SLEEK, SMART AND STATEMENT-MAKING.
Modern design meets efficiency in the magicolor®4650 series. These stylish printers deliver eye-catching documents at top speeds without sacrificing quality. At 25 pages per minute and impressive 9600 x 600 dpi-class contone color, the magicolor 4650EN and magicolor 4650DN produce professional, high-quality prints in a flash. And these quiet powerhouses won’t disturb your office. Even while duplexing, the magicolor 4650DN keeps noise levels at a minimum so your productivity levels can be maximized. Time saving print options and user friendly design make the magicolor 4650 series the perfect complement to any productive workgroup.
CONNECT_
COMMUNICATE_ CONTROL_
magicolor 4650 series
DO BUSINESS_BETTER
_FULL COLOR _LASER _PRINTER
magicolor 4650 series
POWER AND VIVID VERSATILITY
Sleek, productive package. The magicolor 4650 series features the
equipment every workgroup needs to captivate audiences and remain competitive.
Attention-demanding, color laser. Equipped with 9600 x 600 dpi-class
contone color, the magicolor 4650 series produces eye-catching, bold graphics and crisp text project after project at 25 ppm for color and b&w.
Countless options for complete customization. Options, including a
40 GB hard drive, expandable memory and an additional input tray, offer users endless possibilities for personalization.
ECONOMICAL CONVENIENCE
Save time and paper. The magicolor 4650DN comes equipped with an
internal, automatic duplexer. Two-sided printing delivers high-impact documents while using 50% less paper. It also utilizes an enhanced paper crossing system that allows the printer to maintain 100% productivity while producing two-sided documents.
DO BUSINESS_BETTER
25 PPM IN COLOR AND B&W FOR HIGH-DEMAND JOBSBOLD 9600 X 600 DPI-CLASS PHOTOART CONTONE COLOREMPERON
PRINT SYSTEM FOR HIGH PERFORMANCE
256 MB RAM, OPTIONAL 40 GB HARD DRIVE TO BOOST PRODUCTIVITYPOSTSCRIPT 3 & PCL 6 EMULATIONSDIRECT PRINT PDF, XPS, JPEG & TIFF FILESNATIVE XPS INTERPRETER FOR WINDOWS VISTA, INCLUDING WSD SUPPORTGIGABIT ETHERNET, USB 2.0 AND PARALLEL INTERFACESECONOMICAL DUPLEX PRINTING WITH DN MODELUSER-FRIENDLY, ERGONOMIC DESIGNRELIABLE 90,000 PAGE-PER-MONTH MAXIMUM DUTY CYCLEPAGESCOPE SOFTWARE SUITE SIMPLIFIES NETWORK MANAGEMENT
EDGE ENHANCEMENT. GET NOTICED BY USING THE EDGE ENHANCEMENT FUNCTION. EVEN SMALL FONT SIZES HAVE CLEAR AND CRISP CHARACTERS SO YOUR DOCUMENTS RECEIVE THE ATTENTION THEY DESERVE.
SUPERB QUALITY.THE MAGI­COLOR 4650 SPECS INCLUDE HIGH RESOLUTION AND A DEPENDABLE DUTY CYCLE OF 90,000 PRINTS PER MONTH. TRANSLATION: HIGH QUALITY YOU CAN RELY ON, FROM THE FIRST PAGE TO THE LAST.
SLEEK, NEW DESIGN. A LOWER HEIGHT OF 15.2” AND STYLISH MODERN DESIGN MAKE THE MAGI­COLOR 4650 SERIES THE PERFECT COMBINATION OF STYLE AND FUNCTIONALITY.
REDUCED NOISE LEVELS.
LOWER ACOUSTIC LEVELS ALLOW YOUR WORKGROUP TO CARRY ON BUSINESS AS USUAL WHILE MAINTAINING AN ULTRA-FAST PRINT TIME TO KEEP YOUR TASKS ON TRACK.
FEATURES, OPTIONS & BENEFITS
Powered by Emperon. Equipped with Emperon
technology and 500 MHz processor, the magicolor 4650 series boasts a first-page output time of 14.5 seconds. And it quickly delivers 25 pages per minute—color and black and white.
Time-saving direct print options. The magicolor 4650
series allows users to print XPS, PDF, JPEG and TIFF files directly from a USB flash drive, or drag and drop the files for print using PageScope Direct Print.
Quiet workhorse. The magicolor 4650 series features a
low acoustic noise level so it will never disturb your work­flow. When producing bold, two-sided documents the magicolor 4650DN remains quiet while delivering high throughput.
Stylish, ergonomical design. With a height of only 15.2
inches, the magicolor 4650 series seamlessly fits into any workgroup. And its simple control panel design allows users to quickly navigate through the intuitive menu with total ease. The series is also equipped with InfoLine-style display for at-a-glance printer status up close or from a distance.
Robust and reliable. This dependable dynamo effort-
lessly tackles high-volume printing. With a monthly duty cycle of 90,000 prints, this efficient office assistant won’t disappoint.
