOUT
AUTOMATIC DOCUMENT FEEDER
PLUS C-12 Series
CaptureBoards
CAPTURES YOUR HAND WRITTEN NOTES
ALONG WITH PROJECTED IMAGES
The perfect tool for any meeting in which a projected image
is to be discussed, the all new PLUS CaptureBoard allows
meeting attendees to add comments directly over the
projected image and then save their handwritten notes along
with the original projected image as a single file. The saved
file can be easily printed or distributed as an Email
attachment.
C-12S
Standard Model
C-12W
Wide Model
Main F
eatures
• 2 Writable Screen Surfaces
• Unique
“Capture” Function
• Print in Color or Black & White*
1
• Save to a USB Memory Stick*
1
• Save to a PC*
1
• Save as PDF, JPG or PNG
• Standard & Wide Models
• Floor Standing or Wall Mountable*
2
*1 Note: Using the Print Function or Save Function directly from the
CaptureBoard results in only the written information being scanned and
printed/saved. To acquire a print of the combined projected image and
written material, the Capture Function must be performed first and then the
saved file printed from a PC.
*2 CaptureBoards come with a wall mount kit. The floor stand is optional.
BASIC CAPTUREBOARD OPERATION
Project an image you want to discuss.
Write anywhere on the board including
over the projected image.
Combine the projected image and the
hand-written notes!
1
2
3
1
2
3
ALL-IN-ONE PRINTERS
The magicolor 1680MF and 1690MF gives you all the benefits of the 1600W—a small
foot-print, quiet operation and great looking low-cost color prints—as well as the ability to copy, scan
and fax (1690MF). Paired with a PLUS M-12 Copyboard or C-12 CaptureBoard, the magicolor 1680MF
and 1690MF offer an impressive amount of utility in surprisingly small printers.
CAPTUREBOARDS C-12S C-12W
BOARD Surface Panel Dimension W 51.2" x H 36.2" (1300 x 920 mm) W 70.9" x H 36.2" (1800 x 920 mm)
Effective Reading Area W 50.4" x H 35.4" (1280 x 900 mm) W 70.1" x H 35.4" (1780 x 900 mm)
With Opt. Stand (Max.)*
1
W 57.9" x D 27.6" x H 77.6" (1470 x 700 x 1970 mm) W 77.6" x D 27.6" x H 77.6" (1970 x 700 x 1970 mm)
Weight 90.4 lb. (41 kg) 99.2 lb. (45 kg)
Number of Pages 2
Sheet Driving Method Motorized
Grid Lines NA
Writing Instruments Dry Erase CaptureBoard Markers (Black/Red/Green/Blue)
Reading Method CCD Optical Sensor (RGB LED)
USB Port 3 Ports: 1 A-Type for printer and 1 B-Type for PC on lower part of board/ 1 A-Type on the Control Panel for USB Flash Memory
INSTALLATION Stand or Wall Mount
PRINTER Compatible Printers Konica Minolta magicolor 1600W, magicolor 1680MF & magicolor 1690MF (see details right)*
2
EXTERNAL MEMORY Type USB Flash Memory*
3
File Format PNG, JPEG and PDF Formats
PC CONNECTIVITY Interface USB 1.1 or USB 2.0 Full-speed Mode*
4
File Formats PNG, JPEG and PDF Formats
Supported OS Microsoft Windows 2000 Professional (SP 4+) / Windows XP (Home/Professional SP 2+) / Windows Vista (32bit)
OPERATING CONDITIONS Temperature 50°-90° F / 10°-35° C (Operating)
Humidity 30-85% (No condensation)
POWER SUPPLY Source AC Power 100-240 V, 50-60 Hz
Consumption 5W or less (Standby), 5W (Power On), 40W (Operation)
ACCESSORIES In Box CaptureBoard Markers (Black, Red, Green, Blue), Eraser, AC Power Adapter, USB Cable (3m), User’s Manual, Assembly Set-Up Manual,
Quick Guide, CD-ROM (TWAIN Driver, User Manual (PDF), PLUS TOOLBOX software), Printer Tray*
5
, Wall Mounting Brackets
TECHNICAL_SPECIFICATIONS
COPYBOARDS M-12S M-12W
BOARD Surface Panel Dimension W 51.2" x H 36.2" (1300 x 920 mm) W 70.9" x H 36.2" (1800 x 920 mm)
Effective Reading Area W 50.4" x H 35.4" (1280 x 900 mm) W 70.1" x H 35.4" (1780 x 900 mm)
With Opt. Stand (Max.)*
1
W 57.9" x D 27.6" x H 77.6" (1470 x 700 x 1970 mm) W 77.6" x D 27.6" x H 77.6" (1970 x 700 x 1970 mm)
Weight 90.4 lb. (41 kg) 99.2 lb. (45 kg)
Number of Pages 2
Sheet Driving Method Motorized/Manual
Grid Lines 2 in. squares (50 mm)
Writing Instruments Dry Erase Whiteboard Markers (Black/Red/Green/Blue)
Reading Method CCD Optical Sensor (RGB LED)
USB Port 3 Ports: 1 A-Type for printer and 1 B-Type for PC on lower part of board / 1 A-Type on the Control Panel for USB Flash Memory
INSTALLATION Stand or Wall Mount
PRINTER Compatible Printers Konica Minolta magicolor 1600W, magicolor 1680MF & magicolor 1690MF (see details right)*
2
EXTERNAL MEMORY Type USB Flash Memory*
3
File Format PNG, JPEG and PDF Formats
PC CONNECTIVITY Interface USB 1.1 or USB 2.0 Full-speed Mode*
4
File Formats PNG, JPEG and PDF Formats
Supported OS Microsoft Windows 2000 Professional (SP 4+) / Windows XP (Home/Professional SP 2+) / Windows Vista (32bit)
OPERATING CONDITIONS Temperature 50°-90° F / 10°-35° C (Operating)
Humidity 30-85% (No condensation)
POWER SUPPLY Source AC Power 100-240 V, 50-60 Hz
Consumption 5W or less (Standby), 5W (Power On), 40W (Operation)
ACCESSORIES In Box Markers (Black, Red, Green, Blue), Eraser, AC Power Adapter, USB Cable (3m), User’s Manual, Assembly Set-Up Manual,
Quick Guide, CD-ROM (TWAIN Driver, User Manual (PDF), PLUS TOOLBOX software), Printer Tray*
5
, Wall Mounting Brackets
*1 The height is adjustable to 66.7", 73.6" and 77.6" (1770, 1870, 1970 mm). *2 Printer is not included. *3 USB Flash Memory Stick is not included. *4 Not corresponded to USB 2.0 high-speed. *5 Will not support a magicolor printer.
PRINTERS magicolor 1600W magicolor 1680MF/1690MF
PRINT PROCESS Print Method Dual laser diode with polygon mirror
Print Speed Monochrome: up to 20 ppm; Color: up to 5 ppm
First Page Out Monochrome: 11 seconds; Color: 20 seconds
Max. Resolution 1200 x 600 dpi
Print Volume 35,000 pages (average per month)
HARDWARE/SOFTWARE Memory 16 MB standard 1680MF: 64 MB standard / 1690MF: 128 MB standard
CAPABILITIES
Interface Support USB 2.0 1680MF: USB 2.0 / 1690MF: USB 2.0, Ethernet
OPERATING SYSTEM Operating Systems Windows 2000, Server 2003 (32/64), Windows 2000, Server 2003 (32/64), XP (32/64), Vista (32/64);
COMPATIBILITY XP (32/64), Vista (32/64) Mac OS X 10.2+
PAPER HANDLING Paper Input Std: 200-sheet multi manual tray 1680MF: Std: 200-sheet multi manual tray /
1690MF: Std: 200-sheet multi manual tray; Opt: 500-sheet lower feeder tray
Paper Output Standard: 100-sheet face-down output tray
Media Sizes Supported Letter, legal, A4, A5, envelope C6, envelope DL, B5
Printable Area Approx. 0.16" (4 mm) from all edges
COPY Copy Speed NA Monochrome: 21 cpm @ 300 x 300 dpi/10.5 cpm @ 600 x 300 dpi;
Color: 3.5 cpm @ 600 x 300 dpi
First Page Out Time NA Monochrome: 23 seconds; Color: 52 seconds
Resolution NA 600 x 600, 600 x 300 dpi
Copy Settings NA Density (7 steps), Reduce/Enlarge (25-400%), Number of Copies (1-99),
Quality (Text/Photo/Mix, Normal/Fine), ID card copy, Poster copy, Clone copy
SCAN Scanner Type NA 1680MF: Flatbed / 1690MF: ADF
Resolution NA 600 x 600 dpi
Color Depth NA 8-bit RGB
Scan Size NA Platen Glass: letter, A4