Contone color communicates. The magicolor 4650
series boasts 9600 x 600 dpi-class color and eAIDC auto­matic color calibration which ensures consistent, incredible output every time. PhotoArt contone technology delivers crisp detail, smooth gradients and accurate colors. And while utilizing the toner save mode, users can conserve toner usage—up to 60%, while maintaining text quality.
Buy with confidence. The magicolor 4650 series is
backed by a one-year on-site warranty and 24/7 online technical support for complete peace of mind.
Flexible interfaces. A Gigabit Ethernet interface offers
high-speed network printing for any size workgroups. Users can also connect via USB 2.0 and parallel ports for effortless local operation.
25
PPM
25
PPM
VERSATILE HANDLING. FOR BIG
PROJECTS, THE MAGICOLOR 4650 SERIES CAN BE EQUIPPED WITH AN 500-SHEET CASSETTE FOR A MAX INPUT OF 850 SHEETS. THE MAGICOLOR 4650DN HAS A BUILT-IN AUTO DUPLEXER THAT EASILY HANDLES YOUR COLORFUL BOOKLETS AND MULTI-PAGE FILES.
POWERFUL PAGESCOPE™ SOFTWARE.
PAGESCOPE WEB CONNECTION FOR WEB­BASED DEVICE MANAGEMENT, PAGESCOPE NET CARE FOR REMOTE CONFIGURATION OF MIB-COMPLIANT PRINTERS, DESKTOP STATUS MONITOR FOR PRINT STATUS REVIEW AND ERROR ALERTS.
Item #: 4650BRO
04/08
Office imagery courtesy of Knoll, Inc.
© 2008 KONICA MINOLTA BUSINESS SOLUTIONS U.S.A., I NC.
All rights reserved. Reproduction in whole or in part without written permission is pro­hibited. Konica Minolta and The essentials of imaging are trademarks of KONICA MINOLTA HOLDINGS, INC. PageScope is a trademark of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. magicolor and Simitri are registered trademarks of KONICA MINOLTA BUSINESS SOLUTIONS U.S.A., INC. All other brands and product names are reg­istered trademarks or trademarks of their respec­tive owners.
Design and specifications are subject to change without notice.
KONICA MINOLTA BUSINESS SOLUTIONS U.S.A., INC.
100 Williams Drive Ramsey, NJ 07446
(800) 523-2696 www.kmbs.konicaminolta.us www.kmbs.konicaminolta.us/solutions
PRINTING PROCESS
PRINT METHOD:
Electrophotographic Laser
PRINT SPEED*:
Color: 25 ppm Monochrome: 25 ppm
*Exact print speed differs depending on system configuration, software application, driver, and document complexity.
FIRST-PAGE OUTPUT TIME:
Color: 14.5 seconds Monochrome: 14.5 seconds
RESOLUTION:
9600 x 600 dpi-class with PhotoART
(600 x 600 x 4 bit contone)
MAXIMUM MONTHLY DUTY CYCLE:
90,000 prints
HARDWARE AND SOFTWARE CAPABILITIES
PROCESSOR:
500 MHz Marvell Orion II
MEMORY:
256 MB Upgradeable to 768 MB
HARD DISK DRIVE (optional):
40 GB
COMPACT FLASH CARD (optional)*:
256 MB, 512 MB, 1 GB, 2 GB, 4 GB
*Requires Compact Flash Card adapter. Cannot be installed at the same time as Hard Drive option.