Scan Destination NA 1680MF: USB / 1690MF: USB, Email, FTP, SMB (desktop)
Scan Drivers NA TWAIN and WIA (Windows only)
Scan-to-File Formats NA PDF, TIFF, JPEG
Scan Utilities NA LinkMagic (Windows only), PagePort SE (Windows only)
PHYSICAL Dimensions (WxDxH) 15.6" x 15" x 10.8" (396 x 380 x 275 mm) 1680MF: 15.9" x 16.9" x 14.8" (405 x 430 x 375 mm) /
1690MF: 16.0" x 16.9" x 17.0" (405 x 427 x 432 mm)
Weight 33.3 lbs. (15.1 kg) (with consumables) 1680MF: 42 lbs. (19.2 kg) / 1690MF: 46 lbs. (20.8 kg) (with consumables)
ELECTRICAL Input Voltage Range 120V (± 10%)
Frequency 50-60 Hz (± 3%)
Average During Printing Monochrome: < 440W; Color: < 400W Monochrome: < 560W; Color: < 410W
Standby < 140W < 170W
Energy Save < 14W
ENVIRONMENTAL Temperature 50°- 95° F / 10°-35° C (Operating)
Humidity 15 - 85% RH (Operating)
Noise Level Operating < 50 dB; Standby < 29 dB Operating < 52 dB; Standby < 32 dB
CONSUMABLES Toner (pre-installed) Cyan, Magenta, Yellow, Black Cyan, Magenta, Yellow (yield up to 500 pages @ 5% coverage);
(yield up to 500 pages @ 5% coverage) Black (yields up to 1,000 pages @ 5% coverage)
Toner (replacement - std) Cyan, Magenta, Yellow (yield up to 1,500 pages @ 5% coverage)
Toner (replacement - high) Cyan, Magenta, Yellow, Black (yield up to 2,500 pages @ 5% coverage)
Imaging Unit Includes OPC Drum and Waste Toner Box (yields up to 45,000 B&W / 11,250 color pages - continuous printing)
(pre-installed/replacement)
MAINTENANCE PARTS Fuser Unit Yields up to 50,000 pages (continuous printing)
2nd Transfer Unit Yields up to 50,000 pages (continuous printing)
WARRANTY 1 year
DO BUSINESS_BETTER
Scan Speed NA Monochrome: 20 ipm; Color: 3.3 ipm
© 2010 KONICA MINOLTA BUSINESS SOLUTIONS
U.S.A., INC.
All rights reserved. Reproduction in
whole or in part without written permission is
prohibited. Konica Minolta is a trademark of
KONICA MINOLTA HOLDINGS, INC. The essentials
of imaging is a registered trademark of KONICA
MINOLTA HOLDINGS, INC. magicolor is a registered trademark of KONICA MINOLTA BUSINESS
TECHNOLOGIES, INC. Simitri is a registered
trademark of KONICA MINOLTA BUSINESS
SOLUTIONS U.S.A., INC. All other brands and
product names are registered trademarks or
trademarks of their respective owners.
Design and specifications are subject to change
without notice.
KONICA MINOLTA
BUSINESS SOLUTIONS U.S.A., INC.
100 Williams Drive
Ramsey, NJ 07446
www.countonkonicaminolta.com
www
.kmbs.konicaminolta.us
www.kmbs.konicaminolta.us/solutions
Konica Minolta magicolor plus Print Board
Solutions capture your meeting moments
PERFECT PARTNERS. Pair a Konica Minolta magicolor 1600W, magicolor 1680MF or
magicolor 1690MF with a PLUS M-12 Copyboard or C-12 CaptureBoard and make your meeting activities
more efficient.
ADD PRODUCTIVITY TO THE PRESENTATION as your magicolor plus Print Board
Solution eliminates note taking and meeting delays. Instead participants can focus on the discussion
at hand.
SIMPLE OPERATION is at your fingertip, with one-button action to print files for immediate
discussion and distribution, or to save files electronically for further analysis later. A quick USB connection
gets you started.
COLOR IS KEY as the vital details and important highlights you made in color on your print board
are transferred to the printed page.
Focus on the meeting at hand and leave the details
to your magicolor plus Print Board Solution.
Loading...