OPERATING SYSTEM COMPATIBILITY:
Windows Vista Windows Vista x64 Windows Server 2003 Windows Server 2003 x64 Windows XP Windows XP x64 Windows 2000 Macintosh OS X (v10.2+) Macintosh OS X (Intel) (v10.4+) Linux Red Hat 9 Linux SuSE 8.2
PRINTER EMULATIONS:
PostScript 3 PCL 6 XPS Direct Print* PDF 1.6 Direct Print** JPEG/TIFF Direct Print**
*Requires optional Hard Drive **Requires optional Hard Drive or Compact Flash Card
CAMERA DIRECT PHOTO PRINT:
Pictbridge 1.0 via USB 1.1 Host
PRINTER MANAGEMENT:
PageScope Net Care PageScope Web Connection PageScope Network Setup PageScope EMS Plug-Ins:
Tivoli Netview CA Unicenter HP Open View
Microsoft Management Console (MMC) PageScope Web Jet Admin Plug-In PageScope Plug and Print PageScope NDPS Gateway PageScope Direct Print
COLOR CONTROL:
Enhanced Automatic Image Density Control
(eAIDC) ICC device profiles Automatic ICC-based color matching Dynamic Contone Screening PANTONE Color Tables SWOP, Commercial, EuroColor, DIC, and TOYO
press emulations
INTERFACE SUPPORT
Gigabit Ethernet (10/100/1000BaseTX) IEEE 1284 Parallel USB 2.0 USB 1.1 Host Port
ETHERNET PROTOCOLS:
TCP/IP (IPv4/IPv6, IPsec, SSL, IEEE802.1x) AppleTalk / EtherTalk IPX/SPX (Netware 4/5/6), NDS Bindery, NDPS ARP, Ping Bonjour DHCP, AutoIP, BOOTP FTP HTTP, HTTPS IPP1.1 LPR/LPD NetBEUI, SMB RAW Socket SMTP SNMP (v1/2/3) SNTP SLP UDP WSD
PAPER HANDLING
STANDARD PAPER INPUT:
100-sheet multipurpose tray 250-sheet cassette
STANDARD PAPER OUTPUT:
200-sheet face-down output tray
OPTIONAL PAPER INPUT:
500-sheet lower feeder unit
STANDARD AUTOMATIC DUPLEXER*:
For two-sided printing (plain paper only)
*magicolor 4650DN only
PAPER SIZES SUPPORTED:
100-sheet multipurpose tray:
Letter
Legal
4" x 6"
Executive
Folio
Govt. Letter
Govt. Legal
Statement
A4, A5, A6
B5, B6
Custom sizes:
(W) 3.6"-8.5" to (H) 5.8"-14" (W) 92-216 mm to (H) 148-356 mm
Envelopes: Monarch, Com 10, DL, B5 (ISO), C6
250-sheet cassette:
Letter
4" x 6"
Executive
Statement
Govt. Letter
A4, A5, A6
B5, B6
Custom sizes:
(W) 3.6"-8.5" to (H) 5.8"-11.7" (W) 92-216 mm to (H) 148-297 mm
500-sheet lower feeder unit (optional):
Letter Legal Executive Govt. Legal A4 B5
Duplexer: (magicolor 4650DN only)
Letter Legal Executive Folio Govt. Letter Govt. Legal A4 B5 Custom sizes:
(W) 7.2"-8.5" to (H) 10.1"-14" (W) 182-216 mm to (H) 257-356 mm
PRINTABLE AREA:
0.17" (4.2 mm) from all edges
13.7" maximum print length
PAPER WEIGHTS:
Plain paper: 16-24 lb. Bond (60-90 g/m²) Thick Stock: Up to 110 lb. Index (210 g/m²)
(via multipurpose tray only)
Duplexer: 16-24 lb. Bond (60-90 g/m²)
PRINT MEDIA:
Plain Paper Recycled Paper Letterhead Thick Stock Glossy Stock Transparencies Laser Quality Labels Envelopes Postcards
PHYSICAL
TYPE:
Laser printer with Emperon technology
DIMENSIONS (WXDXH):
18.5” x 21.1” x 15.2” (469 x 536 x 385 mm)
WEIGHT:
magicolor 4650EN
77.4 lbs (35 kg) - w/ consumables
65.2 lbs (30 kg) - w/o consumables
91.3 lbs (41.5 kg) - as shipped
magicolor 4650DN
79.1 lbs (36 kg) - w/ consumables
66.9 lbs (30 kg) - w/o consumables
91.3 lbs (41.5 kg) - as shipped
ELECTRICAL
POWER REQUIREMENTS:
120 VAC, 50/60 Hz 220-240 VAC, 50/60 Hz
POWER CONSUMPTION:
Operating: 550W or less, 1200W Max. Standby: 140W or less
ENERGY STAR COMPLIANT*:
16Wh or less
*magicolor 4650DN only. The addition of some options, in some combinations, may cause the product be become non-compliant.
ENVIRONMENTAL
TEMPERATURE REQUIREMENTS:
Operating: 50° to 95° F (10° to 35° C) Non-Operating: 32° to 95° F (0° to 35° C)
HUMIDITY:
Operating: 15% to 85% RH Non-Operating: 30% to 85% RH
NOISE LEVELS:
Operating: <52 dB(A) Standby: <39 dB(A)
REGULATORY/SAFETY CONFORMITY:
UL cUL CDRH CSA DOC FCC-B
CONSUMABLES*:
In-Box Toner: Cyan, Magenta, Yellow, Black
(yield up to 3,000 pages @ 5% coverage)
Replacement Toner: Cyan, Magenta, Yellow,
Black (yield up to 4,000 or 8,000 pages @ 5% coverage)
Imaging Unit: Cyan, Magenta, Yellow, Black
(yield up to 30,000 pages @ 5% coverage)
Waste Toner Box
*The stated life expectancy of each consumable is based on printing under specific operating conditions such as page coverage for a particular page size (5% coverage of letter/A4). The actual consumable’s life will vary depend­ing on the use and other printing variables including page coverage, page size, media type, continuous or intermit­tent printing, ambient temperature, and humidity.
TYPEFACES:
137 resident PostScript fonts 93 PCL fonts 10 line printer fonts
WARRANTY:
1-year on-site
magicolor 4650 series
GENERAL SPECIFICATIONS
(magicolor 4650DN only)
